Transistors
Publication date: June 2007 SJC00402AED 1
This product complies with the RoHS Directive (EU 2002/95/EC).
2SC6036G
Silicon NPN epitaxial planar type
For general amplification
Complementary to 2SA2162G
Features
Low collector-emitter saturation voltage VCE(sat)
SSS-Mini type package, allowing downsizing of the equipment and automatic
insertion through the tape packing
Absolute Maximum Ratings Ta= 25°C
Parameter Symbol Rating Unit
Collector-base voltage (Emitter open) VCBO 15 V
Collector-emitter voltage (Base open) VCEO 12 V
Emitter-base voltage (Collector open) VEBO 5 V
Collector current IC500 mA
Peak collector current ICP 1 A
Collector power dissipation PC100 mW
Junction temperature Tj125 °C
Storage temperature Tstg –55 to +125 °C
Electrical Characteristics Ta= 25°C±3°C
Parameter Symbol Conditions Min Typ Max Unit
Collector-base voltage (Emitter open) VCBO IC= 10 mA, IE= 0 15 V
Collector-emitter voltage (Base open) VCEO IC= 1 mA, IB= 0 12 V
Emitter-base voltage (Collector open) VEBO IE= 10 mA, IC= 0 5 V
Collector-base cutoff current (Emitter open) ICBO VCB = 10 V, IE= 0 0.1 mA
Forward current transfer ratio hFE VCE = 2 V, IC= 10 mA 270 680 
Collector-emitter saturation voltage VCE(sat) IC= 200 mA, IB= 10 mA 250 mV
Transition frequency fTVCB = 2 V, IE= –10 mA, f = 200 MHz–10 mA, f = 200 MHz10 mA, f = 200 MHz 200 MHz
Collector output capacitance
(Common base, input open circuited) Cob VCB = 10 V, f = 1 MHz 4.5 pF
Note) Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
Package
Code
SSSMini3-F2
Marking Symbol: 4U
Pin Name
1: Base
2: Emitter
3: Collector
2SC6036G
2SJC00402AED
This product complies with the RoHS Directive (EU 2002/95/EC).
PCTaICVCE ICVBE
VCE(sat) IChFE ICCob VCB
020 40 60 80 100 120 140
0
20
40
60
80
100
120
2SC6036_ PC-Ta
Collector power dissipation PC(mW)
Ambient temperature Ta(°C)
0 1 2 3 4 5 6
0
20
40
60
80
100
120
2SC6036_ IC-VCE
Collector current IC(mA)
Collector-emitter voltage VCE (V)
140 µA
120 µA
100 µA
80 µA
60 µA
40 µA
20 µA
IB=160 µA
Ta =25°C
00.2 0.4 0.6 0.8 1.0 1.2 1.4
0
10
20
30
40
50
60
100
70
80
90
2SC6036_ IC-VBE
Collector current IC(mA)
Base-emitter voltage VBE (V)
VCE =2 V
Ta =85°C
25°C
−25°C
1 10 100 1
000
0.01
0.1
1
2SC6036_ VCE(sat)-IC
Collector-emitter saturation voltage VCE(sat) (V)
Collector current IC(mA)
IC / IB =20
Ta =85°C
25°C
−25°C
1 10 100 1
000
0
100
200
300
400
500
700
600
2SC6036_ hFE-IC
Forward current transfer ratio hFE
Collector current IC(mA)
VCE =2V
Ta =85°C
25°C
−25°C
0 5 10 15 20 25 30 35 40
1
10
2SC6036_ Cob-VCB
Collector-base voltage VCB (V)
Collector output capacitance
(Common base, input open circuited) Cob (pF)
f = 1 MHz
Ta= 25°C
This product complies with the RoHS Directive (EU 2002/95/EC).
SSSMini3-F2 Unit: mm
0.30 +0.05
−0.02
0.20 +0.05
−0.02 0.13 +0.05
−0.02
(0.4)
(0.4)
0.80 ±0.05
0.80 ±0.05
0.51 ±0.04
1.20 ±0.05
1.20 ±0.05
0.20 ±0.05
3
12
(0.27)
5°
0 to 0.05 (0.5)
5°
