Panasonic LN842RPX User manual

SHD00486BEK
This product complies with the RoHS Directive (EU 2002/95/EC).
Publication date: November 2008 1
Light Emitting Diodes
LN842RPX
Square Type
5.0 mm ×2.0 mm
Absolute Maximum Ratings Ta= 25°C
Parameter Symbol Rating Unit
Power dissipation PD90 mW
Forward current IF30 mA
Pulse forward current *IFP 150 mA
Reverse voltage VR3 V
Operating ambient temperature Topr –25 to +85 °C
Storage temperature Tstg –30 to +100 °C
Note) *: The condition of IFP is duty 10%, Pulse width 1 msec.
Electro-Optical Characteristics Ta= 25°C
Parameter Symbol Conditions Min Typ Max Unit
Luminous intensity IO1.00 2.5 mcd
Reverse current IRVR= 3 V 10 µA
Forward voltage VFIF= 20 mA 2.1 2.8 V
Peak emission wavelength λPIF= 20 mA 630 nm
Spectral half band width Δλ IF= 20 mA 40 nm
Directive characteristics
IOIFIFVF
IFTa
Relative luminous intensity (%) Ambient temperature Ta(°C)
Ambient temperature Ta(°C)
Forward current IF(mA)
Forward voltage VF(V)
Forward current IF(mA)
Luminous intensity IO(mcd)
Relative luminous intensity (%)
Forward current IF(mA)
Relative luminous intensity (%)
Relative luminous intensity Ta
Relative luminous intensity λP
Peak emission wavelength λP(nm)
500
1000
300
100
10 0−20 80 100604020
1.6 1.8 2.0 2.42.2
31 5 10 50 10030
100
50
30
5
3
10
1
10
5
3
0.5
0.3
1
0.1
20°
30°
40°
50°
10°
0°
60°
70°
80°
90°
90°
80°
20°
30°
40°
50°
10°
60°
70°
80°
20°
40°
60°
020
20
10
30
40
50
40 60 80 100
100
600500 700 800
80
60
40
20
0
30
0
50
0 20 40 60 80 10020406080100
Lighting Color
Orange

SHD00486BEK
This product complies with the RoHS Directive (EU 2002/95/EC).
LN842RPX
2
Package (Unit: mm)
LLXFTN2SK420
5.7 ± 2.0
5.62 ± 0.1
0.1
1 2
2− 0.7 Max
2− 0.45
5
.1
2.54
DER
E
DLOSTON.xaM2
2.2 ±0.2
5.2 ±0.2
5.0 ±0.2 2.0 ±0.2
0.45 ±0.1
±
0.3
3.45
±0.1
Pin name
1: Anode
2: Cathode
