For details of operating Remote Operation Panel AK-HRP1015G, please
visit the Panasonic website (https://pro-av.panasonic.net/manual/en/index.
html), and refer to the Operating Instructions (HTML or PDF).
Read this document when using the AK-HRP1015G Remote Operation Panel in
conjunction with AW-UE150 Series 4K Integrated Cameras.
Operating Guide
Remote Operation Panel
Model No. AK-HRP1015G

Connecting the Unit to AW-UE150 Series Cameras 3
Connection Example 3
Connections 4
Compatible Functions List 5
ROP Menu (during AW-UE150 connection) 8
ROP Menu List 8
01 SCENE 14
02 SHUTTER SPEED 15
03 FILTER 16
04 PEDESTAL 17
05 CHROMA 18
06 GAIN 19
07 WHITE BALANCE 20
08 GAMMA 21
09 BLACK GAMMA 22
10 KNEE 23
11 WHITE CLIP 24
12 DRS 25
13 DETAIL 26
14 DOWNCON DTL 27
15 MATRIX 28
16 COLOR CORRECTION 29
17 DNR 32
18 BRIGHTNESS 33
19 LENS CONTROL 34
20 IRIS RELATIVE 35
21 SYSTEM CAM 36
22 CAMERA MENU CONTROL 38
23 ROP SETTING 39
24 CONNECT SETTING 40
25 ROP IP SETTING 41
26 CAMERA IP SETTING 41
27 AUTO IRIS SETTING 42
28 SWITCHER LINK 43
29 AW CONTROLLER LINK 44
- 2 -
Table of Contents

Connecting the Unit to AW-UE150 Series Cameras
Connection Example
Serial connection with AW-UE150
12 V IN
IR ID AUDIO IN
RS-422
SERVICE
MONI OUT 12G SDI OUT
3G SDI OUT G/L IN
LAN
LINK ACT
OPTICAL
External DC
power supply
<RS-422> connector
4K Integrated Camera
AW-UE150
PoE injector
* Prepare a cable that is in accordance
with the following serial connection
cable specifications.
IP connection with AW-UE150
12 V IN
IR ID AUDIO IN
RS-422
SERVICE
MONI OUT 12G SDI OUT
3G SDI OUT G/L IN
LAN
LINK ACT
OPTICAL
External DC
power supply
<LAN LINK/ACT> connector
4K Integrated Camera
AW-UE150
Switching hub
with PoE support
LAN cable (straight cable)
LAN cable (straight cable)
Serial connection cable specifications
ヒヤモヮチチュモヵユドラナ⾺⾺⾼⾼ヱㄊㄏチワㄐハョㄖㄏ㄄ㄕㄊㄐㄏヱㄐㄍ㄂ㄓㄊㄕㄚョㄍㄐㄘチㄐㄇチㄔㄊㄈㄏ㄂ㄍビヤモヮチチュモヵユドロナピヤモヮチチヤヰワヵドラナフヤモヮチチヤヰワヵドロナヤモヮēチンヰヱヤモヮēチンヰヱンヰヱチēチヤモヮンヰヱチēチヤモヮブヤモヮチチワㄐハチモプヤモヮチチワㄐハチャヘヤモヮチチワㄐハチヤベヤモヮチチワㄐハチュペ
ヒビチヷ
ヒパヨワュヒヨワュン㄀ヵモロロヺ㄀リワンヹュノヵヹュノヵヹュヌンヹュヌヰヱヵリヰワ㄀ヰヶヵヒヰヱヵリヰワ㄀ヰヶヵビビピフブプヘベラㄊㄓㄐㄔㄆチホチランヒパモノヒパンノヒパヱチドヘヒナ
AW-UE150
<RS-422> connector side (RJ-45)
AK-HRP1015G
<CCU> connector side
- 3 -
Connecting the Unit to AW-UE150 Series Cameras

Connections
Set the connection setting to “Serial(AW4)” or “LAN(AW4)” in the [CONNECT SETTING] menu.
ヒチバチヒヘ
ヤヰワワユヤヵチヴユヵヵリワヨヴㄆㄓㄊ㄂ㄍ⾷モヸフ⾸ロモワ⾷モヸフ⾸ワヰワワヰワワヰワワヰワヤモヮヒヤモヮピヤモヮプヤモヮフヤモヮブヤモヮビヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナ
When connecting, observe the following points.
Serial connection
Use a dedicated cable to connect the <CCU> connector of this unit to the <RS-422> connector of the AW-UE150.
Use a PoE injector for the power supply.
LAN connection
Connect the <LAN> connector on this unit to the <LAN LINK/ACT> connector on the AW-UE150 using a LAN cable (sold
separately).
Configure the camera IP address and port number settings of the connection destinations in [CAMERA IP SETTING] as
well.
This unit can be powered using PoE. Use a switching hub with PoE support.
Use a straight cable (category 5e or higher; up to 100 m (328.0 ft) in length) for the LAN cable (STP).
For details on switching hubs and PoE injectors that have been verified to support PoE, consult with your dealer.
- 4 -
Connecting the Unit to AW-UE150 Series Cameras

Compatible Functions List
When the unit is used in conjunction with an AW-UE150 4K Integrated Camera, there will be functions that are limited or disabled for some
of the unit's buttons, dials, and other controls. Be sure to refer to the following table.
Front panel 1
Front panel 2
Front panel 3
Front panel 4
Front panel 5
Front panel 6
Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 1
[PANEL LOCK] button ✓
[AUTO] button ✓If auto setup has been assigned, this will not
operate.
[BARS] button ✓Only the ON/OFF for the color bar signal output
will function.
[TALLY/CALL] lamp/button ×
[REF. RECALL] button ×
[FILES] button ✓This is always lit.
[SETUP] button ✓
[AUTO IRIS] button ✓
Front panel 2
Function buttons ✓
LCD panel ✓
Menu operation dials ✓
- 5 -
Connecting the Unit to AW-UE150 Series Cameras

Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 3
[GAIN] button ✓When this button is pressed, the gain menu
appears on the LCD panel. The button is lit dur-
ing menu display.
[SHT] button ✓When this button is pressed, the shutter menu
appears on the LCD panel. The button is lit dur-
ing menu display.
[COLOR] button ✓The menus will switch with each press of the but-
ton. The button is lit during menu display.
[WHITE BALANCE] > [CHROMA] > [MATRIX] >
[COLOR CORRECTION] > Menu off (status
screen)
[FILTER] button ✓Only the ND filter can be configured.
[GAMMA] button ✓The menus will switch with each press of the but-
ton. The button is lit during menu display.
[GAMMA] > [BLACK GAMMA] > Menu off (status
screen)
[FLARE] button ×
[KNEE] button ✓The menus will switch with each press of the but-
ton. The button is lit during menu display.
[KNEE] > [WHITE CLIP] > Menu off (status
screen)
[DTL] button ✓The menus will switch with each press of the but-
ton. The button is lit during menu display.
[DTL] > [DOWNCON DTL] > [DNR] > Menu off
(status screen)
Front panel 4
[GAIN], [TEMP], [GAMMA], [SKIN] adjust-
ment block
✓When [GAIN] is lit,
adjust [GAIN R] with the red (R) adjustment dial,
and adjust [GAIN B] with the blue (B) adjustment
dial.
When [GAMMA] is lit,
“MASTER GAMMA” is adjusted using the green
(G) adjustment dial.
When [TEMP] is lit,
[COLOR TEMP] is adjusted with the green (G)
adjustment dial.
[SKIN] adjustment is disabled.
[PED], [FLARE], [B.GAM] adjustment block ✓When [PED] is lit,
adjust [PED R] with the red (R) adjustment dial,
adjust [M.PED] with the green (G) adjustment
dial,
and adjust [PED B] with the blue (B) adjustment
dial.
When [B.GAM] is lit,
[BLACK GAMMA] is adjusted using the green (G)
adjustment dial.
[FLARE] adjustment is disabled.
- 6 -
Connecting the Unit to AW-UE150 Series Cameras

Number Part name
✓: Enabled
×: Disabled
Remarks
Front panel 5
[ALM] indicator ✓
[OPT] indicator ×
[EXT] indicator ×
[D.EXT] indicator ✓
Adjustment value display ✓The adjustment value of the CC filter is not dis-
played.
[ND] indicator ✓
[CC] indicator ×
[IRIS] indicator ✓
[GAIN] indicator ✓
[PED] indicator ✓
[SHT] indicator ✓
[SYNC] indicator ✓
[DISP] button ✓
[UP (FREE)] button ✓
[DOWN (CHARA)] button ✓
[LOCK] indicator ✓
[SEL] dial ✓
Front panel 6
Memory card slot ✓
Memory card access indicator ✓
Camera number/tally display ✓Only camera numbers are displayed.
[IRIS RELATIVE] button ✓
Torque adjustment screw ✓
IRIS lever ✓
Master pedestal dial ✓
[PREVIEW] button ×
- 7 -
Connecting the Unit to AW-UE150 Series Cameras

ROP Menu (during AW-UE150 connection)
ROP Menu List
When an AW-UE150 4K Integrated Camera is connected, the ROP menu will be as follows.
NOTE
To perform menu operations, upgrade the system version of the unit to V2.00-00-0.00 or later.
For details on menu operations, refer to the following sections in the Operating Instructions.
“Displaying menus”
“Basic menu operations”
01 SCENE
SCENE1(push) “SCENE1(push)” (see page 14)
SCENE2(push) “SCENE2(push)” (see page 14)
SCENE3(push) “SCENE3(push)” (see page 14)
SCENE4(push) “SCENE4(push)” (see page 14)
02 SHUTTER SPEED
MODE “MODE” (see page 15)
SPEED “SPEED” (see page 15)
ELC “ELC” (see page 15)
03 FILTER ND “ND” (see page 16)
04 PEDESTAL
M.PED “M.PED” (see page 17)
OFFSET “OFFSET” (see page 17)
PED R “PED R” (see page 17)
PED G “PED G” (see page 17)
PED B “PED B” (see page 17)
05 CHROMA
LEVEL “LEVEL” (see page 18)
PHASE “PHASE” (see page 18)
06 GAIN
SUPER GAIN “SUPER GAIN” (see page 19)
GAIN “GAIN” (see page 19)
AGC MAX GAIN “AGC MAX GAIN” (see page 19)
07 WHITE BALANCE
MODE “MODE” (see page 20)
COLOR TEMP “COLOR TEMP” (see page 20)
GAIN OFFSET “GAIN OFFSET” (see page 20)
GAIN R “GAIN R” (see page 20)
GAIN B “GAIN B” (see page 20)
ATW SPEED “ATW SPEED” (see page 20)
ATW TRGT R “ATW TRGT R” (see page 20)
ATW TRGT B “ATW TRGT B” (see page 20)
08 GAMMA
MODE “MODE” (see page 21)
GAMMA “GAMMA” (see page 21)
F-REC Dynmc LV “F-REC Dynmc LV” (see page 21)
F-REC B.STR LV “F-REC B.STR LV” (see page 21)
V-REC KNEE SLOPE “V-REC KNEE SLOPE” (see page 21)
V-REC KNEE POINT “V-REC KNEE POINT” (see page 21)
09 BLACK GAMMA
BLACK GAMMA “BLACK GAMMA” (see page 22)
RANGE “RANGE” (see page 22)
- 8 -
ROP Menu (during AW-UE150 connection)

10 KNEE
MODE “MODE” (see page 23)
A.KNEE RESPONSE “A.KNEE RESPONSE” (see page 23)
POINT “POINT” (see page 23)
SLOPE “SLOPE” (see page 23)
HLG KNEE SW “HLG KNEE SW” (see page 23)
HLG KNEE POINT “HLG KNEE POINT” (see page 23)
HLG KNEE SLOPE “HLG KNEE SLOPE” (see page 23)
11 WHITE CLIP
WHITE CLIP “WHITE CLIP” (see page 24)
WHITE CLP LV “WHITE CLP LV” (see page 24)
12 DRS DRS “DRS” (see page 25)
13 DETAIL
MASTER DTL “MASTER DTL” (see page 26)
CORING “CORING” (see page 26)
V DTL LEVEL “V DTL LEVEL” (see page 26)
FREQ “FREQ” (see page 26)
LEVEL DEPEND. “LEVEL DEPEND.” (see page 26)
KNEE APE.LEVEL “KNEE APE.LEVEL” (see page 26)
GAIN(+) “GAIN (+)” (see page 26)
GAIN(-) “GAIN (-)” (see page 26)
SKIN DTL “SKIN DTL” (see page 26)
SKIN DTL EFFECT “SKIN DTL EFFECT” (see page 26)
DTL SW “DTL SW” (see page 26)
14 DOWNCON DTL
MASTER DTL “MASTER DTL” (see page 27)
CORING “CORING” (see page 27)
V DTL LEVEL “V DTL LEVEL” (see page 27)
FREQ “FREQ” (see page 27)
LEVEL DEPEND. “LEVEL DEPEND.” (see page 27)
KNEE APE.LEVEL “KNEE APE.LEVEL” (see page 27)
DTL SW “DTL SW” (see page 27)
15 MATRIX
TYPE “TYPE” (see page 28)
R-G “R-G” (see page 28)
R-B “R-B” (see page 28)
G-R “G-R” (see page 28)
G-B “G-B” (see page 28)
B-R “B-R” (see page 28)
B-G “B-G” (see page 28)
- 9 -
ROP Menu (during AW-UE150 connection)

16 COLOR CORRECTION
TYPE “TYPE” (see page 30)
COLOR CORRECT “COLOR CORRECT” (see page 30)
SAT “SAT” (see page 30)
PHASE “PHASE” (see page 30)
SAT B_Mg “SAT B_Mg” (see page 30)
PHASE B_Mg “PHASE B_Mg” (see page 30)
SAT Mg “SAT Mg” (see page 30)
PHASE Mg “PHASE Mg” (see page 30)
SAT Mg_R “SAT Mg_R” (see page 30)
PHASE Mg_R “PHASE Mg_R” (see page 30)
SAT Mg_R_R “SAT Mg_R_R” (see page 30)
PHASE Mg_R_R “PHASE Mg_R_R” (see page 30)
SAT R “SAT R” (see page 31)
PHASE R “PHASE R” (see page 31)
SAT R_R_Yl “SAT R_R_Yl” (see page 31)
PHASE R_R_Yl “PHASE R_R_Yl” (see page 31)
SAT R_Yl “SAT R_Yl” (see page 31)
PHASE R_Yl “PHASE R_Yl” (see page 31)
SAT R_Yl_Yl “SAT R_Yl_Yl” (see page 31)
PHASE R_Yl_Yl “PHASE R_Yl_Yl” (see page 31)
SAT Yl “SAT Yl” (see page 31)
PHASE Yl “PHASE Yl” (see page 31)
SAT Yl_Yl_G “SAT Yl_Yl_G” (see page 31)
PHASE Yl_Yl_G “PHASE Yl_Yl_G” (see page 31)
SAT Yl_G “SAT Yl_G” (see page 31)
PHASE Yl_G “PHASE Yl_G” (see page 31)
SAT G “SAT G” (see page 31)
PHASE G “PHASE G” (see page 31)
SAT G_Cy “SAT G_Cy” (see page 31)
PHASE G_Cy “PHASE G_Cy” (see page 31)
SAT Cy “SAT Cy” (see page 31)
PHASE Cy “PHASE Cy” (see page 31)
SAT Cy_B “SAT Cy_B” (see page 31)
PHASE Cy_B “PHASE Cy_B” (see page 31)
SAT B “SAT B” (see page 31)
PHASE B “PHASE B” (see page 31)
17 DNR DNR “DNR” (see page 32)
18 BRIGHTNESS
PICTURE LEVEL “PICTURE LEVEL” (see page 33)
FRAME MIX “FRAME MIX” (see page 33)
DAY/NIGHT “DAY/NIGHT” (see page 33)
- 10 -
ROP Menu (during AW-UE150 connection)

19 LENS CONTROL
FOCUS MODE “FOCUS MODE” (see page 34)
FOCUS SPEED “FOCUS SPEED” (see page 34)
FOCUS “FOCUS” (see page 34)
ZOOM WIDE “ZOOM WIDE” (see page 34)
ZOOM SPEED “ZOOM SPEED” (see page 34)
ZOOM TELE “ZOOM TELE” (see page 34)
DIGITAL ZOOM SW “DIGITAL ZOOM SW” (see page 34)
DIGITAL ZOOM MAX “DIGITAL ZOOM MAX” (see page 34)
DIGITAL ZOOM D.EXT “DIGITAL ZOOM D.EXT” (see page 34)
20 IRIS RELATIVE
SENSE “SENSE” (see page 35)
COARSE “COARSE” (see page 35)
RELATIVE “RELATIVE” (see page 35)
21 SYSTEM CAM
FORMAT “FORMAT” (see page 36)
FREQUENCY “FREQUENCY” (see page 36)
12G 3G SDI “12G 3G SDI” (see page 36)
3G 3G SDI “3G 3G SDI” (see page 36)
I.S. “I.S.” (see page 36)
OSD 12G “OSD 12G” (see page 36)
OSD 3G “OSD 3G” (see page 36)
OSD MONI “OSD MONI” (see page 36)
OSD HDMI “OSD HDMI” (see page 37)
OSD IP “OSD IP” (see page 37)
OSD STATUS “OSD STATUS” (see page 37)
AUDIO “AUDIO” (see page 37)
GENLOCK PHASE “GENLOCK PHASE” (see page 37)
HEAD PW(push) “HEAD PW(push)” (see page 37)
TALLY CONTROL “TALLY CONTROL” (see page 37)
TALLY INPUT “TALLY INPUT” (see page 37)
TALLY SIGNAL “TALLY SIGNAL” (see page 37)
TALLY CONT MD “TALLY CONT MD” (see page 37)
22 CAMERA MENU CONTROL
MENU ON/OFF “MENU ON/OFF” (see page 38)
CURSOR/PARAMETER “CURSOR/PARAMETER” (see page 38)
EXECUTE “EXECUTE” (see page 38)
- 11 -
ROP Menu (during AW-UE150 connection)

23 ROP SETTING
IRIS LEV MODE Refer to the following section in the Operating Instructions.
“37 ROP SETTING”
M.PED CONT
LOCK SELECT
AUTO BUTTON
G/M PED VOL
FREE+LOCK
CAM SEL
DTL BUTTON
SKIN VOL
LCD BRIGHT
PANEL BRIGHT
B.GAMMA VOL
BUZZER
PERIOD
CYCLE
STD POSITION M.GAIN
STD POSITION VAR
STD POSITION ND
STD POSITION CC
IRIS PRIORITY
ROP DATA SAVE
ROP DATA LOAD
SD CARD FORMAT
INITIAL with NW
INITIAL
UPGRADE
IRIS CALIBRATION TOP
IRIS CALIBRATION BOTTOM
SYSTEM VERSION
SOFT VERSION
FPGA VERSION
24 CONNECT SETTING
CONNECT MODE(push) CAM1 “CONNECT MODE(push) CAM1” (see page 40)
CONNECT MODE(push) CAM2
to CAM99 “CONNECT MODE(push) CAM2 to CAM99” (see page 40)
- 12 -
ROP Menu (during AW-UE150 connection)

25 ROP IP SETTING
IP ADDRESS 1 Refer to the following section in the Operating Instructions.
“39 ROP IP SETTING”
IP ADDRESS 2
IP ADDRESS 3
IP ADDRESS 4
IP ADDRESS PORT
IP ADDRESS UPLOAD
SUBNET MASK 1
SUBNET MASK 2
SUBNET MASK 3
SUBNET MASK 4
SUBNET MASK UPLOAD
DEFAULT GATEWAY
DEFAULT GATEWAY
UPLOAD
MAC ADDRESS
26 CAMERA IP SETTING
CAM1 to CAM99 IP ADDRESS Refer to the following section in the Operating Instructions.
“40 CAMERA IP SETTING”
CAM1 to CAM99 PORT
CAM1 to CAM99 INF UPLOAD
27 AUTO IRIS SETTING
IRIS SPEED “IRIS SPEED” (see page 42)
IRIS WINDOW “IRIS WINDOW” (see page 42)
28 SWITCHER LINK
SW' IP “SW'IP” (see page 43)
RECEIVE UDP PORT “RECEIVE UDP PORT” (see page 43)
UPLOAD “UPLOAD” (see page 43)
SWITCHER LINK “SWITCHER LINK” (see page 43)
TALLY RECEIVE “TALLY RECEIVE” (see page 43)
PREVIEW “PREVIEW” (see page 43)
TALLY ACTION MATERIAL “TALLY ACTION MATERIAL” (see page 43)
TALLY ACTION CAM No. “TALLY ACTION CAM No.” (see page 43)
29 AW CONTROLLER LINK
RECEIVE PORT Refer to the following section in the Operating Instructions.
“47 AW CONTROLLER LINK”
INFO UPLOAD
AW CONT LINK
- 13 -
ROP Menu (during AW-UE150 connection)

01 SCENE
ヒチバチヒ
ヴヤユワユヰワヰョョヰョョヰョョヴヤユワユヒドㄑㄖㄔㄉナヴヤユワユピドㄑㄖㄔㄉナヴヤユワユフドㄑㄖㄔㄉナヴヤユワユビドㄑㄖㄔㄉナ
Item Setting details
SCENE1(push) Switches the scene file.
Switches to the scene set to ON.
SCENE2(push)
SCENE3(push)
SCENE4(push)
- 14 -
ROP Menu (during AW-UE150 connection)

02 SHUTTER SPEED
ヒチバチヒ
ヴラヶヵヵユンチヴヱユユュヰョョ
ノノ
ヮヰュユユロヤヴヱユユュ
Item Setting details
MODE Selects the operation mode of the shutter.
SPEED Sets the shutter speed.
ELC Sets the maximum shutter value for ELC operation.
- 15 -
ROP Menu (during AW-UE150 connection)

03 FILTER
ヒチバチヒ
ョリロヵユンヒワュ
Item Setting details
ND Sets the transmittance of the lens’ built-in ND (neutral density) filter.
- 16 -
ROP Menu (during AW-UE150 connection)

04 PEDESTAL
ヒチバチヒ
ヱユュユヴヵモロパヰョョヮハヱユュヰョョヴユヵンヨャパパパヱユュ
Item Setting details
M.PED Adjusts the black level of the master pedestal.
OFFSET Sets the [PED R], [PED G], and [PED B] pedestal levels when the auto black balance is adjusted.
PED R Sets the correction level of red to the master pedestal.
PED G Sets the correction level of green to the master pedestal.
PED B Sets the correction level of blue to the master pedestal.
- 17 -
ROP Menu (during AW-UE150 connection)

05 CHROMA
ヒチバチヒ
ヤランヰヮモパパロユヷユロヱラモヴユ
Item Setting details
LEVEL Sets the color intensity of images.
PHASE Finely adjusts the color phase of images.
- 18 -
ROP Menu (during AW-UE150 connection)

06 GAIN
ヒチバチヒ
ヨモリワヰョョフヒベヴヶヱユンヨモリワモヨヤヮモヹチヨモリワヨモリワ
Item Setting details
SUPER GAIN Sets the super gain (increased sensitivity) to ON/OFF.
GAIN Adjusts the gain of images.
AGC MAX GAIN When “AUTO” is selected as the [GAIN] setting, the maximum gain-up amount can be set.
- 19 -
ROP Menu (during AW-UE150 connection)

07 WHITE BALANCE
ヒチバチビ
ヸラリヵユチャモロモワヤユモヸャチモピビパパレヰョョヮヰュユヨモリワヰョョヴユヵヤヰロヰンヵユヮヱンャパパヨモリワ
ビチバチビ
ヸラリヵユチャモロモワヤユワヰンヮモロパパヴヱユユュヵンヨヵチャヵンヨヵチンモヵヸ
Item Setting details
MODE Sets the white balance mode.
COLOR TEMP Sets color temperature settings.
GAIN OFFSET Sets the [GAIN R] and [GAIN B] values when the [MODE] is set to “AWB A” or “AWB B”.
GAIN R Adjusts the R gain.
GAIN B Adjusts the B gain.
ATW SPEED Sets the control speed of the ATW function.
ATW TRGT R Finely adjusts the [GAIN R] output when converged in the auto tracking white balance operation.
ATW TRGT B Finely adjusts the [GAIN B] output when converged in the auto tracking white balance operation.
- 20 -
ROP Menu (during AW-UE150 connection)
