Panasonic CF-C1 Series Installation and operating instructions

Model No. CF-C1 Series
This addendum includes revisions to the Operating Instructions and Reference Manual, as well as
supplementary information.
<Only for model with touchscreen>
About the title of the Reference Manual
Read the title in the Reference Manual given in the Operating Instructions as follows.
Title given in the Operating Instructions Title given in the Reference Manual
“Digitizer / Multi Touch Operation” “Screen Input Operation”
Introduction
Replace “digitizer pen” with “stylus”.
Description of Parts
• Replace “digitizer pen” with “stylus”.
• B: LCD/Digitizer
Replace “LCD/Digitizer” with “LCD/Touchscreen”.
First-time Operation
Preparation
The following accessory is NOT supplied.
• Digitizer Pen . . . . . . . . . . . . . . . . . 1
The following accessory is supplied.
• Stylus . . . . . . . . . . . . . . . . . . . . . . 1
Model No: CF-VNP017AU
Attached in the pen holder at purchase.
( Reference Manual “Screen Input Operation”)
Step 6: Perform the screen calibration
Replace the procedure with the following.
NOTE
•Perform the following calibration for each user.
•Rotate the display to primary landscape before performing the calibration.
A
Click (start) - [Control Panel] - [Hardware and Sound] - [Tablet PC Settings].
BClick [Calibrate].
CIf [User Account Control] is displayed, click [Yes].
DUsing the stylus, touch each of the “+” target marks one by one, and then click [Yes].
AClick [start] - [Control Panel] - [Printers and Other Hardware] - [Tablet and Pen Settings].
BSet the following with [Calibrate] in [Settings].
CUsing the stylus, touch each of the “+” target marks one by one, and then click [Yes].
Handling and Maintenance
When using the digitizer
Replace “digitizer” with “touchscreen”.
Replace “digitizer pen” with “stylus”.
FJ0810-0
DFQX1C17ZA
Printed in Japan
Addendum
CF-C1(DFQX1C17ZA)USFlyer.indd1CF-C1(DFQX1C17ZA)USFlyer.indd1 2010/08/3016:31:272010/08/3016:31:27

Troubleshooting (Basic)
Change the description “Cannot point the correct position using the included digitizer pen or finger.” as follows.
Cannot point the correct posi-
tion using the included stylus or
finger.
Perform the screen calibration. (reverse side)
If the external mouse driver is installed, you may not be able to
use the Touch Pad.
Uninstall the external mouse driver.

If the cursor does not move correctly after calibration, reset the pa-
rameters and perform the screen calibration again, using the follow-
ing steps.
A
Click (start) -
[Control Panel] - [Hardware and Sound] - [Tablet
PC Settings].
B
Click [Reset].
CIf [User Account Control] is displayed, click [Yes].
DClick [OK].
EClick [Calibrate], then perform the screen calibration
(step Con the reverse side).
Add the following description.
When the computer is turned off,
horizontal stripes on the screen
may appear.
This is a product of the touchscreen specifications, and is not a
malfunction.
Specifications
Read the “Keyboard / Pointing Device” in the Operating Instructions as follows.
Keyboard / Pointing Device 83 keys / Touch Pad / Multi touch (Resistive)
<Only for model with Web Camera>
Description of Parts
• A: Web Camera
For further information on how to use the Web Camera, refer to Reference Manual “Web Camera”.
On-screen Manual
Supplementary information on Camera Utility described in Reference Manual “Web Camera”.
• Mirroring
The mirror function is not available when Windows Aero is disabled.
• Assigning the Zoom In/Take Photo Functions to the Tablet Button
If “The file path you specified does not exist…” appears, the file path specified for [Program Location] in
the [Tablet Button Actions] screen may not be correct, or the double quotation mark (“) may be missing.
Click [OK] and confirm the [Tablet Button Actions] screen.
Troubleshooting (Basic)
Add the following description.
The Web Camera does not oper-
ate.
When using the Web Camera after the computer resumes from
sleep / standby or hibernation, wait
for about 10 seconds before starting up the software.
Specifications
Add the following description.
Web Camera 640 x 480 dots, 30 fps
Pre-installed Software*1 Camera Utility
*1 Operations of this computer are not guaranteed except for the pre-installed OS and the installed OS by using the Product
Recovery DVD-ROM (included).
Some parts of the software in the Product Recovery DVD-ROM may not be installed depending on a model.
