Panduit PBTMT User manual

PBTMT and PBTMT/E
PA26091A01
Rev. 00 9-2009
© Panduit Corp. 2009
ENGLISH Pg. 1
DEUTSCH Pg. 7
FRANÇAISE Pg. 9
ITALIANA Pg. 11
ESPAÑOL Pg. 13
ÈESKÝPg. 15
NEDERLANDSE Pg. 17
DANSKE Pg. 19
SVENSKA Pg. 21
SUOMEN Pg. 23
NORSK Pg. 25
Website: www.panduit.com
Email: [email protected]
EU Website:
www.panduit.com/emea
EU Email: EMEA-
[email protected]
Panduit Corp. •USA Headquarters •Tinley Park, IL
Tel: [phone], ext. 3255 •Fax: [phone]
Panduit Europe •EMEA Headquarters
Tel: [phone] •Fax: [phone]

PBTMT and PBTMT/E ENGLISH
PBTMT & PBTMT/E_ENGL PA26091A01_00 Page: 1 of 26 9-2009
SYSTEM SPECIFICATIONS .................................................................................................................. 1
PRECAUTIONS AND GENERAL GUIDELINES ................................................................................... 2
TOOL OPERATION................................................................................................................................ 3
SYSTEM SPECIFICATIONS
Motor: 12 V DC motor
3.7 lbs. / 1.8 kg ( + )
PANDUIT Pan-Steel MLT SERIES TIES ONLY
MLTH (Heavy)
5/16”W
(7.9mm)
MLTEH (Extra-Heavy)
1/2”W
(12.7mm)
MLTSH (Super Heavy)
5/8”W
(15.9mm)
English NOTE: In the interest of higher quality and value, PANDUIT products are continually being
improved and updated. Consequently, pictures may vary from the enclosed product.

PBTMT and PBTMT/E ENGLISH
PBTMT & PBTMT/E_ENGL PA26091A01_00 Page: 2 of 26 9-2009
Replacement Milwaukee®Batteries and Battery Chargers are available for purchase from local Milwaukee®
products distributors or resellers.
Milwaukee® is a registered trademark of Milwaukee Electric Tool Corporation
The information contained in this literature is based on our experience to date and is believed to be reliable. It is intended
as a guide for use by persons having technical skill at their own discretion and risk. We do not guarantee favorable results
or assume any liability in connection with its use. Dimensions contained herein are for reference purposes only. For
specific dimensional requirements consult the factory. This publication is not to be taken as a license to operate under, or
a recommendation to infringe any existing patents. This supersedes and voids all previous literature, etc.
PRECAUTIONS AND GENERAL GUIDELINES
This symbol is used to call your attention to hazards or unsafe practices which could result in an
injury or property damage. The signal word, defined below, indicates the severity of the hazard.
The message after the signal word provides information for preventing or avoiding the hazard.
WARNING Hazards which, if not avoided, COULD result in severe injury or death.
CAUTION Hazards or unsafe practices which, if not avoided, MAY result in injury or
property damage.
WARNING
Read and understand all of the instructions and safety information in this manual before
operating or servicing this tool.
WARNING
Wear eye protection when operating or servicing this tool.
Failure to wear eye protection can result in serious eye injury from flying debris.
WARNING
•Inspect tool before use. A worn or damaged tool may result in breakage striking the operator or nearby
personnel.
CAUTION
•Do not perform any service or maintenance other than as described in this manual.
Injury or damage to the tool may result.
•This tool is not designed for continuous use.
•The tool is designed for hand-held operation.
•Protect the tool from rain and moisture. Water will damage the tool and battery.
•Electric tools should not be operated in pouring rain or under water.
•Use this tool for the manufacturer’s intended purpose only.

PBTMT and PBTMT/E
PBTMT & PBTMT/E PA26091A01_00 Page: 3 of 26 9-2009
ENGLISH TOOL OPERATION
DEUTSCH BEDIENUNG DES WERKZEUGS
FRANÇAISE FONCTIONNEMENT DE L’OUTIL
ITALIANA AVVIAMENTO DELL'ATTREZZO
ESPAÑOL OPERACIÓN DE LA HERRAMIENTA
ÈESKÝ OBSLUHA NÁSTROJE
NEDERLANDSE GEBRUIK VAN HET GEREEDSCHAP
DANSKE BETJENING AF VÆRKTØJET
SVENSKA VERKTYG MANÖVRERING
SUOMEN TYÖKALUN KÄYTTÖ
NORSK BETJENING AV MASKINEN
5/16" (7.9mm) H 1 – 4
½” (12.7mm) EH 3 – 6
5/8” (15.9mm) SH 5 – 7
