Panduit CDPP8RG-S User manual

For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2019 PN627
Page 1 of 5
CDPP8RG-S
Latches
1
Base
Base ASM
Shield contact
DIN Rail
2
Orient base
as shown
** Denotes color.
8-Port Shielded IndustrialNet DIN Rail Mount
Copper Patch Panel
Part Number: CDPP8RG-S

For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2019 PN627
Page 2 of 5
3
Latches
Base
DIN Rail
Patch Panel Pocket
Note: Ensure DIN Rail
compresses Base ASM Shield

For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2019 PN627
Page 3 of 5
4
Faceplate
Single port
Mini-Com modules
(sold separately)
Orient modules
as shown.
Note: Reference module instruction
sheets for termination instructions.
4
Faceplate
Single port Shielded
Mini-Com modules
(sold separately)
Orient modules
as shown.
Note: Reference module instruction
sheets for termination instructions.
5
Route cables up or
down through slot.
6
#6-32 x 3/8"
screws
Torque screws
to 5 - 8 lb-in.
7
Label
Covers
Labels
4a
Faceplate
Base
ASM
Base ASM
Shield
Faceplate
Shield
Note: Assemble Faceplate to Base ASM where Base ASM Shield
contacts the side of the Faceplate Shield

For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2019 PN627
Page 4 of 5
8Insert grounding wire of CJSGK-XY onto
tab of Faceplate Shield
Insert wire into bracket
Tab of Faceplate Shield
OPTIONAL STEPS - SHIELDING WITHOUT DIN RAIL
9
Insert customer supplied
grounding wire into bracket
Bracket only accepts wires of
10-12 gauge
10 Clamp down on grounding tab

INSTALLATION INSTRUCTIONS
© Panduit Corp. 2019 PN627
E-mail:
[email protected]m
Phone:
866-405-6654
For Instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp www.panduit.com
Page 5 of 5
11 Close bracket cover until latch engages
