Panduit BT2HT User manual

E-mail:
[e-mail]
Technical Support:
888-506-5400, ext. 83255
E
C
A
B
FIGU E 1
Page: 1 of 4
© Panduit Corp. 2013
INT ODUCTION
The BT2HT Tool installs Panduit Pan-Steel coated and
uncoated S Series strap and buckles in widths of 3/8” X
.015” thick (9.5mm), 1/2” X .015” thick (12.7mm); and 5/8” X
.015” and .025” thick (15.9mm).
Note: This tool is not intended for other uses such as cutting
or tensioning other types of fastening devices.
TOOL FEATU ES
A. Rear Handle
B.* Tension Pawl Release - Knob pointing towards the front
of tool for pawl engagement and to rear of tool for disen-
gagement.
C.* Anti-Backup Pawl Release - Lever up against tool for
pawl engagement and pulled down to disengage pawl.
D.* Detent Lock Pins - For controlled tension, pull both pins
forward; for manual tension, push both pins backward.
E. Cutter Handle - Cuts tie when strap is tensioned properly.
F. Cutter Blade
G. Tensioning andrel
H.* Tension Indicator Window - Located on the back of front
handle.
I.* Adjustment Knob - Adjust tension of strap application.
J. Tension Locking Set Screw
K. Front Handle - With ratchet controlled tensioning.
* See Page 2 for Feature Detail
I
K
H
G
F
J
FIGU E 2
TOOL OPE ATION
See Steps 1 - 8 on Pages 3 and 4.
D
PA25758A01
Rev: 02 2-2013
MS ST APPING TOOL
BT2HT
www.panduit.com

Page: 2 of 4
PUSH BACKWA D
FOR ANUAL
TENSION
PULL FO WA D
FOR CONTROLLED
TENSION
D
B
C
T OUBLESHOOTING
TO RELEASE AND RE OVE STRAP
FRO TOOL BEFORE CUTTING,
DISENGAGE BOTH KNOB AND LEVER.
ULTI-POSITION HANDLE
ALLOWS ACCESS TO TIGHT AREAS.
A
TOOL MAINTENANCE
TO INHIBIT CORROSION AND AINTAIN PERFOR ANCE OF THE TOOL, KEEP THE ETAL SURFACES COATED
WITH A LIGHT OIL (WD-40®OR EQUIVALENT).
6
4
2
7
5
3
1
-+
I
LOW
TENSION
HIGH
TENSION
ST AP SIZE SETTING
3/8” STRAP 1 – 5
1/2” STRAP 1 – 7
5/8” STRAP 1 – 7
ADJUST ENT
KNOB
TENSION
INDICATOR
WINDOW
H
TENSION LOCKING SET SCREW
(USE .050” SIZE ALLEN WRENCH)
BT2HT
© Panduit Corp. 2013

Page: 3 of 4
STEP 1 STEP 2
Slide in buckle and bend the end of strap. Loop strap around bundle.
Thread strap into nose of tool
and through slot of tensioning mandrel.
STEP 3 STEP 4
Pull front handle to tension strap and rotate the tool
to touch the buckle (as shown).
Under controlled tension, the front handle will
break free when pre-determined tension is attained.
Push cutter lever downward to cut strap.
Remove cut-off portion of strap from tool.
BT2HT
© Panduit Corp. 2013

Page: 4 of 4
STEP 5 STEP 6
Bend cut-off end of strap down. Position tab of the tool inside the buckle slot.
STEP 7 STEP 8
Bend the buckle lock down as shown. Strap correctly installed.
BT2HT
© Panduit Corp. 2013
