DCT6
Wireless Door Contact
V1.0
Installation Manual
Introduction
The DCT6 is a wireless magnetic door contact that is discreetly
hidden within the frame of a door or window.
Installation
Transmitter: Drill a 3/4 in. x 2.75 in. depth (16 mm x 70 mm depth)
hole in the frame and insert the DCT6 transmitter. Secure the
transmitter body A- with two screws or B- with one screw and
remove one flange if it interferes with the radial opening or C-
press fit installation on narrow frames, see Figure 3, A, B and C.
Magnet: Drill a 3/4 in. x 1.1 in. (19 mm x 28 mm) hole in the frame
to be aligned with the transmitter when door/window is closed
and insert the magnet with press fit. Make sure it is aligned with
the transmitter and that the gap, when closed, is not greater than
0.4 in. / 10 mm.
Setting RF Frequency / Replacing Battery
1. Open the top of the DCT6 transmitter, turning the cover
counter clockwise, see Figure 2.
2. Locate the switch on the PCB, as shown in Figure 4.
3. Slide the switch to the desired frequency 433 MHz or
868 MHz.
4. Remove the battery for a few seconds. Replace the battery
back (verify the polarity and insert properly + and - marked on
the battery terminals, see Figure 5.
We recommend to replace the battery ever 3 years to
avoid leakage.
Anti-Tamper
Switch
Selectable RF
433 MHz / 868 MHz
FIGURE 4
FIGURE 5
A - Two Screws B - One Screw / One Flange
Flange
removed to
allow opening
C - Press Fit
FIGURE 2 FIGURE 3
2.8 in. /
7.3 cm
1.6. in. / 4 cm (flange)
0.8 in. / 2.1 cm
Close
Open
Breaking the Flange
Open/Close

DCT6-EI00 11/2017
paradox.com
EVO Programming and Testing
1. Enter section [4003]
2. Enter RTX3 or K641LX serial number.
3. Enter section [101] to [132] to assign the DCT6.
4. Open the transmitter as per Figure 2 then close it. This will
register the DCT6 entered section.
5. Test signal strength by entering section [601] to [632].
6. Open the transmitter as per Figure 2 then close it.
7. Verify the signal strength on your LCD keypad or TM70/TM50.
MGSP Programming and Testing
1. Enter available section to assign the DCT6 [061] - [092].
2. Open the transmitter as per Figure 2, then close it. This will
register the DCT6 to the entered section.
3. Test signal strength by entering correspondent section [101]
to [132].
4. Open the transmitter as per Figure 2 then close it.
5. Verify the signal strength on your LCD keypad, TM70/TM50.
Technical Specifications
Power 1 x AAA alkaline battery
RF Frequency Selectable 433/868 MHz on-board
Battery Life 3 years (replace to avoid leakage)
Based on 10 openings/closing a day
Wireless Range
MG5000/MG5050/RTX3 - 40m (130 ft)
MG6250 - 20m (65 ft)
Wireless range is based on typical indoor
installation
Operating
Temperature
-20°C to 50°C (-4°F to 122°F)
Anti-tamper Switch Cover opening
Magnet distance Up to 0.4 in. / 10 mm
Dimensions 7.3 x 2.1 x 2.1 cm (2.8 x 0.8 x 0.8 in.)
Anti-Tamper Switch Cover opening
Approvals CE, EN 50131 Grade 2
Remarks In-frame installation
Supervision Live supervision, Battery low
Compatibility Magellan Panels, MG6250, K32LX,
K641LX, RTX3, RX1
Warranty
For complete warranty information on this product, please refer to the
Limited Warranty Statement is found on the website:
www.paradox.com/terms or contact your local distributor.
Specifications may change without prior notice.
