Paradyne 8310 MVLt User manual

HOTWIREDSLAM
FOR 8310 MVLAND
8510 RADSL CARDS
USER’S GUIDE
Document No. 8000-A2-GB26-10
January 1999

Printed on recycled paper
A 8000-A2-GB26-10
January 1999
Copyright E1999 Paradyne Corporation.
All rights reserved.
Printed in U.S.A.
Notice
This publication is protected by federal copyright law. No part of this publication may be copied or distributed,
transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language in any form
or by any means, electronic, mechanical, magnetic, manual or otherwise, or disclosed to third parties without the
express written permission of Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773.
Paradyne Corporation makes no representation or warranties with respect to the contents hereof and specifically
disclaims any implied warranties of merchantability or fitness for a particular purpose. Further, Paradyne Corporation
reserves the right to revise this publication and to make changes from time to time in the contents hereof without
obligation of Paradyne Corporation to notify any person of such revision or changes.
Changes and enhancements to the product and to the information herein will be documented and issued as a new
release to this manual.
Warranty, Sales, and Service Information
Contact your local sales representative, service representative, or distributor directly for any help needed. For
additional information concerning warranty, sales, service, repair, installation, documentation, training, distributor
locations, or Paradyne worldwide office locations, use one of the following methods:
HVia the Internet: Visit the Paradyne World Wide Web site at http://www.paradyne.com
HVia Telephone: Call our automated call system to receive current information via fax or to speak with a
company representative.
— Within the U.S.A., call 1-800-870-2221
— Outside the U.S.A., call 1-727-530-2340
Trademarks
All products and services mentioned herein are the trademarks, service marks, registered trademarks or registered
service marks of their respective owners.
Patent Notification
Hotwire MVL products are protected by U.S. Patents: 4,637,035, 4,744,092, 4,669,090, 5,291,521 and 5,280,503.
Other U.S. and foreign patents pending.
Document Feedback
We welcome your comments and suggestions about this document. Please mail them to Technical Publications,
Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to [email protected]. Include
the number and title of this document in your correspondence. Please include your name and phone number if you
are willing to provide additional clarification.

i
8000-A2-GB26-10 January 1999
Contents
About This Guide
HDocument Purpose and Intended Audience v. . . . . . . . . . . . . . . . . . . . . . . . .
HDocument Summary vi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HProduct-Related Documents vii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 Hotwire DSLAM System Description
HWhat is the Hotwire DSLAM? 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HHotwire DSLAM Components 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hotwire DSLAM Chassis 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MCC Card 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RADSL or MVL Card 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HHotwire DSLAM Features 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HLevels of Access 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HSoftware Functionality 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring the DSL Cards 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Monitoring the DSL Cards 1-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting and Diagnostics 1-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Hotwire Menus and Screens
HOverview 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HMenu and Screen Formats 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Components of a Hotwire Menu 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Components of a Hotwire Screen 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HCommonly Used Navigation Keys 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HHotwire Menu Hierarchy 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hotwire Chassis Main Menu 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hotwire – MCC Menu 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hotwire – DSL Menu 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DSL Card Configuration Menu 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DSL Card Monitoring Menu 2-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
ii 8000-A2-GB26-10
January 1999
HLogging In to the System 2-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reviewing the Levels of Access 2-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
User Login Screen 2-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Card Selection Screen 2-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessing the Hotwire – DSL Menu 2-12. . . . . . . . . . . . . . . . . . . . . . . . . . . .
HExiting from the System 2-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manually Logging Out 2-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatically Logging Out 2-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Configuring the Hotwire DSLAM
HOverview 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDomain Types 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Domain 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Management Domain 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HConfiguring the DSL Cards 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring VNID(s) on a DSL Card 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring the Active VNID on each DSL Port 3-4. . . . . . . . . . . . . . . . . .
Configuring Static Users 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring Addresses with DHCP 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring Subnet Masks 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring Subnet Addressing 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring IP Filter Rules 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 8310 MVL and 8510 RADSL Card Configuration
HOverview 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Configuration Card Status Screens 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Configuration Ports Screens 4-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Configuration Interfaces Screens 4-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Configuration Users Screens 4-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Configuration Bridge Screens 4-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Configuration Service Node Screens 4-14. . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Configuration Filters Screen 4-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
iii
8000-A2-GB26-10 January 1999
5 Monitoring the Hotwire DSLAM
HOverview 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Monitoring Card Status Screens 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Monitoring Physical Layer Screens 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Monitoring Interfaces Screens 5-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Network Protocol Screens 5-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Bridge Screens 5-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL SN Information Screen 5-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HDSL Monitoring IP Filters Screen 5-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 Diagnostics and Troubleshooting
HDiagnostic Screens 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HTroubleshooting 6-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking Alarms 6-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
No Response at Startup 6-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Major Alarms 6-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Minor Alarms 6-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HNetwork Problems 6-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High-Level Troubleshooting 6-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Client Cannot Ping the Gateway Router 6-8. . . . . . . . . . . . . . . . . . . . . . . .
Client Cannot Reach Service Node 6-9. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Client Cannot Reach DSLAM 6-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Client Cannot Reach IPC 6-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Client Cannot Reach Router 6-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cannot Upload Configurations to a UNIX Server 6-15. . . . . . . . . . . . . . . . .
Performance Issues – Viewing Network Statistics 6-16. . . . . . . . . . . . . . . .
A Download Code
HDownload Code A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Download Only System: Automatic Immediate Apply A-2. . . . . . . . . . . . .
B Traps
HDSL Card Traps B-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glossary
Index

Contents
iv 8000-A2-GB26-10
January 1999
This page intentionally left blank.

v
8000-A2-GB26-10 January 1999
About This Guide
Document Purpose and Intended Audience
This guide describes how to configure and operate the software component of
the Hotwire Digital Subscriber Line Access Multiplexer (DSLAM) system. It is
intended for administrators and operators who maintain the networks that support
Hotwire operation.
A basic understanding of internetworking protocols and their features is assumed.
Specifically, you should have familiarity with Simple Network Management
Protocol (SNMP), Network Management Systems (NMSs), and the following
internetworking concepts:
HTCP/IP applications
HIP and subnet addressing
HIP forwarding (also referred to as IP routing)
HBridging
It is also assumed that you have already installed either the Hotwire 8600, 8800,
or 8810 DSLAM. If you have not done so already, refer to the appropriate Hotwire
DSLAM Installation Guide for installation instructions.
NOTE:
It is highly recommended that you read the Hotwire DSLAM for 8310 MVL
and 8510 RADSL Cards Network Configuration Guide before you begin to
use this guide and the Hotwire software. The Hotwire DSLAM 8310 MVL and
8510 RADSL Cards Network Configuration Guide
provides introductory
information about the Hotwire DSLAM network models and theories.

About This Guide
vi 8000-A2-GB26-10
January 1999
Document Summary
Section Description
Chapter 1 Hotwire DSLAM System Description. Provides an
overview of the Hotwire 8600 and 8800 systems.
Chapter 2
Hotwire Menus and Screens. Describes the operation
of Hotwire menus, screens, and commonly used
navigation keys. Also provides instructions on how to
log in and log out of the system.
Chapter 3
Configuring the Hotwire DSLAM. Describes the
required procedures for configuring the Hotwire
system.
Chapter 4
8310 MVL and 8510 RADSL Card Configuration.
Describes the optional procedures for configuring the
DSL cards on the Hotwire system.
Chapter 5 Monitoring the Hotwire DSLAM. Describes operator
programs that monitor the Hotwire system.
Chapter 6 Diagnostics and Troubleshooting. Describes common
Hotwire operational problems and solutions.
Appendix A Download Code. Describes how to work with the
Download Code and Apply Download menus.
Appendix B
Traps. Describes the traps that are generated by the
Hotwire system.
Glossary Defines acronyms and terms used in this document.
Index Lists key terms, acronyms, concepts, and sections in
alphabetical order.

About This Guide
vii
8000-A2-GB26-10 January 1999
Product-Related Documents
Document Number Document Title
5020-A2-GN10 Hotwire 5020 POTS Splitter Central Office Installation
Instructions
5030-A2-GN10 Hotwire 5030 POTS Splitter Customer Premises
Installation Instructions
5038-A2-GN10 Hotwire 5038 Distributed POTS Splitter Customer
Premises Installation Instructions
5038-A2-GN11 Hotwire 5038 MVL POTS Filter Customer Premises
Installation Instructions
5620-A2-GN10 Hotwire 5620 RTU Customer Premises Installation
Instructions
6020-A2-GZ40 Hotwire 6020 MVL POTS Splitter Central Office
Installation Instructions
6038-A2-GN10 Hotwire 6038 MVL POTS Filter Customer Premises
Installation Instructions
6310-A2-GN10 Hotwire 6310 MVL Modem Customer Premises
Installation Instructions
8000-A2-GB22 Hotwire Management Communications Controller
(MCC) Card, IP Conservative, User’s Guide
8000-A2-GB27 Hotwire DSLAM for 8310 MVL and 8510 RADSL
Cards Network Configuration Guide
8000-A2-GB90 Hotwire 8100/8200 Internetworking Packet
Concentrator (IPC) User’s Guide
8000-A2-GZ40 Hotwire MCC Card, IP Conservative, Installation
Instructions
8310-A2-GZ40 Hotwire 8310 MVL Card Installation Instructions
8510-A2-GZ40 Hotwire 8510 RADSL Card Installation Instructions
8600-A2-GN20 Hotwire 8600 Digital Subscriber Line Access
Multiplexer (DSLAM) Installation Guide
8800-A2-GN21 Hotwire 8800 Digital Subscriber Line Access
Multiplexer (DSLAM) Installation Guide
8810-A2-GN20 Hotwire 8810 Digital Subscriber Line Access
Multiplexer (DSLAM) Installation Guide
Contact your sales or service representative to order additional product
documentation.
Most Paradyne documents are also available on the World Wide Web at:
http://www.paradyne.com
Select Service & Support → Technical Manuals

About This Guide
viii 8000-A2-GB26-10
January 1999

1-1
8000-A2-GB26-10 January 1999
Hotwire DSLAM System
Description 1
What is the Hotwire DSLAM?
The HotwiretDigital Subscriber Line Access Multiplexer (DSLAM) is a Digital
Subscriber Line (DSL) platform that houses a Management Communications
Controller (MCC) card and up to 18 DSL cards. These can be 8310 Multiple
Virtual Lines (MVLt) cards, 8510 Rate Adaptive Digital Subscriber Line (RADSL)
cards, or a combination of both.
NOTE:
All references to DSL cards refer to both the 8510 RADSL and 8310 MVL
cards, unless specifically noted otherwise.
The DSLAM interoperates with two types of Hotwire Service Nodes
(SNs)/endpoints to deliver applications at high speeds in support of packet
services over a DSL link.
HThe 8310 MVL card interoperates with the Hotwire 6310 MVL modem.
HThe 8510 RADSL card interoperates with the Hotwire 5620 RTU (Remote
Termination Unit).
The DSLAM is a set of central site products that terminate and consolidate packet
data traffic from many customers in a serving area. It then forwards the traffic to
one or more network access provider networks.
High-speed Internet and intranet access is bridged on the Layer 2 port cards and
multiplexed over backbone networks. By enabling very high speeds using DSL
technology and concentrating Internet Protocol (IP) traffic, greater performance is
realized.
In addition, the Hotwire DSLAM with an endpoint such as a 6310 MVL modem
and 5620 Service Node can co-exist with Plain Old Telephone Service (POTS)
over the same copper telephone line, providing simultaneous usage of POTS and
digital applications. That is, the optional central office (CO) POTS splitter and
customer premises POTS filter allow simultaneous voice and data connections
over a standard telephone line.

Hotwire DSLAM System Description
1-2 8000-A2-GB26-10
January 1999
The following illustration shows a typical Hotwire configuration.
Legend: DSL - Digital Subscriber Line SN - Service Node
MDF - Main Distribution Frame POTS - Plain Old Telephone Service
IPC - Interworking Packet Concentrator
DSL
CARD
DSLAM
Central Office (CO)
98-15974
Customer Premises (CP)
Ethernet
SN
CP
POTS
Splitter
CO
POTS
Splitter
MDF POTS/DSL
Hotwire
IPC
Voice
Interface
Data
Interface
POTS
Network
Service
Provider
Optional Optional
CO
Switch
Hotwire DSLAM Components
The minimum hardware requirements for a Hotwire DSLAM system consists of
the following components:
HOne Hotwire 8600, 8800, or 8810 DSLAM chassis
HOne MCC card
HOne 8310 MVL or 8510 RADSL card

Hotwire DSLAM System Description
1-3
8000-A2-GB26-10 January 1999
Hotwire DSLAM Chassis
There are three types of chassis:
HThe Hotwire 8600 DSLAM chassis is an independent, standalone system.
The stackable design provides for up to six chassis to share management
access through a single MCC card, which in turn, allows an additional slot for
a DSL card in each of up to five additional chassis.
INPUT
AC
48VDC CLASS 2 OR
LIMITED PWR SOURCE
RTN48V
AAB B
LAN/WAN SLOT
2
46
AB
.
.
.
3.
1
2
POSITION
STACK ALM A
IN
B
DC FUSES
T4A, MIN. 48V 5PWR
FAN
OUT SERIAL MCC 1
MANAGEMENT
3
LINE 1
2
3
SYSTEM
OKAlrm Test TXRXCol
ETHERNET
MCC
8000
SYSTEM
OKAlrm Test TXRXCol 1234
ETHERNET
DSL PORT
RADSL
8546
SYSTEM
OKAlrm
Test TXRXCol 1234
ETHERNET
DSL PORT
RADSL
8546
98-15350-02
ESD
In a stacked configuration, the first or base chassis must contain an MCC
card in Slot 1. In addition to the MCC card, the base chassis can house up to
two DSL cards. Each additional chassis in the stack houses up to three DSL
cards. For more information, see the
Hotwire 8600 Digital Subscriber Line
Access Multiplexer (DSLAM) Installation Guide .

Hotwire DSLAM System Description
1-4 8000-A2-GB26-10
January 1999
HThe Hotwire 8800 DSLAM chassis is a 20-slot chassis designed to house up
to 18 DSL cards and one MCC card. (The remaining slot is reserved for the
future use of a redundant MCC card.) For more information, see the
Hotwire
8800 Digital Subscriber Line Access Multiplexer (DSLAM) Installation Guide .
HThe Hotwire 8810 DSLAM chassis is a higher density carrier, for use with
new and future high-density cards. This 20-slot chassis with integral power,
alarm, cooling, and interface subsystems is designed to house up to 18 DSL
cards and one MCC card. (The remaining slot is reserved for the future use
of a redundant MCC card.) For more information, see the
Hotwire 8810
Digital Subscriber Line Access Multiplexer (DSLAM) Installation Guide
.
ALARMS
Major MinorFanBA
POWER
MCC
SYSTEM
OK
Alm
Test
ETHERNET
TX
RX
Coll
99-15280-04
MGT
SERIAL
MGT
10BT ALARM
SLOTS 1 - 6
SLOTS 7-12
SLOTS 13-18
LINES
-48V (A)
-48V INPUT
-48V (B) RET (A) RET (B) FR GND
246810 12 14 16 18
19
1357911 13 15 17
LAN/WAN SLOT 20
LAN/WAN SLOT
RADSL
SYSTEM
OK
Alm
Test
ETHERNET
TX
RX
Coll
DSL PORT
1
2
3
4
SLOTS 13-18
Interface
Module Ground
Lug
FrontView of a Hotwire 8800 or 8810 DSLAM Chassis

Hotwire DSLAM System Description
1-5
8000-A2-GB26-10 January 1999
MCC Card
The chassis requires one MCC card, which is a processor card that administers
and provides diagnostic connectivity to the DSL cards. It acts as a mid-level
manager and works in conjunction with a Simple Network Management Protocol
(SNMP) system, such as Paradyne’s OpenLanetDCE Manager for HP
OpenView, via its LAN port. It gathers operational status for each of the DSL
cards and responds to the SNMP requests. It also has a serial port for a local
user interface to the DSLAM.
For more information, see the
Hotwire Management Communications Controller
(MCC) Card, IP Conservative, User’s Guide.
RADSL or MVL Card
The chassis requires at least one RADSL or MVL card, which is a circuit card that
contains four RADSL or MVL ports, an Ethernet interface to the Internet Service
Provider (ISP), and a processor/packet forwarder. The processor/packet
forwarder controls the endpoints and forwards the packet traffic via the Ethernet
and RADSL or MVL interfaces. When the 8600 DSLAM chassis is fully populated
with 5 expansion chassis, it provides a total of 68 RADSL or MVL modem ports.
When the 8800 or 8810 DSLAM chassis is fully populated, it provides a total of
72 RADSL or MVL modem ports.
Hotwire DSLAM Features
The Hotwire DSLAM system contains the following features:
HHigh-speed Internet or intranet access
HRADSL ports
HMVL ports
HSubscriber authentication, security access, and permission features that
prevent users from accessing unauthorized services
HDiagnostic tests and performance capabilities
HPrimary network management support via SNMP agent for monitoring and
traps
HTelnet for configuration and diagnostics

Hotwire DSLAM System Description
1-6 8000-A2-GB26-10
January 1999
Levels of Access
There are two levels of diagnostic/administrative access in the Hotwire DSLAM
system:
HAdministrator
The Administrator has complete read/write access to the DSLAM system.
With Administrator permission, you can set specific parameters and variables
to configure cards, ports, interfaces, Virtual Network ID (VNID) bridging, and
endpoint selection.
HOperator
The Operator has read-only access and can view configuration information
and monitor performance but has no configuration menu access or
modification permission.
Software Functionality
Depending upon your system access, you can:
HConfigure the system,
HMonitor the system, and/or
HRun applications and diagnostic tests to troubleshoot the network.
Configuring the DSL Cards
The Hotwire DSLAM software provides DSL configuration options to:
HConfigure the DSL cards
HConfigure the interfaces and ports
HSet up user accounts
HUpload or download a copy of a card’s configuration data to or from a Trivial
File Transfer Protocol (TFTP) server
HDownload a new version of the DSL and endpoint software
NOTE:
You must have Administrator permission to configure the system.
For more information about configuring the system, see Chapter 3, Configuring
the Hotwire DSLAM, and Chapter 4, 8310 MVL and 8510 RADSL Card
Configuration
.

Hotwire DSLAM System Description
1-7
8000-A2-GB26-10 January 1999
Monitoring the DSL Cards
The Hotwire DSLAM software provides submenu options to monitor the activity of
the Hotwire DSL cards. The monitoring screens allow you to:
HList the status of active ports and interfaces in a card, as well as display
statistics about other physical layers and interfaces.
HDisplay network protocol statistics, such as information about an application
program assigned to a specific socket number, UDP statistics, TCP data and
connection statistics, IP statistics, ICMP packet statistics, and SNMP
statistics including SNMP authentication statistics.
HDisplay information about the Client, ARP, and VNIDs.
HDisplay endpoint information about DSL Ports 1–4 such as Service Node
type, system name, system contact, and system location. Model and serial
number, along with firmware and hardware revisions, are also shown.
Use the monitoring screens to help you gather pertinent information and isolate
potential problem areas. You can monitor the system with either Administrator or
Operator permission.
For more information about monitoring the system, see Chapter 5,
Monitoring the
Hotwire DSLAM .

Hotwire DSLAM System Description
1-8 8000-A2-GB26-10
January 1999
Troubleshooting and Diagnostics
The Hotwire DSLAM system provides DSL diagnostic submenu options that:
HDisplay self-test results for CPU health, memory and ports, and resets.
HShow major alarms such as Selftest Failure, Processor Failure, and DSL or
Ethernet port failure.
HShow minor alarms such as Configuration Error or Incorrect SN ports.
HRun a nondisruptive packet echo test over the DSL line.
NOTE:
You must have Administrator permission to perform most of the
troubleshooting and diagnostic activities. However, you can run nondisruptive
tests as a user with Operator permission.
For more information about troubleshooting and diagnostics, see Chapter 6,
Diagnostics and Troubleshooting .
NOTE:
If you would like more information on DSL-based services, applications, and
network deployment, refer to Paradyne’s DSL Sourcebook. The book may be
downloaded or ordered through Paradyne’s World Wide Web Site at
http://www.paradyne.com.

2-1
8000-A2-GB26-10 January 1999
Hotwire Menus and Screens 2
Overview
The Hotwire DSLAM has a menu- and screen-driven user interface system that
enables the user to configure and monitor the Hotwire cards. This chapter
contains:
HMenu and Screen Formats
HCommonly Used Navigation Keys
HHotwire Menu Hierarchy
HLogging In to the System
HExiting from the System

Hotwire Menus and Screens
2-2 8000-A2-GB26-10
January 1999
Menu and Screen Formats
The Hotwire DSLAM uses an ASCII-based text format for its menus and screens.
This section describes the components of a typical Hotwire menu and screen.
Components of a Hotwire Menu
A typical Hotwire menu format looks like this:
1
2
3
1. Menu Title is the top line of the menu window that displays the title of the
menu or submenu.
2. Menu List is the portion of the menu window that displays the list of menu
options. When selected, a menu option displays a submenu window or
screen.
3. Letter Navigation Keys are provided within a menu list. These keys provide
a convenient way (shortcut) to select a menu item.
For example, from the Hotwire – DSL menu illustrated above, you can simply
press the A key to select the Configuration menu item. The Configuration
menu appears. You can then press the A key to select the Card Status menu
item. This action displays the Card Status menu. (You can also use the arrow
keys on your keyboard to select a menu item. See
Commonly Used
Navigation Keys on page 2-4 for more information.)
