Parkside PFDFA 20-Li A1 User manual

CORDLESS BISCUIT JOINTER 20V / AKKU-
FLACHDÜBELFRÄSE 20 V / FRAISEUSE À LAMELLES
SANS FIL 20V PFDFA 20-Li A1
FRAISEUSE À LAMELLES
SANS FIL 20V
Traduction des instructions d’origine
AKKU-FLACHDÜBELFRÄSE 20 V
Originalbetriebsanleitung
CORDLESS BISCUIT JOINTER 20V
Translation of the original instructions
AKU FRÉZA NA DRÁŽKY
PLOCHÝCH CEPU 20 V
Překlad originálního provozního návodu
VLAKKE DEUVELFREES
OP ACCU 20V
Vertaling van de originele gebruiksaanwijzing
AKUMULÁTOROVÁ FRÉZA NA
DRÁŽKY PLOCHÝCH CAPOV 20 V
Preklad originálneho návodu na obsluhu
AKUMULATOROWA FREZARKA DO
KOŁKÓW PŁASKICH 20V
Tłumaczenie oryginalnej instrukcji obsługi
ENGALLETADORA
RECARGABLE 20V
Traducción del manual de instrucciones original
BATTERIDREVEN
FLADDYBELFRÆSER 20 V
Oversættelse af den originale driftsvejledning
FRESATRICE PER TASSELLI
PIATTI RICARICABILE 20 V
Traduzione delle istruzioni d’uso originali
AKKUS LAPOS DÜBELMARÓ 20 V
Az originál használati utasítás fordítása
IAN 438488_2304

GB/ IE Translation of the original instructions Page 1
DE/AT / CH Originalbetriebsanleitung Seite 15
FR/BE Traduction des instructions d’origine Page 31
NL/BE Vertaling van de originele gebruiksaanwijzing Pagina 49
CZ Překlad originálního provozního návodu Strana 65
PL Tłumaczenie oryginalnej instrukcji obsługi Strona 81
SK Preklad originálneho návodu na obsluhu Strana 97
ES Traducción del manual de instrucciones original Página 111
DK Oversættelse af den originale driftsvejledning Side 127
IT Traduzione delle istruzioni d’uso originali Pagina 141
HU Az originál használati utasítás fordítása Oldal 157
Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of the
device.
Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich anschließend
mit allen Funktionen des Gerätes vertraut.
Avant de lire le mode d’emploi, ouvrez les deux pages contenant les illustrations et familiarisez-vous ensui-
te avec toutes les fonctions de l’appareil.
Vouw vóór het lezen de beide pagina‘s met de afbeeldingen open en maak u vertrouwd met alle functies
van het apparaat.
Před čtením si odklopte obě dvě strany s obrázky a potom se seznamte se všemi funkcemi přístroje.
Przed przeczytaniem proszę rozłożyć obie strony z ilustracjami, a następnie proszę zapoznać się z
wszystkimi funkcjami urządzenia.
Pred čítaním si odklopte obidve strany s obrázkami a potom sa oboznámte so všetkými funkciami prístroja.
Antes de empezar a leer abra las dos páginas que contienen las imágenes y, en seguida, familiarícese
con todas las funciones del dispositivo.
Før du læser, vend begge sidene med billeder frem og bliv bekendt med alle apparatets funktioner.
Prima di leggere aprire le due pagine con le immagini e prendere confidenza con le diverse funzioni
dell‘apparecchio.
Olvasás előtt kattintson az ábrákat tartalmazó mindkét oldalra és végezetül ismerje meg a készülék
mindegyik funkcióját.

AB
C

D E
F G
27a

H I
J
K
LM

All Parkside tools and the chargers PLG20A1/A4/C1/A2/C2/A3/C3/PDSLG20A1/
PLGS2012A1 of the X20V Team series are compatible with the PAP 20 A1/A2/A3/B1/B3/
PAPS 204 A1/PAPS 208 A1 battery pack.
Alle Parkside Geräte und die Ladegeräte PLG20A1/A4/C1/A2/C2/A3/C3/PDSLG20A1/
PLGS2012A1 der X20V Team Serie sind mit dem Akku-Pack PAP 20 A1/A2/A3/B1/B3/
PAPS204 A1/PAPS 208 A1 kompatibel.
Tous les outils Parkside et les chargeurs PLG20A1/A4/C1/A2/C2/A3/C3/PDSLG20A1/
PLGS2012A1 de la série X20V Team sont compatibles avec la batterie PAP 20 A1/A2/A3/
B1/B3/PAPS 204 A1/PAPS 208 A1.
Charging times
Ladezeiten
Temps de charge
Charging currents
Ladeströme
Courants de charge
max. 2,4 A
Charger
Ladegerät
Chargeur
PLG 20 A1/A4/C1
max. 3,5 A
Charger
Ladegerät
Chargeur
PLG 20 A2/C2
max. 4,5 A
Charger
Ladegerät
Chargeur
PLG 20 A3/C3
max. 4,5 A
Charger
Ladegerät
Chargeur
PDSLG 20 A1
max. 12,0 A
Charger
Ladegerät
Chargeur
PLGS 2012 A1
2 Ah PAP 20 A1/B1
Battery pack · Akku ·
Batterie
60 min
2,4 A
45 min
3,5 A
35 min
3,8 A
35 min
3,8 A
35 min
3,8 A
3 Ah PAP 20 A2
Battery pack · Akku ·
Batterie
90 min
2,4 A
60 min
3,5 A
45 min
4,5 A
45 min
4,5 A
32 min
5,3 A
4 Ah PAP 20 A3/B3
Battery pack · Akku ·
Batterie
120 min
2,4 A
80 min
3,5 A
60 min
4,5 A
60 min
4,5 A
35 min
7,8 A
4 Ah PAPS 204 A1
Battery pack · Akku ·
Batterie
120 min
2,4 A
80 min
3,5 A
50 min
4,5 A
50 min
4,5 A
35 min
6,0 A
8 Ah PAPS 208 A1
Battery pack · Akku ·
Batterie
210 min
2,4 A
165 min
3,5 A
120 min
4,5 A
120 min
4,5 A
45 min
12,0 A

PFDFA 20-Li A1 GB│IE │ 1 ■
Contents
Introduction............................................................ 2
Intended use........................................................................2
Features ...........................................................................2
Package contents ....................................................................3
Technical data ......................................................................3
General power tool safety warnings .......................................4
1. Work area safety..................................................................4
2. Electrical safety ...................................................................4
3. Personal safety....................................................................4
4. Power tool use and care ............................................................5
5. Use and handling of the cordless electrical power tool.....................................5
6. Service ..........................................................................5
Safety instructions for biscuit joiners......................................................6
Safety guidelines for battery chargers ....................................................6
Before use ............................................................. 6
Charging the battery pack (seefig.A)....................................................6
Attaching/disconnecting the battery pack to/from the appliance (see fig. L) ......................7
Checking the battery charge level .......................................................7
Installing the dust extraction system ......................................................7
Setting the biscuit groove size (seefig. C) .................................................8
Setting the biscuit groove depth (seefig.C)................................................8
Angle setting (see fig.E)...............................................................8
Height stop.........................................................................8
Changing the saw disc (see fig.F).......................................................9
Getting started .........................................................9
Switching on/off.....................................................................9
Working procedures..................................................................9
Maintenance and cleaning...............................................10
Changing the carbon brushes .........................................................10
Disposal..............................................................10
Kompernass Handels GmbH warranty ....................................11
Service ...............................................................12
Importer .............................................................12
Original declaration of conformity ........................................13
Ordering a replacement battery and charger ...............................14

PFDFA 20-Li A1
■ 2 │ GB│IE
CORDLESS BISCUIT JOINTER
20V PFDFA 20-Li A1
Introduction
Congratulations on the purchase of your new appli-
ance. You have selected a high-quality product.
The operating instructions are part of this product.
They contain important information about safety,
usage and disposal. Before using the product,
please familiarise yourself with all operating and
safety instructions. Use the product only as de-
scribed and for the specified range of applications.
Please also pass on all documents to any future
owner.
Intended use
This appliance is designed for cutting semicircular
slots for biscuit joints in wood.
Any other usage or modification of the appliance
is deemed to be improper and carries a significant
risk of accidents. The manufacturer accepts no
responsibility for damage resulting from improper
use. The appliance is not intended for commercial
use.
Explanation of the symbols used
Before using the tool for the first time,
read the original operating instructions
and safety instructions.
Wear protective goggles!
Wear ear muffs!
Wear protective gloves!
Wear a dust mask!
Features
1Additional handle
2 Carbon brush cover
3 Blade guard
4 Angle stop
5 Battery pack*
6 Battery display LED
7 Battery charge level button
8 High-speed charger*
9 Red control LED
0 Green control LED
q Face spanner
w Adapter for external extraction
e Extraction nozzle
r Spring clip
t Dust bag
z Zip on the dust bag
u Depth adjustment screw
i Depth adjustment
o Scale window
p Height adjustment knob
a Height stop
s Height stop lock
d Angle stop screw
f Spindle lock
g Angle scale
h Flange
j Saw disc
27a Direction of rotation arrow
k Screws
l Chip ejector
y ON/OFF switch
x Release button
c Groove marking

PFDFA 20-Li A1 GB│IE │ 3 ■
Package contents
1 cordless biscuit jointer 20V
1 additional handle (pre-assembled)
1 saw disc (pre-assembled)
1 extraction nozzle
1 adapter for external extraction
1 dust bag
1 face spanner
1 height stop
1 set of operating instructions
Technical data
Cordless Biscuit Jointer 20V PFDFA 20-Li A1
Rated voltage 20 V (DC)
Rated speed n0= 6500 rpm
Disc size Ø 100mm
Thread size M10
Max. milling depth 20 mm
Battery PAP 20 B3*
Type LITHIUM ION
Rated voltage 20 V (DC)
Capacity 4 Ah
Cells 10
High-speed battery charger PLG 20 C3*
INPUT
Rated voltage 230–240 V ∼ 50 Hz
(AC)
Rated power
consumption 120 W
Fuse (internal) 3.15 A
T3.15A
OUTPUT
Rated voltage 21.5 V (DC)
Rated current 4.5 A
Charging time approx. 60 minutes
Protection class II/ (double insulation)
* BATTERY AND CHARGER ARE NOT SUPPLIED
Noise and vibration data
Noise measurement value determined in accord-
ance with EN60745. The A-rated noise level
of the power tool is typically:
Noise emission value
Sound pressure level LPA = 74.7 dB
Uncertainty K = 3 dB
Sound power level LWA = 85.7 dB
Uncertainty K = 3 dB
Wear ear muffs!
Total vibration value
Surface grinding,
main handle ah< 2.5 m/s2
Uncertainty K = 1.5 m/s2
Surface grinding,
additional handle ah< 2.5 m/s2
Uncertainty K = 1.5 m/s2
NOTE
► The vibration emission value given in the in-
structions has been measured in accordance
with a standardised test procedure and can
be used for comparison of the power tool
with another tool. The specified vibration
emission value can also be used to make an
initial exposure estimate.
WARNING!
► The vibration emission value may differ from
the stated value during the actual use of the
power tool, depending on the manner in
which the power tool is being used. Try to
establish safety measures to protect the oper-
ator based on an estimation of the exposure
during actual use (wherein all states of opera-
tion must be included, e.g. times when the
power tool is switched off and times where
the power tool is switched on but running
without load).

PFDFA 20-Li A1
■ 4 │ GB│IE
General power tool
safety warnings
WARNING!
► Read all safety warnings and all instructions.
Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious
injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1. Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmos-
pheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control of the appliance.
2. Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d)
Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b)
Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate condi-
tions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools
with your finger on the switch or energising
power tools that have the switch on invites acci-
dents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewel-
lery or long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.

PFDFA 20-Li A1 GB│IE │ 5 ■
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is danger-
ous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children. Do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have
the power tool repaired before use. Many
accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits,
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
5. Use and handling of the cordless
electrical power tool
a) Charge rechargeable batteries only in
chargers recommended by the manufacturer.
Chargers are often designed for a particular
type of rechargeable battery unit. There is the
danger of fire if other types of rechargeable
battery units are used.
b) Only the rechargeable battery units supplied
are to be used with an electrical power tool.
The use of other rechargeable battery units may
lead to the danger of injury or fire.
c) When they are not being used, store re-
chargeable battery units away from paper-
clips, coins, keys, nails, screws or other small
metal objects that could cause the contacts to
be bridged. Short-circuiting the contacts of a
rechargeable battery unit may result in heat
damage or fire.
d) Fluids may leak out of rechargeable battery
units if they are misused. If this happens,
avoid contact with the fluid. If contact occurs,
flush the affected area with water. Seek addi-
tional medical help if any of the fluid gets into
your eyes. Escaping battery fluid may cause
skin irritation or burns.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable
batteries.
Protect the recharge-
able battery from heat (for example, from
continuous exposure to sunlight), fire, water
and moisture. There is a risk of explosion.
6. Service
a) Have your power tool serviced by a qualified
repair person using only identical replace-
ment parts. This will ensure that the safety of
the power tool is maintained.
b) Never try to repair damaged batteries.
Batteries should only be maintained by the
manufacturer or an approved customer service
centre.

PFDFA 20-Li A1
■ 6 │ GB│IE
Safety instructions for biscuit joiners
■Disc milling cutters must be designed at least
for the speed indicated on the power tool.
Disc cutters running at excessive speed can fly
apart and cause injuries.
■Always use the blade guard.
A blade guard protects the user against parts of
the milling disc which have broken off and also
against unintentional contact with the disc.
■ Always wear a dust mask when using the appli-
ance!
■ Do not use blunt or damaged disc milling
blades!
■ Check that the blade guard return system works
correctly before every use!
Safety guidelines for battery chargers
■ This appliance may be used by
children aged 8 years and
above and by persons with limited
physical, sensory or mental
capabilities or lack of experience
and knowledge, provided that
they are under supervision or
have been told how to use the
appliance safely and are aware
of the potential risks. Do not allow
children to play with the appli-
ance. Cleaning and user mainte-
nance tasks may not be carried
out by children unless they are
supervised.
■ To avoid potential risks, damaged
power cables should be replaced
by the manufacturer, their customer
service department or a similarly
qualified person.
The charger is suitable for indoor use only.
WARNING!
■ To avoid potential risks, damaged power
cables should be replaced by the manufactur-
er, their customer service department or a
similarly qualified person.
ATTENTION!
♦ This charger can only charge the following
batteries: PAP20A1/PAP20A2/
PAP20A3/PAP20B1/PAP20B3/
PAPS204A1/PAPS208A1.
WARNING!
Always wear safety goggles.
WARNING!
Always wear a dust mask.
Before use
Charging the battery pack
(seefig.A)
CAUTION!
► Always disconnect the mains plug before re-
moving the battery pack 5from or inserting
it into the charger.
NOTE
► Never charge the battery pack if the ambient
temperature is below 10°C or above 40°C.
If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level
is between 50% and 80%. The storage climate
should be cool and dry and the ambient tem-
perature should be between 0°C and 50°C.
♦ Insert the battery pack5into the high-speed
charger8.
♦ Plug the mains plug into the mains power
socket. The red control LED 9lights up

PFDFA 20-Li A1 GB│IE │ 7 ■
♦ The green control LED0indicates that the
charging process is complete and the battery
pack 5is ready for use.
ATTENTION!
♦ If the red control LED9flashes, this means
that the battery pack5has overheated and
cannot be charged.
♦ If the red and green control LEDs90both
flash, this means that the battery pack5is
defective.
♦ Switch off the charger for at least 15 minutes
between successive charging sessions. Also
disconnect the power plug from the mains pow-
er socket.
Attaching/disconnecting the
battery pack to/from the appli-
ance (see fig. L)
Inserting the battery pack
♦ Snap the battery pack5into the handle.
Removing the battery pack
♦ Press the release buttonxand remove the
battery pack5.
Checking the battery charge level
♦ To check the battery status, press the battery
charge level button7. The status/remaining
charge is shown on the battery display LED 6
as follows:
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Installing the dust extraction system
Dust from materials such as lead-based paints,
some types of wood, minerals and metal can be
harmful to health. Touching or inhaling the dusts
may cause allergic reactions and/or respiratory
illnesses of the user or people in the vicinity. Certain
dusts such as oak or beech dust are considered
carcinogenic, especially in combination with wood
treatment additives (chromate, wood preservatives).
Materials containing asbestos may only be worked
on by specialists.
■ Always use dust extraction.
■ Ensure that your workplace is adequately
ventilated.
■ We recommend you wear a respirator with a
class P2 filter.
Follow the regulations that apply in your country
regarding the materials to be worked.
NOTE
► When working with wood or materials that
produce dust that is hazardous to health, the
device must be connected to a suitable, test-
ed extraction device (e.g. in accordance with
dust
class M as per EN60335-2-69).
Connecting an external extraction system
♦ Attach the extraction nozzleefirmly onto
the chip ejectorl.
♦ Attach the adapter for external extraction w
firmly onto the matching opening of the extrac-
tion nozzle e.
♦ Push the hose of a suitable workshop vacuum
cleaner onto the adapter for external extrac-
tion w.
♦ To dismantle, proceed in reverse order.
Fitting the dust bag
♦ Put the appropriate end of the extraction
nozzle e onto the chip ejector l.
♦ Use two fingers to press the spring clipr
on the opening of the dust bag together.
♦ Push the opening of the dust bag over the other
end of the extraction nozzlee.
♦ Let go of the spring clipr.
♦ To dismantle, proceed in reverse order.
Emptying the dust bag
To ensure optimum dust extraction, empty the
dust bag tregularly.
♦ Open the zip on the dust bag z.
♦ Shake out the dust bagtover a suitable
waste container.

PFDFA 20-Li A1
■ 8 │ GB│IE
Setting the biscuit groove size
(seefig. C)
The appliance can cut biscuit grooves in six sizes.
To do this, use the depth adjustmenti.
Setting Biscuit type Cutting depth
0 No. 0 approx. 8 mm
10 No. 10 approx. 10 mm
20 No. 20 approx. 12.3 mm
S Simplex approx. 13 mm
D Duplex approx. 14.7 mm
Max. ‒ approx. 20 mm
♦ Turn the depth adjustmentiuntil the desired
biscuit groove size is set on the ▼ marking on
the upper side.
Setting the biscuit groove depth
(seefig.C)
You can adjust the depth of the biscuit groove if the
depth of the biscuit groove does not correspond
with the size of the biscuit you are using.
♦ Turn the depth adjustment screw uwith a
Phillips screwdriver (not supplied):
clockwise: reduce cutting depth
anticlockwise: increase
♦ Carry out a test on some scrap material to
check that the setting is correct.
Angle setting (see fig.E)
The angle stop4is adjustable to cut slots with
different angles.
♦ Loosen the angle stop screwdby turning it
anticlockwise.
♦ Set the desired angle using the angle scaleg
and the ▼ marking above it.
♦ Re-tighten the angle stop screwdby turning it
clockwise.
Height stop
The height stopais fitted in front of the angle
stop4. The height stop can be adjusted to match
the thickness of the workpiece.
Fit the height stop (see fig. D)
♦ Undo the height stop locks.
♦ Align the lower part of the height stopawith
the upper side of the angle stop4. Press the
height stopadownwards. The gear wheel on
the back of the height adjustment knobpmust
engage in the grooves of the angle stop4.
♦ Turn the height adjustment knobpin both
directions to test whether the height stopa
can move in both directions.
CAUTION!
► If you use the angle stop4and the height
stopaat the same time, make sure that the
saw discjdoes not come into contact with
the height stopa!
Adjusting the height stop
♦ Undo the height stop locks. Turn the height
adjustment knobpuntil you reach the desired
setting.
♦ The values in the scale windowsoserve as
reference value. The set height is shown by the
► marking.
♦ After you have set the height, retighten the
height stop locks.
Removing the height stop
♦ Undo the height stop locks.
♦ Turn the height adjustment knobpclockwise
until you reach the highest setting and you can
remove the height stopa.

PFDFA 20-Li A1 GB│IE │ 9 ■
Changing the saw disc (see fig.F)
WARNING! RISK OF INJURY! Always
switch the appliance off and remove
the battery before carrying out any
work on the appliance.
♦ Set up the appliance so that the rear side of
the blade guard3is facing towards you.
♦ Undo the screwkon the rear of the blade
guard3using a Phillips screwdriver (not
supplied; see fig.G).
♦ Pull the blade guard forwards off the appliance.
♦ Press the spindle lockfand keep it pressed.
Check whether the saw discjstill turns. If yes,
turn the saw discjuntil the spindle lockf
clicks into place.
♦ Insert the face spannerqinto the corresponding
holes on the flangeh. Undo the flangehusing
the face spannerqby turning it in the direction
indicated by the arrows on the saw discjand
the appliance.
♦ Remove the flangehand the saw discjfrom
the spindle.
♦ Insert the new saw disc and check that the
direction of rotation is correct using the arrows
on the disc and device (direction of rotation
arrow27a).To reassemble, proceed in reverse
order.
■ Before use, check to ensure that the blade
guard3closes properly. When the saw
discjretracts from a cut, it must retract
completely into the blade guard 3.
■ Always carry out a test run without load before
starting work and after replacing an accessory
tool. Switch off the product immediately if the
accessory tool runs unevenly, if there is a signifi-
cant vibration or if you hear unusual noises.
Getting started
WARNING!
■ Never activate the spindle lockfwhile the
saw discjis still turning.
■ Before use, check to ensure that the blade
guard3closes properly. When the saw
discjretracts from a cut, it must retract
completely into the blade guard 3.
■ Keep your hands out of the sawing area and
away from the saw disc jwhile the appli-
ance is switched on!
Switching on/off
Switching on
♦ Push the ON/OFF switch yforwards until it
clicks into place.
Switching off
♦ Press the rear part of the ON/OFF switchy.
Working procedures
♦ Always use both hands to hold the appliance
while you are working. Use the additional
handle1to have optimum control over the
appliance.
♦ Make sure that you apply an even force to
saw even slots.
♦ Do not apply the running saw disc jto the
workpiece until the appliance has reached full
speed. Otherwise, this could cause a kickback.
♦ Select a biscuit that is appropriate to the materi-
al thickness. Choose the largest one possible to
ensure optimal stability. You can also use sever-
al biscuits on top of each other.
♦ Mark the centre of the groove that you want to
mill on the workpiece with a pencil (not supplied).
Apply the appliance with the groove marking c
at the marked position (see fig. M).

PFDFA 20-Li A1
■ 10 │ GB│IE
♦ You can see examples of the grooves you can
mill for different connections on the fold-out
page:
–Fig. H: Butt joint with angle stop4
–Fig. I: Butt joint with height stopa
–Fig. J: Frame connection with angle stop4
–fig. K: T-connection with angle stop4
Maintenance and cleaning
WARNING! RISK OF INJURY! Always
switch the appliance off and remove
the battery before carrying out any
work on the appliance.
■ Do not use any sharp objects to clean the
appliance. Do not allow any liquids to get
into the appliance. Otherwise the appliance
could be damaged.
■ Clean the appliance regularly, preferably imme-
diately after use.
■ Clean the housing with a dry cloth – do not use
petrol, solvents or cleaners which can attack the
plastic.
■ A vacuum cleaner is required for thorough
cleaning of the appliance.
■ Ventilation openings must never be obstructed.
■ Remove any grinding dust stuck to the tool with
a brush.
NOTE
► Replacement parts not listed (such as carbon
brushes, saw discs) can be ordered via our
Service Hotline.
WARNING!
■ Do not use any accessories that are not
recommended by PARKSIDE. This can
lead to electric shock and fire.
Changing the carbon brushes
♦ Use a flat-head screwdriver to open the carbon
brush covers 2on each side of the appliance
to replace worn carbon brushes.
Disposal
Applies only to France
The product, its packaging and the operating in-
structions are recyclable. They are subject to an
extended manufacturer responsibility and will be
collected separately.
Do not dispose of power tools
in your normal domestic waste!
The adjacent symbol of a crossed-out
dustbin means that this appliance is
subject to Directive 2012/19/EU. This directive
states that this appliance may not be disposed of in
the normal household waste at the end of its useful
life, but must be taken to specially set-up collection
locations, recycling depots or disposal companies.
The disposal is free of charge for the user.
Protect the environment and dispose of this
appliance properly.
If your old appliance has stored any personal data,
you are responsible for deleting it yourself before
returning it.
If it is possible to do so without destroying the old
appliance, remove the old batteries or rechargea-
ble batteries before returning the appliance for
disposal and take them to a separate collection
point. In the case of permanently installed
rechargeable batteries, you must indicate during
disposal that the appliance contains a battery.

PFDFA 20-Li A1 GB│IE │ 11 ■
Your local community or municipal
authorities can provide information on
how to dispose of the worn-out product.
Do not dispose of batteries in
your normal household waste!
Defective or worn-out rechargeable
batteries must be recycled according to
Directive 2006/66/EC. Batteries/rechargeable
batteries must be treated as hazardous waste and
must therefore be disposed of in an environmentally
sound manner by appropriate bodies (dealers,
specialist dealers, public municipal bodies, com-
mercial disposal companies). Batteries/recharge-
able batteries may contain toxic heavy metals.
For this reason, do not dispose of batteries/
rechargeable batteries in domestic waste. Take
them to a specialist collection point. Only return
batteries that are fully discharged.
The packaging is made from environ-
mentally friendly material and can be
disposed of at your local recycling plant.
Dispose of the packaging in an
environmentally friendly manner.
Note the labelling on the packaging
and separate the packaging material
components for disposal if necessary. The packag-
ing material is labelled with abbreviations (a) and
numbers (b) with the following meanings:
1–7: plastics, 20–22: paper and cardboard,
80–98: composites.
Kompernass Handels GmbH
warranty
Dear Customer,
This appliance has a 3-year warranty valid from
the date of purchase. If included with the product
on delivery, the battery packs of the X12V and
X20V Team series also come with a 3-year warranty
from the date of purchase. If this product has any
faults, you, the buyer, have certain statutory rights.
Your statutory rights are not restricted in any way
by the warranty described below.
Warranty conditions
The warranty period starts on the date of purchase.
Please keep your receipt in a safe place. This will
be required as proof of purchase.
If any material or manufacturing fault occurs within
three years of the date of purchase of the product,
we will either repair or replace the product for you
or refund the purchase price (at our discretion).
This warranty service requires that you present the
defective appliance and the proof of purchase (re-
ceipt) within the three-year warranty period, along
with a brief written description of the fault and of
when it occurred.
If the defect is covered by the warranty, your prod-
uct will either be repaired or replaced by us. The
repair or replacement of a product does not signify
the beginning of a new warranty period.
Warranty period and statutory claims
fordefects
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must
be reported immediately after unpacking. Repairs
carried out after expiry of the warranty period shall
be subject to a fee.

PFDFA 20-Li A1
■ 12 │ GB│IE
Scope of the warranty
This appliance has been manufactured in accord-
ance with strict quality guidelines and inspected
meticulously prior to delivery.
The warranty covers material faults or production
faults. The warranty does not cover product parts
that are subject to normal wear and tear and can
therefore be considered wearing parts, such as saw
blades, replacement blades, abrasive papers, etc.
or for damage to fragile parts, such as switches or
parts made of glass.
The warranty does not apply if the product has
been damaged, improperly used or improperly
maintained. The directions in the operating instruc-
tions for the product regarding proper use of the
product are to be strictly followed. Uses and actions
that are discouraged in the operating instructions
or which are warned against must be avoided.
This product is intended solely for private use and
not for commercial purposes. The warranty shall
be deemed void in cases of misuse or improper
handling, use of force and modifications/repairs
which have not been carried out by one of our
authorised Service centres.
The warranty does not apply to
■ Normal reduction of the battery capacity
overtime
■ Commercial use of the product
■ Damage to or alteration of the product by the
customer
■ Non-compliance with safety and maintenance
instructions, operating errors
■ Damage caused by natural hazards
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
■ Please have the till receipt and the item number
(IAN)438488_2304 available as proof of
purchase.
■ You will find the item number on the type plate
on the product, an engraving on the product,
on the front page of the operating instructions
(below left) or on the sticker on the rear or
bottom of the product.
■ If functional or other defects occur, please
contact the service department listed either by
telephone or by e-mail.
■ You can return a defective product to us free of
charge to the service address that will be pro-
vided to you. Ensure that you enclose the proof
of purchase (till receipt) and information about
what the defect is and when it occurred.
You can download these instructions
along with many other manuals,
product videos and installation
software at www.lidl-service.com.
This QR code will take you directly to the Lidl
service page (www.lidl-service.com) where you
can open your operating instructions by entering
the item number (IAN) 438488_2304.
Service
Service Great Britain
Tel.: [phone]
E-Mail: kom[email protected]
Service Ireland
Tel.: [phone]
E-Mail: kom[email protected]
IAN 438488_2304
Importer
Please note that the following address is not the
service address. Please use the service address
provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

PFDFA 20-Li A1 GB│IE │ 13 ■
Original declaration of conformity
We, KOMPERNASS HANDELS GMBH, document officer: Mr Semi Uguzlu, BURGSTR. 21,
44867 BOCHUM, GERMANY, hereby declare that this product complies with the following
standards, normative documents and EC directives:
Machinery Directive (2006/42/EC)
Electromagnetic Compatibility (2014/30/EU)
RoHS Directive (2011/65/EU)*
* The manufacturer bears the sole responsibility for compliance with this conformity declaration. The subject of the
declaration described above meets the requirements of Directive 2011/65/EU of the European Parliament and
Council of 8 June 2011 on the limitations of use of certain dangerous substances in electrical and electronic tools.
Related harmonised standards
EN 60745-1:2009/A11:2010
EN 60745-2-19:2009/A1:2010
EN IEC 55014-1:2021
EN IEC 55014-2:2021
EN IEC 63000:2018
Type designation of the machine: Cordless Biscuit Jointer 20V PFDFA 20-Li A1
Year of manufacture: 09–2023
Serial number: IAN 438488_2304
Bochum, 20/06/2023
Semi Uguzlu
- Quality Manager -
We reserve the right to make technical changes in the context of further product development.

PFDFA 20-Li A1
■ 14 │ GB│IE
Ordering a replacement battery and charger
You can easily order a replacement battery or charger on the Internet at www.kompernass.com.
♦ Scan the QR code with your smartphone/tablet.
You can use this QR code to go directly to our website to view and order the available replacement
parts.
NOTE
► If you have problems with your online order, you can contact our service centre by phone or email.
► Always quote the article number (IAN)438488_2304 in your order.
► Please note that online ordering of replacement parts is not possible for all countries.
*The following articles can be ordered at www.Lidl.de or from www.grizzlytools.shop.
