Table of contents
Introduction
Proper use ............................................................................... Page 6
Features and equipment......................................................... Page 6
Included items......................................................................... Page 7
Technical information ............................................................. Page 7
Safety advice
1. Workplace safety............................................................... Page 8
2. Electrical safety .................................................................. Page 8
3. Personal safety ................................................................... Page 9
4. Careful handling and use of electrical power tools........ Pag e 11
Original accessories/attachments....................................... Pa ge 11
Before first use
Fitting the helical spring ......................................................... Page 12
Inserting/replacing soldering tips........................................ Page 12
Operation
Switching on and off .............................................................. Page 13
Third hand ............................................................................... Page 13
Solder sponge......................................................................... Page 13
Soldering................................................................................. Page 14
Maintenance and cleaning.................................. Page 15
Service centre ................................................................. Page 16
Warranty ............................................................................ Page 16
Disposal................................................................................ Page 17
Declaration of Conformity/
Manufacturer.................................................................. Page 18

6 GB/IE
IntroductionIntroduction
Fine soldering iron set PLBS 30 A1
Q Introduction
We congratulate you on the purchase of your new device. You have
chosen a high quality product. The instructions for use are part of the
product. They contain important information concerning safety, use
and disposal. Before using the product, please familiarise yourself with
all of the safety information and instructions for use. Only use the unit as
described and for the specified applications. If you pass the product on
to anyone else, please ensure that you also pass on all the documen-
tation with it.
Q Proper use
The appliance is intended for electronic soldering for leisure and DIY
purposes. It is designed for uses such as soldering work, wood-engrav-
ing, welding and gluing plastics and the application of decorations.
Use the device only as described and for the indicated purposes. The
device is not intended for commercial use. Any other use or modifica-
tion to the device shall be considered as improper use and could give
rise to considerable dangers. The manufacturer will not accept liability
for loss or damage arising from improper use.
Q Features and equipment
1Soldering pencil
2Soldering tip

7GB/IE
IntroductionIntroduction
3Helical spring
4Clips
5Third hand
6Holder for copper attachments
7Multifunctional holder
8Soldering sponge
9Universal attachment
10 Pointed attachment
11 Conical attachment
12 Tin solder
Q Included items
1 Fine soldering iron set PLBS 30 A1
1 Multifunctional holder
2 Rolls of soldering tin (10 grams each)
2 Soldering tips (1x installed)
4 Copper attachments (engraving tips)
1 Solder sponge
1 Operating instructions
Q Technical information
Electricity supply: 230V AC
Nominal frequency: 50Hz
Rated power: 30W

8 GB/IE
Q Safety advice
CAUTION! Failure to observe the instructions and
advice given below may result in electric shock, fire
and/ or serious injury.
1. Workplace safety
a) Keep your working area clean and well lit. Untidy or
poorly lit working areas can lead to accidents.
b) Do not work with the device in potentially explosive
environments in which there are inflammable liq-
uids, gases or dusts. Electrical power tools create sparks,
which can ignite dusts or fumes.
c) Keep children and other people away while you are
operating the electrical tool. Distractions can cause you to
lose control of the device.
2. Electrical safety
To avoid danger to life from electric shock:
a)
The mains plug on the device must match the mains
socket. The plug must not be modified in any way.
Do not use an adapter plug with devices fitted with
a protective earth. Unmodified plugs and matching sockets
reduce the risk of electric shock.
b) Keep the device away from rain or moisture. Water
entering an electrical device increases the risk of electric shock.
Safety adviceSafety advice

9GB/IE
c) Use a residual current device (RCD) for protection if
operating the electrical power tool in a moist envi-
ronment is unavoidable. The use of an RCD reduces the risk
of electric shock.
d) Do not use the mains lead for any purpose for which
it was not intended, e.g. to carry the device, to hang
up the device or to pull the mains plug out of the
mains socket. Keep the mains lead away from heat,
oil, sharp edges or moving parts of the device. Dam-
aged or tangled mains leads increase the risk of electric shock.
e) D
o not operate the device if the mains lead or mains plug is damaged.
A damaged mains lead presents a serious
danger to life from electric shock.
f) Always keep the mains lead out of the operating area and run it
away from the rear of the device.
g) Always pull out the mains plug if you are about to leave the device
unattended or wish to carry out any tasks on the device.
3. Personal safety
a) Children or persons who lack the knowledge or ex-
perience to use the device or whose physical, sensory
or
intellectual capacities are limited must never be al-
lowed to use the device without supervision or in-
struction by a person responsible for their safety.
Children must never be allowed to play with the device.
b) Remain alert at all times, watch what you are doing
and always proceed with caution. Do not use the
device if you are tired or under the influence of drugs,
alcohol or medication. One moment of carelessness when
using the device can lead to serious injury.
Safety adviceSafety advice

10 GB/IE
DANGER OF BURNS! Never touch the hot soldering tip or the
molten solder. You could suffer burn injuries. Always let the device
cool before you replace components on the device, clean it or check
its condition.
After use let the soldering pencil cool down in air only. Under no
circumstances quench the tip in water!
CAUTION! DANGER OF FIRE! Place the soldering pencil
down only in the special multifunctional holder or on a fire-re-
sistant pad.
Place the soldering pencil in the multifunctional holder during
pauses in your work.
Keep the device away from combustible material.
Never leave the device switched on and unattended.
CAUTION! DANGER OF INJURY! Keep your hands away
from the hot workpiece. The heat from soldering can be conducted
through the workpiece. For this reason you should use the third
hand to hold small workpieces.
Avoid placing the hot soldering tip in contact with the plastic parts
of the multifunctional holder. Failure to observe this advice may
result in damage to the device.
If a dangerous situation arises, pull the mains plug immediately
out of the mains socket.
CAUTION! DANGER OF POISONING! Do not breathe air
contaminated with soldering fumes.
When working with the device for long periods do not allow the
fumes from soldering to build up. They may be hazardous to
health. Always provide adequate ventilation of your working area.
In addition, it is recommended
that you wear protective gloves, a
face mask and a protective
apron.
Do not eat, drink or smoke in rooms where soldering is carried
out. Otherwise your hands may transfer any adhering traces of
lead via food or cigarettes into your body.
Safety adviceSafety advice

11GB/IE
Always wash your hands immediately after soldering .
Do not dispose of soldering waste with the household rubbish.
Soldering waste must disposed of as special waste.
4. Careful handling and use
of electrical power tools
a) When not in use always ensure that electrical power
tools are kept out of reach of children. Do not let any-
one use the device if he or she is not familiar with it
or has not read the instructions and advice. Electrical
power tools are dangerous when they are used by inexperienced
people.
b) Look after the device carefully. Check for broken
parts or parts that are damaged to the extent they
detrimentally affect the functioning of the device.
Have any damaged parts repaired before you use
the device. Many accidents have their origins in poorly main-
tained electrical tools.
Q Original accessories/attachments
Use only the accessories detailed in the operating instructions. The
use of attachments or accessories other than those recommended
here could lead to you suffering an injury.
Safety adviceSafety advice

12 GB/IE
Q Before first use
Q Fitting the helical spring
Insert the narrower end of the helical spring 3into the opening
of the multifunctional holder 7.
Ensure that the outwardly bent end of the helix points upwards
and insert it into the recess provided for it in the multifunctional
holder 7(see arrow in Fig. B).
Push the helical spring 3into the opening as far as it will go.
Turn the helical spring 3clockwise to fix the multifunctional
holder 7in place.
Q Inserting/replacing soldering tips
CAUTION! DANGER OF BURNS! Allow the soldering pencil to
heat up without a soldering tip.
Removal of a soldering tip 2or a copper attachment 910 11
may only be done when the appliance has been switched off and
the soldering tip or attachment has cooled down.
All soldering tips and attachments have a screw thread and can,
therefore, be easily and quickly replaced on the soldering pencil 1.
Turn the soldering tip or attachment anti-clockwise to remove it.
Turn the soldering tip or attachment clockwise to fix it in place.
OperationBefore first use

13GB/IE
Q Operation
Q Switching on and off
Switching on:
Insert the mains plug into a suitable mains socket.
Switching off:
Pull the plug out of the mains socket to switch off the device.
Q Third hand
CAUTION! DANGER OF BURNS! The clips on the third hand 5
can become hot while you are soldering the workpiece.
1. Fold out the third hand 5upwards.
2. Rotate the clips 4until they are oriented in the required direction.
3. Clamp the workpiece between the two clips 4.
Q Solder sponge
CAUTION! The hot soldering tip 2must never be placed in
contact with a dry solder sponge 8, otherwise the solder sponge
may be damaged.
The solder sponge 8is used to clean soldering tips.
Moisten the solder sponge 8before you use it.
OperationBefore first use

14 GB/IE
Soldering
If inhaled, vapours may cause headaches and fatigue as
well as other symptoms.
— The soldering pencil has a rated output of 30watts and is therefore
ideal for electronics soldering.
— The design of the soldering pencil makes it especially suitable for
use where access is difficult or for fine soldering work.
— To achieve the best results use electronics solder 1.0 or 1.5mm
diameter 60% Sn, 40 % Pb. We recommend the use of soldering
paste (not soldering grease or soldering fluid) as a flux.
Clean the soldering tip 2on the moist solder sponge 8.
After cleaning the tip 2it must be “tinned” (coated with solder).
This is done by melting solder on to the hot soldering tip 2.
Guide the soldering tip 2to the intended joint site and heat the joint.
Place the solder (with flux) between the joint site and the tip 2
to melt it.
Continue to feed further solder until the whole joint has a covering
of solder.
Then quickly remove the soldering tip in order to avoid overheating
the molten solder.
Allow the solder to harden while not subjecting it to vibration or
movement.
Note: The flux is either already contained in the solder or applied
separately. Ask the advice of the retailer when buying solder in or-
der to choose the most suitable solder for your intended purpose.
Attachments and applications:
ATTENTION! Do not carry out any special changes or repairs to the
electrics or other parts. Exceptions are permitted if the person carrying
out such changes or repairs is qualified or trained to do so.
Operation/Maintenance and cleaningOperation

15GB/IE
You can fashion and decorate various materials with your soldering
pencil. Remove the parts of the surface or engrave design elements
into it (see Fig. D).
You can carry out these decorations in, for example, wood, leather,
paper, papier mâché, smooth fabrics, thin plastics or candle wax.
Try every application out on surplus material and see if you get the effect
you wish to have. This means you will avoid damaging the item you
wish to work on.
Universal attachment 9:
E.g. for drawings with broad and thin lines on various materials
Pointed attachment 10 :
E.g. for details or shading in over large areas
Conical attachment 11 :
E.g. for dots, curves and handwriting, detailed work
Q Maintenance and cleaning
RISK OF INJURY! Before you carry out any
work on the device always pull the mains plug out of the mains socket
and allow the device to cool.
Clean the device after you have finished using it.
Use a cloth and a little mild detergent for cleaning the device.
In no circumstances use sharp objects, or petrol, solvents or clean-
ing agents that might attack plastic.
Do not allow any liquids to enter the inside of the device.
Operation/Maintenance and cleaningOperation

16 GB/IE
Q Service centre
Have your device repaired only by
qualified specialist personnel using original manu-
facturer parts only. This will ensure that your device remains
safe to use.
If the plug or mains lead needs to be
replaced, always have the replacement carried out
by the manufacturer or his service centre. This will ensure
that your device remains safe to use.
QWarranty
The warranty for this appliance is for 3 years from the
date of purchase. The appliance has been manufactured
with care and meticulously examined before delivery.
Please retain your receipt as proof of purchase. In the
event of a warranty claim, please make contact by tele-
phone with our Service Department. Only in this way can
a post-free despatch for your goods be assured.
The warranty covers only claims for material and maufacturing defects,
but not for transport damage, for wearing parts or for damage to frag-
ile components, e.g. buttons or batteries. This product is for private use
only and is not intended for commercial use.
The warranty is void in the case of abusive and improper handling, use
of force and internal tampering not carried out by our authorized ser-
vice branch. Your statutory rights are not restricted in any way by this
warranty.
Warranty/DisposalService centre/Warranty

17GB/IE
The warranty period will not be extended by repairs made unter war-
ranty. This applies also to replaced and repaired parts. Any damage
and defects extant on purchase must be reported immediately after un-
packing the appliance, at the latest, two days after the purchase date.
Repairs made after the expiration of the warranty period are subject to
payment.
GB
Service Great Britain
Tel.: [phone]
(0,10 GBP/Min.)
e-mail: [e-mail]
IAN 86586
IE
Service Ireland
Tel: [phone]
(0,08 EUR/Min. (peak)
0,06 EUR/Min. (off peak))
e-mail: [e-mail]
IAN 86586
Q Disposal
The packaging is wholly composed of environmentally-friendly
materials that can be disposed of at a local recycling centre.
Warranty/DisposalService centre/Warranty

18 GB/IE
Do not dispose of electrical devices
with the household rubbish!
In accordance with European Directive 2002/96/EC (covering
waste electrical and electronic equipment) and its transposition into
national legislation, worn out electrical devices must be collected
separately and taken for environmentally compatible recycling.
Contact your local refuse disposal authority for more details of how to
dispose of your worn-out devices.
Q Declaration of Conformity/Manufacturer
We, Kompernaß GmbH, the person responsible for documents:
Mr Semi Uguzlu, Burgstr. 21, D-44867 Bochum, Germany, hereby
declare that this product complies with the following standards, norma-
tive documents and EU directives:
EU Low Voltage Directive
(2006/95/EC)
Electromagnetic Compatibility
(2004/108/EC)
RoHS Directive
(2011/65 / EU)
Declaration of Conformity/ManufacturerDisposal/Declaration of Conformity/Manufacturer

19GB/IE
Applicable harmonized standards
EN 60335-2-45/A1:2008
EN 60335-1/A13:2008
EN 62233:2008
EN 55014-1/A1:2009
EN 55014-2/A2:2008
EN 61000-3-2/A2:2009
EN 61000-3-3:2008
Type/Device description:
Fine soldering iron set PLBS 30 A1
Date of manufacture (DOM): 01–2013
Serial number: IAN 86586
Bochum, 31.01.2013
Semi Uguzlu
- Quality Manager -
We reserve the right to make technical modifications in the course of
further development.
Declaration of Conformity/ManufacturerDisposal/Declaration of Conformity/Manufacturer

20
Sisällysluettelo
