Parrot MKi9100 User manual

Parrot MKi9100
User guide

Parrot MKi9100 –User guide
2
Contents
Contents........................................................................................................................... 2
Installation ....................................................................................................................... 4
Before you begin..................................................................................................................................................... 4
Checking the car configuration .................................................................................................................... 4
Caution......................................................................................................................................................... 4
Removing the car stereo.............................................................................................................................. 4
Installing the kit....................................................................................................................................................... 5
Car stereo with ISO connectors ................................................................................................................... 5
Car stereo with line-in.................................................................................................................................. 6
Installing the electronic box......................................................................................................................... 6
Installing the kit’s power cable .................................................................................................................... 7
Checking the wiring ..................................................................................................................................... 7
Installing the audio connectors.................................................................................................................... 7
Installing the individual components ...................................................................................................................... 8
Installing the double microphone................................................................................................................ 8
Installing the remote control ....................................................................................................................... 9
Installing the screen................................................................................................................................... 11
Getting started ............................................................................................................... 12
Navigating through the menus ............................................................................................................................. 12
Associating the remote control to the electronic box ............................................................................... 12
Icons........................................................................................................................................................... 13
Commands ................................................................................................................................................. 13
Using the vocal menus ............................................................................................................................... 13
Establishing a Bluetooth connection with a phone............................................................................................... 14
Using a phone with the Parrot MKi9100 for the first time ........................................................................ 14
Using the Parrot MKi9100 with 2 phones.................................................................................................. 15
Managing Bluetooth devices ..................................................................................................................... 16
Synchronizing the phonebook .............................................................................................................................. 17
Phone............................................................................................................................. 18
Making and receiving calls .................................................................................................................................... 18
Making a call .............................................................................................................................................. 18
Receiving a call........................................................................................................................................... 19
Using the Parrot MKi9100 while on a call.................................................................................................. 19
Using voice recognition......................................................................................................................................... 21
Receiving a call via voice recognition......................................................................................................... 21
Making a call via voice recognition ............................................................................................................ 21

Parrot MKi9100 –User guide
3
Music.............................................................................................................................. 23
Using the Parrot MKi9100 with an external source .............................................................................................. 23
Using the Parrot MKi9100 with an iPod / iPhone ...................................................................................... 23
Using the Parrot MKi9100 with a USB peripheral...................................................................................... 24
Using the Parrot MKi9100 with an audio player connected via Bluetooth ............................................... 24
Using the Parrot MKi9100 with an analogue audio player ........................................................................ 25
Commands ............................................................................................................................................................ 26
Settings .......................................................................................................................... 27
Brightness .................................................................................................................................................. 27
Ringtone..................................................................................................................................................... 27
Call ............................................................................................................................................................. 27
Activating the external noise elimination .................................................................................................. 28
Audio.......................................................................................................................................................... 29

Parrot MKi9100 –User guide
4
Installation
WARNING: We advise our customers to have the Parrot MKi9100 fitted by a professional.
Before you begin
Checking the car configuration
The cables supplied with the kit feature ISO connectors and two pairs of line-out jacks. The line-out
jacks can be used if your audio system features this option (use of an amplifier). Several set-ups are
therefore possible depending on the type of car stereo and your vehicle.
If your car stereo is not fitted with ISO connectors, you need to purchase an ISO adapter cable to
simplify the wiring procedure. Refer to the range of ISO adapters on our website.
Caution
Unplug the battery before installing the kit’s power cable.
Before you install the individual components, check that the installation locations have been
selected in such a way that the cable length is sufficient to connect every element.
Do not install any component (screen, remote control…) in the airbag deployment area.
Once the installation is complete, make sure that no cables are pinched or trapped.
Removing the car stereo
Remove your car stereo from you vehicle. You may need release keys to do so.
►Refer to your car stereo user guide or contact your car dealer for more information.
Remove the audio system from your vehicles dashboard to access the wiring harness.
The mute function is used to cut the sound of your car stereo to enable a phone call. The choice of
the mute-in jack depends on your car stereo’s configuration.

Parrot MKi9100 –User guide
5
Installing the kit
Note : If you have the possibility to use a multimeter, test and verify all connections on the vehicle before
connecting the Parrot MKi9100 wiring loom.
Car stereo with ISO connectors
1. Connect the male connectors of the hands-free kit to the car stereo.
2. Join the vehicle’s audio and power supply cables to the female connectors of the Parrot MKi9100.
3. On the installation cable, connect the free yellow wire to one of the audio system’s corresponding
mute-in jacks if available (mute in 1, mute in 2 or mute in 3).
Note : Mute in 1, mute in 2 and mute in 3 are only suggested mute locations. You first have to test and verify
the mute on the vehicle.

Parrot MKi9100 –User guide
6
Car stereo with line-in
Use this type of connection by wiring the line-out (brown & white wire or red & black wire) to your
car stereo’s line-in.
Using the two pairs of line-out will enable you to take advantage of the music function in stereo over
your vehicle’s speakers.
On the installation cable, connect the free yellow wire to the corresponding audio system’s mute-
input if available (mute in 1, mute in 2 or mute in 3).
Installing the electronic box
Avoid installing the electronic box near heating or air-conditioning system, on a spot directly exposed
to sunlight or behind metal walls.
Make sure the electronic box stays fixed once it is installed and that it will not move while you are
driving.
Do not reinstall the car stereo forcibly. If you are short of space behind the car stereo to install the
electronic box, consider installing it in the glove box.

Parrot MKi9100 –User guide
7
Installing the kit’s power cable
Note : In order to check the wiring, connect the screen before placing it on the dashboard.
►Refer to the Checking the wiring section for more information.
Refer to your car stereo’s wiring diagram.
The red wire of the kit’s cable must correspond to the constant +12V supply, the orange wire to the
ignition +12V and the black wire to ground. Check that the orange wire is not connected to the
constant +12V supply, as you could run down the vehicle’s battery.
Note : On some vehicles, there is no ignition +12V on the vehicle’s connectors. You must therefore connect the
orange power supply wire to the fuse box or another ignition power source.
Checking the wiring
To perform the installation check, turn the ignition on then off once the Parrot MKi9100 is installed:
the message “Goodbye!” must be displayed.
If it is not the case, it is necessary to inverse the positions of the red and orange wires. Indeed, the
red wire of the power cable must be connected to the permanent 12V, the orange wire to the 12V
ignition and the black wire to the ground. This can be done simply by reversing both fuse holders
located on the Parrot wiring.
Installing the audio connectors
Installing the music
cable
Connect the music cable to the electronic box and place the USB /
iPod / Jack connectors into the glove box, the central console or the
parcel tray depending on the configuration of your dashboard. Make
sure that the cable is not pinched.
Note : Use the provided protection cap to protect the connectors.
Installing the music
cable grommet system
The music cable grommet system allows you to adjust the cable length
while reducing its wear.
1. Drill a 20 mm hole in your dashboard (glove compartment or parcel tray).
2. Insert manually two flexible arms of the grommet system.

Parrot MKi9100 –User guide
8
3. Use a flat screwdriver in order to insert the last two arms.
> You can now connect your music cable to the bluebox.
Installing the individual components
Installing the double microphone
Selecting a location
In order to get hi-quality conversations, we advise you to respect the following
recommendations:
Make sure the microphone is installed as close to the mouth of the user as possible.
The ideal distance is 60 cm. The best possible location for the microphone is near
the rear-view mirror.
The microphone needs to be pointed towards the user.

Parrot MKi9100 –User guide
9
D < 60 cm
α < 45°
Make sure the microphone is not exposed to the air stream from air vents.
Do not install the microphone cable in heating, ventilation or air
conditioning systems.
Mounting the double
microphone
The mounting location for the microphone must be clean and free from grease or
dust. Prior to installation, clean the area with an appropriate cleansing product.
Once you have stuck the support on the dashboard, wait for approximately 2 hours to
make sure the adhesive tape adheres well.
Installing the remote control
Installing the remote
control on the steering
wheel
If you want to place the remote control on the steering wheel, make sure it is
securely attached, so that it does not move when you are driving.
WARNING: Do not install the remote control on the outside of the steering
wheel and ensure it does not get in the way when driving.

Parrot MKi9100 –User guide
10
Installing the remote
control on the
dashboard
If you want to place the remote control on the dashboard, stick the double-sided
tape located on the flat side of the bracket to fix it against the dashboard. You can
then insert the remote onto the bracket.
WARNING: Once you have stuck the support on the dashboard, wait for
approximately 2 hours to make sure the adhesive tape adheres well.
Replacing the
battery
The remote control only works with a 3V CR2032 battery.
Make sure the battery is correctly positioned before inserting it into the
remote control.

Parrot MKi9100 –User guide
11
Installing the screen
Selecting a location
Install the screen in an easily accessible and visible location.
Do not install the screen in the airbag deployment area or in a possible head impact
area.
Mounting the
screen
The mounting location for the
screen must be clean and free
from grease or dust. Prior to
installation, clean the area with
an appropriate cleansing product.
Once you have stuck the support
on the dashboard, wait for
approximately 2 hours to make
sure the adhesive tape adheres
well.
Avoiding theft and
sunlight exposure
Remember to remove your screen when leaving the vehicle to avoid tempting any would-be
thieves and to prevent prolonged exposure to sunlight.

Parrot MKi9100 –User guide
12
Getting
started
WARNING : If the remote control doesn’t seem to be associated to the electronic box while using the Parrot
MKi for the first time, refer to the Associating the remote control to the electronic box section.
Navigating through the menus
Associating the remote control to the electronic box
If the remote control doesn’t seem to be associated to the electronic box while using the Parrot MKi9200:
After verifying the CR2032 battery is properly
inserted in the remote unit, press and hold the
and buttons then press the button
several times. This has to be done when you
see the "Parrot MKi9200" Logo on the display
screen.
Within 1 to 2 seconds, you should then see a
“Pairing Remote Control” message displayed on
the screen. At that time, you can release the
buttons and the remote should then be paired
with the kit and the message will go away. You
can verify remote operation by navigating
through the menus.
Note : If you are unsuccessful on the first attempt, power off the unit until you see the “Goodbye” message,
power it back on, and repeat the process.

Parrot MKi9100 –User guide
13
Icons
-The and icons relate to the battery charge level and the status of the network for
the telephone connected to the Parrot MKi9100. Whether these icons are present or not depends on
which telephone model you have.
-The icon indicates that synchronisation of the directory is in progress.
-The icon indicates that your device is in night mode (the screen is dimmer). To exit night
mode, press the knob for 2 seconds.
-The icons on the top left show the peripherals connected to the Parrot MKi9200. The highlighted icon
shows which audio source is being used.
Commands
Accessing the main
menu
Press the central jog wheel to access the menus.
> The kit says the name of the current menu.
Browsing through the
menus
Turn the jog wheel to browse through the menus.
Press the button or the jog wheel to confirm.
Press the button to get back to the previous menu.
Exiting the menu
Press the button to exit the menu or get back to the Now Playing
screen if a song is currently being played.
Using the vocal menus
Activating / deactivating
the vocal menus
You can activate or deactivate the vocal menus of the Parrot
MKi9100. To do so:
1. Press the jog wheel and select Settings > Audio > Spoken
menus.
2. Press the jog wheel to activate or deactivate this option.
Adjusting the vocal
menus volume
1. Press the jog wheel and select Settings > Audio > Menu
Volume.
2. Use the jog wheel to adjust the volume and confirm.

Parrot MKi9100 –User guide
14
Establishing a Bluetooth connection with a phone
Using a phone with the Parrot MKi9100 for the first time
Adjusting the kit
visibility
Before pairing your phone with the Parrot MKi9100, make sure that it is visible by all
Bluetooth ® devices. To do so press the jog wheel and select Settings > Bluetooth
>Visibility. Then, make sure this option is selected.
If it is not the case, select it by pressing the jog wheel.
Note : The Parrot MKi9100 is visible by default.
Pairing a phone
1. Press the jog wheel and select Settings > Bluetooth > Pair with….
> If your mobile phone’s model appears in the list, select it and
confirm by pressing the jog wheel.
> If your mobile phone model doesn’t appear in the list, select the Other
phones option.
2. From your phone, search for Bluetooth peripherals. Refer to your phone user
guide for more information.
> The list of the available Bluetooth peripherals is displayed.
3. Select « Parrot MKi9100 » in the list.
4. Enter « 0000 » on your phone when you are prompted to enter a PIN code.
> «Pairing successful» is displayed on the screen of the Parrot
MKi9100.
Automatic connection
Once your phone is paired to the Parrot MKi9100, the connection between both
devices will be automatically established each time you enter your vehicle if your
screen is plugged in.

Parrot MKi9100 –User guide
15
Using the Parrot MKi9100 with 2 phones
Dual mode allows you to simultaneously connect two phones to the Parrot MKi9100.
Activating dual mode
To activate dual mode and connect two phones, select Settings > Bluetooth > Dual
mode.
N.B. Dual mode is deactivated by default.
Connecting two phones
to the Parrot MKi9100
When the Parrot MKi9100 is switched on, it attempts to connect all paired phones
in the vehicle. If there are more than two paired phones in the vehicle, the device
connects the two phones with the oldest pairing.
Main and secondary
phones
When two phones are connected to the Parrot MKi9100, one of them becomes
the main phone and the other is the secondary phone.
By default, the main phone is the one with the oldest pairing to the Parrot
MKi9100.
Your preferred phone will automatically become the main phone when dual
mode is activated.
The information displayed on the Parrot MKi9100 screen is for your main
phone.
To define the secondary phone as your main phone (and make your main phone
the new secondary phone), press and hold for two seconds.
Making and receiving
calls
You can receive calls (manually or through voice recognition) to your main or
secondary phones. The Parrot MKi9100 ringtone varies according to the phone
receiving the call.
Only the phonebook for your main phone may be accessed through the Parrot
MKi9100. You can only make calls using your main phone. However, you can easily
switch between the connected phones by pressing and holding for two seconds.
If you receive a call to one of your phones while you are on the other phone, only
the latter will ring. You can take the call directly on that phone but not via the Parrot
MKi9100.

Parrot MKi9100 –User guide
16
Managing Bluetooth devices
Defining a phone as
preferred phone
The phone which you will define as Preferred is the one whose connection with
the Parrot MKi9100 will take priority. This option may be useful if several phones
paired with the Parrot MKi9100 are simultaneously in the vehicle.
Note : Your preferred phone will automatically become the main phone when
dual mode is activated.
To define a phone as preferred :
1. Select Settings > Bluetooth > Paired devices.
2. Select the phone you want to define as Preferred.
3. Check the Preferred phone option.
Disconnecting a
phone
1. Press the jog wheel and select Settings > Bluetooth > Paired devices.
2. Select the phone you want to disconnect from the kit.
3. Select Disconnect.
Connecting an
already used phone
The Parrot MKi9100 automatically connects itself to the last phone you used
with it. If you want to connect the Parrot MKi9100 to another phone you
already paired:
1. Press the jog wheel and select Settings > Bluetooth > Paired devices.
2. Select the phone you want to connect to the Parrot MKi9100.
3. Select the Connect option.
Managing the
“Memory full”
problem
You can pair up to 10 devices with the Parrot MKi9100.
If you attempt to pair an 11th phone, you will get the « Memory full »
message. You must then delete a phone from the paired devices list. To do
so:
1. Press the jog wheel and select Settings > Bluetooth > Paired
devices.
2. Select the phone you want to delete from the list.
3. Select Delete.

Parrot MKi9100 –User guide
17
Synchronizing the phonebook
Note : Only contacts stored in the memory of the phone will be synchronised in the kit’s memory.
Automatic
synchronisation
With most of the Bluetooth phones, the phonebook is automatically synchronized in the
kit’s memory. Refer to the compatibility section of our website for more information.
WARNING : The automatic synchronization is limited to 2 000 contacts for each
paired phone.
Sending contacts
via Object Push
If your phone doesn’t support automatic synchronization, you can also send contacts
from your mobile to the car kit via Object Push. To do so:
1. Press the jog wheel and select Phone > Receive contacts.
2. Refer to your phones ‘user guide for more information about sending contacts
via Object Push.
Deleting a contact
Note : You can only delete contacts sent via Object Push.
1. Press the jog wheel and select Phone > Contacts management.
2. Select the contact you want to delete.
3. Press the jog wheel and select Delete contact.
Deleting all
contacts
Note : You can only delete contacts sent via Object Push.
Press the jog wheel and select Phone > Delete all contacts.

Parrot MKi9100 –User guide
18
Phone
Before using your Parrot MKi9100 telephone function, you first have to connect it with your
phone / PDA.
►For more information,refer to the Establishing a Bluetooth connection with a phone section.
Making and receiving calls
The network signal at the top of the screen shows wether you are in range of the cellular network and can
make and receive calls. The more bars, the stronger the signal.
Making a call
Calling a contact in the
phonebook
If the contact you want to call is in the phonebook of the phone
connected to the Parrot MKi9100:
1. Press the jog wheel to enter the main menu and select Phonebook.
2. Select a letter and press the jog wheel.
> Once the contact chosen:
- Press the button to call this contact.
- Or use the jog wheel to choose between different numbers
of the same contact.
Dialling a number
If the contact you want to call is not in the phonebook of the phone connected
to the Parrot MKi9100, stop your vehicle in a safe location, press the jog wheel
and select Phonebook > Dial a number. You can then use the jog wheel to select
the digits.
You can also make the call directly from your phone.
Bringing up the last dialled
number
Hold down the key of the Parrot MKi9100 for two seconds to redial
the last dialled number.

Parrot MKi9100 –User guide
19
Receiving a call
An incoming call is indicated by a ringtone. The name of the caller is announced if his details are stored in the
phonebook of the phone connected to the Parrot MKi9100.
Answering a call
Press the button to answer an incoming call.
Declining a call
Press the button to decline an incoming call.
Using the Parrot MKi9100 while on a call
Adjusting the volume
Use the jog wheel during a call to adjust the communication volume.
> The volume setting is saved for subsequent calls.
Transfering a call to the
phone
During a call, if you want to continue the conversation on your phone
(private conversation), press the button of the Parrot MKi9100.
> The call is automatically transferred to the phone.
If you want to switch back to the kit, press the button again.
Muting a call
If you want to deactivate the microphone during a call, press the
button : you will still hear your caller but your caller will not be able to
hear you.
Press the button to reactivate it again.
Managing a second call
During a call, you can receive another call if your phone supports this
functionality.
Press the button to accept the second incoming call.
> The first call is automatically put on hold.
Press the button to decline the second incoming call.
You can also hang up directly from your phone.
Press the button to switch from a call to another.

Parrot MKi9100 –User guide
20
Managing voice mail
During a call, the Parrot MKi9100 allows you to send DTMFs to manage
your voice mail for example. To do so :
1. Press the jog wheel to access the DTMF menu.
> « 0 » is displayed by the kit.
2. Use the jog wheel to select your DTMF between the following
possibilities : 0,1,2,3,4,5,6,7,8,9,# or *.
3. Press the jog wheel to send this DTMF to your phone.
Ending a call
Press the button to end a call.
