Paslode TrimMaster IM250A-Li User manual

OPERATING MANUAL
IMPORTANT!
DO NOT DESTROY
Read all instructions before use.
www.paslode.com.au
www.paslode.co.nz
IMPULSE 16 GAUGE LITHIUM-ION
ANGLED BRADDER
Part No. B20721
Model IM250A Li
Impulse
IMPULSE 16 GAUGE LITHIUM-ION
ANGLED BRADDER

2
Contents
Subject Page
Warranty ........................................................................................................................................................................ 4
An Overview of the Paslode
Impulse 16 Gauge Li-Ion Angled Bradder.......................................................................... 5
Safety Instructions........................................................................................................................................................... 6
Battery and Charger System .......................................................................................................................................... 9
Fuel Cell/Cartridge System ........................................................................................................................................... 10
Fasteners and Applications ........................................................................................................................................... 14
Servicing........................................................................................................................................................................ 15
Troubleshooting 18
The battery charger system meets all safety requirements for power tools.
is a trademark
Paslode
An IIlinois Tool Works Company
888 Forest Edge Drive
Vernon Hills, Illinois 60061
www.paslode.com
Power Nailers are made in the U.S.A.
Preparing the Paslode Impulse 16 Gauge Li-Ion Angled Bradder for Use....................................................................
Paslode
Impulse 16 Gauge Li-Ion Angled Bradder Operation ..................................................................................... 13
Paslode®is a member of:
RBRC
RBRC
Li-ion
Introduction ........................................................................................................................................................................
3
12
.............................................................................................................................................................

Introduction
Name
Address
City
State Postcode
Telephone Number
Paslode Impulse 16 Gauge Li-Ion
Angled Bradder Operating Manual
Congratulations and thank you for choosing this
Paslode Impulse Li-Ion Angled Bradder.
Before operating your Li-Ion Angled Bradder:
This manual is designed to help you get the maxi-
mum
performance from your new Impulse Bradder.
1. PLEASE READ THE MANUAL FROM COVER TO
COVER BEFORE USING THE TOOL.
2. PLEASE FOLLOW ALL INSTRUCTIONS IN THE
MANUAL.
Your Impulse Angled Bradder is completely self-con-
tained. When made ready for use it carries it’s own
fuel supply, battery and fasteners.
Unlike other fastening tools, the Impulse bradder is
powered by an internal combustion linear motor,
similar to that of an automobile. When triggered, the
Impulse bradder ignites a fuel and air mixture to pro-
duce energy that drives a piston, which in turn drives the
fastener.
Always use safe work practices when using your Impulse
bradder. Misuse could result in tool damage or personal
injury. If you allow others to use your Impulse bradder
please ensure that they also read and comply with the
instructions in this manual before operating the tool.
Please contact your local Paslode representative if you
have any questions about your Paslode Impulse Brad-
der or wish to obtain additional copies of this manual.
The space below is provided to record your represent-
3
ative’s details.

4
Warranty
For Paslode, Duo -Fast, Maestri, STOCK-ade Tools and Equipment
Please register your new Paslode, Duo-Fast, Maestri or STOCK-ade tool within 14 days of purchase at either
Australia - www.paslode.com.au
OR
New Zealand - www.paslode.co.nz
Warranty and Limitations
This warranty covers all tools and equipment supplied by Paslode Australia and Paslode New Zealand. All tools, equipment,
parts and accessories are warranted to be free from defects in material and workmanship for 12-months after the date of
delivery to the original user except those covered by an extended warranty as follows:
A five year warranty will apply to all moulded nylon parts on Impulse tools only
Motor Housing, Cap and Grille
Handle Halves and Actuator
Trigger
Magazine Parts
Paslode’s liability under this warranty is to replace any part or accessory which proves to be defective within the specified time
period. Any replacement part or accessory provided in accordance with this warranty will carry a warranty for the balance of
the period of warranty applicable to the part it replaces. This warranty does not apply to part(s) replacement required as a
result of normal wear. A proof of purchase (receipt) must be supplied before repair can commence.
This warranty will be void as to any tool and/or equipment which has been subjected to misuse, abuse, accidental or intentional
damage. The warranty may also be void if tools are used with fasteners, fuel, batteries or battery chargers not meeting Paslode
specifications, size or quality, or if any product is improperly maintained, is repaired with other than genuine replacement parts,
is damaged in transit or handling or in our opinion, has been altered or repaired in a way that affects or detracts from the
performance and safety of the tool and/or equipment.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure. All rights provided under the Paslode Australia warranty are in addition to any rights you have as a Consumer
under the Australian Consumer Law.
Notwithstanding your statutory rights, in the event goods require investigation or repair under this warranty purchasers are
advised to deal directly with a Paslode warranty provider –locations and all contact information are detailed on our websites -
Australia - www.paslode.com.au OR New Zealand - www.paslode.co.nz.
Subject to any mandatory terms:
(a) Paslode makes no warranty, express or implied, relating to merchantability, fitness or otherwise, except as stated above; (b)
Paslode’s liability as stated above is in lieu of all other warranties arising out of, or in connection with, the use and performance
of the tool and/or equipment; (c) Paslode shall in no event be liable for any direct, indirect, or consequential damages,
including, but, not limited to, damages which may arise from loss of anticipated profits or production, spoilage of materials,
increased cost of operation or otherwise; (d) Paslode is not liable for personal injury whether direct or indirect howsoever
suffered arising from or in connection with any misuse of the product; and (e) Paslode is not liable for any negligence in the
manufacture, supply or any instructions related to the tool and/or equipment.
Paslode reserves the right to change specifications, equipment or designs at any time without notice and without incurring
obligation.
If you do not have internet access to register your tool and/or equipment, please contact either Paslode Australia or Paslode
New Zealand at the following address.
Paslode Australia Paslode New Zealand
PO Box 914 PO Box 100 303 NSMC
Ingleburn, 1890 Auckland, New Zealand
t
t
t
t

5
Description Specifications
Dimensions: Weight-with battery 2.0 Kg
Height 292 mm
Length 274 mm
Magazine Angled
(use Paslode angled fasteners only.)
Cycle Rate: Intermittent Operation – 2 to 3 nails
per second
NOTE:
Fasteners: 16 Gauge Angled - 1.6 mm
Magazine
Capacity: 2 nail strips, or 100 fasteners.
Battery : 7.4 volts DC - Provides enough energy to
drive approximately 6000 fasteners on a
full charge.
Fuel Cell:
Magazine Assembly
Fuel Cell Compartment
Cap
Removable
Grille & Filter
No-Mar Tip
Handle Assembly
(Soft Grip)
Soft
Touch
Trigger
Motor
Assembly
Battery Compartment
(opposite side)
Battery Indicator Light
(opposite side)
Follower
Motor Housing
Nail Count Indicator
Lockout
Feature
Adjustable
Depth of Drive
(opposite side)
Quick Clear
Cover
Rafter/Belt Hook
Overview of the Paslode Impulse
16 Gauge Lithium-Ion Angled Bradder
Your new Paslode Impulse 16 gauge Li-Ion Angled Bradder
offers the latest in cordless power nailing technology and is
the result of more than 75 years of experience in develop-
ing power nailing systems. Engineered with the demands of
the trade professional in mind, the Paslode Li-Ion Angled
Bradder is designed to provide years of reliable service. To
help you get the most from your new Li-Ion Angled Bradder
this operation guide provides important information on
safety and tool operation as well as service and trouble-
shooting tips.
The Paslode Impulse 16 gauge Li-Ion Angled Bradder is an
internal combustion design. To keep your Li-Ion Angled
Bradder operating at its best you will need to ensure regular
maintenance and cleaning.
Paslode accredited warranty service agent or visit www.
paslode.com.au | www.paslode.co.nz.
Bradder. For more information please contact your local
dures to properly clean and maintain your Li-Ion Angled
tenance booklet which provides instruction of the proce-
Angled Bradder comes with a separate cleaning and main-
To help with this, your Li-Ion
As you can see in the illustration below, the Impulse 16
gauge Li-Ion Angled Bradder is made up of three major
areas: handle, motor, and magazine.
is designed to drive several thousand nails in a typical workday.
The Paslode Impulse 16 gauge Lithium-Ion Angled Bradder
Exceeding the recommended cycle rates may cause
the tool to overheat, reduce performance or damage
the tool.
Paslode bradder fuel cell.
Part #B20544S.
Liquid hydrocarbon - Provides enough fuel
to drive approximately 1,000 fasteners.

6
Safety Instructions
WARNING
WARNING
WARNING
Do not expose the tool to
temperatures in excess of
49° C (120° F). Fuel and/
or the battery may burst,
releasing flammable gas.
WARNING
WARNING
The following safety instructions provide the information
necessary for the safe operation of the Paslode Impulse
16 Gauge Li-Ion Angled Bradder.
DO NOT ATTEMPT TO OPERATE THIS TOOL UNTIL
YOU HAVE READ AND UNDERSTAND ALL SAFETY
PRECAUTIONS AND MANUAL INSTRUCTIONS.
The Impulse Angled Bradder
is an internal combustion
device. It produces hot
exhaust gases that may
ignite flammable materials.
This tool must not be used
in a combustible environ-
ment or in the presence
of combustible materials,
such as flammable chemi-
cals, adhesives, gasoline,
or solvents.
Do not attempt to operate
this tool until you have read
and understood all safety
precautions and manual
instructions.
Failure to follow all safety
precautions and instructions
may result in a permanent
loss of vision, serious personal
or even fatal injury, property
damage and/or tool damage.
ALWAYS keep the Impulse
Angled Bradder , fuel cell,
battery and battery charger
out of the reach of children.
CF
49° 120°
This tool must be operated
environment, because the
only in a well-ventilated
tool exhausts carbon mon-
oxide similar to a petrol
chainsaw or lawnmower.
Exposure to carbon mon-
oxide may cause dizziness,
nausea, or unconsciousness.

7
Safety Instructions
WARNING
7. NEVER OPERATE THE TOOL WITH THE
WORK CONTACT ELEMENT REMOVED OR
DISABLED.
NEVER operate the tool if the work contact element
is not working properly.
8.
Pull the follower slightly back and push the release
lever. Tip the tool nose up slightly and fasteners should
slide out of the rear of the magazine. If fasteners are
jammed, refer to the appropriate servicing section of
this manual.
9.
NEVER OPERATE THE IMPULSE BRADDER IF
PARTS ARE LOOSE, DAMAGED OR MISSING.
10. DO NOT DRIVE FASTENERS INTO KNOTS OR ON
TOP OF OTHER FASTENERS.
A fastener may ricochet and cause serious injury.
11. OPERATE THE TOOL ONLY ON THE WORKPIECE.
1.
Eye protection must meet the requirements of AS/NZS
1337:1992 and should have side shields for increased
2. NEVER ASSUME THE TOOL IS EMPTY.
Never point the tool at yourself or anyone else.
3. NEVER ENGAGE IN "HORSEPLAY" WITH THE
TOOL.
Careless and improper use may result in a serious
accident.
4. NEVER CARRY THE TOOL WITH YOUR FINGER ON,
OR SQUEEZING, THE TRIGGER.
This practice may result in the accidental discharge of
a fastener.
5. NEVER OPERATE A MALFUNCTIONING TOOL.
Refer to the servicing or troubleshooting section of this
manual to correct the problem. If the problem cannot
be corrected, stop using the tool and contact Paslode.
®
6. DO NOT LOAD FASTENERS WITH THE TRIGGER
AND/OR WORK CONTACT ELEMENT DEPRESSED.
A fastener may be accidentally discharged.
WARNING
should be operated only
when it is in contact with
the work
surface. When
fastening thin materials
such as plywood, be sure
to position the tool so that
the fastener is driven into
the underlying piece.
ALWAYS POINT THE TOOL AWAY FROM YOUR-
SELF AND OTHERS WHEN CLEARING A JAM OR
REMOVING FASTENERS. ALWAYS REMOVE THE
Always wear EYE and EAR
safety gear when working
with or in the vicinity of the
Paslode Impulse Bradder.
protection.
FUEL CELL AND BATTERY BEFORE CHECKING
THE TOOL.
The Impulse Angled Bradder

8
Safety Instructions
12. NEVER DRIVE FASTENERS INTO AREAS WITH
CONCEALED HAZARDS.
Always check the area behind the work surface for
electrical wiring, gas pipes, water pipes, sewer drains
or other potential hazards.
13. ALWAYS MAINTAIN SECURE AND UNOBSTRUCTED
FOOTING WHEN ON LADDERS, PLATFORMS OR
OTHER HIGH LOCATIONS.
14. ALLOW ONLY QUALIFIED PERSONNEL TO OPERATE
THE IMPULSE BRADDER.
15. PROPERLY STORE FUEL CELL.
16. ALWAYS STORE THE TOOL WITH THE FUEL
CARTRIDGE AND BATTERY REMOVED.
17. KEEP THE TOOL CLEAN AND WELL MAINTAINED.
A clean tool is less likely to jam or malfunction.
18. KEEP YOUR HANDS CLEAR OF THE WORK AREA
SURFACE.
WARNING
Never over-reach, since
tool recoil may cause a
loss of balance. Always
dnasegdefoerawaeb
drop-offs when nailing on
rooftops and other high
locations. Keep them in
full view.
WARNING
Only persons who have
read and fully understand
all tool operation, safety
and maintenance
instructions should be
allowed to operate the
tool.
WARNING
A fastener may exit at an
angle unexpectedly and
cause injury.
WARNING
Always store fuel cells
where they will not
be
exposed to an open flame,
sparks or temperatures
above 49° C (120° F).
Store the fuel cartridge in the case with the Impulse
bradder.

9
WARNING
CHEMICAL/EXPLOSION
HAZARD
Read ALL instructions be-
fore charging or using bat-
tery. Failure to follow ALL
instructions may result in
fire, severe burns, or re-
lease of toxic materials.
Battery and Charging System
Charging Instructions
1.
2. Remove the battery from tool or case and insert ter-
minals down into charger. The red light will come on
indicating that the battery is charging and the green
light will go out.
3. After charging is complete, the red light will go out
and the green light will come on, indicating that the
battery is fully charged. The charger will keep the
battery at full charge until it is removed.
4.
Unplug the wall mount unit from the charger and
remove the wall mount unit from the 240V AC outlet.
CHARGING TIMES:
First charge (new battery) 1 hour
Discharged Battery 5 minutes to 1 hour
Do Not:
1. Charge battery outdoors or in temperatures
below 5°C (40°F).
2. Allow metal objects to come in contact with
battery terminals.
3. Puncture or attempt to open battery case or
cells.
4. Store battery where it will be subjected to
temperatures above 49°C (120°F).
5. Incinerate battery.
6. Use a defective battery charger, one that
over-heats and/or smokes when plugged in.
7. Immerse the battery in water.
Note
Important Charging Notes:
Remove wall mount unit from the tool case and plug
it into a 240V AC outlet. Set the charger base on a
stable surface and insert wall mount transformer
unit’s round plug into the plug receptacle on the
bottom
of the charger (see picture). A green light
indicates power is on and charging system is ready.
If battery is completely discharged, the red light and
the green light may alternate back and forth for up to
20 minutes. This safety feature slowly recharges the
battery until it is ready to accept the full charging
current. If the red and green lights continue to alter-
nate after 20 minutes, the battery may be damaged.
The Paslode Impulse Angled Bradder includes two
rechargeable Lithium-Ion (Li-Ion) batteries with a
unique charging system. The charging system is
unique to Paslode Li-Ion batteries. The first step in
preparing a new tool for operation is to fully charge
the battery. New batteries are shipped partially
discharged and must be charged prior to first use.
Batteries will take 5 minutes to 1 hour (time will be
dependant on the amount of discharge).battery
IMPULSE BATTERY CHARGING SYSTEM
AC-DC Adapter
Charger Base
DC Plug
Battery
Plug Receptacle
Charging System Accessories:
Battery Charger Kit ..........Part No. B20543B
Wall Mount Transformer...Part No. B20543C
Automotive Adapter.......... Part No. B20543E
TECHNICAL DATA
Impulse Adapter (AC-DC)
Australia/New Zealand
Impulse Charger Base
Impulse Battery
7.4 VDC, 1250mAh, Lithium-ion
tupnI
240V, 50HZ
12VDC
Output
Polarity
12VDC, 1.8A
Battery Disposal:
The Paslode batteries contain lithium and should
be disposed of responsibly.

10
Battery and Charging System
Inserting Battery
1. e Impulsehtotni,tsrfistcatnoc,yrettabehtdaoL
bradder.
2. Push battery fully forward into its locked position.
You may need to depress the lock tab.
3.
Battery Indicator Light
On the right side of the handle is a small plastic lens. This is
the battery indicator light. When you insert a fully-charged
battery into the tool, you will see a blinking green light. If
the indicator light blinks red, recharge the battery.
BATTERY INDICATOR LIGHT
! CARBONMONOXIDE HAZARD-USEONLYIN VENTILATED AREA TOAVOIDNAUSEA AND UNCONSCIOUSNESS.
LISEZ SOIGNEUSEMENTLEMODE D' EMPLOI.LEUR NON RESPECTPEUT ENTRAINER DESACCIDENTS.
! EXPLOSION HAZARD - NEVER USE IN EXPLOSIVE ATMOSPHERE - TOOL EXHAUST COULD IGNITE FUMES.
! TOOL OPERATORS AND BYSTANDERSMUSTWEAREYE AND HEARINGPROTECTION THATCONFORMSTOANSIST ANDARDS.
LEA TODASLAS PAGINASDEL MANUAL.DELOCONTRARIOPUEDERESULTAREN ACCIDENTES.
! ASSUME TOOLIS ALWAYSLOADED AND WILL ALWAYS FIREA FASTENER.
! READ MANUAL FROM COVER TOCOVER. DISREGARDING WARNINGSCOULD RESULT IN ACCIDENTS.
! CARBON MONOXIDE HAZARD - USEONLYIN VENTILATEDAREA TO AVOID NAUSEA AND UNCONSCIOUSNESS.
LISEZ SOIGNEUSEMENT LE MODE D'EMPLOI.LEURNON RESPECT PEUT ENTRAINERDES ACCIDENTS.
! EXPLOSION HAZARD -NEVER USE IN EXPLOSIVEATMOSPHERE - TOOL EXHAUST COULD IGNITE FUMES.
! TOOL OPERATORS ANDBYSTANDERS MUST WEAR EYE AND HEARINGPROTECTION THAT CONFORMS TO ANSI STANDARDS.
LEA TODASLAS PAGINASDEL MANUAL.DE LOCONTRARIOPUEDERESULTARENACCIDENTES.
! ASSUME TOOL IS ALWAYS LOADEDAND WILL ALWAYSFIREA FASTENER.
! READMANUAL FROMCOVER TOCOVER. DISREGARDING WARNINGSCOULD RESULTINACCIDENTS.
To remove battery, push down on locking tab and
slide battery out.
Ready
Position
Standby
Position
NOTE: If the battery is left inserted in the tool in the “on”
position for an extended period, the battery will discharge
completely and require recharging. Complete discharge
may lead to battery damage.

11
WARNING
EXPLOSION/ FIRE
HAZARD
WARNING
Sunlight can raise the inside temperature of an
unventilated motor vehicle or storage container to
above
60°C (140°F).
Never puncture or attempt to open the fuel cell; it is
non-refillable.
Never incinerate, reclaim or recycle the fuel cell.
Never smoke while installing the fuel cell or operating
Never inhale the spray.
Keep out of the reach of children.
Store fuel cell(s) in well-ventilated areas only.
Fuel Cell
To eject the fuel, propellant pressure squeezes the inner fuel
container, much as you squeeze a tube of toothpaste. This
squeezing action ensures that all the fuel is used, and that
the Impulse bradder can operate in any position.
Because of this container-within-a-container design, you
might hear the sound of fluid when shaking the fuel cell
after all the fuel has been used. This is the propellant, which
remains between the containers even after all the fuel has
been expelled.
Fuel Cell
WARNING
1. Do not attempt to remove or reuse the fuel cell cap.
NOTE: Altitude Restriction
There is a second container inside the fuel cartridge. The
inner container holds the fuel. The space between the
inner container and the outer cylinder is filled with a gas,
called the propellant, which is under pressure.
using or handling the fuel
cell.
tions may result in explo-
sion or fire.
Keep the fuel cell away
from heat, sparks and
open flame. Do not smoke
tool or fuel cell.
Exposure to temperatures
above 49°C
(120°F) may
cause the fuel cell to burst,
the propellant gas will expand and could cause the
container to burst, releasing flammable gases.
2. Do not attempt to install the fuel cell cap on other
fuel cells. This may result in damage to the tool and
personal injury.
the tool.
Paslode Impulse tools are powered by an internal
combustion engine and are affected by altitude. The tool
may lose power or not cycle consistently at elevations of
2,400 metres (6,000 feet) or greater.
NOTE:
1. Never attempt to refill the fuel cell! Replace with fresh
fuel cell. Dispose of used cell responsibly.
2. When replacing fuel cell also clean or replace air filter
for optimum tool operation.
3.
Paslode Impulse fuel cells are marked with a "Best
Use Before" date on the bottom of the can. For
maximum performance use fuel before the "Best Use
Before"date.
when handling or operating
CF
49° 120°
If you expose the empty fuel cell to extreme temperatures,
™
™
Read all instructions before
Failure to follow all instruc-
releasing flammable gas.

12
Inserting
£
1. PRESS UP
£
1. CLOSE OVER
2. PULL OUT
£
2. PRESS DOWN
£
B. Lift the fuel cell adaptor and insert the fuel cell into
the tool.
C. Release the adapter so it is centered on the fuel cell.
A.
When loading a fuel cell, lift the tool off of the work
surface so the work contact element (WCE) is not depres-
sed. Press forward at the back of the actuator cover and
pivot outward to open. The cover will swing out of the way.
D. Close the actuator cover over the fuel valve/cylinder
assembly. Push forward and down until the actuator
cover snaps into position to complete the loading of fuel
in the Impulse Bradder.
Fuel Cell
Fuel Cell
™
™

13
Paslode Impulse
HOT WEATHER OPERATION
COLD WEATHER OPERATION
Fasteners
Loading Fasteners
STEP 1: Align the heads of the Paslode16
Gauge
Angled
Brads
to the silver brad channel in the rear of the
magazine
and insert one or two strips. Push the nails strips forward.
STEP 2: Next, while applying pressure to the release lever,
pull
the follower toward the rear of the magazine until the
follower passes the last strip of fasteners. Release the lever
on the follower and let the follower push the nails forward
into the nose of the tool.
In the illustration above, you will see an indicator arrow
on the side of the follower.
When the indicator arrow is in
the reload area, marked on the side of the magazine, you
may insert a new strip of nails.
When the follower arrow
reaches the lockout area the tool automatically locks the
tool from dry firing. To unlock the tool, simply reload another
strip of nails.
Lockout Feature
Pull
Follower
Nail
Channel

Use only Paslode 16
Gauge Angled Brads.
Do not use Straight Brads!
WARNING
Li-Ion Angled
Bradder and Outdoor Weather
The Impulse bradder
should not be used in the
the rain or where excessive moisture is present.
The use of
Paslode Impulse Technology under
these conditions may result in damage
to tool
components and cause the tool to malfunction.
The purpose of this feature is to prevent needless
blank cycling, which could mar woods,waste fuel and
damage tool components.Ten
(10) nails will be left in
the magazine when the follower reaches the lockout
area.
When changing fastener length or loading at
the beginning of the work day, you should inspect the
magazine and nose for any fasteners left in the tool.
These nails will not be visible unless you open the
nose of the tool.
Use the Impulse Li-Ion Angled Bradder outdoors, in
tery are between -7°C (20°F) and 49°C (120°F).
clear weather, when the nailer, fuel cell, and bat-
The Impulse Bradder requires cooling to operate
optimally.
The fan should provide the necessary air
flow to permit continuous operation. Whenever the
Impulse bradder is idle for
extended periods, keep
the fuel and tool out of direct sunlight and in sur-
roundings where temperatures will not exeed 49°C
(120°F). After
extended
periods
of continuous use,
it may be necessary to cool the
motor by setting
the tool
aside until the tool
operates normally. An
over heated tool may not drive nails completely or
Fuel combustion can be adversely affected at
extreme low temperatures. Ensure that the tool
battery and fuel cell
are above the minimum oper-
ating temperature of -7°C (20°F) before use.
damage or void your warranty.
®
®
The Paslode Impulse Li-Ion Angled Bradder drives
Paslode 16 gauge angled fasteners. The use of fasteners
®
that do not meet Paslode standards may cause tool
may operate erratically.
Preparing the Paslode Impulse 16 Gauge
Lithium-Ion Angled Bradder Operation

14
Preparing the Paslode Impulse 16 Gauge
Lithium-Ion Angled Bradder Operation
Depth of Drive Adjustment
Remove the battery before adjusting the depth of
drive.
Adjust the depth of drive by
turning the adjustment wheel
as shown by the arrows on the side of the tool.
PRESS WORK –
CONTACT
ELEMENT
AGAINST THE
WORK SURFACE.
Fan motor starts,
fuel is injected
into combustion
chamber and
mixed with air
by the fan.
SQUEEZE
TRIGGER
Spark plug ignites
the fuel/air mixture
driving the piston
assembly down on
the fastener.
RELEASE
TRIGGER -
LIFT TOOL
Combustion
chamber opens.
Fan exhausts
hot gases and
cools internal
components.
Operation:
£
CAUTION
The work contact
element and nose may
become hot
after prolonged or rapid use. If it becomes necessary
to adjust the work contact
element, avoid touching
with bare hands.
CAUTION
Turn
adjustment
wheel
in either
direction
This tool must be operated in a well ventilated environ-
ment, because the tool exhausts carbon monoxide.
Exposure to carbon monoxide may cause dizziness,
nausea or unconsciousness.
£

15
Fasteners and Applications
Applications
The Paslode Impulse Li-Ion Angled Bradder is suited for a variety of applications. These include securing door and
window architraves; attaching skirting boards where walls meet floors; attaching moulding where walls meet ceilings;
securing paneling; securing chair rails, picture moulding and other decorative trim.
The Paslode Impulse 16 Gauge Li-Ion Angled Bradder drives Paslode 16 Gauge Angled Brads.
Fasteners are
collated into strips of 50 for easy loading.
Paslode fasteners are designed to be used in Paslode tools, use of
other fasteners
may cause damage to the tool or injury to the tool operator.
PART
NO. LENGTH APPLICATION
B20732 32mm Architraves, Decorative Trim
B20738
B20780
38mm
Skirting Board, Architraves,
Paneling,Cabinets,Balustrades
B20745 45mm
Stairs, Door Stops
B20750
B20785
50mm Door Jambs, Stairs,
Chair Rails
B20765 63mm Door Jambs
Paslode 16 Gauge Angled Brads are available in galvanised finish for internal applications and stainless steel finish
for external applications.
THE PASLODE IMPULSE 16 GAUGE ANGLED BRADDER
DRIVES THESE BRADS
Fasteners

16
Restrict Field Service to the Following
RECHARGING THE BATTERY
CHECKING THE FUEL CELL
REPLACING THE FUEL CELL
CLEANING/REPLACING THE AIR FILTER
CLEARING A JAM
CLEANING THE TOOL (See cleaning manual)
Attempts to go beyond these procedures could result
in
serious personal injury or damage to the Impulse bradder
and void the warranty.
When carrying out servicing procedures please follow
the instructions provided in this manual. Any servicing
be performed by a fully trained technician.
Servicing
Fuel Cell Check (continued)
DANGER
Wear safety glasses when performing this test. Never
perform this test near an open flame or sparks, while
smoking, or where the fuel may get into your eyes.
If fuel is not released with each operation of the metering
valve, this indicates that there is no more fuel left in the
cylinder and it must be replaced. Dispose of the empty fuel
cell. (see page 11)
Clearing a Jam
An occasional problem you may encounter is a jammed
. To clear a jammed fastener:renetsaf
1. Remove the battery,fuel and fasteners.
2. Pull the latch, releasing front guide. Pivot front guide
forward.
3. Clear jam, and push driver blade back up to its normal
position.
4.
Battery Check
Periodically check on the battery indicator light (the light
in the handle) of the Impulse bradder. When encounter-
ing a problem, the first step should always
be to make
sure the battery has enough charge to
operate the tool.
CAUTION
Never attempt any maintenance of a Paslode
Impulse
tool without first removing the fuel cell and battery.
Maintenance should be started only after the tool is
completely inoperative.
CHECKING THE ENERGY LEVEL OF THE
BATTERY
Close front guide and latch it. Check that the work
contact element moves freely.
or repair work that is not explained in this manual should
Fuel Cell Check
tool will not cycle consistently or at all, check the fuel cell.
cell has never been used.
If the nailer’s fan operates and the light is green but the
First remove the fuel cell from the tool and check the
“Best Use Before” date stamped on the bottom of the
cell. If it is beyond this date, the fuel cell may not consis-
tently dispense the proper amount of fuel – even if the
To determine if there is any fuel left in the fuel cell, hold in
the upright position and simply place the metering stem
against a solid object, and gently push about three or four
times. A small amount of fuel should be released each
time.
When the work contact element is pressed against the
red, recharge the battery.
work piece, the fan motor will turn on and blinking green
light will turn solid green. If the light blinks red or glows

17
Servicing
Air Filter
Open the grille by pressing slightly above the adapter and
pivoting the cover open. The air filter simply lifts out.
naelcdnakcehC.tsudynaevomerotYLTNEGretlfiehtpaT
the air filter every two days. Soap and water restores the
filter to a "like new" condition.
End-of-Workday Routine
These simple steps are based on maintaining the safety and
operational efficiency of the Impulse bradder.
Before you leave the work site:
1.
ehtesusyawlA.esaclootnierotsdnayrettabevomeR
Impulse Bradder case for transporting and storing the
the tool.
2.
When you get home:
1. Place the battery in its charger if it needs charging as
indicated by the red charge light on the handle.
2. Wipe your Impulse Li-Ion Angled Bradder with a soft
clean cloth.
3. Remove and clean the filter every two days.
4.
Check work contact element to ensure it is operating
freely.
Paslode Impulse Tool Accessories
edolsaPehtrofelbaliavaeraseirosseccafoyteiravA
Impulse 16 Gauge Lithium-Ion Angled Bradder:
Contact your Paslode®representative for additional
information.
Tools
A 9/64 Allen Key is provided with each Impulse Li-Ion
Angled Bradder.
GRILLE
FILTER
CAP
Product Description Part Number
Battery B20543A
Impulse and Pneumatic Degreaser B20544L
Paslode Impulse Lubricating Oil B20544F
Battery Charger Kit B20543B
Automotive Adapter Kit B20543E
Dispose of all empty fuel cells responsibly. Remember
crushed, punctured, burned or found by children.
to dispose of these fuel cells where they will not be

18
Battery does not appear to accept charge
when battery is plugged into the charger.
Charger gets hot, makes excessively loud
noise, or smokes during charging cycle.
Charger cord or wall plug gets hot.
Inoperative indicator lights on charger, or
defective charger.
Battery damaged or cycle life exhausted.
Damaged charger.
Try battery in tool after a full charge cycle.
If tools indicator light is red, charger not
working properly. Replace charger, or
monitor charging time to ensure battery has
adequate time for recharging. It is normal
for battery to feel warm after properly
charging.
Replace battery.
Discontinue use immediately and unplug
from power source. Replace charger
and tag or dispose of charger to prevent
accidental re-use or connection to power
source.
Preparing Tool for Operation - Battery/Charger Problems
SYMPTOM POSSIBLE PROBLEMS SERVICE
Normal Stage of Operation
Fan does not run - tool indicator light is
blinking red or solid red.
Fan does not run, or runs slower than nor-
mal - tool indicator light is solid red.
Battery is not charged.
Battery terminals are oily, dirty, or corroded.
Battery is discharged.
Charge battery.
Clean battery terminals with soft cloth.
Charge battery.
SYMPTOM POSSIBLE PROBLEMS SERVICE
Work contact element does not depress
fully - tool does not operate.
Tool will not cycle - fan runs, indicator light
is solid green.
Work-contact element is bent, or build-up of
debris in track restricts operation.
Lockout feature is engaged.
Fuel Cell is empty.
Spark wire out of spark plug.
Spark plug is dirty.
No spark is generated.
Remove and inspect lower probe. Clean track.
Repair or replace lower probe as required.
Add strip of nails.
Replace fuel cell.
Remove cap and check spark lead, insert in
spark plug and replace cover.
Clean tool cylinder head.
Return tool to authorised Paslode®dealer for
service.
Troubleshooting

Tool operates properly, but fasteners do not
drive fully.
Tool operates properly, but fasteners are
sometimes over-driven, and sometimes
under-driven.
Tool operates, but no fastener is driven.
Tool operates erratically or appears to be
losing power - tool indicator light is green.
Work contact element requires adjustment.
Fuel cell is low.
There may be loss of seal in combustion
chamber.
Work contact element is not adjusted properly
for the type of material being fastened.
Wrong fasteners being used.
Follower not properly engaged behind fastener
strip.
Jammed fastener.
Fuel cell is low.
Spark plug wire is loose.
Air filter is dirty, causing tool to overheat.
Tool is dirty.
Adjust work contact element.
Check fuel cell and replace as required.
Press work contact element against workpiece
for one minute. Pull trigger. If fastener does not
drive, there is a leak that requires service.
Adjust work contact element. Re-adjust as
required when material density or thickness
of material being fastened changes.
®
section for fastener types and sizes recom-
Position follower behind fastener strip and
engage strip.
Clear jam.
Check fuel cell.
Check spark plug wire.
Remove air filter and clean. Use soap and
water to remove stubborn debris.
Clean tool. Lubricate piston.
Normal Stage of Operation
SYMPTOM POSSIBLE PROBLEMS SERVICE
Tool operated and drove fasteners, but
driver blade did not return to up position.
Combustion chamber does not drop after
tool cycles.
Built-up dirt and debris on driver blade or in
nose bore.
Tool is dirty.
Work contact element is bent, or is dirty.
Clean driver blade and nose bore with
degreaser cleaner.
Clean tool. Lubricate piston.
Clean track or replace work contact element.
Troubleshooting
If tool will not operate after following the above service directions, return the tool to an authorised Paslode®
representative for service.
For technical support contact Paslode:
Australia: 1-800-PASLODE (727-563) | www.paslode.com.au
New Zealand: 09-477-3000 | www.paslode.co.nz
19
Use only fasteners meeting Paslode
speci-
fications. Check Fasteners and Applications
mended for use in the Paslode Impulse tool.

18
Printed in U.S.A.
903508-1
08/12
©2012, Illinois Tool Works Inc.
PO Box 914
Ingleburn 1890
www.paslode.com.au
PO Box 100 303 NSMC
Auckland
www.paslode.co.nz
ailartsuA
Australia
New Zealand
New Zealand
