PDG Mobility BENTLEY Series Installation guide

BENTLEY
Series
Bentley/ Bentley LT
MANUAL TILT WHEELCHAIR
Owner’s Operation and Maintenance Manual
DEALER This manual must be given to
the user of the wheelchair.
USER Before using this wheelchair read
this entire manual and save it for future
reference.
Attendant/Assistants: Before assisting
the user of this wheelchair, read this
manual and save for future reference.
For more information regarding PDG
products, parts and service, please visit
www.pdgmobility.com
Rev: 2
Description: Bentley Series Manual
Date: 2019 July 8th
Document: 16058

PAGE 2
Class 1 Medical
Rev. 2
1INTRODUCTION
Thank you for purchasing a PDG mobility wheelchair.
Please do not operate this equipment without first reading and understanding this
manual. If you are unable to understand the warnings and instructions, contact a health
care professional such as an Assistive Technology Practitioner (ATP), clinical professional
or therapist who is familiar with this type of product before attempting to use this
equipment.
If you have any questions or comments about this manual, the safety and reliability of
your wheelchair and the service you receive by us or your PDG supplier, please write or
call us using the contact information below:
PDG PRODUCT DESIGN GROUP INC.
#103- 318 East Kent Avenue South, Vancouver, BC V5X 4N6
Ph: [phone] Fax: [phone]
E-mail: [e-mail]
Please note and reference your product serial number when contacting PDG for us to
better serve your customer support needs.
Serial Number:
SAVE THIS MANUAL FOR FUTURE REFERENCE

PAGE 3
Class 1 Medical
Rev. 2
2TABLE OF CONTENTS
1 INTRODUCTION ....................................................................................................... 2
2 TABLE OF CONTENTS ............................................................................................... 3
3 NOTICE – READ BEFORE USE .................................................................................... 5
4 SAFETY SUMMARY ................................................................................................... 6
5 SAFETY AND HANDLING OF WHEELCHAIRS .............................................................. 7
5.1 Stability and Balance ................................................................................................... 7
5.2 Tilting ........................................................................................................................... 8
5.3 Curbs and Steps ........................................................................................................... 8
5.4 Stairways and Escalators ........................................................................................... 10
5.5 Transfers to and from Other Seats ............................................................................ 10
5.6 Weight Distribution ................................................................................................... 11
5.7 Reaching, Leaning, and Bending Forward ................................................................. 11
6 ENVIRONMENTAL CONDITIONS ............................................................................. 12
7 STANDARD FEATURES ............................................................................................ 13
8 UNPACKING AND ASSEMBLY.................................................................................. 14
8.1 Inspection .................................................................................................................. 14
8.2 Out of the Box Assembly Instructions ....................................................................... 14
9 STORAGE ............................................................................................................... 15
10 SAFETY INSPECTION CHECKLIST ............................................................................. 15
11 MAINTENANCE ...................................................................................................... 17
11.1 Cleaning ..................................................................................................................... 17
11.2 Suggested Maintenance Procedures ......................................................................... 17
12 TROUBLESHOOTING .............................................................................................. 17
13 DAMAGE REQUIRING SERVICE BY QUALIFIED SERVICE AGENT .............................. 18
14 SETUP, ADJUSTMENTS & OPTIONS ........................................................................ 18
14.1 Adjustment Guide ...................................................................................................... 18
14.2 Frame Options (and Identification) ........................................................................... 19
14.3 Seat Depth ................................................................................................................. 20
14.4 Seat-To-Floor Height ................................................................................................. 20
14.5 Armrests .................................................................................................................... 22
14.6 Front Rigging .............................................................................................................. 23
14.7 Footplates .................................................................................................................. 27
14.8 Backrest Adjustments and Options ........................................................................... 28
14.9 Rear Wheels ............................................................................................................... 29
14.10 Anti-Tippers ............................................................................................................... 31
14.11 Front Casters.............................................................................................................. 32

PAGE 4
Class 1 Medical
Rev. 2
14.12 Wheel-Locks .............................................................................................................. 32
14.13 Seat Tilt ...................................................................................................................... 33
14.14 Gas Strut and Cable Assembly ................................................................................... 35
14.15 Heel Loops (Optional) ................................................................................................ 36
14.16 Padded Calf Strap (Optional) ..................................................................................... 36
14.17 Headrest (Optional) ................................................................................................... 36
14.18 Postural Support Devices or Lap Belts (Optional) ..................................................... 36
14.19 Oxygen (O2) Tank Holder (Optional) ......................................................................... 37
14.20 IV (Intravenous) Pole Mount (Optional) .................................................................... 37
14.21 Extended Base with Rear Floor Jacks (Optional) ....................................................... 38
14.22 Motor Vehicle and Transit Use .................................................................................. 38
15 ISO 7176-15 TEST INFORMATION DISCLOSURE ...................................................... 41
16 LIMITED WARRANTY .............................................................................................. 42

PAGE 5
Class 1 Medical
Rev. 2
3NOTICE –READ BEFORE USE
As a manufacturer of wheelchairs, PDG endeavors to supply a wide variety of
wheelchairs to meet the many needs of the end user. However, final selections of the
type of wheelchair to be used by an individual rests solely with the user and his/her
healthcare professional capable of making such a selection. Thus it is recommend an
Assistive Technology Professional, clinical professional or therapist be consulted to
determined which model would best meet the wheelchair user’s mobility and
positioning needs.
All wheelchair set-up and adjustments must be performed by a qualified technician.
The options you choose and the set-up and adjustments have a direct impact on the
wheelchairs stability. Factors to consider that affect your safety and stability are:
a. User’s abilities and capabilities specifically of strength, balance and
coordination.
b. The types of daily hazards and obstacles encountered.
c. The specific dimensions, options and set up of the wheelchair. In particular
any changes to the seat height, seat depth, seat angle, back angle, size and
position of the rear wheels and front casters will change the stability of your
wheelchair. You should only make changes after consulting with a qualified
professional.
WARNING and CAUTION notices as used in this manual apply to hazards or unsafe
practices, which could result in personal injury or property damage.
NOTE – THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE
WITHOUT NOTICE. An updated version of this owner’s manual may be available at
www.PDGMobility.com
INDICATIONS FOR USE – The Bentley Manual Tilt Wheelchair is intended to provide
mobility to persons restricted to a seated position.
CONTRAINDICATIONS:
Does not have the required ability to adequately manage the functions of a
manual tilt-in-space wheelchair and does not have a capable caregiver for the
required assistance
Cannot tolerate prolonged periods in a seated position with posterior tilt
Highly agitated occupants
WHEELCHAIR TIE-DOWN RESTRAINTS AND SEAT RESTRAINTS – PDG does not
recommend wheelchair users be transported in vehicles of any kind while in
wheelchairs. Wheelchair users should transfer to the vehicle seat and use the vehicle-
manufacturer-installed restraint systems whenever it is feasible, and the unoccupied
wheelchair should be stored in a cargo area or secured in the vehicle during travel.
However, if transportation in a vehicle in the wheelchair is required, the wheelchair
must be equipped with PDG factory installed transport-ready tiedown mounting points
and the wheelchair occupant must use a restraint device. The Bentley wheelchair
complies with the crash testing requirements of ISO 7176-19: 2008 and, as such, has
been designed and tested for use as a forward-facing seat in motor vehicle. Thus, for
transportation in a vehicle the wheelchair must be restrained from movement using
RESNA WC-4:2017, section 18 wheelchair tie-down system and the vehicle must be
equipped with RESNA WC-4:2017, section 19 anchor points.

PAGE 6
Class 1 Medical
Rev. 2
POSITIONING STRAPS and SEAT BELTS - IT IS THE OBLIGATION OF THE HOME DEALER,
THERAPISTS AND OTHER HEALTH CARE PROFESSIONALS TO DETERMINE IF A
POSITIONING DEVICE IS REQUIRED TO ENSURE THE SAFE OPERATION OF THIS
EQUIPMENT BY THE USER. SERIOUS INJURY CAN OCCUR IN THE EVENT OF A FALL
FROM A WHEELCHAIR.
4SAFETY SUMMARY
Operating Information Warning
Unless otherwise noted, all service and adjustments should be performed while the
wheelchair is unoccupied.
To determine and establish particular safety limits, practice bending, reaching and
transferring activities in several combinations in the presence of a qualified health
professional BEFORE attempting active use of the wheelchair.
The necessary back angle MUST be selected BEFORE repositioning the rear wheels
forward.
DO NOT operate the tilt function if the trigger release levers and cables are not
properly adjusted. Ensure that the tilt function is locked in place when the trigger
is released.
DO NOT traverse, climb or go down ramps or slopes greater than 9°.
DO NOT leave the occupied wheelchair unattended at any time, especially on an
incline.
DO NOT attempt to reach objects if you have to move forward in the seat.
DO NOT attempt to reach objects if you have to pick them up from the floor by
reaching down between your knees.
DO NOT lean over the top of the back upholstery to reach objects from behind as
this may cause the wheelchair to tip.
DO NOT shift weight or sitting position toward the direction of reach as the
wheelchair may tip.
DO NOT tip the wheelchair about the rear wheel without assistance.
DO NOT use an escalator to move a wheelchair between floors. Serious bodily
injury may occur.
DO NOT attempt to stop a moving wheelchair with the wheel locks. WHEEL
LOCKS ARE NOT BRAKES.
Before attempting to transfer in or out of wheelchair, every precaution should be
taken to reduce the transfer gap distance. Turn both casters towards the object
you are transferring onto. When transferring to and from the wheelchair,
ALWAYS ENGAGE BOTH WHEEL LOCKS.
DO NOT operate the wheelchair on roads, streets or highways.
DO NOT attempt to move up or down an incline that is wet, icy or is covered in an
oily film.
DO NOT attempt to ride over curbs or obstacles. Doing so may cause your
wheelchair to tip and cause bodily harm or damage to the wheelchair.
DO NOT use unauthorized parts, accessories, or adapters other than those
authorized by PDG.
DO NOT attempt to lift the wheelchair by any removable (detachable) parts.
DO NOT stand or use feet to apply significant pressure on the frame of the
wheelchair.
For products supplied with anti-tippers, anti-tippers must be attached at all times.

PAGE 7
Class 1 Medical
Rev. 2
DO NOT use the footplate as a platform when getting in or out of the wheelchair.
Use positioning devices as recommended by home dealers, therapists, and other
healthcare professionals.
Positioning belts should be considered to meet the user’s specific safety
requirements.
Tire Pressure
If pneumatic tires are supplied, DO NOT use your wheelchair unless it has the
proper tire pressure (psi). DO NOT over inflate the tires. Failure to follow these
suggestions may cause the tire to explode and cause bodily harm. Recommended
tire pressure is listed on the side wall of the tire.
Weight Training
PDG DOES NOT recommend the use of this wheelchair as a weight training
apparatus. PDG wheelchairs have NOT been designed or tested as a seat for any
kind of weight training. If the occupant uses said wheelchair as a weight training
apparatus, PDG shall NOT be liable for bodily injury and the warranty will be
voided immediately.
Weight Capacity
The Bentley wheelchair has a weight limitation of 250 lbs. for the standard base frame
5SAFETY AND HANDLING OF WHEELCHAIRS
“Safety and Handling” of the wheelchair requires the close attention of the wheelchair
user as well as the assistant. This manual points out the most common procedures and
techniques involved in the safe operation and maintenance of the wheelchair. It is
important to practice and master these safe techniques in order to comfortably and
safely navigate in your environment.
Use this information only as a basic guide. The techniques that are discussed on the
following pages have been used successfully by many individuals.
Individual wheelchair users often develop skills to deal with daily living activities that
may differ from those described in this manual. PDG recognizes and encourages each
individual to try what works best in overcoming architectural obstacles that they may
encounter. Techniques in this manual are a starting point for the new wheelchair user
and assistant with “safety” as the most important consideration for all.
5.1 Stability and Balance
To assure stability and proper operation of your wheelchair, you must at all times
maintain proper balance. Your wheelchair has been designed to remain upright and
stable during normal daily activities as long as you do not move your centre of gravity
beyond the boundary of the wheelchair and exceed the balance point.
Virtually all activities which involve movement in the wheelchair have an effect on the
systems center of gravity. Anti-tippers MUST be attached at all times. PDG
recommends using positioning devices for additional safety while involved in activities
that shift your weight.
DO NOT lean forward out of the wheelchair any further than the length of the
armrests. Make sure the casters are pointing in the forward position whenever
you lean forward. This can be achieved by advancing the wheelchair and then
reversing it in a straight line.

PAGE 8
Class 1 Medical
Rev. 2
PDG DOES NOT recommend the use of this wheelchair for stretching exercises. If
the occupant uses the wheelchair as a stretching exercise apparatus, keep in mind
this will result in changes to the normal balance, the center of gravity and the
weight distribution of the wheelchair and make sure stability and balance are not
compromised.
Coping with Everyday Obstacles
Coping with the irritation of everyday obstacles can be alleviated somewhat by learning
how to manage your wheelchair. Always keep in mind the position of your center of
gravity to maintain stability and balance.
WARNING: DO NOT attempt to perform a “wheelie” in your wheelchair because
of the dangerous nature of this type of maneuver.
A Note to Wheelchair Assistants
When assistance to the wheelchair user is required, remember to use good body
mechanics. Keep your back straight and bend your knees whenever tilting the
wheelchair or traversing curbs, or other obstacles.
Be aware of any removable (detachable) parts. These must NEVER be used for hand-
held or lifting supports, as they may be inadvertently released, resulting in possible
injury to the user and/or assistant(s)
When learning a new technique, have an experienced assistant help before attempting
it alone.
5.2 Tilting
WARNING: DO NOT tilt the wheelchair without assistance.
WARNING: Decreased stability may result from a seat position tilted past 0°
(neutral) or horizontal. Ensure that anti-tippers are used at all times.
When tilting the wheelchair, an assistant should grasp the back of the wheelchair on a
non-removable (non-detachable) part. Inform the wheelchair occupant before tilting
the wheelchair and remind him/her to lean back. Be sure the occupant’s feet and hands
are clear of all wheels and pinch points. In preparation to operate the tilt:
Ensure the occupant’s arms and legs are stable on the armrest and the
footrest/legrest respectively.
Ensure the tilt mechanism is clear of hands, feet or foreign objects.
DO NOT push or propel the chair with the seat tilted in a forward position.
DO NOT add chair accessories that are not specifically designed for the Bentley.
5.3 Curbs and Steps
WARNING: Maneuvering over curbs and steps can be dangerous.
WARNING: DO NOT try to climb or descend a curb or step without assistance. It
may cause your chair to exceed its balance point and tip over.
NEVER attempt to climb or descend a curb or step more than 4” high.
CAUTION: ALWAYS maneuver straight up and down a curb or step. Climbing or
descending at an angle can lead to a fall or tip.
CAUTION: be aware that dropping down from a curb or step can damage your
chair or loosen fasteners.
Use the following procedure to tackle shallow curbs, steps or obstacles:

PAGE 9
Class 1 Medical
Rev. 2
Climbing a curb or single step –Method 1
To climb over a curb or single step have the front of
the wheelchair facing the obstacle and advise your
assistant to stand at the rear of your wheelchair and
apply a continuous downward motion. This will tip the
wheelchair about the rear wheels thereby lifting the
front caster of the ground. As a balance point is
achieved and the front casters clear the curb, instruct
your assistance to roll the wheelchair forward and
slowly lower the front caster to the upper level as they
are beyond the edge of the curb or step. Following,
instruct your assistant to lift and roll the rear wheels
up to the upper level.
Climbing a curb or single step –Method 2
Unless the first assistant has exceptional upper body
strength, it is recommended that METHOD 2 uses two
(2) assistants. The second assistant should be
positioned at the front of the wheelchair lifting upward
on a non-removable (non-detachable) part of the
wheelchair frame when lifting and stabilizing the
wheelchair and when the wheelchair is being lowered
to the ground. The first assistant should stand on the
sidewalk and turn the wheelchair so that the rear
wheels are against the curb. The wheelchair should be
tilted back to the balance point and, in one continuous
downward movement, the rear wheels should be
pulled up and over the curb. DO NOT return the front
casters to the ground until the wheelchair has been
pulled backward far enough for the front casters to
clear the edge of the curb.
Descending a curb or single step
WARNING: NEVER attempt to descend down any curb or obstacle facing forward.
To descend from a curb or a single step, position your
wheelchair so that the front of the wheelchair is facing
away from the curb a couple of meters and ask your
assistant to stand behind your wheelchair. Next,
instruct your assistant to step down the curb and
carefully pull the wheelchair backwards. As the rear
wheels roll over the edge of the curb, allow them to
slowly roll down the rear wheels to the lower level.
Once the rear wheels are safely on the lower level
instruct your assistant to tip the chair about the rear
wheels, lifting the casters off the upper level and
continue to slowly roll the wheelchair backwards
taking small steps until the front casters have cleared
the curb or single step and they can be lowered to the
ground at the lower level.
Figure 5.1: Assistant positioning
for climbing curbs single steps –
method 1
Figure 5.2: Assistant positioning for
climbing curbs or single steps-
method 2
Figure 5.3: Assistant positioning
for climbing curbs single steps –
method 1

PAGE 10
Class 1 Medical
Rev. 2
5.4 Stairways and Escalators
WARNING –DO NOT use an escalator to move a wheelchair between floors. Serious
bodily injury may occur.
WARNING –DO NOT attempt to lift a wheelchair by lifting on any removable
(detachable) parts. Lifting by means of any removable (detachable) parts of a
wheelchair may result in injury to the user or damage to the wheelchair.
Extreme caution is advised when it is necessary to move an occupied wheelchair up or
down the stairs. PDG recommends using two (2) assistants and making thorough
preparations. Make sure to use ONLY secure, non-detachable parts for hand-held
supports.
Follow this procedure for moving the wheelchair
between floors when an elevator is NOT available:
1. After the wheelchair has been tipped back to the
balance point, one assistant (in the rear) backs the
wheelchair up against the first step, while securely
grasping a non-removable (non-detachable) part of
the wheelchair for leverage.
2. The second assistant, with a firm hold on a non-
detachable part of the framework, lifts the
wheelchair up and over the stair and steadies the
wheelchair as the first assistant places one (1) foot on
the next stair and repeats STEP 1.
3. The wheelchair should not be lowered and released
until the last stair has been negotiated and the
wheelchair has been rolled clear of the top of the
stairway.
5.5 Transfers to and from Other Seats
WARNING —before attempting to transfer in or out of
the wheelchair, every precaution should be taken to
reduce transfer gap distance. Turn both casters toward
the object you are transferring onto. Ensure the wheel
locks are engaged to help prevent wheels from moving.
NOTE — this activity may be performed independently
provided you have adequate mobility and upper body
strength.
1. Position the wheelchair as close as possible alongside
the seat to which you are transferring, with the front
casters pointing toward it. Engage wheel locks. Shift
body weight into seat as you transfer.
2. During independent transfer, little or no seat platform
will be beneath you. Use a transfer board if at all
possible.
Figure 5.4: Assistant
positioning for climbing
stairs
Figure 5.5: Transferring to
and from other seats

PAGE 11
Class 1 Medical
Rev. 2
5.6 Weight Distribution
WARNING –DO NOT attempt to reach objects if you have to move forward in the seat
or pick them up from the floor by reaching down between your knees.
Many activities require the wheelchair owner to
reach, bend and transfer in and out of the
wheelchair. These movements will cause a
change to the normal balance, the center of
gravity, and the weight distribution of the
wheelchair. To determine and establish your
particular safety limits, practice bending, reaching
and transferring activities in several combinations
in the presence of a qualified health professional
BEFORE attempting active use of the wheelchair.
5.7 Reaching, Leaning, and Bending Forward
Functional Reach from a Wheelchair
Proper positioning is essential for your safety. When
reaching, leaning, bending forward, it is important
to use the front casters as a tool to maintain
stability and balance.
Bending Forward
Position the front casters so that they are extended
as far forward as possible and engage wheel locks.
DO NOT LEAN FORWARD OF THE ARMRESTS.
Bending Backward
WARNING —DO NOT lean over the top of the back upholstery. This will change your
center of gravity and may cause you to tip over.
Reaching Objects on Ground
Position wheelchair as close as possible to the
desired object. Point front casters forward to create
the longest possible wheelbase. Reach back only as
far as your arm will extend without changing your
sitting position.
Figure 5.6: Center of gravity location
Figure 5.7: Forward reach in
wheelchair
Figure 5.7: Reaching objects on the ground

PAGE 12
Class 1 Medical
Rev. 2
6ENVIRONMENTAL CONDITIONS
WARNING:
1. Use extra care if you must operate your wheelchair on a wet or slick surface. If
you are in doubt, ask for help.
2. Contact with water or excess moisture may cause your chair to rust or corrode,
resulting in failure of critical components.
a. Do not use your chair in a shower, pool or other body of water. The chair
tubing and parts are NOT water-tight and may rust or corrode from the
inside.
b. Avoid excess moisture (for example, do not leave your chair in a damp
bathroom while taking a shower or store it outside).
c. If your chair does get wet (from cleaning or otherwise), dry it as soon as
possible.
3. Terrain
a. Your wheelchair is designed for use on firm, regular, even surfaces such as
typical interior spaces, concrete or asphalt.
b. Operating your wheelchair in sand, loose soil or over rough terrain may
damage wheels, casters, the footrests, or other components of your
wheelchair.
NOTE - Failure to heed these warnings could result in severe injury to yourself or others
as well or damage to your wheel chair.

PAGE 13
Class 1 Medical
Rev. 2
7STANDARD FEATURES
Figure 7.1: Standard Features
1. Lower Frame
2. Upper Frame
3. Sub-Frame Assembly
4. Gas Strut Assembly (Yellow Spring)
5. Removable – Adjustable Height Armrest – Single Post
6. Front Casters
7. Rear Wheels
8. Standard Hand Rims
9. Rear Axle Bolts/Quick Release Axles
10.Wheel locks
11.Backrest
12.Plug-in Front Rigging
13.Composite Foot Plates
14.Tilt Activator (Trigger)
15.Anti-Tippers

PAGE 14
Class 1 Medical
Rev. 2
8UNPACKING AND ASSEMBLY
NOTE – Unless the wheelchair is to be assembled immediately, retain cartons and
packing materials for use in storing the wheelchair until assembly is required
1. Check for any obvious damage to the carton or its contents. If damage is evident,
take pictures of the damages and notify your Dealer/Carrier immediately.
2. Remove all loose packing from the carton.
3. Carefully remove all components from the carton.
8.1 Inspection
Examine exterior of the wheelchair for nicks, dents, scratches or other damage. Inspect
all components. Check the rear wheels for camber. If damage is evident, notify your
Dealer/Carrier immediately.
8.2 Out of the Box Assembly Instructions
When unpacking the wheelchair, you will need to assemble the armrests, backrest, and,
front rigging (if applicable), connect the cable from the strut to the tilt activator (trigger)
and anti-tip tubes to complete the set-up.
Backrest
The seat frame has two bolts installed along the left and right side of the rear of the seat
frame. Remove these bolts on each side and place the backrest subassembly into the
back of the seat frame and replace bolts and fasten securely, see section 14.3. To attach
tilt actuator cable to the back post (trigger) follow instructions in section 14.14.2
Front Rigging
Installing the front rigging depends on the type of front rigging included with chair – For
the Easy-Out front rigging, squeeze the front rigging trigger and slide the front rigging
into the square cross-sections on the side of the upper frame until the latch aligns and
engages with the upper frame hole and snaps into place. For the standard plug-in front
rigging, push in the button on the side of the upper tube and slide into the frame until
snap button engages. For the “swing-away” style front rigging attach the front rigging on
top of the pre-installed mounted adaptor and rotate to lock into place.
Armrest Assembly
Install the arm assembly by simply sliding the arms into the armrest receivers on the
upper frame.
Cable
To install the cable, ensure the lower end of the cable housing is placed in the holes in
the junction block and then install the other end of the cable to the trigger, as usual.
Once the cable is assembled into the trigger, the assembly will be under slight tension,
and the cable housing will stay inserted in the block. Refer to section 14.14 to detailed
instructions.

PAGE 15
Class 1 Medical
Rev. 2
Anti-Tip Tubes
If anti-tip tubes are not already installed on the chair, locate them in the box and slide
them into the receivers at the back underside of the frame so that the rollers are
pointing downwards. These will prevent the chair from overturning if the centre of
gravity moves too far rearward. Anti-tip tubes are mandatory for safety and warranty
protection.
IMPORTANT — with the user sitting in the chair, check to ensure the wheelchair is
stable in all tilted/un-titled positions before dispensing the wheelchair.
9STORAGE
Store the repackaged PDG Wheelchair in a dry area away from sunlight and sources of
heat. Do not place other objects on top of the repackaged wheelchair.
10 SAFETY INSPECTION CHECKLIST
Examine the exterior of the PDG Wheelchair for nicks, dents, scratches, or other
damages. Inspect all components. If damage is evident, notify your Dealer/Carrier
immediately.
NOTE — twice per year take your wheelchair to a qualified dealer for a thorough
inspection and servicing. Regular cleaning will reveal loose or worn parts and enhance
the smooth operation of your wheelchair. To operate properly and safely, your
wheelchair must be cared for in a manner similar to a motor. Routine maintenance will
extend the life and efficiency of your wheelchair.

PAGE 16
Class 1 Medical
Rev. 2
Initial adjustments should be made to suit your personal body profile and preference.
Thereafter the following maintenance schedule is recommended:
ITEM
Initially
Inspect/Adjust
Weekly
Inspect/Adjust
Monthly
Inspect/Adjust
Every 6 Months
GENERAL
Wheelchair rolls straight (no
excessive drag or pull to one side).
×
×
Ensure all fasteners are secure.
×
×
WHEEL LOCKS
Do not interfere with tires when
rolling.
×
×
Pivot points free of wear and
looseness.
×
×
Wheel locks easy to engage.
×
×
CLOTHING GUARDS
Inspect for damage
×
×
Ensure all fasteners are secure.
×
×
SEAT/BACK UPHOLSTERY
Inspect for rips or sagging.
×
Ensure all fasteners are secure
×
×
REAR WHEELS
No excessive side movement or
binding when lifted and spun.
×
×
Quick-release axles lock properly and
lubricate
×
×
FRONT CASTER
Inspect wheel/fork assembly for
proper tension by spinning caster;
caster should come to a gradual
stop.
×
×
Wheel bearings are clean and free of
moisture.
×
×
Ensure caster stem fastener is secure
×
CAUTION: Wheels and tires should
be checked periodically for cracks
and wear, and should be replaced
when necessary.
×
×
TIRES
Inspect for flat spots and wear.
×
×
If pneumatic tires, check for proper
inflation
×
×
Inspect rear tires for cracks and
wear.
×
×
CAUTION: Wheels and tires should
be checked periodically for cracks
and wear, and should be replaced
when necessary.
×
CLEANING
Clean and wax all parts.
×
Clean upholstery and armrests.
×
Inspect axles are free from dirt, lint,
etc.
×
TILT MECHANISM
Ensure fasteners are secure and do
not show signs of excess wear
×

PAGE 17
Class 1 Medical
Rev. 2
11 MAINTENANCE
11.1 Cleaning
Periodic cleaning of all surfaces will help maintain the appearance and ensure proper
operation of your wheelchair. All surfaces can be cleaned using warm water and a mild
soap solution. Do not use abrasive cleaners on any surfaces.
11.2 Suggested Maintenance Procedures
1. Before using your wheelchair, make sure all nuts and bolts are tight. Check all parts
for damage or wear and replace them if necessary. Check all parts for proper
adjustment.
2. Keep quick-release axles, if fitted, free of dirt and lint to ensure positive locking and
proper operation. Refer to ADJUSTING THE QUICK-RELEASE AXLE in section 14.9 of
this manual.
3. If applicable, oil quick-release axles at least once (1) a month (3-in-1 oil or
equivalent).
4. Keep wheel-locks free of dirt to ensure they do not get stuck.
WARNING – If pneumatic tires are used, do not use the wheelchair unless it has the
proper tire pressure (psi). DO NOT over inflate the tires. Failure to follow these
suggestions may cause the tire to explode and cause bodily harm.
5. If tires are pneumatic, recommended tire pressure is listed on the side wall of the tire.
6. The rear wheels and casters should be checked periodically for cracks and wear, and
should be replaced when necessary at your authorized dealer or by a qualified
technician.
7. For wheelchairs with hand rims, periodically check hand rims to ensure they are
secured to the rear wheels.
12 TROUBLESHOOTING
Problems
Solution
Chair veers right
Chair veers left
Sluggish turn or performance
3 of 4 wheels contacting ground surface
If pneumatic, check tires for correct/equal
pressure
Sluggish turn or performance
Casters flutter
Squeaks and Rattles
Looseness in chair
Check for loose caster stem nuts and caster axle
bolts
Chair veers right
Chair veers left
Sluggish turn or performance
Casters Flutter
Check caster angle
Chair veers right
Chair veers left
Casters flutter
Check that both casters contact the ground at
the same time
Quick release will not lock and there is
excessive play when the wheel hub is
being pushed back and forth.
The nut on the axle needs to be adjusted.
The wheel bearing may not be seated properly.
This can occur if the bearing have be replaced
and may have not been completely seated in the
bearings.

PAGE 18
Class 1 Medical
Rev. 2
13 DAMAGE REQUIRING SERVICE BY QUALIFIED SERVICE AGENT
PDG has trained customer service representatives in many locations. To find your
nearest Customer Service Center, contact PDG directly using telephone, fax, or e-mail
contact information.
PDG PRODUCT DESIGN GROUP INC.
#103- 318 East Kent Avenue South, Vancouver, BC, Canada. V5X 4N6
Ph: [phone] Fax: [phone] E-mail: [e-mail]
Supply the serial number from the product you are attempting to service and we will be
happy to inform you of the supplier who initially provided your product.
In some circumstances it may be required that your wheelchair be returned to a
Qualified Service Agent for repairs. If any of the following conditions are observed, the
wheelchair must be serviced by a Qualified Service Agent:
Any part of the frame is cracked or broken
Any weld is cracked or broken
Always contact your Service Agent prior to sending a wheelchair for repairs. For safe and
secure shipping, the wheelchair must be boxed or fastened to a pallet to ensure it does
not become damaged during shipping. Service agent will provide specific instructions for
packaging and shipping your wheelchair. Alternatively, Qualified Service Agent may
arrange for pick-up.
14 SETUP, ADJUSTMENTS & OPTIONS
14.1 Adjustment Guide
The following instructions are intended to help in making wheelchair adjustments. It is
important to note the initial wheelchair configuration prior to making changes. When
making changes, dealers and users should do so under the guidance of a health care
professional who is knowledgeable of the abilities of the wheelchair user. Be sure that
when finished, all components are properly tightened and have been completed in
accordance with these instructions. DO NOT over tighten hardware attaching to the
frame. This could cause damage to the frame tubing or fasteners.
Tools Required
Philips Screw Driver
Allen Key……………………………….................□1/8” □5/32” □3/16” □1/4”
Adjustable or Open End Wrench.............□7/16” □3/8” □1/2” □9/16”
Socket Head Driver with Socket Heads........................................ □9/16” □3/4”

PAGE 19
Class 1 Medical
Rev. 2
14.2 Frame Options (and Identification)
Standard
Base and
Seat Frame
250 lbs Weight
Capacity.
Light Weight (LT)
Configuration
available.
Not recommended
for agitated users.
Can be identified by
rectangular shaped
crossbar at the rear
of the lower frame.
Figure 14.1
Upgraded
Base and
Seat Frame
300 lbs Weight
Capacity with
addition of a
secondary Gas
Strut.
Available for Seat
Widths up to 22”.
Figure 14.2
Heavy Duty
Base and
Seat Frame
450 lbs Weight
Capacity. Available
for all sizes, but
required for seat
width of 23” or
wider.
Requires 20”
Composite or 24”
Heavy Duty Spoke
Wheels.
Fixed Axles only.
Not compatible with
Transit Tie Down
System.
Figure 14.3

PAGE 20
Class 1 Medical
Rev. 2
Figure 14.5: Adjusting the seat depth
14.3 Seat Depth
WARNING – After adjusting, always make sure that parts are properly tightened
BEFORE using the wheelchair. The seat depth can be adjusted from 16” to 22”,
depending on the position of the rear seat depth insert. The illustration and table in
figure 14.4 show the seat depth set-up positions and can be referenced for making
adjustments.
Adjusting the Seat Depth
1. Loosen and remove the two 5/16-18
flat head fasteners on each side (see
Figure 14.5).
2. Adjust the rear seat depth insert to the
desired position.
3. Retighten the fasteners. Torque to 18
ft.lbs
14.4 Seat-To-Floor Height
WARNING – After making adjustments, always make sure that parts are properly
replaced and tightened BEFORE using the wheelchair.
The seat to floor height is measured from the top of the seat pan to the floor. It can be
adjusted from 13” to 20” depending on front caster and rear wheel combinations. The
frame consists of 3 main components: the upper frame, sub-frame and lower frame.
Additionally, a shim, or tie down plate, will be present between the lower frame and
sub-frame on some models.
Adjusting Seat to Floor Height
1. Remove the wheels, front rigging, and arms from the chair. Tip it forward so that
it is resting on the back post and front rigging receivers as shown in Figure 14.6.
2. Remove the nuts from the 3/8” hex head seat height adjustment bolts; there are
two 3/8” hex bolts on each side of the frame, as shown.
3. Remove the four hex bolts while supporting the lower frame with your other
hand.
CAUTION – When the four hex bolts are removed, the lower frame and upper frame will
be disconnected and will drop apart.
Seat Depth
16”
17”
18”
19”
20”
21”
22”
Reference
position
1
2
3
4
5
5*
6*
Figure 14.4: Seat Depth positions and Setup
