PDQ CLS User manual

CLS INSTALLATION INSTRUCTION
BLE ONLY INTERCONNECTED LOCK
2.INSTALLLOCKASSEMBLY
• Install lock chassis into bottom hole
making sure to properly engage lock body
into latchbolt
• Install inside mounting plate and secure
with (2) screws
Rev0 – 5-26-23
1.PREPAREDOOR&
INSTALLLATCHES
• Prepare door according to template
• Install deadbolt latch in top hole with
cross slot for tailpiece toward bottom
• Install beveled latch on bottom with bevel
toward door frame
• Secure with (4) combo screws
CYLINDER
ASSEMBLY
For Mechanical Concerns:
Phone: [phone]
www.pdqlocks.com
For Mechanical Concerns:
Phone: [phone]
www.pdqlocks.com
RIGHT
HAND
LEFT
HAND
RIGHT
HAND
LEFT
HAND
3.INSTALLCYLINDER
ASSEMBLY
• Install cylinder assembly from outside of
door
• If extended, retract deadbolt
Left Hand Door – Rotate tailpiece clockwise
until it stops in the vertical orientation
Right Hand Door – Rotate tailpiece counter-
clockwise until it stops in the vertical
orientation

CLS INSTALLATION INSTRUCTION
BLE ONLY INTERCONNECTED LOCK
5.INSTALLINSIDE
ESCUTCHEONANDLEVER
• Rotate thumb turn away from leading
edge of door
• Install inside escutcheon
• Secure escutcheon using two screws
• Install lever
• Install batteries and battery cover
4.PREPAREINSIDE
ESCUTCHEON
• Rotate lever driver tab to correct
orientation as shown
Rev0 – 5-26-23
DRIVER TAB
Rotate Driver Tab
For Proper
Handing
DRIVER TAB
Rotate Driver Tab
For Proper
Handing
LH/LHR RH/RHR
OUTSIDE TRIM
LH/LHR RH/RHR
OUTSIDE TRIM
