peerless-AV DS-S560-1X3 User manual

12015-07-01 #:009-9120-6 (2020-01-13)
ENG
DS-S560-1X3
375 lb
(170 kg)
MAX
46" - 60"
(117 - 152 cm)

22015-07-01 #:009-9120-6 (2020-01-13)
ENG - This product is designed to be installed on solid concrete. Hardware is included for solid concrete
installation. Before installing make sure the supporting surface will support the combined load of the equipment
and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product
may fail. Never exceed the Maximum Load Capacity. Always use an assistant or mechanical lifting equipment to
safely lift and position equipment. This product is intended for indoor use only. Use of this product outdoors could
lead to product failure or personal injury. Be careful not to pinch ngers when operating the mount. For support
please call customer care at 1-800-865-2112.
WARNING
Symbols
ENG
WARNING
ENG
x3
Screws must get at
least three full turns
and t snug.
ENG
Do not overtighten screws.
ENG
Tools Needed for Assembly.
ENG
To properly tighten screws: Tighten until screw
head makes contact, then tighten another 1/2
turn. Do not overtighten screws.
1
2
+1/2
4
3
ENG
Display center.
ENG
3/8"
(10mm)
3/8"
(10mm)

32015-07-01 #:009-9120-6 (2020-01-13)
This page intentionally left blank.ENG

42015-07-01 #:009-9120-6 (2020-01-13)
Parts List
Part #Description Qty
Apedestal 2 147-T1426
Bcover 2 145-T1809
Cvertical support bracket 6 145-T1806
Dcolumn 2 146-T1131
Eextension 2 145-T1778
Fleft adaptor bracket 3 146-1609
Gright adaptor bracket 3 146-1608
Hcross support 3 146-T1904
Icomputer cover 1 145-T1930
Jcomputer shelf 1 145-T1931
Kextension adaptor 2 145-T1935
Lcord bracket 4 146-T1321
Mknob 4 560-1160
NM8 x 16mm socket button screw 56 520-9527
OM8 square nut 24 530-1066
Pcover clip 8 590-0317
QM5 x 10mm type-f, socket pin screw 8 520-1164
Rbar nut 4 146-1319
Snylon shoulder washer 12 590-2233
TM6 x 12mm socket pin screw 12 520-1050
U1/4" power bit 1 560-0263
V5mm allen wrench 1 560-9640
W4mm allen wrench 1 560-9646
XM6 x 35mm screw 8 520-0717
Yrawl bolt #6913 8 5M9-381-H03
Parts (Before beginning, make sure you have all parts shown below).
E (2)
extension
B (2)
cover
D (2)
column
C (6)
vertical support
bracket
A (2)
pedestal G (3)
right adaptor
bracket
F (3)
left adaptor
bracket
ENG

52015-07-01 #:009-9120-6 (2020-01-13)
I (1)
computer cover
N (56)
M8 x 16mm
O (24)
M8 square nut
P (8)
cover clip
Q (8)
M5 x 10mm
U (1)
1/4" power
bit
V (1)
5mm allen
wrench
nylon shoulder
washer
S (12)
M6 x 12mm
T (12)
4mm allen
wrench
W (1)
J (1)
computer shelf
L (4)
cord
bracket
M (4)
knob
bar nut
R (4)
K (2)
extension
adaptor
H (3)
cross support
rawl bolt
Y (8)
M6 x 35mm
X (8)

62015-07-01 #:009-9120-6 (2020-01-13)
1
x2
X (4)
AD
2
N (4)
R (2)
K
x2 Do not fully tighten hardware
V

72015-07-01 #:009-9120-6 (2020-01-13)
3
E
D
x2
V
K
TIGHTEN
CONNECTING
HARDWARE

82015-07-01 #:009-9120-6 (2020-01-13)
4-1
4-2
O (4)
N (6)
C
C (6)
1/8"
(3mm)
1/8"
(3mm)
DISPLAYHEIGHT
DISPLAYHEIGHT
x6
V
V
TIGHTEN
CONNECTING
HARDWARE

92015-07-01 #:009-9120-6 (2020-01-13)
x2
5
P (4)
B
x2
6
L (2)
M (2)
LM
TIGHTEN
CONNECTING
HARDWARE
TOP VIEW

10 2015-07-01 #:009-9120-6 (2020-01-13)
7
ENG - When installing Peerless mounts on a concrete oor, the oor must be at least 8" thick with a minimum
compressive strength of 2000 psi. Never attach concrete expansion anchors to concrete covered with plaster,
drywall, or other nishing material.
WARNING

11 2015-07-01 #:009-9120-6 (2020-01-13)
4
Y (8)
7-1
Align base. Mark mounting holes.
ENG
7-3
Align base. Install using concrete anchors
provided.
ENG
3/8"
(10mm)
25.50"
(648mm)
ENG Maximum 35 ft • lb (47 N.M.).
25.50"
(648mm)
7-2
Drill mounting holes into
supporting surface
(3" (76mm) minimum
depth required).
ENG
3/8"
(10mm)
3"
(76mm)
3/8"
(10mm)

12 2015-07-01 #:009-9120-6 (2020-01-13)
8
Cross supports must center on vertical leg supports.
TIGHTEN
CONNECTING
HARDWARE
H (3)
V
ENG
Tighten.
ENG

13 2015-07-01 #:009-9120-6 (2020-01-13)
X
X
9-1
G
F
9-2
Center adaptor brackets
vertically on back of screen.
ENG
G
F
x3
STN
OR
x3
x3
W V

14 2015-07-01 #:009-9120-6 (2020-01-13)
10-1
Must hang displays on bottom row rst;
Secure pin in "locked" position.
10-2
OPTIONAL: Insert M5 x 10mm type-F socket pin screws
(Q) to lock latches. W
Q
"LOCKED"
POSITION
"LOCKED"
POSITION
x6
ENG
ENG

15 2015-07-01 #:009-9120-6 (2020-01-13)
11
Display adjustment
IN
TILT BACKWARD
OUT
TILT RIGHT
TILT FORWARD
TILT LEFT
SIDE
SIDE
SIDE
TOP
SIDE
TOP
UP DOWN
ROTATE LEFT ROTATE RIGHT
ENG

16 2015-07-01 #:009-9120-6 (2020-01-13)
This page intentionally left blank.ENG

17 2015-07-01 #:009-9120-6 (2020-01-13)
12-1
J

18 2015-07-01 #:009-9120-6 (2020-01-13)
J
Q (2)
J
I
1/8"
(3mm)
TIGHTEN
CONNECTING
HARDWARE
12-2
12-3
W
W

19 2015-07-01 #:009-9120-6 (2020-01-13)
13
Route cables through cord brackets.
L
L
ENG

Peerless Industries, Inc. (“Peerless-AV”) warrants to original end-users that each Peerless-AV®mounting product will be free from defects
in material and workmanship, under normal use, for the applicable warranty period (from date of the original installation of the product).
At its option, Peerless-AV will repair or replace, or refund the purchase price of, any product which fails to conform with this warranty.
Any implied warranty of merchantability or tness for a particular purpose shall be limited to the period of the
express warranty set forth below.
In no event shall Peerless-AV be liable for incidental or consequential damages, whether or not secured by a
security device which may be included with the product.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion of incidental or consequential damages, so
the above limitation and/or the above exclusion may not apply to you.
This warranty does not cover damage caused by incorrect selection, installation or the failure to follow Peerless-AV instructions or
warnings when installing, using or storing the product.
This warranty gives specic legal rights, and you may also have other rights which vary from state to state. To make a warranty claim in
North America, contact Peerless-AV customer care at 1-800-865-2112. See complete global warranty information for regions outside North
America at www.peerless-av.com/en-uk/customer-care/warranties-returns.
LIMITED FIVE-YEAR WARRANTY
