peerless-AV ACC450 Guide

1 of 2 ISSUED: 10-13-05 SHEET #: 202-9039-2 08-16-11
Note: Read entire instruction sheet before you start installation and assembly.
For customer care call [phone].
DF
B
• Do not begin to install your Peerless product until you have read and understood the instructions and warnings
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, please
call Peerless customer care at 1-800-865-2112.
• This product should only be installed by a qualified professional.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached
hardware and components.
• Never exceed the Maximum Load Capacity of 150 lb (68 kg).
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screws firmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding
power.
WARNING
CEGH
IJ
Installation and Assembly:
Accessory Plate for VESA®200 mm x 200 mm Pattern
Model: ACC450
Description Qty Part #
A
adapter plate 1 095-1721
BM6 x 12 mm phillips screw 4 520-1128
CM6 x 12 mm serrated washer head socket pin screw 4 510-1050
DM6 x 20 mm phillips screw 4 520-9402
EM6 x 20 mm serrated washer head socket pin screw 4 510-9554
FM8 x 10 mm phillips screw 4 520-1605
GM8 x 10 mm serrated washer head socket pin screw 4 520-1706
HM5 x 6 mm phillips screw 4 520-1023
IM5 x 6 mm serrated washer head socket pin screw 4 520-1114
J4 mm security allen wrench 1 560-9646
Parts List
Before you begin, make sure all parts shown are included with your product.
A

2 of 2 ISSUED: 10-13-05 SHEET #: 202-9039-2 08-16-11
A
Attaching Adapter Plate to Display with VESA 200 x 200 Mounting Pattern
Choose hole pattern as shown. Attach adapter
plate (A) to back of display using four M6 x 12 mm
screws (B) or M8 x 10 mm screws (F).
Notes:
• If screw (B) gets less than three threads of
engagement, attach adapter plate (A) to back of
display using four M6 x 20 mm screws (D).
• For security option, use M6 x 12 mm screws (C)
in place of (B), M6 x 20 mm screws (E) in place of
(D), and M8 x 10 mm screws (G) in place of (F).
Tighten security screws using allen wrench (J).
Note:Flat panel display
may appear slightly
different than illustrated.
• If screws don't get three complete turns in the display inserts or if screws bottom out and adapter plate is still not
tightly secured, damage may occur to display or product may fail.
WARNING
A
H or I
H or I
Thread two M5 x 6 mm screws (H), leaving .25" exposed thread, into top holes of adapter plate (A). Hook adapter
plate onto mounting plate, and secure using bottom two M5 x 6 mm screws as shown in figures 2.1 and 2.2.
Tighten all four screws.
Note: For security option, use M5 x 6 mm screws (I) in place of (H). Tighten security screws using allen wrench (J).
MOUNTING PLATE
(NOTE: MOUNTING PLATE
SHOWN WITHOUT FULL
WALL MOUNT ASSEMBLY
FOR CLARITY)
fig. 2.1 fig. 2.2
MOUNTING PLATE
(NOTE: MOUNTING PLATE
SHOWN WITHOUT FULL
WALL MOUNT ASSEMBLY
FOR CLARITY)
1
2
