Pego ECP300 EXPERT VD Series User manual

Use and maintenance manual
ELECTRICAL BOARDS FOR REFRIGERATING INSTALLATIONS
READ AND KEEP
REV. 01
12
ENG
ECP300 EXPERT

ECP300 EXPERT
Thanks for choosing this PEGO electrical panel.
This manual gives detailed information on installation, use and maintenance of ECP300
EXPERT series electrical panels and special version. Our products are designed and built
in compliance with current standards, on the specific field of refrigeration and conditioning
systems. A different use is allowed respecting the working conditions for which the panel is
designed and made.
Before using the panel it’s suggested to fully read this manual paying special attention to
the highlighted parts with the simbology descripted below:
This symbol is used to focus on notes concerning installation, use and
maintenance operations
This symbol is used to focus on important notes
This symbol is used to indicate the prohibition to do the shown operation

ECP300 EXPERT
Pag. 3
USE AND MAINTENANCE MANUAL
Rev. 01-12
INTRODUCTION
Pag. 4 1.1 General
TECHNICAL CHARACTERISTICS
Pag. 5 2.1 Product ID codes
Pag. 6 2.2 Product series - Technical characteristics
Pag. 8 2.3 Overall dimensions
Pag. 9 2.4 Identification data
Pag. 10 2.5 Transport and storage
Pag. 11 2.6 Warranty
INSTALLATION
Pag. 12 3.1 Standard assembly kit
Pag. 12 3.2 Mechanical assembly
Pag. 17 3.3 Electrical wirings
Pag. 18 3.4 Front panel connections
Pag. 19 3.5 Verifications before use
Pag. 20 3.6 Compressor motor circuit breaker calibration
Pag. 21 3.7 Electrical panel closing
FUNCTIONS
Pag. 22 4.1 ECP300 Expert panel functions
DATA PROGRAMMING
Pag. 23 5.1 Control panel
Pag. 23 5.2 Front keypad
Pag. 24 5.3 LED Display
Pag. 25 5.4 General
Pag. 25 5.5 Key to symbols
Pag. 25 5.6 Setting and displaying the set points
Pag. 26 5.7 Level 1 programming. (User Level)
Pag: 27 5.8 List of Level 1 variables
Pag. 27 5.9 Level 2 programming. (Installer Level)
Pag. 29 5.10 List of Level 2 variables
Pag. 30 5.11 Switching on the ECP300 Expert electrical panel
Pag. 30 5.12 Compressor activation/deactivation conditions
Pag. 30 5.13 Manual defrosting
Pag. 31 5.14 Pump-Down function
Pag. 32 5.15 Password protection
OPTIONAL KIT
Pag. 32 6.1 TeleNET monitoring / supervision system
Pag. 32 6.2 Net configuration with Modbus-rtu protocol
Pag. 33 6.3 Alarm/AUX relay / TeleNET switching
TROUBLESHOOTING
Pag. 38 7.1 Alarm codes
Pag. 39 7.2 Troubleshooting
MAINTENANCE
Pag. 38 8.1 General security rules
Pag. 39 8.2 Maintenance
Pag. 39 8.3 Spare parts
ALLEGATI / APPENDICES
Pag. 40 A.1 EC declaration of conformity
Pag. 41 A.2 TeleNET network connection diagram
Pag. 42 A.3 Part list
CHAP. 1
Index
CONTENTS
CHAP. 3
CHAP. 4
CHAP. 5
CHAP. 2
CHAP. 6
CHAP. 7
CHAP. 8

ECP300 EXPERT
Pag. 4
USE AND MAINTENANCE MANUAL
Rev. 0
1
-
12
GENERAL
DESCRIPTION:
A line of power and control panels for refrigeration systems with three-phase compressor or
to control only the three-phase evaporating unit, for the complete management of the room.
Magnetothermic protection and motor circuit breaker for the compressor accessible from the
front panel linked to an innovative form makes it a perfect and functional choice.
ECP300 Expert VD
A line of power and control panels for refrigeration plants with three-phase compressor up to
7.5 HP, for the complete management of the room.
Different range of power combined with the various options allow the choice of an “AD HOC”
panel for the system.
APPLICATIONS:
-Complete management of three-phase refrigerating systems up to 7,5 HP static or
ventilated, with off-cycle or electrical defrosting.
ECP300 Expert U VD
A line of power and control panels for refrigeration systems to control only the three-phase
evaporating unit where units are served by a central refrigerator or remote condenser unit.
Different range of power combined with the various options allow the choice of an “AD HOC”
panel for the system.
APPLICATIONS:
-Control of evaporating unit with electrical defrost up to 12 kW.
-Remote control for compressor enable to be linked with a power panel.
1.1
CHAPTER 1: INTRODUCTION
CHAP. 1 - Introduction

ECP300 EXPERT
Pag. 5
USE AND MAINTENANCE MANUAL
Rev. 01-12
PRODUCT ID CODES
(*) Code available on request
Panels line ECP300 Expert VD 4 series
Siemens components
PEGO identification codes Compressor motor
circuit breaker range
110300EVD401 (*) 1,1-1,6A
110300EVD402 1,4-2A
110300EVD403 1,8-2,5A
110300EVD404 2,2-3,2A
110300EVD405 2,8-4A
110300EVD406 3,5-5A
110300EVD407 4,5-6,3A
110300EVD408 5,5-8A
110300EVD409 7-10A
110300EVD410 (*) 9-12A
Panels line ECP300 Expert VD 7 series
Panels line ECP300 Expert U VD series
Siemens components
PEGO identification codes Heaters electrical
defrost
110300EUVD01 6kW
110300EUVD02 12kW
Telemecanique components
PEGO identification codes Compressor motor
circuit breaker range
110300EVD421 (*) 1-1,6A
110300EVD422 1,6-2,5A
110300EVD423 2,5-4A
110300EVD424 4-6,3A
110300EVD425 6-10A
Telemecanique components
PEGO identification codes Compressor motor
circuit breaker range
110300EVD721 (*) 6-10A
110300EVD722 9-14A
110300EVD723 13-18A
Siemens components
PEGO identification codes Compressor motor
circuit breaker range
110300EVD701 (*) 5,5-8A
110300EVD702 (*) 7-10A
110300EVD703 9-12,5A
110300EVD704 11-16A
110300EVD705 14-20A
Telemecanique components
PEGO identification codes
Heaters electrical
defrost
110300EUVD21 6kW
110300EUVD22 12kW
CHAPTER 2:
TECHNICAL CHARACTERISTICS
2.1
CHAP. 2 - Technical characteristics

ECP300 EXPERT
Pag. 6
USE AND MAINTENANCE MANUAL
Rev. 0
1
-
12
PRODUCT SERIES – TECHNICAL CHARACTERISTICS
Technical characteristics ECP300 Expert VD 4 ECP300 Expert VD 7
Box dim
ensions
400x300x135 mm
400x300x135 mm
Weight
9 Kg
10 Kg
Protection rating
IP65
IP65
Power supply
(3F+N+T)
400Vac ±10% 50/60Hz
400Vac ±10% 50/60Hz
Load type
3
-
pha e
3
-
pha e
Working temperature
-
5 ÷ + 40 °C
-
5 ÷ + 40 °C
Storage temperature
-
25 ÷ +55
°C
-
25 ÷ +55 °C
Relative ambient humidity
From 30% to 95% RH w/out conden ate
From 30% to 95% RH w/out conden ate
Altitude
< 1.000 m
< 1.000 m
Main switch general protection
Interruption power
4 pole magnetothermic
16A
“D”
Icn=6kA / Ic =8kA / Icu=15kA
4 pole magnetothermic
25A
“D”
Icn=6kA / Ic =8kA / Icu=15kA
Compressor protection
Adju table motor circuit breaker
Adju table motor circuit breaker
Control
PEGO PEGO
Defrosting
Electrical
Electrical
Status indicators
LED + di play
LED +
di play
Alarm signals
LED + Buzzer
LED + Buzzer
Inputs
Ambient probe
NTC 10K 1%
NTC 10K 1%
Evaporator probe
NTC 10K 1%
NTC 10K 1%
Door switch
Pre ent
Pre ent
High low pressure switch
Pre ent
Pre ent
Kriwan
®
connection
Pre ent
Pre ent
Compre
ssor functioning mode selection
Pump
-
down / Thermo tat
Pump
-
down / Thermo tat
Outputs
Compressor
See motor circuit breaker thermal range
relative to PEGO panel ID code
See motor circuit breaker thermal range
relative to PEGO panel ID code
Condense
r fans output 1
800W (1ph)
800W
(1ph)
Condenser fans output 2
( eparated)
total
(1ph)
Evaporator fans
500W (1ph)
2000W (1ph / 3ph)
Defrosting heaters
6000W (AC1) eq. re i tive load
9000W (AC1) eq. re i tive load
Room light
800W (AC1) re i tive load
800W (AC1) re i tive load
Solenoid valve
Pre ent
Pre ent
Compressor oil heater
Pre ent
Pre ent
Alarm relay
100W
100W
Supervision system
Tele
NET
Tele
NET
Connection diagrams :
2.2
CAP. 2 - Caratteristiche tecniche

ECP300 EXPERT
Pag. 7
USE AND MAINTENANCE MANUAL
Rev. 01-12
Technical characteristics
ECP300 Expert U VD 6 ECP300 Expert U VD 12
Box dimensions
400x300x135 mm
400x300x135 mm
Weight
9 Kg
10 Kg
Protection rating
IP65
IP65
Power supply
(3F+N+T)
400Vac ±10% 50/60Hz
400Vac ±10% 50/60Hz
Load type
3
-
pha e
3
-
pha e
Working temperature
-
5 ÷ + 40 °C
-
5 ÷ + 40 °C
Storage temperature
-
25 ÷ +55 °C
-
25 ÷
+55 °C
Relative ambient humidity
From 30% to 95% RH w/out conden ate
From 30% to 95% RH w/out conden ate
Main switch general protection
Interruption power
4 pole magnetothermic
16A
“D”
Icn=6kA / Ic =8kA / Icu=15kA
4 pole magnetothermic
25A
“
D”
Icn=6kA / Ic =8kA / Icu=15kA
Room light protection
Differential magnetothermic circuit breaker
Id=30mA
Differential magnetothermic circuit breaker
Id=30mA
Control
PEGO PEGO
Defrosting
Electrical
Electrical
Status indicators
LED + di play
LED +
di play
Alarm signals
LED + Buzzer
LED + Buzzer
Inputs
Ambient probe
NTC 10K 1%
NTC 10K 1%
Evaporator probe
NTC 10K 1%
NTC 10K 1%
Door switch
Pre ent
Pre ent
Man in cold
-
room alarm
Available
Available
Outputs
Evaporator fans
500W (1ph)
2000W (1ph / 3ph)
Defrosting heaters
6000W (AC1) eq. re i tive load
12000W (AC1) eq. re i tive load
Room light
800W (AC1) re i tive load
1200W (AC1) re i tive load
Solenoid valve
Pre ent
Pre ent
Enable condensing unit
Pre ent
Pre ent
Configurable alar
m relay (AUX alarm)
100W
100W
Door heater
Pre ent
Pre ent
Supervision system
TeleNET TeleNET
Connection diagrams :
CHAP. 2 - Technical characteristics

ECP300 EXPERT
Pag. 8
USE AND MAINTENANCE MANUAL
Rev. 0
1
-
12
OVERALL DIMENSIONS
CHAP. 2 - Technical characteristics
2.3

ECP300 EXPERT
Pag. 9
USE AND MAINTENANCE MANUAL
Rev. 01-12
IDENTIFICATION DATA
The product descripted in this manual is provided on the side with a label where its
identification data are written :
• Name of Manufacturer
• Code and model of unit electrical board
• Serial number (S/N)
• Power supply
• Auxiliary circuits power supply
• IP protection rating
2.4
CHAP. 2 - Technical characteristics

ECP300 EXPERT
Pag. 10
USE AND MAINTENANCE MANUAL
Rev. 0
1
-
12
TRANSPORT AND STORAGE
Every panel is packed to be delivered without damages in normal transport conditions. In case
of following transport it must be verified that :
 No objects or free parts could be inside the panel.
 The door is correctly closed and locked.
 In case of not using the original package, protect the product to
allow transport without any damages.
Storage room must have an adeguate temperature and low humidity value; then avoid contact
between the electrical panel and aggressive contaminating substances that could prejudice
functionality and electrical security.
2.5
CHAP. 2 - Technical characteristics

ECP300 EXPERT
Pag. 11
USE AND MAINTENANCE MANUAL
Rev. 01-12
WARRANTY
 ECP300 EXPERT panel series are covered by 24-months warranty from delivery
date against all manufacturing defects.
 In case of defect, the product will be sent with appropriate package to our factory or
any authorized Service center.
 Customer has granted the repair of detective product with spare parts and labour
included. The expenses and transport risk are totally at Customer charge.
 Every warranty intervention does not prolong nor renews warranty expiration date.
 Warranty excluded for:
oDamages result of tampering, impact or improper installation.
oBehaviour not in compliance with Manufacturer prescriptions and instructions.
oRepair intervention made by unauthorized people.
In all these cases repair cost will be totally at Customer charge.
 Warranty intervention service may be refused if the device results modified or
changed.
 The Manufacturer declines every responsibility for any direct or indirect damages to
animal, people or things in consequence of missing observance of all the
prescriptions shown in the user manual, specially instructions regarding installation,
use and maintenance of the device.
 For all not expressely indicated, usual law rules are applied and in particular
art.1512 C.C.
 For every controversy we mean elected and recognized by the parts the
competence of “Foro di Rovigo”.
 PEGO S.r.l. cannot be held liable for possible errors or inaccuracies written in this
manual as a result of printing or transcription errors
 PEGO S.r.l. reserves the right to modify its products as it deems necessary without
altering its main characteristics.
 Each new release of a PEGO user manual replaces previous ones.
CHAP. 2 - Technical characteristics
2.6

ECP300 EXPERT
Pag. 12
USE AND MAINTENANCE MANUAL
Rev. 0
1
-
12
STANDARD ASSEMBLY KIT
For the purposes of assembly and use, the electronic ECP300 EXPERT control unit comes
with:
• N° 4 seals, to be fitted between the fixing screws and the box back panel
• N° 1 use and maintenance manual.
• N° 1 electrical drawing.
• N° 1 drilling layout.
• N° 2 probes NTC 10K 1%
MECHANICAL ASSEMBLY
 Each panel is conceived to be wall-mounted; please choose depending on the
weight a correct fixing method.
 Install the device in places where the protection rating is observed.
 To effect correct electrical connection and maintain the protection rating, use
appropriate cable glands and plugs to ensure a good seal
 Install the device at height allowing the installer an easier use and maintenance.
The installer must not be in danger when it’s working on the panel. Height must
be between 0,6 and 1,7 mt from the ground.
 Install the device away from fire and heat sources and possibly repaired from
weather shelter.
Below we show step by step how to correctly install the panel.
CHAPTER 3: INSTALLATION
CHAP. 3 - Installation
3.2
3.1

ECP300 EXPERT
Pag. 13
USE AND MAINTENANCE MANUAL
Rev. 01-12
Fig. 1: Pull up transparent cover protecting
the general magnetothermic circuit
breaker.
Fig. 2: Remove screw cover on the right-hand
side.
Fig. 3: Undo the 4 fixing screws at the front of
the box.
CHAP. 3 - Installation

ECP300 EXPERT
Pag. 14
USE AND MAINTENANCE MANUAL
Rev. 0
1
-
12
Fig. 4: Close the transparent protection cover.
Fig. 5: Open the front of the box, lift it and
slide the two hinges out as far as they
will go.
.
Fig. 6: Bend the hinges and rotate the front
panel by 180° downward to get access
inside the panel; then disconnect the
connector to electronic card.
CHAP. 3 - Installation

ECP300 EXPERT
Pag. 15
USE AND MAINTENANCE MANUAL
Rev. 01-12
Fig. 7: Press on the sides of the hinges to
remove them from their seats and so
completely remove the front panel
Fig. 8: Press with a screwdriver on the 4
preimpressed holes on the bottom to
prepare fixing of the panel.
.
Fig. 9: Using the furnished drilling layout make
four fixing holes on the wall.
CHAP. 3 - Installation

ECP300 EXPERT
Pag. 16
USE AND MAINTENANCE MANUAL
Rev. 0
1
-
12
Fig.10: Using holes made on previous point fix
the bottom with 4 screws of a length
suitable for the thickness of the wall to
which the panel will be attached. Fit a
o-ring (supplied) between each screw
and the box backing.
.
Fig.11: Now make the electrical wirings as
indicated in the next chapter
.
CHAP. 3 - Installation

ECP300 EXPERT
Pag. 17
USE AND MAINTENANCE MANUAL
Rev. 01-12
ELECTRICAL WIRINGS
 For the electrical wirings please refer to the wiring diagram and technical
characteristics of the panel model to be installed.
 Panel power supply must be on a dedicated line, and must be placed a
device suitable for protection against indirect contacts upstream the line
(differential interruptor).
 Do not fit power supply wiring and signal wiring (probes/sensors and
digital inputs) in the same raceways or ducts.
 Do not use multi-polar cables in which there are wires connected to
inductive/power loads or signalling wires (e.g. probes/sensors and digital
inputs).
 Minimise the length of connector wires so that wiring does not twist into a
spiral shape as this could have negative effects on the electronics.
 When it is necessary to make a probe/sensor extension, the wires must
have a cross-section of at least 1 mm
2
.
 All wiring must be of a cross-section suitable for relevant power levels.
Insulation degree must be compatible with the applied voltages.
Preferably use cables with insulator not propagating the flame and a low
toxic smoke emission if interested by fire.
 It is obligatory to connect clamp marked with PE abbreviation to the
ground of the supply system. If necessary, please verify ground system
efficiency.
 Do not connect to the PE clamp conductors different from the external
protection one.
CHAP. 3 - Installation
3.3

ECP300 EXPERT
Pag. 18
USE AND MAINTENANCE MANUAL
Rev. 0
1
-
12
FRONT PANEL CONNECTION
Hook front panel and reconnect the electronic card connector as indicated below.
Fig.12: Hook the frontal panel back up to the
lower part of the box by inserting the
two hinges in their seats.
Fig.13: Bend the hinges and rotate the front
panel downwards 180° to gain access
inside the panel and then reconnect
the electronic card connector.
.
Fig.13: In case panel is connected with
TeleNET or Alarm/Aux relay is used
wirings must be done directly on the
electronic card clamps.
It’s suggested to put that wirings
beside the connection cables from
electronic card and bottom of the box.
For further clarification on the clamps
please refer to the chapter “TeleNET
SUPERVISING AND MONITORING
SYSTEM”.
3.4
CHAP. 3 - Installation

ECP300 EXPERT
Pag. 19
USE AND MAINTENANCE MANUAL
Rev. 01-12
VERIFICATIONS BEFORE USE
 After doing the wirings, please verify using the wiring diagram on the
correct execution of the connections.
 Please check the correct screw clamping.
 Check, when possible, the correct functioning of the outside protection
devices.
 Please correctly calibrate the motor circuit breaker (if present) dedicated
to the compressor as indicated in the next chapter.
 After powering the electrical panel please check the correct current
absorption on the loads, and after few hours of functioning check the
good tightening of screws on terminal blocks (included power supply line
connection). Warning: before doing that it’s necessary to cut off power
sectioning power supply upstream the line and block it with a padlock for
max. safety. Before any operation verify with a tester the absence of
voltage.
CHAP. 3 - Installation
3.5

ECP300 EXPERT
Pag. 20
USE AND MAINTENANCE MANUAL
Rev. 0
1
-
12
COMPRESSOR MOTOR CIRCUIT BREAKER CALIBRATION
Below we show step by step how to correctly calibrate motor circuit breaker dedicated to the
compressor.
Fig.12: When the system is started for first
time it’s suggested to calibrate the
motor circuit breaker on the
compressor power circuits. Using an
ammeter verify the effective
absorption.
.
Fig.13: Make the motor circuit breaker
calibration basing on the measured
absorption. Any way the set up value
must not be higher than the one
expected by the compressor
manufacturer. Warning: a wrong
calibration may cause compressor
breakdown or bad intervention of the
motor circuit breaker.
Fig.14: To make the calibration use the
regulation screw on the front side of
motor circuit breaker.
.
CHAP. 3 - Installation
3.6
