Securit 800L
COMFORTABLE SECURITY, USER-FRIENDLY DESIGN
8 Zone Control Panel

SPECIFICATIONS
HSCE-Securit800L-02-EN(11/05)SB-B
© 2005 Honeywell International Inc.
Honeywell Security
Honeywell International Inc.
2 Redwood Crescent
East Kilbride
G74 5PA
Scotland
Tel [phone]
www.honeywell.com/security/uk/intruder
Eight Zones Alarm: 6 Programmable for: Alarm, Entry/Exit, Access (walk through), Personal Attack, Part Set
Entry, Part Set Isolation. 1 Programmable for: Entry, Alarm, Fire, Keyswitch.
1 Fixed: Entry/Exit.
Home Set Facility: Gives flexibility by automatically isolating pre-programmed zones, allowing the system to be
armed while the User remains inside.
Manual Isolation: The system can be tailored for any situation that arises by isolating individual zones which
have not been programmed for Home or Part Set Isolation.
Remote P.A. option: The Remote keypads can be programmed to give a Personal Attack Feature, using the *
and # Keys.
Extension Speaker Output: For greater enhanced sounds, up to two 16 Ohm extension speakers can be fitted.
Chime Function: Enabling this feature allows Monitoring of chosen zones while the panel is disarmed.
Two User Codes: Main User code plus second code for children or cleaner etc.
Securit 800L CONTROL PANEL
Dimensions: 261mm x 266mm x 88mm (h x w x d)
Material: White, epoxy powder coated, 18 swg shell
Weight: 3.10 Kg
Mains Supply Voltage: 230 V AC Nominal
PSU Output Voltage: 13.6 V Nominal
Maximum Output Current: 1 A (total)
Event Memory: Allows checking of past events
Panel Quiescent: 40 mA.
Normal Operating Temperature: 0°C to 40°C
Humidity: 10 to 90% R.H. non-condensing
KEYPAD
Dimensions: 70mm x 120mm x 25mm (h x w x d)
Weight: 0.13 Kg
Supply Voltage: 12V
Quiescent Current: 20 mA.
Active: 45 mA.
Maximum Number Allowed: Six
Approvals: CE Designed to comply with BS4737 Part I
Order Part Number: ST800L-UI
Securit 800L
8 Zone Control Panel
Versatile Installation
User-Friendly Design
Easy to Operate Remote Keypad
