Pego ECP200 BASE Series User manual

ECP 200 BASE 2 / 4
USE AND MAINTENANCE MANUAL
REV. 01-09

ECP200 BASE 2/4

ECP200 BASE 2/4
Page 3
USE AND MAINTENANCE MANUAL
Rev. 01-09
INTRODUCTION
Page 4 1.1 General
Page 4 1.2 Product ID codes
Page 5 1.3 Overall dimensions
Page 5 1.4 Identification data
INSTALLATION
Page 6 2.1 Important information for the installer
Page 6 2.2 Standard assembly kit
Page 7 2.3 Installing the unit
FUNCTIONS
Page 8 3.1 ECP200 BASE panel functions
TECHNICAL CHARACTERISTICS
Page 9 4.1 Technical characteristics
Page 10 4.2 Warranty
PARAMETER PROGRAMMING
Page 11 5.1 Control panel
Page 11 5.2 Frontal keypad
Page 12 5.3 LED display
Page 13 5.4 General
Page 13 5.5 Key to symbols
Page 13 5.6 Setting and displaying set points
Page 14 5.7 Level 1 programming
Page 15 5.8 List of Level 1 variables
Page 16 5.9 Level 2 programming
Page 16 5.10 List of Level 2 variables
Page 18 5.11 Switching on the ECP200 BASE electronic controller
Page 18 5.12 Compressor activation/deactivation conditions
Page 18 5.13 Manual defrosting
Page 19 5.14 Hot gas defrosting
Page 19 5.15 Pump down function
Page 19 5.16 Password protection
OPTIONAL KITS
Page 20 6.1 TeleNET monitoring / supervision system
Page 21 6.2 ALARM RELAY /TeleNET switching
TROUBLESHOOTING
Page 24 7.1 Troubleshooting
ALLEGATI / APPENDICES
Page 23 A.1 EC declaration of conformity
Page 24 A.2 ECP200 BASE 4 wiring diagram
Page 25 A.3 ECP200 BASE 4A wiring diagram
Page 26 A.4 ECP200 BASE 2 wiring diagram
Page 27 A.5 ECP200 BASE 2A wiring diagram
Page 28 A.6 Connection example (1) - ECP200 BASE4 /BASE4A
Page 29 A.7 Connection example (2) - ECP200 BASE4 /BASE4A
Page 30 A.8 Connection example (3) - ECP200 BASE2 /BASE2A
Page 31 A.9 Connection example (4) - ECP200 BASE2 /BASE2A
Page 32 A.10 TeleNET network connection diagram
Page 33 A.11 SCHINT230 OPTIONAL KIT
Page 34 A.12 SCHINT230 OPTIONAL KIT wiring diagram
CONTENTS
CHAP. 1
CHAP. 2
CHAP. 3
CHAP. 4
CHAP. 5
CHAP. 6
CHAP. 7

ECP200 BASE 2/4
Page 4 USE AND MAINTENANCE MANUAL Rev. 01-09
GENERAL
The electronic controllers of the ECP200 BASE series have been designed to control
static or ventilated cold rooms.
The ECP200 BASE 4 electronic board allows the user to control all the components on a
refrigeration unit such as compressor, evaporator fans, defrosting elements and cold room
light.
The applications are:
- single-phase static or ventilated refrigeration systems up to 2 HP, with off-cycle or
electrical defrosting
- out of room unit to be connected to power board for compressor, defrosting and fan
start.
- single-phase evaporator control unit with cold solenoid consensus or remote
condensing unit consensus
The ECP200 BASE 2 electronic board allows the user to control the compressor and room
light.
The applications are:
- single-phase refrigeration systems up to 2 HP with off-cycle defrosting.
- out of room unit to be connected to power board for compressor start.
The ABS controller box is simple to install and can easily be wall-mounted as the ECP200
BASE is extremely compact and features an IP65 protection rating.
PRODUCT ID CODES
ECP200 BASE 2 controls and manages compressor and
room light.
ECP200 BASE 2 A controls and manages compressor and
room light. Alarms relay.
ECP200 BASE 4 controls and manages compressor,
defrosting elements, evaporator fans and
room light.
ECP200 BASE 4 A controls and manages compressor,
defrosting elements, evaporator fans and
room light. Alarms relay.
1.1
1.2
CHAPTER 1: INTRODUCTION
CHAP. 1 - Introduction

ECP200 BASE 2/4
Page 5
USE AND MAINTENANCE MANUAL
Rev. 01-09
OVERALL DIMENSIONS
IDENTIFICATION DATA
The unit described in this manual has an ID plate on the side showing all the relevant
identification data:
• Name of Manufacturer
• Code and model of unit electrical board
• Serial number
• IP protection rating
• Power supply
1.3
1.4
CHAP. 1 - Introduction

ECP200 BASE 2/4
Page 6 USE AND MAINTENANCE MANUAL Rev. 01-09
IMPORTANT INFORMATION FOR THE INSTALLER
1. Install the device in places where the protection rating is observed and try not to
damage the box when drilling holes for wire/pipe seats.
2. Do not use multi-polar cables in which there are wires connected to inductive/power
loads or signalling wires (e.g. probes/sensors and digital inputs).
3. Do not fit power supply wiring and signal wiring (probes/sensors and digital inputs) in
the same raceways or ducts.
4. Minimise the length of connector wires so that wiring does not twist into a spiral shape
as this could have negative effects on the electronics.
5. Fit a general protection fuse upstream from the electronic controller.
6. All wiring must be of a cross-section suitable for relevant power levels.
7. When it is necessary to make a probe/sensor extension, the wires must have a cross-
section of at least 1 mm2.
STANDARD ASSEMBLY KIT
For the purposes of assembly and use, the electronic ECP200 BASE control unit comes
with:
• N° 3 seals, to be fitted between the fixing screws and the box back panel
• N° 1 user’s manual.
CHAPTER 2: INSTALLATION
CHAP. 2 - Installation
2.1
2.2

ECP200 BASE 2/4
Page 7
USE AND MAINTENANCE MANUAL
Rev. 01-09
(
(
(
INSTALLING THE UNIT
Fig. 1: Undo the 4 screws on the front of the panel.
Fig. 2: Use the three existing holes to fix the box back panel
to the wall: use three screws of a length suitable for the
thickness of the wall to which the panel will be attached. Fit a
rubber washer (supplied) between each screw and the box
backing.
Make all the electrical connections as illustrated in the diagram for the corresponding
model (see relative table in APPENDICES).
To effect correct electrical connection and maintain the protection rating, use
appropriate wire/raceway grips to ensure a good seal.
Route the wiring inside the unit in as tidy a fashion as possible: be especially careful to keep power
wires away from signal wires. Use clips to hold wires in place.
Fig. 3: close the front panel, making sure that all the wires are
inside the box and that the box seal sits in its seat properly.
Tighten the front panel using the 4 screws, making sure the O-rings
on the head of each screw are used.
Power up the panel and carry out thorough reading/programming of
all the parameters.
Be careful not to over-tighten the closure screws as this could warp the box and
compromise proper operation of the membrane-type keypad.
Install short-circuit overload safety devices on all the power cables connected to the
ECP200 controller so as to prevent damage to the device. Work and/or maintenance
must ONLY be carried out on the unit after disconnecting the panel from the power supply and
from any inductive/power loads: doing so allows the worker to do his job safely.
CHAP. 2 - Installation
2.3

ECP200 BASE 2/4
Page 8 USE AND MAINTENANCE MANUAL Rev. 01-09
ECP200 BASE PANEL FUNCTIONS
- Display and adjustment of cold room temperature accurate to 0.1 °C.
- Display of evaporator temperature from parameter
- System control activation/deactivation
- System warnings (probe/sensor errors, minimum and maximum temperature warnings,
compressor shutdown)
- Evaporator fans control
- Automatic and manual defrost (static, heating element, cycle inversion)
- Direct control of compressor unit up to 2 HP
- Room light, via panel key or door switch
- Alarms/auxiliary relay
CHAP. 3 - Functions
CHAPTER 3: FUNCTIONS
3.1

ECP200 BASE 2/4
Page 9
USE AND MAINTENANCE MANUAL
Rev. 01-09
TECHNICAL CHARACTERISTICS
Power supply
Voltage 230 V~ ±10% 50/60 Hz
Max power ~ 7 VA
Cold room conditions
Working temperature -5 - 60°C
Storage temperature -10 - 70°C
Relative humidity Less than 90%
General characteristics
Type of sensors that can be connected NTC 10K 1%
Resolution 0.1°C
Sensor read precision ± 0.5°C
Read range -45…+45
ECP200 BASE 4 - Output characteristics - max applicable load (230 V AC)
Compressor 1500 W (AC3)
Elements 3000 W (AC1)
Fans 500 W (AC3)
Room light 800 W (AC1)
Alarm contact (non-powered contact) 100 W (BASE 4 A version only)
ECP200 BASE 2 - Output characteristics - max applicable load (230 V AC)
Compressor (non-powered contact) 1500W (AC3)
Room light (non-powered contact) 800W (AC1)
Alarm contact 100W (BASE 2 A version only)
Dimensional characteristics
Dimensions 19.3 cm x 7.9 cm x 20.3 cm (HxDxL)
Insulation / mechanical characteristics
Box protection rating IP65
Box material Self-extinguishing ABS
Type of insulation Class II
CHAP. 4 - Technical characteristics
CHAPTER 4: TECHNICAL CHARACTERISTICS
4.1

ECP200 BASE 2/4
Page 10 USE AND MAINTENANCE MANUAL Rev. 01-09
WARRANTY
The electronic controllers in the ECP200 BASE series are covered by a 24-month
warranty against all manufacturing defects, valid from date of delivery. If the system
malfunctions as a result of tampering, impact or improper installation the warranty will
automatically be rendered null and void. It is strongly recommended that you observe all
instructions/information regarding the technical characteristics of the device.
WARNING !
Any modifications made to wiring and/or internal components or any work
carried out in a way that fails to comply with the information/instructions in this
manual shall render the warranty null and void immediately.
Modifications/improper work may cause malfunctions, irreparable damage,
serious injury or put persons/objects in danger.
PEGO S.r.l. cannot be held liable for possible errors or inaccuracies written in
this manual as a result of printing or transcription errors.
PEGO S.r.l. reserves the right to modify its products as it deems necessary
without altering its main characteristics. Each new release of a PEGO user
manual replaces previous ones.
4.2
CHAP. 4 – Technical characteristics
)

ECP200 BASE 2/4
Page 11
USE AND MAINTENANCE MANUAL
Rev. 01-09
CONTROL PANEL
FRONT KEYPAD
1. key: AUXILIARY RELAY CONTROL (on the version with alarm relay
controls the relay manual if parameter AU=1)
2. key: UP / MUTE WARNING BUZZER
3. key: STAND BY (if the system shuts down the LED flashes)
4. key: room temperature SETTING
5. key: DOWN / MANUAL DEFROST
6. key: ROOM LIGHT
CHAP. 5 – Parameter programming
CHAPTER 5: PARAMETER PROGRAMMING
5.1
n
p
q
r
s
o
5.2

ECP200 BASE 2/4
Page 12 USE AND MAINTENANCE MANUAL Rev. 01-09
LED DISPLAY
1. Cold room temperature / parameters
2. Stand-by (flashes on stand-by. Outputs are deactivated)
3. Room light (flashes if door switch activated)
4. Cold (indicates activation of compressor)
5. Fans
6. Defrosting
7. Auxiliary
8. Alarm/warning
CHAP. 5 - Programmazione dati
5.3
o
p
q
r
s
t
u
n

ECP200 BASE 2/4
Page 13
USE AND MAINTENANCE MANUAL
Rev. 01-09
GENERAL
To enhance safety and simplify the operator’s work, the ECP200 BASE system has two
programming levels; the first level (Level 1) is used to configure the frequently-modified
SETPOINT parameters. The second programming level (Level 2) is for general parameter
programming of the various controller work modes.
It is not possible to access the Level 2 programming directly from Level 1: you must exit
the programming mode first.
KEY TO SYMBOLS
For purposes of practicality the following symbols are used:
• (t)the UP key is used to increase values and mute the alarm.
• (u)the DOWN key is used to decrease values and force defrosting.
SETTING AND DISPLAYING THE SET POINTS
1. Press the SET key to display the current SETPOINT (temperature)
2. Hold down the SET key and press the (t) or (u) keys to modify the SETPOINT.
Release the SET key to return to cold room temperature display: the new setting will be
saved automatically.
5.4
CHAP. 5 – Parameter programming
5.5
5.6

ECP200 BASE 2/4
Page 14 USE AND MAINTENANCE MANUAL Rev. 01-09
LEVEL 1 PROGRAMMING (User level)
To gain access to the Level 1 configuration menu proceed as follows:
1. Press the (t) and (u)keys simultaneously and keep them pressed for a few seconds
until the first programming variable appears on the display.
2. Release the (t) and (u)keys.
3. Select the variable to be modified using the (t) or (u) key.
4. When the variable has been selected it is possible:
• to display the setting by pressing SET key
• to modify the setting by pressing the SET key together with the (t) or (u)key.
When configuration values have been set you can exit the menu by pressing the (t) and
(u)keys simultaneously for a few seconds until the cold room temperature reappears.
5. The new settings are saved automatically when you exit the configuration menu.
CHAP. 5 - Programmazione dati
5.7

ECP200 BASE 2/4
Page 15
USE AND MAINTENANCE MANUAL
Rev. 01-09
LIST OF LEVEL 1 VARIABLES (User level)
VARIABLES MEANING VALUE DEFAULT
r0 Temperature difference compared to main SETPOINT 0.2 - 10 °C 2°C
d0 Defrost interval (hours) 0 - 24 hours 4 hours
d2
End-of-defrost setpoint.
Defrost is not executed if the temperature read by the
defrost sensor is greater than d2
(If the sensor is faulty defrosting is timed)
-35 - 45 °C 15°C
d3 Max defrost duration (minutes) 1 - 60 min 25 min
d7
Drip duration (minutes)
At the end of defrost the compressor and fans remain at
standstill for time d7, the defrost LED on the front panel
flashes.
0 - 10 min 0 min
F5
Fan pause after defrost (minutes)
Allows fans to be kept at standstill for a time F5 after
dripping. This time begins at the end of dripping. If no
dripping has been set the fan pause starts directly at the end
of defrost.
0 - 10 min 0 min
A1
Minimum temperature alarm
Allows user to define a minimum temperature for the room
being refrigerated. Below value A1 an alarm trips: the alarm
LED flashes, displayed temperature flashes and the buzzer
sounds to indicate the problem.
- -45°C
A2
Maximum temperature alarm
Allows user to define a maximum temperature for the room
being refrigerated. Above value A2 an alarm trips: the alarm
LED flashes, displayed temperature flashes and the buzzer
sounds to indicate the problem.
- +45°C
tEu Evaporator sensor temperature display
Displays
evaporator
temperature
(displays nothing
if dE =1)
read only
5.8
CHAP. 5 - Parameter programming

ECP200 BASE 2/4
Page 16 USE AND MAINTENANCE MANUAL Rev. 01-09
LEVEL 2 PROGRAMMING (Installer level)
To access the second programming level press the UP (t) and DOWN (u)keys and the
LIGHT key simultaneously for a few seconds.
When the first programming variable appears the system automatically goes to stand-by.
1. Select the variable to be modified by pressing the UP (t) and DOWN (u)keys.
When the parameter has been selected it is possible to:
2. View the setting by pressing the SET key.
3. Modify the setting by holding the SET key down and pressing the (t) or (u)key.
4. When configuration settings have been completed you can exit the menu by pressing
the (t) and (u)keys simultaneously and keeping them pressed until the room
temperature reappears.
5. Changes are saved automatically when you exit the configuration menu.
6. Press the STAND-BY key to enable electronic control.
LIST OF LEVEL 2 VARIABLES (Installer level)
VARIABLES MEANING VALUES DEFAULT
AC Door switch status 0= normally open
1= normally closed 0
F3 Fan status with compressor off
0 = Fans run continuously
1 = Fans only run when
compressor is working
1
F4 Fan pause during defrost
0 = Fans run during defrost
1 = Fans do not run during
defrost
1
dE
Sensor presence
If the evaporator sensor is disabled
defrosts are carried out cyclically with
period d0: defrosting ends when an
external device trips and closes the remote
defrost contact or when time d3 expires.
0 = evaporator sensor present
1 = no evaporator sensor
0
d1 Defrost type, cycle inversion (hot gas) or
with heater elements
1= hot gas
0= element 0
Ad Network address for connection to the
TeleNET supervision system 0 - 31 0
Ald Minimum and maximum temperature
signalling and alarm display delay 1…240 min 120 min
C1
Minimum time between shutdown and
subsequent switching on of the
compressor.
0…15 min 0 min
CAL Cold room sensor value correction -10…+10 0
Pc Compressor protection contact status 0 = NO
1 = NC 0 = NO
CHAP. 5 - Data programming
5.9
5.10

ECP200 BASE 2/4
Page 17
USE AND MAINTENANCE MANUAL
Rev. 01-09
doC
Compressor safety time for door
switch: when the door is opened the
evaporator fans shut down and the
compressor will continue working for time
doC, after which it will shut down.
0…5 minutes 0
Fst
FAN shutdown TEMPERATURE
The fans will stop if the temperature value
read by the evaporator sensor is higher
than this value.
-45…+45°C +45°C
Fd Fst differential 0…+10°C 2°C
tA NO – NC alarm relay switching
0=activates when alarm is on
1=deactivates when alarm is
on
1
AU Auxiliary/alarm relay control (only on
version with relay fitted)
0=alarm relay
1=manual auxiliary relay
controlled via AUX key
2= automatic auxiliary relay
managed by StA temp. setting
with 2°C differential
3= relay disabled / TeleNET
function
4= pump down function (see
5.15)
5= free voltage contact for
condensing unit (AUX relay
and compressor relay in
parallel)
0
StA Temp. setting for aux. relay -45…+45°C 0
In1
Man in cold room alarm
Select input INP1 on the board as
compressor protection alarm or as man in
cold room alarm (contact NC).
0 = compressor protection
1 = man in room alarm 0
P1 Password type of protection
( active when PA is not equal 0)
0 = only display set point
1= display set point, AUX,
light access
2= access in programming not
permitted
3= access in second level
programming not permitted
3
PA Password
(see P1 for the type of protection)
0...999
0 = not active 0
reL Software release indicates software version Read only
CHAP. 5 - Data programming

ECP200 BASE 2/4
Page 18 USE AND MAINTENANCE MANUAL Rev. 01-09
SWITCHING ON THE ECP200 BASE ELECTRONIC CONTROLLER
After wiring the electronic controller correctly, power up at 230 V AC; the display panel will
immediately emit a beep and all the LEDs will come on simultaneously for a few seconds.
COMPRESSOR ACTIVATION/DEACTIVATION CONDITIONS
The ECP200 BASE controller activates the compressor when cold room temperature
exceeds setting+differential (r0); it deactivates the compressor when cold room
temperature is lower than the setting.
MANUAL DEFROSTING
To defrost just press the dedicated key (see section 5.2) to activate the elements relay.
Defrosting will not take place if the end-of-defrost temperature setting (d2) is lower than
the temperature detected by the evaporator sensor. Defrosting ends when the end-of-
defrost temperature (d2) or maximum defrost time (d3) is reached.
5.11
5.12
CHAP. 5 – Parameter programming
5.13

ECP200 BASE 2/4
Page 19
USE AND MAINTENANCE MANUAL
Rev. 01-09
HOT GAS DEFROSTING
Set parameter d1 =1 to defrost in cycle inversion mode.
The compressor relay and defrost relay are activated throughout the defrost phase.
To ensure proper control of the system the installer must use the defrost output: this must
allow opening of the cycle inversion solenoid valve and closure of the liquid solenoid valve.
For capillary systems (without thermostat valve) it is only necessary to control the cycle
inversion solenoid valve via the defrost relay control.
PUMP DOWN FUNCTION
Pump down function is activated when parameter AU=4 (only for version with AUX/Alarm
relay).
Connect pump down pressostat on the digital input 1-3. The compressor is directly
controlled by pressostat.
Connect evaporator solenoid valve on the AUX relay. The solenoid is controlled directly by
thermostat.
PASSWORD FUNCTION
When parameter PA is setting with value different to 0 the protection function is activated.
See parameter P1 for the different protection.
When PA is setting the protection start after two minutes of inactivity. On display appear
000. With up/down modify the number, with set key confirm it.
Use universal number 100 if you don’t remember the password.
CHAP. 5 - Parameter programming
5.14
5.15
5.16

ECP200 BASE 2/4
Page 20 USE AND MAINTENANCE MANUAL Rev. 01-09
TeleNET MONITORING/SUPERVISION SYSTEM
For connections regarding the TeleNET monitoring/supervision system see APPENDIX
A.10 (page 32) of this manual and, for the ECP200 BASE4A and ECP200 BASE2A
models, jumper JP2 as described in 6.2 on page 21.
-
CHAP. 6 - Optional kit
s
CHAPTER 6: OPTIONAL KITS
6.1
TeleNE
T
SYSTEM
