Pelsis LURALITE PLUS R4 User manual

Please read these instructions carefully and store in a safe
place for future reference.
LURALITE PLUSTM
As part of the Insect-O-Cutor brand of insect control
products, Luralite PlusTM is an easy to service and highly
effective decorative insect control unit for use within front of
house applications. Luralite PlusTM utilises highly effective UV
lamps and is designed for use with a high specification
Glupac®glueboard.
CONTENTS OF PACKAGE
- 1 x Luralite Plus flykiller
- 1 x Mains cable (Type X)
- 1 x Glupac®glueboard
- 2 x Screws and wall plugs
- 2 x 15W High powered insect attractive UV lamps (fitted)
WARNING - THIS APPLIANCE MUST BE EARTHED (CLASS 1)
INSECT CONTROL PRODUCTS
Luralite PlusTM utilises high powered ultra violet lamps to
attract flying insects and retains the caught insects on a
glueboard for inspection or hygienic disposal.
WARNING
Luralite PlusTM is not to be used by children or persons with
reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction.
Children should be supervised to ensure they do not play
with the appliance.
If the mains cable is damaged it must be replaced by a
specialist mains cable available from Pelsis Ltd or your
supplier.
Not suitable for applications where potentially explosive
environments may exist.
POSITIONING AND GUIDANCE FOR USING LURALITE PLUS™
THIS UNIT IS FOR INDOOR USE ONLY, NOT SUITABLE FOR USE
IN BARNS, STABLES & SIMILAR LOCATIONS. KEEP OUT OF
REACH OF CHILDREN.
Luralite PlusTM should ideally be fixed around two meters above
the ground, preferably in the darkest place within the area to
be protected. Do not position the unit close to windows,
skylights or other sources of light, or where it may be obscured
by furniture, doors or other obstacles. Ideally, Luralite PlusTM
should be visible from every part of the area to be protected.
INSTALLATION
INSTALLATION SHOULD BE CARRIED OUT BY SERVICE
PERSONNEL ONLY.
Luralite PlusTM should be mounted to a vertical surface using
the supplied wall plugs and fixing screws. For ease of
installation and servicing, the front guard can be swung
open by first lifting up, then pulling forward. Once installed in
position, fit the Glupac®glueboard in position as described in
the glueboard replacement section of this document. Use
the removable mains lead and plug to connect the Luralite
PlusTM to an appropriate power supply.
Luralite Plus
Decorative Glueboard Insect Control
MOUNTING FIXING CENTRES
METHOD Luralite Plus
Wall 380mm
USING LURALITE PLUSTM
Luralite PlusTM should ideally be in operation for 24 hours a
day, ensuring your premises are kept free of flying insects.
Insects are most attracted to Luralite PlusTM units at night when
there is no competition from daylight or other light sources.
CLEANING
CLEANING SHOULD BE CARRIED OUT BY SERVICE PERSONNEL
ONLY, AFTER ENSURING THAT THE UNIT IS DISCONNECTED
FROM THE MAINS SUPPLY.
It is recommended that cleaning is carried out regularly when
the glueboard is replaced. Once the glueboard is removed,
the unit should be thoroughly wiped down with a damp
cloth, removing any build up of dirt. Ensure the unit is
completely dry before reconnecting it to the power supply.
GUARANTEE
Luralite PlusTM has a two year guarantee and if maintained as
recommended in these instructions should continue to work
for many years.* Use of non-approved consumables may
invalidate the guarantee. Ensure genuine Glupac®
glueboards are used in conjunction with this product.
*Excludes lamps, glueboards and starters. Does not cover breakdown due to misuse,
incorrect operation or use in an incorrect application.

Starter Replacement
SPECIFICATION / REPLACEMENT PARTS
GLUEBOARD REPLACEMENT
GLUEBOARD REPLACEMENT SHOULD BE CARRIED OUT BY SERVICE PERSONNEL ONLY, AFTER
ENSURING THAT THE UNIT IS DISCONNECTED FROM THE MAINS SUPPLY.
The glueboard should be replaced every month with a genuine Glupac®glueboard. Use of
non-approved glueboards may invalidate your guarantee.
To replace the glueboard:
1. Swing open the front guard by first lifting up, then pulling forward.
2. Remove the used Glupac®glueboard by simply sliding it forward out of the glueboard
runners and either retain for insect evaluation or dispose of it hygienically.
2. Remove the protective release paper from the new Glupac®glueboard.
3. Slowly slide the new glueboard into position with the adhesive side facing the lamps.
Always ensure the selected genuine Glupac®glueboards are compatible with your unit, available
from your pest control operator or Pelsis Ltd.
TUBE REPLACEMENT
TUBE REPLACEMENT SHOULD BE CARRIED OUT BY SERVICE PERSONNEL ONLY, AFTER ENSURING THAT
THE UNIT IS DISCONNECTED FROM THE MAINS SUPPLY.
To ensure the efficiency of Luralite PlusTM in catching flying insects, the UV lamps should be
replaced annually. After twelve months the phosphor coating that emits the correct wavelength
of UV light has burnt away and the UV output is diminished substantially.
To replace the UV lamps:
1. Rotate the lamp through 90 degrees.
2. Gently pull the lamp away from the unit.
3. Dispose of the used UV lamps in conjunction with local WEEE regulations.
STARTER REPLACEMENT
STARTER REPLACEMENT SHOULD BE CARRIED OUT BY SERVICE PERSONNEL ONLY, AFTER ENSURING
THAT THE UNIT IS DISCONNECTED FROM THE MAINS SUPPLY.
The starters provides an extra spark to initially light the UV lamps. Starters wear out and should be
replaced at the same intervals as the UV lamps.
To replace the starters…
1. Swing open the front guard by first lifting up, then pulling forward.
2. Rotate the starter anti-clockwise.
3. Pull the starter free from the unit.
R4 11/18
Unit Luralite Plus
Voltage 230V ~ 50Hz
Dimensions(mm) 625 x 220 x 155
Coverage 50 Sq. Metres
Weight 4.5 Kg
Light Output 30W
Lamps 2 x TPX15-18
Starter 2 x I154
Glueboards (x6) INL199
C2018
Pelsis Ltd
Information provided on these instructions is modified and
updated from time to time. This is due to the constant
redevelopment of our products. As such, it is not intended that
you should rely on it or that it should form part of any contract.
Sterling House
Grimbald Crag Close
Knaresborough
North Yorkshire
HG5 8PJ UK
T [phone]
F [phone]
W www.pelsis.com
W insect-o-cutor.co.uk
E [email protected]
WEEE Compliance No. 01576542
Glueboard Replacement
