IntelliFlo®VS-3050
Installation and
User’s Guide
Variable Speed Programmable Pump
P/N 357219 - REV. A - MARCH 10, 2008
English Deutsch Nederlands Français Español Italiano
Pentair Water Belgium bvba
Industriepark Wolfstee
Toekomstlaan 30
B-2200 Herentals - Belgium
+32 (0) 14.25.99.11
www.pentairpooleurope.com

© 2007 Pentair Water Pool and Spa, Inc. All rights reserved
This document is subject to change without notice
Trademarks and disclaimers: IntelliFlo®and Pentair Pool Products®are trademarks and/or registered
trademarks of Pentair Water Pool and Spa, Inc. and/or its afliated companies in the United States and/or other
countries.Unless noted, names and brands of others that may be used in this document are not used to indicate
an afliation or endorsement between the proprietors of these names and brands and Pentair Water Pool and
Spa, Inc. Those names and brands may be the trademaks or registered trademarks of those parties or others.
Customer Support
HERENTALS, BELGIUM (8:30 A.M. to 4:30 P.M.) CET
Phone: + 32 (0) 14 25 99 11
Website: www.pentairpooleurope.com
Declaration of Conformity
We declare, under our sole responsibility, that the product identied in this declaration, and to which
this declaration relates, are in conformity with the protection requirements of Council Directive 98/
37/EEG
• Standard EN60335-1, EN50178, EN61800-5-1
• Standard EN61800-3, EN61000-6-2, EN61000-6-4
Manufacturer: Pentair Water Pool and Spa, Inc.
English
P/N 357219 - REV. A - MARCH 10, 2008

3
Important Safety Precautions 4
Section 1: IntelliFlo®Overview 7
IntelliFlo®VS Variable Speed Pump 7
Features 8
IntelliFlo® VS Motor Assembly 8
IntelliFlo® VS Drive Assembly and Control Panel 8
IntelliFlo®VS Operator Control Panel 9
Controls and LEDs 9
Section 2: Operating IntelliFlo®VS 10
Setting the pump preset speed 10
Adjusting the pump speed 10
Starting the pump 11
Stopping the pump 11
Resetting the pump to factory defaults 11
Priming the pump for the rst time or after service 12
Priming the Pump 13
Section 3: User Maintenance 14
Pump Strainer Basket 14
Pump Strainer Basket Service 14
Motor Service 15
Winterizing 16
Priming the pump after service 16
Section 4: Installation and Removal 17
IntelliFlo®VS Kit Contents 17
Installing IntelliFlo®VS 17
Location 17
Piping 17
Check Valve 17
Wiring the IntelliFlo®VS 18
Pump Disassembly 19
Pump Reassembly/Seal Replacement 20
Shaft Seal Replacement 20
Drive Assembly Removal and Installation 21
Illustrated Parts List 22
IntelliFlo®Pump Dimensions 23
IntelliFlo®Flow and Power vs Flow Pump Curve 23
IntelliFlo® VS Electrical Specications 23
Section 5: Troubleshooting 24
Warning and Alarm conditions 24
Alarm and warning LED sequence 24
General IntelliFlo® VS Troubleshooting Problems 25
Contents
English

4
Important Notice:
Attention Installer: This manual contains important information about the installation, operation and safe
use of this product. This information should be given to the owner and/or operator of this equipment.
WARNING — Before installing this product, read and follow all warning notices and instructions which
are included. Failure to follow safety warnings and instructions can result in severe injury,
death, or property damage.
WARNING — Entrapment Avoidance Notice:
The suction outlet connected to a swimming pool or spa pump can pull a high vacuum
if it is blocked. Therefore, if only one suction outlet smaller than 46 cm x 58 cm is used,
anyone blocking the suction outlet with their body can be trapped and held against the
suction outlet. Disembowelment or drowning can result. Therefore, if small suction outlets
are used with this pump, to prevent this entrapment and possible death, install at least two
suction outlets in the body of water. Separate these suction outlets as described in the
International Residential Code (IRC), the International Business Code (IBC), the Consumer
Products Safety Council (CPSC) Guidelines for Entrapment Hazards: Making Pools and
Spas Safer or ANSI/IAF-7 Standard for Suction Entrapment Avoidance in Swimming
Pools, Wading Pools, Spas, Hot Tubs and Catch Basins. If suction outlets are not used,
additional entrapment avoidance measures as described in the CPSC Guidelines or ANSI/
IAF-7 should be employed.
The covers used on suction outlets should be approved and listed as conforming to the
currently published edition of ANSI/ASME A112.19.8 Standard covering Suction Fittings
for Use in Swimming Pools, Wading Pools, Spas and Hot Tubs. These covers should
be inspected regularly and replaced if cracked, broken or older than the design lifetime
indicated on them by the manufacturer. The maximum possible ow rate of this pump
should be less than or equal to the maximum approved ow rate indicated on the suction
outlet cover by the manufacturer. THE USE OF UNAPPROVED COVERS OR ALLOWING
USE OF THE POOL OR SPA WHEN COVERS ARE CRACKED OR BROKEN CAN
RESULT IN HAIR ENTANGLEMENT WHICH CAN RESULT IN DEATH.
WARNING — Risk of electrical shock or electrocution.
This pool pump must be installed by a licensed or certied electrician or a qualied pool
serviceman in accordance with all applicable local codes and ordinances. Improper
installation will create an electrical hazard which could result in death or serious injury to
pool users, installers, or others due to electrical shock, and may also cause damage to
property.
Always disconnect power to the pool pump at the circuit breaker before servicing
the pump. Failure to do so could result in death or serious injury to serviceman, pool
users or others due to electric shock.
IMPORTANT SAFETY PRECAUTIONS
English

5
IMPORTANT SAFETY PRECAUTIONS (continued)
WARNING — Water temperature in excess of 100° Fahrenheit may be hazardous to your health. Prolonged
immersion in hot water may induce hyperthermia. Hyperthermia occurs when the internal
temperature of the body reaches a level several degrees above normal body temperature
of 98.6° F. (37° C.). The symptoms of hyperthermia include: drowsiness, lethargy, dizziness,
fainting, and an increase in the internal temperature of the body.
The effects of hyperthermia include: 1) Unawareness of impending danger. 2) Failure to
perceive heat. 3) Failure to recognize the need to leave the spa. 4) Physical inability to exit the
spa. 5) Fetal damage in pregnant women. 6) Unconsciousness resulting in danger of drowning.
WARNING —The use of alcohol, drugs, or medication can greatly increase the risk of fatal
hyperthermia in hot tubs and spas.
WARNING — To reduce the risk of injury, do not permit children to use this product unless they are closely
supervised at all times.
WARNING — For units intended for use in other than single-family dwellings, a clearly labeled emergency
switch shall be provided as part of the installation. The switch shall be readily accessible to the
occupants and shall be installed at least 5 feet (1.52 m) away, adjacent to, and within sight of
the unit.
WARNING — When setting up pool water turnovers or ow rates the operator must consider local codes
governing turnover as well as disinfectant feed ratios.
WARNING — Before servicing the system, switch the main power OFF and remove the communication cable
from the pump.
CAUTION — Install the pump a minimum of 5 feet (1.5 m) from the inside wall of the pool and spa.
CAUTION — A No. 8 AWG or larger conductor must be wired to the motor bonding lug.
CAUTION — This pump is for use with permanently installed pools and may also be used with hot tubs and
spas if so marked. Do not use with storable pools. A permanently installed pool is constructed
in or on the ground or in a building such that it cannot be readily disassembled for storage. A
storable pool is constructed so that it may be readily disassembled for storage and reassembled
to its original integrity and has a maximum dimension of 18 feet (5.49m) and a maximum wall
height of 42 inches (1.07m).
CAUTION — For hot tubs and spa pumps, do not install within an outer enclosure or beneath the skirt of a
hot tub or spa unless so marked.
CAUTION — IntelliFlo® is capable of generating systems pressures up to 30 meters. Installers must ensure
that all system components are rated to withstand at least 30 meters. Over pressurizing the
system can result in catastrophic component failure or property damage.
General Installation Information
•All work must be performed by a licensed electrician, and must conform to all EU country, and
local codes.
•Install to provide drainage of compartment for electrical components.
English

6
General Installation Information
WARNING — Pumps improperly sized or installed or used in applications other than for
which the pump was intended can result in severe personal injury or death.
These risks may include but not be limited to electric shock, re, ooding,
suction entrapment or severeinjury or property damage caused by a
structural failure of the pump or other system component
WARNING — The pump can produce high levels of suction within the suction side of the
plumbing system. These high levels of suction can pose a risk if a person
comes within the close proximity of the suction openings. A person can
be seriously injured by this high level of vacuum or may become trapped
and drown. It is absolutely critical that the suction plumbing be installed in
accordance with the latest national and local codes for swimming pools.
WARNING — In a domestic environment, this product may cause radio interference in
which case supplementary mitigation measures may be required.
WARNING — Do not install on IT (insulated terra) mains network (marine applications)
NOTE — If required by local building codes, the pump is to be supplied by an isolating
transformer or supplied through a residual current device (RCD) having a residual
operating current not exceeding 30 mA.
NOTE — Use only RCD/GFCI suitable for protecting equipment with a DC current content in
the fault current.
• These instructions contain information for a variety of pump models and therefore
some instructions may not apply to a specic model. All models are intended for
use in swimming pool applications. The pump will function correctly only if it is
properly sized to the specic application and properly installed.
IMPORTANT SAFETY PRECAUTIONS (continued)
General Warnings
• Never open the inside or the drive motor enclosure. There is a capacitor bank that
holds a 230 VAC charge even when there is no power to the unit.
• The IntelliFlo®VS pump is not submersible
• The IntelliFlo®VS pump is capable of 35 m3/hr or 35 meters of head; use caution
when installing and programming to limit pumps performance potential with old or
questionable equipment
• Code requirements for the electrical connection differ from state to state. Install
equipment in accordance with all applicable local codes and ordinances.
• Always Press the Stop button and disconnect the communication cable before
performing maintenance
English

7
Section 1
Overview
IntelliFlo®VS-3050 Variable Speed Pump
TheIntelliFlo®VS-3050variablespeedpumpiswellsuitedforallofyourpool,spa,cleaner,waterfalland
otherwaterapplication.Usingthecontrolpanel,IntelliFlo®VScanuseoneofthefourselectablepreset
speedsorthepumpspeedcanbeadjustedtorunataspecicspeed.IntelliFlo®outperformsall
conventionalpumpsinitsclass.Advancedenergyconservationfeaturesensurethatyourltrationsystemis
operatingatpeakefciency.
Features
• Adjuststovariouspoolsizes
• Preventsthermaloverload
• Detectsandpreventsdamagefromunderandovervoltageconditions
• Protectsagainstfreezing
• Easytouseoperatorcontrolpanel
• Operatorcontrolpanelbuttonsforspeedcontrol
• Built-instrainerpotandvolute
• Ultraenergy-efcientTEFCSquareFlangeMotor
• Compatibilitywithmostcleaningsystems,lters,andjetactionspas
• Driverassemblyfeaturespermanentmagnetsynchronousmotor
• Heavy-duty,durableconstructiondesignedforlonglife
English

8
IntelliFlo®VS Drive Assembly and Control Panel
TheIntelliFlodriveassemblyconsistsofanoperatorcontrolpanelandthesystemelectronicsthat
drivethemotor.Thedrivemicroprocessorcontrolsthemotorbychangingthefrequencyofthe
currentitreceivestogetherwithchangingthevoltagetocontroltherotationalspeed.
IntelliFlo®VS Motor Assembly
TheIntelliFlo®three-phasesix-polemotoroperatesat3400RPM(at92%efciency)and1000RPM
(at90%).Themotorassemblyiscontinuallycooledbyanexternalfan.Dualsealsonthemotorshaft
andatthefanassemblysealtheentiremotorfromanymoisturefromenteringthemotorassembly.
Foraddedprotection,aslingerlocatedinfrontofthemainshaftsealassistsinslingingwateraway
fromtheshaftopeningintheange.
• PermanentMagnetSynchronousMotor(PMSM)
• Highefciency(3400RPM92%and1000RPM90%)
• Superiorspeedcontrol
• Operatesatlowertemperaturesduetohighefciency
• Sametechnologyasdeployedinhybridelectricvehicles
• Designedtowithstandoutdoorenvironment
• Totallyenclosedfancooled
• Three-phasemotor
• 56SquareFlange
• Six-Pole
• Lownoise
Drive assembly and
electronics enclosure
IntelliFlo® VS Motor Assembly
Motor fan cover
Control panel cover
Motor assembly
Three Wire Harness
Brown (hot),
Blue (neutral),
Green/Yellow (ground)
Operator Control Panel,
buttons and LEDs
IntelliFlo® VS Drive Assembly
English

9
Controls and LEDs
Speed 1, Speed 2, Speed 3, and Speed 4 button/LED: Pressoneofthespeedbuttonstoselectthe
desiredpresetpumpspeed.Thepumppresetspeedsare:Speed 1 (750 RPM), Speed 2 (1500 RPM),
Speed 3 (2350 RPM), and Speed 4 (3110 RPM). ThespeedbuttonLEDisonwhentheselected
buttonispressed.IfthepumpisrunningandtheUp/Downbuttonisusedtoadjustthespeed,the
selectedspeedLEDswillgooff.
Up/Down button: Whilethepumpisrunning,presstheUporDownbuttontoincreaseordecrease
thepumpspeed.Tosavethenewpumpspeed,pressanyoneofthefourspeedbuttonsforthree
secondstoassignthespeedtotheselectedbutton(theLEDbeon).Fouradjustedpumpspeeds
canbeassignedtothespeedbuttons.Whenthepumpisusinganadjustedspeedandthepumpis
powereddown,thenexttimethepumpispoweredupthepumpwillusethesamespeed.
Start button/LED:Startsthepumpusingaselectedoradjustedspeed.ThisLEDisonwhenthepump
isrunning.
Stop button:Pressthisbuttontostopthepump.
On LED: ThisgreenpowerLEDisonwhenIntelliFlo®VSispoweredup.
Alarm LED: ThisLEDisonwhenanerrorconditionoccurs.ThisgreenLEDwillashacertain
numberoftimesindicatingaspecicerrorcondition.ForthealarmLEDashsequence,referto
“AlarmandWarningLEDSequence,”Section5.
IntelliFlo®VS Operator Control Panel
TheIntelliFlo®VSoperatorcontrolpanelprovidesmanualspeedcontrolsforthepump.Therearefour
presetspeedbuttonsthatcanbeselected.TheUpandDownbuttonisusedtoadjustthepumpspeed.
Theselectedspeedcanbesavedandassignedtooneofthespeedbuttons.
5
4
3
2
1
6
English

10
Section 2
Operating IntelliFlo®VS
ThissectiondescribeshowtousetheIntelliFlo®4pumpcontrolpanel.
Setting the pump preset speed
IntelliFlo®VSoperatesusingoneofthepresetspeeds.Usethespeedbuttonstoselectthepreset
speeds.
To set the pump speed
1. EnsurethatthepumpispoweredonandthegreenpowerLEDison.
2. Pressthedesiredspeedbutton(1-4)forlessthanthreesecondstoselectthepresetpump
speed.Whentheselectedspeedbuttonispressed,theLEDison.Thepumppresetbuttons
andspeedsare:
Speed 1 button - 750 RPM
Speed 2 button - 1500 RPM
Speed 3 button - 2350 RPM
Speed 4 button - 3110 RPM
3. PresstheStart buttontostartthepumpusingtheselectedspeedifnecessary.
Adjusting the pump speed
IntelliFlo®canbeadjustedtorunatanyspeedbetween400RPMand3450RPM.
To adjust the pump speed
1. EnsurethatthepumpispoweredonandthegreenpowerLEDison.
2. PresstheStart buttontostartthepumpifthepumpisnotrunning.
3. PresstheUP/Downbuttontoincreaseordecreasethepumpspeed.
• 10 RPM increments:PressandquicklyreleasetheUp/Downbuttonto
increaseordecreasethespeedin10RPMincrements.
• 20 RPM increments:PressandholdtheUp/Downbuttonto
continuouslyincreaseordecreasethepumpspeed.
4. Saving an adjusted speed:Tosavethenewlyadjustedpumpspeed,press
andholdthedesiredspeedbuttonstoassignthecurrentspeed.Fournew
pumpspeedscanbeassignedtoSpeedbuttons(1-4).
5. PresstheSpeed buttonthatisassignedtotheadjustedspeed.
Up/Down button
English

11
Starting the pump
To start the pump
1. EnsurethatthepumpispoweredonandthegreenpowerLEDison.
2. PresstheStart button(LEDon)tostartthepump.
Note: When the pump is using a modied speed and is powered down, the next time the pump is
powered up, the pump will use that same speed.
Stopping the pump
To stop the pump
• PresstheStop buttontostopthepump.
Note: Thepumpcanautomaticallyrestartifthecommunicationcableisconnected.
Resetting the pump to factory defaults
TheIntelliFlo®VSpumpcanberesettothefactorydefaultsettings.Allpreviouslyadjustedpumpspeeds
thatweresavedwillbeerased.
Toresetthepumptothefactorydefaultsettings:
1. EnsurethatthepumpispoweredonandthegreenpowerLEDison.
2. PresstheStop buttontostopthepump.
3. PressandholdallofthefourSpeed buttonssimultaneouslyforthreeseconds.Poweroffthe
driveandreenergize.Thedefaultsettingswillbeineffect.
Control Panel Speed Buttons
English

12
Priming the pump for the rst time or after service
BeforetheIntelliFlo®VSpumpisstartedforthersttimeitmustbeprimed.Toprimeapumpmeanslling
thepumpandsuctionpipewithwater.Thisprocessevacuatestheairfromallthesuctionlinesandthepump.
Itmaytakeseveralminutestoprimedependingonthedepthofwater,pipesizeandlength.Itiseasierto
primeapumpifyouallowalltheairtoescapefromthepumpandpipes.Thewatercannotenterunlessthe
aircanescape.Pumpsdonotholdprime,thepoolpipingsystemhasthattask.
CAUTION - To avoid permanent damage to the IntelliFlo® VS pump, before starting the pump, ll the IntelliFlo®
housing strainer with water so that the pump will prime correctly. If there is no water in the stainer the pump will
not prime.
• NEVER run the pump dry! Running the pump dry may damage the seals, causing leakage and
ooding!
• Do not add chemicals to the system directly in front of pump suction. Adding undiluted chemicals
may damage the pump and will void the warranty.
• Open gate valves before starting system.
• Pump will prime itself when used in ooded suction system.
• Be sure to release all air from lter and piping system.
• The IntelliFlo® VS pump is a variable speed pump. Typically the lower speeds are used for
ltration and heating. The higher speeds can be used for spa jets, water features, and priming.
CAUTION - Before starting this procedure, rst read the following
Before removing the pump lid:
1. Press the Stop buttonifthepumpisrunningbeforeproceeding.
1. Disconnect the communication cable from the pump.
2. Close the gate valvesinsuctionanddischargepipes.
3. Release all pressurefrompumpandpipingsystem.
4. Never tighten or loosentheclampwhilethepumpisoperating.
WARNING!If the pump is being pressure tested, release all pressure before removing the clamp.
Do not block the pump suction while the pump is running. If a body part blocks the pump suction it may cause
severe or fatal injury. Small children using the pool must ALWAYS have close adult supervision.
WARNING! FIRE and BURN HAZARD- The pump motor may run at a high temperatures. To reduce the
risk of re, do not allow leaves, debris, or foreign matter to collect around the pump motor. To avoid burns when
handling the motor, shut off the motor and allow it to cool for 20 minutes before trying to work on it. The IntelliFlo
VS provides an automatic internal cutoff switch to protect the motor from heat damage during operation.
English

13
Priming the pump for the rst time or after service (Continued)
Priming the Pump
• Releaseallpressurefromlter,pump,andpipingsystem;seethelterowner’smanual.
• Inaoodedsuctionsystem(watersourcehigherthanpump),theIntelliFlo®VSpumpwill
primeitselfwhensuctionanddischargevalvesareopened.
• IftheIntelliFlo®VSpumpisnotinaoodedsuctionsystem,removeclampandlid;llthe
pumpwithwater.
• Donotlubricatethelido-ring.Theoriginalequipmento-ringcontainsapermanentinternal
lubricant.
NOTICE: Ifyoureplacetheo-ringwithanon-internallylubricatedo-ring,youmayneedtoapplya
siliconebasedlubricant.
• Cleanandinspecto-ring;reinstallonlid.
• Replaceclamponstrainerpot;turnclockwisetotightenclamp.
NOTICE:Tightenthepumpclampbyhandonly(nowrenches)!
Pumpshouldprimenow.Primingtimewilldependonverticallengthofsuctionliftandhorizontal
lengthofsuctionpiping.Ifpumpdoesnotprime,makesurethatallvalvesareopen,suctionpipeend
isunderwater,pumpsuctionisbelowwaterlevel,andthattherearenoleaksinsuctionpipe.
ToprimetheIntelliFlo®VSpump:
1. Turnthepumpclampandlidinacounterclockwisedirectionuntilit
stopsandremovethem.
2. Fillthepumpstrainerpotwithwater.
3. Reinstallthepumpclampandlidontothestrainerpot.Thepumpis
nowreadytoprime.
4. Makesureallelectricalconnectionsarecleanandtight.
5. Opentheairreleasevalveonthelter,andstandclearofthelter.
6. SwitchtheIntelliFlo®pumponatthecircuitbreaker.Ensurethat
thegreenpowerlightison.
7. PresstheSpeed 1 buttontoselectthepumpspeedof750RPM.
8. PresstheStartbuttontostartthepump.UsetheUp/Downbuttontoincreasethespeedas
necessarytoprimethepump.
9. Whenwatercomesoutoftheairreleasevalve,closethevalve.Thesystemshouldnowbe
circulatingwaterbacktothepoolwithoutairbubblesshowingineitherthehairandlintpotoratthe
poolreturnttings.
10.UsetheUp/Downbuttontoadjusttheoperatingspeedasdesired.
Top view
English

14
Section 3
User Maintenance
ThefollowinginformationdescribeshowtoserviceandmaintaintheIntelliFlo®pump.
Pump Strainer Basket
Thestrainer,sometimesreferredtoasthe“HairandLintPot,”isinfrontoftheofthepump.Inside
thereisabasketwhichmustbekeptcleanofleavesanddebrisatalltimes.Viewthebasketthrough
thetopseethroughlidtoinspectforleavesanddebris.
Regardlessofthelengthoftimebetweenltercleaning,itismostimportanttovisuallyinspectthehairandlint
potbasketatleastonceaweek.Adirtybasketwillreducetheefciencyofthelterandpossiblytheheater.
WARNING — DO NOT open the strainer pot if pump fails to prime or if pump has been operating
without water in the strainer pot. Pumps operated in these circumstances may experience
a build up of vapor pressure and may contain scalding hot water. Opening the pump may
cause serious personal injury. In order to avoid the possibility of personal injury, make
sure the suction and discharge valves are open and that the strainer pot is cool to the
touch, then open with extreme caution.
CAUTION — To prevent damage to the pump and lter and for proper operation of the system, clean
pump strainer and skimmer baskets regularly.
Pump Strainer Basket Service
IftheIntelliFlo®pumpisinstalledbelowthewaterlevelofthe
pool,closethereturnandsuctionlinesbeforeopeningthehair
andlintpotonthepump.
1. PresstheStopbuttontostopthepumpandswitchoffthe
pumpatthecircuitbreaker.
2. Relievepressureinthesystem.
3. Turntheclampandlidinacounterclockwisedirectionuntil
itstops.
4. Removetheclampandlid.
5. Removethebasketandputthedebrisintothetrashandrinse
outthebasket.Ifthebasketiscracked,replacethebasket.
6. Replacethebasketandllthepumppotandvolutewith
wateruptotheinletport.
7. Cleanthecover,o-ring,andsealingsurfaceofthepumppot.
Greasetheo-ringwithTeonorsiliconelubricant.
8. Reinstallthelidbyplacingtheclampandthelidonthepot.
English

15
Motor Service
1. Protect from heat:
• Shadethemotorandcontrollerfromthesun.
• Anyenclosuremustbewellventilatedtopreventoverheating.Particularattentionshouldbepaid
tothemotorfancoverandthecoolingnsbetweenthedriveandthemotor.
• Provideamplecrossventilation.
2. Protect against dirt:
• Protectfromanyforeignmatterorsplashingwater.
• Donotstore(orspill)poolchemicalsnearthemotor.
• Avoidsweepingorstirringupdustnearthemotorwhileitisoperating.
• Ifamotorhasbeendamagedbydirtitvoidsthemotorwarranty.
3. Protect against moisture:
• Protectfromsplashingpoolwater.
• Protectfromtheweather.
• Protectfromlawnsprinklers.
• Ifamotorhasbecomewet-letitdrybeforeoperating.Donotallowthepumptooperateifithas
beenooded.
• Ifamotorhasbeendamagedbywateritvoidsthemotorwarranty.
Note: DO NOT wrap motor and controller with plastic or other air tight materials. The motor and
controller may be covered, but not wrapped in plastic, during a storm, for winter storage, etc., but
never when operating, or expecting operation.
Whenreplacingthemotor,becertainthatthemotorsupportiscorrectlypositionedtosupportthe
sizeofmotorbeinginstalled.
Pump Strainer Basket Service (Continued)
9. Ensurethatthelido-ringisproperlyplaced.Seattheclampandlid
thenturnclockwiseuntilthehandlesarehorizontalasshown.
10.Reconnectthecommunicationcabletothepumpifrequired.
11.SwitchthepowerONatthecircuitbreaker.Resetthepooltime
clocktothecorrecttime.
WARNING — FILTER OPERATES UNDER HIGH PRESSURE. WHEN
ANY PART OF THE CIRCULATING SYSTEM (e.g., LOCK RING,
PUMP, FILTER, VALVES, ETC.) IS SERVICED, AIR CAN ENTER
THE SYSTEM AND BECOME PRESSURIZED. PRESSURIZED
AIR CAN CAUSE THE LID TO BLOW OFF WHICH CAN RESULT IN
SEVERE INJURY, DEATH, OR PROPERTY DAMAGE. TO AVOID
THIS POTENTIAL HAZARD, FOLLOW THESE INSTRUCTIONS.
12. Openthemanualairreliefvalveontopofthelter.
13. Standclearofthelter.PresstheStartbuttononthepump.
14. Bleedairfromthelteruntilasteadystreamofwatercomesout.
15. Closethemanualairreliefvalve.
English

16
Priming the pump after service
Beforeasystemstart-up,thepumpandsystemmustbemanuallyprimed.Makesuretoreopen
valvesbeforeoperating.ToprimeIntelliFlo®VS,thestrainerpotmustbelledwithwater.
CAUTION — DO NOT run the pump dry. If the pump is run dry, the mechanical seal will be damaged
and the pump will start leaking. If this occurs, the damaged seal must be replaced.
ALWAYS maintain proper water level in your pool. Continued operation in this manner
could cause a loss of pressure, resulting in damage to the pump case, impeller and seal.
ForinstructionsabouthowtoprimetheIntelliFlo®VSpump,referto“Primingthepumpfortherst
timeorafterservicing,”Section2.
Winterizing
ToprotecttheIntelliFlo®VSpumpelectronicsfromdamageduetofreezingconditions,thepump
willswitchitselfontogenerateinternalheatwhentheairtemperaturedropsbelow40°F.This
feature is not intended to protect the system plumbing from freezing.
1. Iftheairtemperaturedropsbelow40°Fthewaterinthepumpcanfreezeandcausedamage.
Freezedamageisnotwarrantable.
2. Topreventfreezedamagefollowtheprocedureslistedbelow.
• Shutoffelectricalpowerforthepumpatthecircuitbreaker.
• Drainthewateroutofthepumpbyremovingthetwothumb-twistdrainplugslocatedatthe
bottomofthevolute.Storetheplugsinthepumpbasket.
• Coverthemotortoprotectitfromsevererain,snowandice.
• Donotwrapthemotorinplastic.Itwillcausecondensationandrustontheinsideofthemotor.
Note: Inmildclimateareas,whentemporaryfreezingconditionsmayoccur,runyourltering
 equipmentallnighttopreventfreezing.
English

17
Section 4
Installation and Removal
ThefollowinginformationdescribeshowtoinstalltheIntelliFlo®VSpump.
Note: Before installing this product, read and follow all warning notices and instructions.
IntelliFlo VS Kit Contents
• IntelliFlo®VS3050pump
Installing the IntelliFlo®VS
OnlyaqualiedservicepersonshouldinstalltheIntelliFloVSpump.
Location
1. Installthepumpasclosetothepoolorspaaspossible.Toreducefrictionlossandimprove
efciency,useshortanddirectsuctionandpipingreturns.
2. Installaminimumof5feet(1.5m)fromtheinsidewallofthepoolandspa.
3. Installthepumpaminimumof2feet(0.6m)fromtheheateroutlet.
4. Donotinstallthepumpmorethan8feet(2.4m)abovethewaterlevel.
5. Installthepumpinashelteredwellventilatedlocationprotectedfromexcessivemoisture,(i.e.,rain,
sprinklers,etc.).
6. Forhottubsandspas,donotinstallwithinanouterenclosureorbeneaththeskirtofahottuborspa.
7. Installthepumpwitharearclearanceofatleast6inches(15cm)sothatthemotorcanberemoved
easilyformaintenanceandrepair.
Piping
Forimprovedpoolplumbing,itisrecommendedtousealargerpipesize.Wheninstallingtheinlet
andoutletttings(maleadaptors),usethreadsealant.
Donotinstall90°elbowsdirectlyintopumpinletoroutlet.Avalve,elboworteeinstalledinthe
suctionlineshouldbenoclosertothefrontofthepumpthanve(5)timesthesuctionlinepipe
diameter.Thiswillhelpthepumpprimefasterandlastlonger.
Floodedsuctionsystemsshouldhavegatevalvesinstalledonsuctionanddischargepipesfor
maintenance,however,thesuctiongatevalveshouldbenocloserthanve(5)timesthesuctionpipe
diameterasdescribedabove.
Check Valve
CheckvalvesmustbeusedwhentheIntelliFlo®VSisusedinparallelwithotherpumps.IntelliFlo®
pumpscannotbeusedinserieswithotherpumps.
English

18
Wiring the IntelliFlo®VS
ToconnecttheIntelliFlo®toanACpowersource:
1. Makesureallelectricalbreakersandswitchesareturnedoffbeforewiringmotor.
2. Makesurethatthewiringvoltageis230VAC.
3. Use#12AWGforwirerunsupto100feet(30m)and#10AWGforlengthslongerthan100feet
(30m).Whenindoubtuseaheaviergauge(largerdiameter)wire.Heaviergaugewillallowthe
motortoruncoolerandmoreefcient.
4. Makesureallelectricalconnectionsarecleanandtight.
5. Cutthewirestotheappropriatelengthsotheydonotoverlaportouchwhenconnected.
6. Permanentlygroundthemotorusingthegreen/yellowgroundwire,asshownbelow.Usethe
correctwiresizeandtypespeciedbyEUElectricalCodes.Makesurethegroundwireis
connectedtoanelectricalserviceground.
7. Bondthemotortothepoolstructureinaccordancewiththelocalregulatiosn.UseasolidNo.8
AWGorlargercopperconductor.Runawirefromtheexternalbondinglugtothepoolbonding
structure,asshownbelow.
NOTE: When the IntelliFlo®VS pump is started and stopped by removing power with a relay or timer,
a two-pole device should be used to apply and remove power to both of the red power leads.
 TheIntelliFlo®isdesignedtobepermanentlyconnectedtoitspowersource.Typicallythepump
receivespowerdirectlyfromthecircuitbreaker.Nocontactorormotorstarterisrequired.IntelliFlo®
canbeoperatedin“stand-alone”mode,startingandstoppingwhenpowerisappliedorremoved.
Whenthedrivepowersupitwillreturntothemodeandrunstatusthatitwasinwhenpowerwas
removed.Thissetupmaybeappropriateifyouneedtouseexistingrelaysortimers.
IntelliFlo®VS wiring harness
Brown = Hot
Blue = Neutral
Green/yellow stripe = Ground
BONDING LUG
English

19
Pump Disassembly
WARNING — Always disconnect power to the pool pump at the circuit breaker and disconnect the
communication cable before servicing the pump. Failure to do so could result in death or
serious injury to serviceman, pool users or others due to electric shock.
Read all servicing instructions before working on the pump.
WARNING — DO NOT open the strainer pot if pump fails to prime or if pump has been operating
without water in the strainer pot. Pumps operated in these circumstances may experience
a build up of vapor pressure and may contain scalding hot water. Opening the pump may
cause serious personal injury. In order to avoid the possibility of personal injury, make
sure the suction and discharge valves are open and strainer pot temperature is cool to
touch, then open with extreme caution.
CAUTION — Be sure not to scratch or mar the polished shaft seal faces; seal will leak if faces are
damaged.
AllmovingpartsarelocatedintherearsubassemblyoftheIntelliFlo®pump.
Toolsrequired:
• 3/32inchAllenheadwrench.
• ½inchopenendwrench.
• 9/16inchopenendwrench.
• Flatbladescrewdriver.
Toremoveandrepairthepumpmechanicalseal,performthefollowingprocedures:
1. Switchoffthepumpcircuitbreakeratthemainpanel.
2. Drainthepumpbyremovingthedrainplugs.
3. Removethesixboltsthatholdthemainpumpbody(strainerpot/volute)totherearsubassembly.
4. GENTLYpullthetwopumphalvesapart,removingtherearsubassembly.
5. Usea3/32inchAllenheadwrenchtoloosenthetwoholdingscrewslocatedonthediffuser.
6. HoldtheimpellersecurelyinplaceandremovetheimpellerlockscrewbyusingaPhillipshead
screwdriver.Thescrewisaleft-handedthreadandloosensinaclockwisedirection.
7. Useaatbladescrewdrivertoholdthemotorshaft.Themotorshafthasaslotontheendwhich
isaccessiblethroughthecenterofthefancover.
English

20
Pump Disassembly (Continued)
8. Tounscrewtheimpellerfrom
theshaft,twisttheimpeller
counterclockwise.
9. Removetherotatingportionof
themechanicalsealfromtheimpeller.
10.Removethefourboltsfrom
thesealplatetothemotor,usinga
9/16inchwrench.
11.Placethesealplatefacedownon
aatsurfaceandtapout
thecarbonspringseat.
12.Cleanthesealplate,sealhousing,
andthemotorshaft.
Pump Reassembly/Seal Replacement
1. Wheninstallingthereplacementshaftseal,usesiliconesealantonthemetalportionbefore
pressingintothesealplateasshown.
2. Beforeinstallingtherotatingportionofthesealintotheimpeller,besuretheimpelleris
clean.Usealightdensitysoapandwatertolubricatetheinsideoftheseal.Pressthesealinto
theimpellerwithyourthumbsandwipeofftheceramicandcarbonfaceswithacleancloth.
3. Remountthesealplatetothemotor.
4. Greasethemotorshaftthreadandscrewimpellerontothemotorshaft.
5. Screwintheimpellerlockscrew(counterclockwisetotighten).
6. Remountthediffuserontothesealplate.Makesuretheplasticpinsandholdingscrewinserts
arealigned.
7. Greasethediffusero-ringandsealplategasketpriortoreassembly.
8. Greasetheboltthreads,assemblethemotorsubassemblytothestrainerpot-pumpbodyby
usingthetwo(2)throughboltsforproperalignment.Donottightenthethroughboltsuntil
allsix(6)boltsareinplaceandngertightened.
9. Fillthepumpwithwater.
10.Reinstallthepumplidandplasticclamp.
11.Primethepump.
Shaft Seal Replacement
TheShaftSealconsistsprimarilyoftwoparts,arotatingmemberandaceramicseal.Thepump
requireslittleornoserviceotherthanreasonablecare,however,ashaftsealmayoccasionally
becomedamagedandmustbereplaced.
Note: Thepolishedandlappedfacesofthesealcouldbedamagedifnothandledwithcare.
LOCK SCREW
SEAL
LOCK SCREW
SEAL O-RING
SET SCREW
MOTOR
BOLT (4x)
MOTOR
BOLT (2x)
GASKET
SEAL
PLATE
IMPELLER
English
