Pentair HOME SUMP CONTROLLER Assembly instructions

PENTAIR HOME
SUMP CONTROLLER
Homeowner's Guide
ENGLISH: 1-14 ESPANOL: 15-28 FRANCAIS: 29-42

2PENTAIR HOME SUMP CONTROLLER HOMEOWNER'S GUIDE
TABLE OF CONTENTS
Getting Started
Overview................................................................................................................................................... 3
Mobile App Registration............................................................................................................................4
Install the Sump Controller ....................................................................................................................... 5
Add Your Device........................................................................................................................................ 6
Connect Sump Controller To WiFi ............................................................................................................ 7
Using The App
App Overview........................................................................................................................................... 8
 EditProle............................................................................................................................................... 8
Change WiFi Network.............................................................................................................................. 9
 NoticationPreferences......................................................................................................................... 9
Alerts......................................................................................................................................................10
Nickname Product..................................................................................................................................10
Controller Modes .....................................................................................................................................11
Controller LED Indicators ........................................................................................................................11
Sump Controller Alerts ............................................................................................................................... 12
General Troubleshooting ............................................................................................................................ 13
Warranty...................................................................................................................................................... 14

3PENTAIR HOME SUMP CONTROLLER HOMEOWNER'S GUIDE
Pentair® Sump Controller is an easy-to-install,
versatile sump pump controller that activates your
pump when waters rise. The universal outlet allows
the controller to be used with most existing sump
pumps.
The Sump Controller is WiFi enabled and designed to
sync with Pentair Home App, providing homeowners
the ability to remotely control pump settings, monitor
critical pump data, receive pump alerts such as high
water alarms, and receive maintenance reports to
dispatch service calls in a timely manner.
The App is simple to use by navigating these icons
available at app's dashboard.
Seethefollowingpagesforquickstartinstructions.
Sump Controller
Pseudo plug
Reed Float switch
Wall mount and screw
OVERVIEW
Pentair
Dashboard
Schedule
(future feature)
My Devices
Sump Controller
Dashboard
Account
The following items are included in the package:

4PENTAIR HOME SUMP CONTROLLER HOMEOWNER'S GUIDE
Download the Pentair Home App to your
mobiledevicefromtheAppStore®or
Google Play™ Store. Open the App.
EXISTING USERS: LOGIN to your account.
NEW USERS: Scroll down in the App and click
SIGN UP.
Enter a valid EMAIL and PASSWORD.
Select TERMS OF SERVICE.
Click CREATE AN ACCOUNT.
Complete instructions in the
VERIFICATION EMAIL.
LOGIN to your account.
Existing User
New User
MOBILE APP REGISTRATION

5PENTAIR HOME SUMP CONTROLLER HOMEOWNER'S GUIDE
1. Unplugyourexistingsumppumpfromwalloutlet.
2. Plugyourpump’scordintothetopoutletofthe
Sump Controller.
3. Plug the Piggyback Switch into the bottom outlet
oftheSumpController.
4. PlugthePseudoPlugintothebackofthe
piggyback switch
5. Plugtheincludedreedfloatswitchwiresinto
thesideoftheSumpController.
6. Plug the Sump Controller into the wall outlet.
7. Secure the High Level Switch to the discharge
pipe with a cable tie. It should be located near
thetopofthesumppit.
Pump
Pseudo
Plug
Float
Switch
INSTALL THE SUMP CONTROLLER

6PENTAIR HOME SUMP CONTROLLER HOMEOWNER'S GUIDE
1. From the Sump Controller, press and hold
the MODEbuttonfor4to15secondsto
enter the PAIRING MODE (blinking blue).
2. In the App, go to the Pentair dashboard,
then press ADD A DEVICE.
Steps 1 & 2
Step 3
Step 4
3. Select SUMP CONTROLLER. Click
CONTINUE on both the INSTALLATION
and the Bluetooth® wireless technology
PAIRING screens.
4. Choose the device (name will always
start with the letters PNR). The Bluetooth
iconwillturnwhiteafterconnecting,
soyouknowyou’vemadeasuccessful
connection.
5. Press CONTINUE on your phone when
prompted.
ADD YOUR DEVICE

7PENTAIR HOME SUMP CONTROLLER HOMEOWNER'S GUIDE
1. Select your home WiFi account, add
your home WiFi password and press
CONTINUE.
2. SetthelocationofyourSumpController.
IfyouclickonSELECT LOCATION, your
current location should appear; select it
and press SAVE.Ifnot,manuallyenter
the address. Press OK when prompted.
3. You are now connected!
CONNECT SUMP CONTROLLER TO WIFI
Step 2
Step 1
Note: During the rst 20 pump cycles, the device learns what is
normal operating behavior in your installation. For example, how
long and the frequently at which the system runs, as well as how
much power is required to remove water from your application.
Over time, the device repeats this process to continue monitoring
the change in performance, ensuring you get notied of any
abnormalities.

8PENTAIR HOME SUMP CONTROLLER HOMEOWNER'S GUIDE
APP OVERVIEW
EDIT PROFILE
The ACCOUNT icon takes you to all
thedetailsofyouraccount,fromyour
proleanddevicenoticationsto
contactingaprofessionalforservice
andwarrantyinformation.
1. Go to the ACCOUNT screen.
2. Select EDIT PROFILE to:
Add/edit your account photo.
Add/change your name, email,
password or phone number.
Change or add an address.
Delete your account.

9PENTAIR HOME SUMP CONTROLLER HOMEOWNER'S GUIDE
CHANGE WIFI NETWORK
NOTIFICATION PREFERENCES
1. Press the GEAR icon on the
dashboard.
2. Select WIFI and press CHANGE.
3. Press CHANGE WIFI NETWORK.
1. Toadjustyournotificationpreferences,
go to your ACCOUNT and select
NOTIFICATIONS.
2. Select SUMP CONTROLLER, then
choose how to receive alerts.
3. Return to the NOTIFICATIONS screen
and select News & Marketing.
4. Choose how to receive News &
Marketing alerts.
Step 1 Step 2 Step 3
Step 1 Step 2

10 PENTAIR HOME SUMP CONTROLLER HOMEOWNER'S GUIDE
ALERTS
NICKNAME YOUR PRODUCT
All alerts are displayed on the dashboard
screen through the MY DEVICE icon.
Alerts remain on the dashboard until the
issue has been resolved.
ConsulttheAlertstableinthisguidefora
completelistofpossiblealerts.
Pentair
Dashboard
Sump Pump
Dashboard
1. Press the GEAR icon in the
upperleftoftheApp.
2. Select PRODUCT OVERVIEW.
3. Press NICKNAME, update it,
then press SAVE.
