Pentair INTELLISYNC User manual

IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
INSTALLATION GUIDE
INTELLISYNC™
CONTROL AND MONITORING SYSTEM

2
IntelliSync Control and Monitoring System Installation Guide
This is the safety alert symbol. When you see this symbol on your system
or in this manual, look for one of the following signal words and be alert
to the potential for personal injury.
Warns about hazards that can cause death, serious personal injury, or
major property damage if ignored.
Warns about hazards that may cause death, serious personal injury, or
major property damage if ignored.
Warns about hazards that may or can cause minor personal injury or
property damage if ignored.
NOTE: Indicates special instructions not related to hazards.
Carefully read and follow all safety instructions in this manual and on equipment. Keep safety
labels in good condition; replace if missing or damaged.
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
SERIOUS BODILY INJURY OR DEATH CAN RESULT IF THIS PRODUCT (UNIT) IS
NOT INSTALLED AND USED CORRECTLY.
INSTALLERS, POOL OPERATORS AND POOL OWNERS MUST READ THESE
WARNINGS AND ALL INSTRUCTIONS BEFORE USING THIS PRODUCT. This Guide
provides installation and operation instructions for the product. Consult Pentair Water Pool and
Spa, Inc. (“Pentair”) with any questions regarding this product.
This product is intended for use in swimming pool applications only. Most states and local codes
regulate the construction, installation, and operation of public pools and spas, and the construction
of residential pools and spas. It is important to comply with these codes, many of which directly
regulate the installation and use of this product. Consult your local building and health codes
for more information. A pool or spa pump must be installed by a qualied pool and spa service
professional in accordance with the current National Electrical Code and all applicable local codes
and ordinances. Improper installation may create an electrical hazard which could result in death
or serious injury to pool users, installers, or others due to electrical shock, and may also cause
damage to property.
IMPORTANT WARNING AND SAFETY INSTRUCTIONS
This guide provides installation and operation instructions for this product. Consult Pentair with
any questions regarding this equipment.
Attention Installer: This guide contains important information about the installation, operation and
safe use of this product. This information should be given to the owner and/or operator of this
equipment after installation or left on or near the equipment.
Attention User: This manual contains important information that will help you in operating and
maintaining this product. Please retain it for future reference.

3
IntelliSync Control and Monitoring System Installation Guide
The use of alcohol, drugs, or medication can greatly increase the risk of fatal hyperthermia in
hot tubs and spas.
Do not use this product to control an automatic pool cover Swimmers may become entrapped
underneath the cover. For units intended for use in other than single-family dwellings, a clearly
labelled emergency switch shall be provided as part of the installation. The switch shall be
readily accessible to the occupants and shall be installed at least ve (5) feet (1.52 m) away,
adjacent to, and within sight of, the unit.
Except for listed spa-side remote controls, install a minimum of ve (5) feet (1.52 m) from the
inside wall of the pool and spa.
The electrical supply for this product must include a suitably rated switch or circuit breaker
to open all ungrounded supply conductors to comply with the current National Electrical Code
(NEC), NFPA 70 or the Canadian Electrical Code (CEC), CSA C22.1. All applicable local installation
codes and ordinances must also be adhered to.
Use only copper supply conductor’s rated for 60C/75C sized based on ampacity to support all
loads (refer to NEC tables).
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION!
Always disconnect power at the circuit breaker before servicing the
enclosure or equipment connected to the enclosure.
Improper installation can create an electrical shock hazard that can result
in death or serious injury.
All applicable local installation codes and ordinances must also be adhered to. Improper installation
will create an electrical hazard which could result in death or serious injury to pool users, installers
or others due to electrical shock, and may also cause damage to property. Always disconnect the
power to the pool light at the circuit breaker before servicing the light. Failure to do so could result
in death or serious injury to serviceman, pool users or others due to electrical shock.
Water temperature in excess of 100° F (37.7° C) may be hazardous to your
health. Prolonged immersion in hot water may induce hyperthermia.
Hyperthermia occurs when the internal temperature of the body reaches
a level several degrees above normal body temperature of 98.6° F (37° C).
Effects of hyperthermia include: (1) Unawareness of impending danger. (2)
Failure to perceive heat. (3) Failure to recognize the need to leave the spa.
(4) Physical inability to exit the spa. (5) Fetal damage in pregnant women.
(6) Unconsciousness resulting in danger of drowning. The use of alcohol, drugs, or medication can
greatly increase the risk of fatal hyperthermia in hot tubs and spas.
IMPORTANT WARNING AND SAFETY INSTRUCTIONS

4
IntelliSync Control and Monitoring System Installation Guide
For information about the Virginia Graeme Baker Pool and Spa Safety Act,
contact the Consumer Product Safety Commission at [phone] or
visit www.cpsc.gov.
NOTE: Always turn off all power to the pool pump before installing the
cover or working on any suction outlet.
RF Exposure Requirements: The antenna(s) used for this device must be
installed to provide a separation distance of at least 7.0 inches (20 cm)
from all persons and must not be co-located or operating in conjunction
with any other antenna or transmitter.
L’antenne (s) utilisé pour cet appareil doit être installé pour fournir une
distance de séparation d’au moins (20 cm) à partir de toutes les personnes
et ne doit pas être co-localisés ou fonctionner en conjonction avec une
autre antenne ou un autre émetteur.
General Installation Information
1. This equipment is not provided with integral Ground Fault Circuit
Interruptor (GFCI) protection.
2. The electrical supply for this product must include a suitably rated
switch or circuit breaker to open all ungrounded supply conductors
to comply with in accordance with the current National Electrical
Code (NEC), NFPA 70 or the Canadian Electrical Code (CEC), CSA
C22.1. All applicable local installation codes and ordinances must
also be adhered to. The disconnecting means must be readily
accessible to the tub occupant but installed at least 10 ft. (3.05 m)
from the inside wall of the pool.
For Installation of Electrical Controls at Equipment Pad (ON/OFF
Switches, Timers and Automation Load Center)
Install all electrical controls at equipment pad, such as on/off
switches, timers, and control systems, etc. to allow the operation
(startup, shut-down, or servicing) of any pump or lter so the user
does not place any portion of his/her body over or near the pump
strainer lid, lter lid or valve closures. This installation should allow
the user enough space to stand clear of the lter and pump during system start-up, shut
down or servicing of the system lter.
IMPORTANT WARNING AND SAFETY INSTRUCTIONS

5
IntelliSync Control and Monitoring System Installation Guide
FCC Standard - 47 CFR Part 15, Subpart C (Section 15.247). This version is limited to chapter 1 to chapter 11 by
specied rmware controlled in the U.S.A.
Instruction to user - This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Note: In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment.
Operation with non-approved equipment or unshielded cables is likely to result in interference to radio and TV
reception. The user is cautioned that changes and modications made to the equipment without the approval of the
manufacturer could void the user’s authority to operate this equipment.
Canada - Industry Canada (IC) Regulatory Notice: - This device complies with RSS210 of Industry Canada. (1999).
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference
to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful communication. This device complies with Industry Canada
licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Conformément à la réglementation d’Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne
d’un type et d’un gain maximal (ou inférieur) approuvé pour l’émetteur par Industrie Canada. Dans le but de réduire
les risques de brouillage radioélectrique à l’intention des autres utilisateurs, il faut choisir le type d’antenne et
son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l’intensité nécessaire à
l’établissement d’une communication satisfaisante. Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes
: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
IMPORTANT WARNING AND SAFETY INSTRUCTIONS

6
IntelliSync Control and Monitoring System Installation Guide
CUSTOMER SERVICE / TECHNICAL SUPPORT
Please visit www.pentair.com for IntelliSync™ Control and Monitoring System
manuals:
IntelliSync Quick Start Guide (P/N 523415)
IntelliSync Pentair Home App User's Guide (P/N 523491)
IntelliSync Installation Guide (P/N 523414)
P/N 523414.A 3/2020
Customer Service and Technical Support, USA
(8 AM - 5:00 PM — Eastern/Pacic Times)
Phone: [phone]
Fax: [phone]
www.pentair.com
Sanford, North Carolina (8 AM - 5.00 PM ET)
Phone: [phone]
Fax: [phone]
Moorpark, California (8 AM - 5.30 PM PT)
Phone: [phone] (Ext. 5591)
Fax: [phone]
CONTENTS
Important Warning and
Safety Instructions .......................................................................
Overview/Features .......................................................................
IntelliSync Wiring Bay ...................................................................
IntelliSync LEDs and Buttons Actions............................................
Location and Installation ..............................................................
Connecting Power ........................................................................
Connecting a SuperFlo VS, VST, and SuperMax VST,
WhisperFloXF VS and Max-E-ProXF VS Pump................................
Connecting a SuperFlo and SuperMax VS Pump to IntelliSync......
Wiring IntelliFlo (IntelliPro) Pump .................................................
Installing Ambient Air Temperature Sensor...................................
Installing Water Temperature Sensor ...........................................
Replacement Parts List ................................................................
2-4
7
8
9
10
11
11
14
15
16
16
17

7
IntelliSync Control and Monitoring System Installation Guide
IntelliSync™ Control and Monitoring System
IntelliSync Control and Monitoring System communicates to the homeowner's WiFi
router using a 2.4GHz wireless connection. The Pentair Home app can control and
monitor two pumps and two sensors through IntelliSync.
Note: IntelliSync Control and Monitoring System supports pump speeds (RPM), not
pump ows (GPM). For IntelliFlo VSF pumps, pump speeds are supported.
IntelliSync Control and Monitoring System supports the following pool and spa
pumps. Note: Pump Communication Cables are required and are sold separately.
IntelliFlo Communication Cable P/N 350122. SuperFloVS Communication Cable P/N
353129Z.
• IntelliFlo®VS Pump
• IntelliPro®VS Pump
• IntelliPro®VSF Pump
• IntelliFlo®i1 Pump
• IntelliFlo®i2 Pump
• IntelliFlo®VSF Pump
• IntelliFloXF®Pump
• IntelliProXF®Pump
• IntelliFloXFVS®Pump
• IntelliProXFVS®Pump
• IntelliFlo®VS+SVRS Pump
• IntelliPro®VS+SVRS Pump
• Temperature Sensors:
Air and Water
IntelliSync Control and
Monitoring System
(Top cover open)
• IntelliFlo®2VST Pump
• IntelliPro®2VST Pump
• SuperFlo®VS Pump*
• SuperFlo®VST Pump*
• SuperMax®VS Pump*
• WhisperFloXFVS Pump*
• Max-E-ProXFVS®Pump*
Note: (*) Pump speeds (RPM
1-3) are assigned from the
pump control pad. Speed 4 is
assigned for QuickClean. See
page 12.
Overview
Features
• Dimensions:
5 5/8" H x 7 7/8" W x 1 3/16" D
• Vertical or horizontal mounting
• Internal antenna for WiFi
(2.4 GHz) and Bluetooth®wireless
technology connectivity
• 120 VAC to 12 VDC Power Adapter

8
IntelliSync Control and Monitoring System Installation Guide
Button
Action
Connection
LED
Mode
LED
State Comment
Amber Startup, connecting to
WiFi
Normal (Briey)
Green WiFi connected with
internet
Green/Red WiFi connected; no
internet
Red/Blink WiFi conguration
needed
Unit doesn't have WiFi congura-
tion stored, has timed out.
Press
3-5 sec
Green
pulse
Bluetooth® wireless
technology pairing mode
(Temporary state)
Temporary state - will change
back to solid Green after Bluetooth
and WiFi are connected to Pentair
Home app.
Press
once
Amber Toggle Service mode
with
timeout
Disable remote and scheduled
control of equipment
(LED columns show LED state
while in Service mode, and not
about to timeout)
Green Normal (Auto mode)
Red Toggle Service mode
(Permanent hold)
Disable remote and scheduled
control of equipment. Press once
(from Service mode) Amber Toggle
Service mode with timeout
Press once
(from
Service
mode)
Amber/
Blink
Service mode about to
expire
Timeout duration
Amber Fast
Blink
Over The Air (OTA)
rmware update in
progress
Hold
during
power up
Red Blink Red
Blink
Reset to Factory Mode.
Caution, reset will
erase the SSID and the
home router network
password.
Three (3) blinks, then goes to
regular display.
Connection LED
Green: WiFi internet connected to the home network.
Yellow: Connecting to the home network.
Red: Not connected to the home network.
Mode LED
Green: System in Auto mode (normal operating mode).
Red: The system is in Service mode.
Yellow: The system is in Time out mode.
Mode Button (Bluetooth® wireless technology pairing): Press and hold
Mode button for three seconds to enter Bluetooth pairing mode.
The Connection LED will start blinking (Green). From the Pentair Home app
connect the IntelliSync Control and Monitoring System unit to the mobile
device.
RS 485 (Digital outputs): Four wire screw terminal. Black (GND), Green
(-DT), Yellow (+DT), Red (+12 VDC). Use this terminal if +12VDC is required for
equipment.
RS 485 (Digital outputs): Two wire screw terminal (Green (-DT), Yellow
(+DT). Connect IntelliFlo pumps.
SuperFlo VS Pump: Six wire screw terminal: Red (+5V), Black (GND), Green
(speed 1), Yellow (speed 2), Orange (speed 3), Brown (speed 4 - Quick Clean
feature).
Temperature Sensors (Air and Water): Two wire screw terminal for each
sensor.
PWR: Plug the provided 12 VDC, 1.5 A power plug into the power socket on
the unit. Plug the other end of the power cord into a 120 VAC power source.
See page 11.
Note: H1/H2 and S1/S2 (Not used - For future use)
IntelliSync™ Control and Monitoring System Wiring Bay
Black: Black 6C
Green: 802C
Yellow: 803C
Orange: 164C
Brown: 470C
Red: Strong Red C
Light Blue: 656C
Blue: 2728C
G
O
Br
AIR
W
ATER
Bk
R
Y
Pantone Colors:
Font: Barlow Light, medium and Condensed
H1 S1 H2 S2

9
IntelliSync Control and Monitoring System Installation Guide
IntelliSync™ Control and Monitoring LEDs and Button Action
Button
Action
Connection
LED
Mode
LED
State Comment
Amber Startup, connecting to
WiFi
Normal (Briey)
Green WiFi connected with
internet
Green/Red WiFi connected; no
internet
Red/Blink WiFi conguration
needed
Unit doesn't have WiFi congura-
tion stored, has timed out.
Press
3-5 sec
Green
pulse
Bluetooth® wireless
technology pairing mode
(Temporary state)
Temporary state - will change
back to solid Green after Bluetooth
and WiFi are connected to Pentair
Home app.
Press
once
Amber Toggle Service mode
with
timeout
Disable remote and scheduled
control of equipment
(LED columns show LED state
while in Service mode, and not
about to timeout)
Green Normal (Auto mode)
Red Toggle Service mode
(Permanent hold)
Disable remote and scheduled
control of equipment. Press once
(from Service mode) Amber Toggle
Service mode with timeout
Press once
(from
Service
mode)
Amber/
Blink
Service mode about to
expire
Timeout duration
Amber Fast
Blink
Over The Air (OTA)
rmware update in
progress
Hold
during
power up
Red Blink Red
Blink
Reset to Factory Mode.
Caution, reset will
erase the SSID and the
home router network
password.
Three (3) blinks, then goes to
regular display.

10
IntelliSync Control and Monitoring System Installation Guide
Location and Installation
Before installing the IntelliSync™ Control and Monitoring System, read the following
guidelines carefully:
• Before permanent installation, test the 2.4 GHz WiFi signal strength
at the location where the enclosure will be mounted (refer to "Testing
WiFi Signal Strength" in the IntelliSync Pentair Home App User's
Guide). IntelliSync operates on 2.4 GHz. Be sure the home network
router supports 2.4 GHz. Dual Band routers are supported.
• If possible, minimize the number and volume of obstacles that may
block the wireless signal to the enclosure.
• Before choosing the nal location for the unit, consider the length
of all of the RS-485 wires that will need to be connected to the unit.
Note: Be sure to consider cable lengths for the sensors to the unit
location as well.
• Mount the unit on a at vertical surface with unobstructed access to
the front of the unit. The unit can be mounted outside or inside of a
pool equipment shed or other enclosure.
• All electrical equipment, except for UL Listed spa-side remote
switches, must be installed no fewer than 5 ft. (1.5 m). For Canada,
3 m (9.75 ft.) from the pool and/or spa. Comply with all national, state,
and local codes.
• Install the IntelliSync unit to allow enough space at the equipment
pad to stand clear of the lter and pump during system start-up.
Mounting IntelliSync
1. Press the front sides of the cover upward and slide it off the base.
2. Insert a #12 screw (recommended) through the top and lower mounting hole.
Secure the base to mounting surface.
3. To reinstall the cover; insert the rear cover side slots onto the base and slide
downward.
Mounting Hole
Mounting Hole
(Located in base)
Cover Open
Press upward on
sides to remove
cover from base
Press upward on
sides to remove
cover from base
IntelliSync Control and Monitoring System Cover

11
IntelliSync Control and Monitoring System Installation Guide
Connecting Power to IntelliSync Control and Monitoring
System
1. Plug the IntelliSync 12 VDC, 1.5 AMP power adapter power cord to a 120 VAC
power source. Plug the other end into the IntelliSync unit.
2. Apply AC power to the IntelliSync unit. Both Mode and Connection LEDs will
illuminate. IntelliSync is ready for conguration and operation.
AC Power Plug
(connect to 120 VAC outlet)
AC Adapter Power Plug
IntelliSync Control and Monitoring System Power Plug
Connecting a SuperFlo® VS, VST, and SuperMax® VST,
WhisperFloXF® VS and Max-E-ProXF® VS Pump to IntelliSync
Used
Not
Digital Output Pump
Screw Terminals
SuperFlo® VS Pump
SuperFlo VS Pump (P/N 342001)
SuperFlo VST Pump (P/N 342002)
SuperMax VST Pump (P/N 343001)
Legacy pumps (see page 14)
SuperFlo VS Pump (P/N 342000)
SuperMax VS Pump (P/N 343000)
•
IntelliSync provides digital output screw
terminals for pump connections
• Pump must be wired with constant AC
power from a GFCI breaker
• IntelliSync must be in Auto mode (Green
LED) and Connection mode (Green LED)
for the Pentair Home app to control
pump speeds (RPM). See page 8.
Continue to next page.

12
IntelliSync Control and Monitoring System Installation Guide
Set the pump schedules to zero: To ensure any existing schedules on the pump
do not conict with the IntelliSync schedules, all schedules need to be set to zero
duration for the pump to work properly.
To zero out the pump schedules:
1. Stop the pump. Press the desired speed button until the duration LED is
blinking.
2. Press the arrow button to set each schedule duration to 0:00 (hr. min.)
3. Repeat Steps 1-2 for all speed buttons (1, 2, and 3).
Operating the SuperFlo VS/VST, SuperMax VST pump:
• The SuperFlo VS/VST, SuperMax VST pumps have four (4) default
speed settings for speeds 1, 2, and 3 and the QuickClean feature.
Speeds can only be adjusted on the pump's control key pad.
• Pump Speed Priority (Speed 1, Speed 2, Speed 3, and QuickClean):
The lowest speed number will take priority over the highest speed
number. The priority in which speeds will run is Speed 1 has the
highest priority then Speed 2, Speed 3, and Quick Clean.
Example: A recommended set up would be to set Speed 2 for the
pump ltration speed, and set a lower speed for Freeze protection
on Speed 3. If the temperatures drops to the freeze set point, the
pump will run at a low speed to keep the pool water from freezing.
When it's time to run the pump ltration schedule, the pump will ramp
up to the ltration speed since it's set as speed 2 and has higher
priority. As a rule, set up higher RPMs on the lower speed number
buttons and lower RPMs on the higher speed buttons.
Continue to next page.
(Continued)
De-Activating External Control Only
Note: If the pump has been stopped via the Start/Stop button, the pump will not
run until the pump is turned back on by pressing the Start/Stop button. If the Start/
Stop LED is illuminated, that indicates the pump is on and will run via Digital Inputs.
Note: When multiple low voltage triggers are present priority will be: PROGRAM 1 >
PROGRAM 2 > PROGRAM 3 > QUICK CLEAN.
Pump External Control Mode:
•
For proper operation with IntelliSync, the
pump should NOT be in External Control
Only mode (Green LED on). The green LED
next to Ext. Control Only should not be
illuminated.
• To take the pump out of Ext. Control Only
mode, press the Start/Stop button to stop
the pump. Press and hold the Start/Stop
button for at least 10 seconds. The green
LED should go out next to Ext. Control Only.

13
IntelliSync Control and Monitoring System Installation Guide
SuperFlo VS Pump
RED +5V OUTPUT FOR D.I. TRIGGER
GREEN SPEED 1 DIGITAL INPUT
YELLOW SPEED 2 DIGITAL INPUT
ORANGE SPEED 3 DIGITAL INPUT
BROWN SPEED 4 DIGITAL INPUT
BLACK GROUND
RED BLK
GRN
YEL
ORN
BRN
RED
GREEN
YELLOW
ORANGE
BROWN
BLACK
IntelliSync Control
and Monitoring System
to SuperFlo VS Pump
Wiring Terminals
SuperFlo VS Pump Cable Plug
DIGITAL INPUTSWIRE COLOR
Connector
(Continued)
When a Digital Input is triggered, the LED above the PROGRAM button will begin
to blink and the display will toggle between the display parameter and “E.C.”. This
indicates an External Control is running.
The pump will run the Digital Input as long as the Digital Input trigger is present and
will override any schedules programmed via the keypad. The Display button is still
functional along with the Start/Stop button.
Connecting the pump to the IntelliSync Control and Monitoring System:
1. Unplug power from the IntelliSync Control and Monitoring unit. See page 11.
2. Use a 25 ft. (7.62 m) or 50 ft. (15.2 m) low voltage, six conductor low voltage
control cable. External Control Wiring Kit (P/N 353129Z), sold separately.
3. Align the "keyed" cable plug with the pump's communication port, then insert the
plug into the port socket located on the side of the pump. Twist the lock nut on
the cable to secure the cable.
4. Run the cable from the pump to the IntelliSync unit screw terminals. Strip back
the outer jacket of the cable by 1-inch, exposing the conductors. Strip back each
conductor 1/4-inch. Insert and secure the six (6) conductors into the IntelliSync
digital output screw terminals as shown below:
Red (+5V), Black (GND), Green (Speed 1), Yellow (Speed 2), Orange (Speed 3)
Brown (Speed 4 - Quick Clean feature).

14
IntelliSync Control and Monitoring System Installation Guide
Pump Input Connector
Access to the SuperFlo VS terminals are
in close proximity to the AC power mains
connectors which carry line voltage capable
of causing personal injury or damaging the
equipment if contact is made. AC Power
to the pump should be turned off when
accessing this area.
Used
Not
IntelliSync SuperFlo® VS
Wiring Terminals
SuperFlo VS Pump
(Wiring Compartment Cover Removed)
Connecting a SuperFlo® and SuperMax® VS Pump to IntelliSync
1. Unplug power from the IntelliSync Control and Monitoring unit. See page 11.
2. Use a 25 ft. (7.62 m) or 50 ft. (15.2 m) low voltage, six conductor low voltage control
cable. External Control Wiring Kit (P/N 353129Z), sold separately.
3. Strip back the outer jacket of the cable by 1-inch, exposing the conductors. Strip
back each conductor 1/4-inch. Insert and secure the ve (5) conductors into the
pump's DIP switch digital output terminals as shown below:
4. Run the cable from the pump to the IntelliSync unit screw terminals. Strip back
the outer jacket of the cable by 1-inch, exposing the conductors. Strip back each
conductor 1/4-inch. Insert and secure ve (5) conductors into the IntelliSync
SuperFlo VS digital output screw terminals as shown below:
GREEN (STEP 1), YELLOW (STEP 2), ORANGE (STEP 3), BROWN (OVRD),
BLACK (ICOM).
5. Add a wire from J3 (RED (+), RS-485 4-pin connector) to J8 (RED- SuperFlo
6-pin connector) as shown below.
SuperFlo® VS
Digital Input Voltage Specications: 18-30 VAC (24 VAC +/- 20%) - 9-30 VDC
(12-24 VDC +/- 20%)
J3
Connecting Legacy pumps (SuperFlo VS Pump (P/N 342000) and SuperMax VS
Pump (P/N 343000) to IntelliSync:
Note: If the pump has been
stopped via the Start/Stop button,
the pump will not run until the
pump is turned back on by pressing
the Start/Stop button. If the
Start/Stop LED is illuminated, that
indicates the pump is on and will
run via Digital Inputs.
Note: When multiple low voltage
triggers are present priority will
be: PROGRAM 1 > PROGRAM 2 >
PROGRAM 3 > QUICK CLEAN.

15
IntelliSync Control and Monitoring System Installation Guide
Note: The IntelliSync™ Control and Monitoring System supports
supports control of only one IntelliFlo or one IntelliPro pump.
IntelliSync provides two RS-485 screw terminals (four and
two terminals) for pump connections.
• The IntelliFlo and IntelliPro pump must be wired with
constant AC power from a GFCI breaker.
• The IntelliSync must be in Automation (Mode LED Green), for the
Pentair Home app to send commands to control the pump speeds
(RPM).
• IntelliFlo Pump Speed Priority: As on the IntelliFlo stand alone
pump, the highest speed (RPM) takes priority over lower speeds
(RPM).
Note: IntelliSync supports pump speeds (RPM), not pump ows (GPM). For IntelliFlo
VSF pumps, pump speeds are supported. For a complete list of supported pumps,
see page 7.
1. Unplug power from the IntelliSync unit.
2.
Provided with the IntelliFlo pump is a 50 ft. (15.2 m) low voltage, two conductor
RS-485 cable. Note: The IntelliFlo communication cable is not provided with
IntelliSync. A 25 ft. (7.62 m) or 50 ft. (15.2 m) communication cable can be
purchased separately. External Control Wiring Kit (P/N 350122).
3. Connect the RS-485 communication cable plug into the socket located on the
side of the pump.
4. Run the cable from the pump to the IntelliSync unit screw terminals. Strip back
the outer jacket of the two cables by 1-inch. Strip back each conductor 1/4-inch.
5. Insert the two conductors into the IntelliSync RS-485 screw terminals (Green and
Yellow). Secure the conductors in each of the screw terminals.
Wiring an IntelliFlo® (IntelliPro®) Pump
Used
Not
RS-485
Pump
RS
485
To wire an IntelliFlo pump:
GRN
YEL
GREEN
YELLOW
Pump to IntelliSync
Wiring Terminals
To IntelliFlo pum
p

16
IntelliSync Control and Monitoring System Installation Guide
Installing the Water Temperature Sensor
Install the water temperature sensor into the plumbing system between the
ltration pump and lter. Refer to sensor installation manual (P/N 520326) for
Installing the Ambient Air Temperature Sensor
Install the air sensor in a shady area (not in direct sunlight) near the equipment pad.
Refer to sensor manual for specic sensor installation instructions.
To wire the air temperature sensor to IntelliSync Control and Monitoring System:
1. Unplug power from the IntelliSync unit. See page 11.
2. Run a 22 AWG (provided with the sensors), two-conductor cable from the Air
Sensor to the IntelliSync Air sensor screw terminals.
3. Strip back the outer jacket of the cable by 1-inch, exposing the two conductors.
Strip back each conductor 1/4-inch.
4. Insert the conductors into the Temperature AIR sensor screw terminals. Secure
the individual wires into the screw terminal. See AIR temperature screw terminal
illustration below.
IntelliSync® AIR and WATER Screw Terminals
Black: Black 6C
Green: 802C
Yellow: 803C
Orange: 164C
Brown: 470C
Red: Strong Red C
Light Blue: 656C
Blue: 2728C
G
O
Br
AIR
WATER
Bk
R
Y
Pantone Colors:
Font: Barlow Light, medium and Condensed
H1 S1 H2 S2
A licensed plumber should perform all plumbing installation, as they will be
familiar with all local, state and national codes.
Required Tools: Electric Drill, 3/8” Drill Bit, and a Flat-Head Driver
1. Unplug power from the IntelliSync unit, see page 11.
2. Be sure all power to the ltration pump is turned OFF at the circuit breaker to
prevent unexpected start-ups during installation.
3. Relieve all pressure from the ltration system at the lter.
4. Close all valves to prevent ooding.
5. Heater installed: Install the water sensor between the lter and heater. Mark the
pipe where the sensor will be installed.
6. No heater installed: Install the water sensor between the lter pump and lter.
Mark the pipe where the sensor will be installed.
7. Set the electric drill to low speed. Drill a 3/8” hole (2 in or 3 in pipe) at the mark
made in the pipe. Gently deburr the hole. See Figure 1 on next page.
Failure to relieve all pressure from the filtration system before installing this
equipment may result in serious injury.

17
IntelliSync Control and Monitoring System Installation Guide
Installing the Water Temperature Sensor (Continued)
9. Install the sensor o-ring onto the end of the sensor.
10. Insert the sensor and o-ring into the hole in the pipe. See Figure 2.
11. Wrap the clamp around the pipe and over the sensor. Tighten the clamp nut to
secure the clamp and sensor onto the pipe with a at-head screwdriver.
See Figure 2.
12. Run a 22 AWG (provided with the sensors), two-conductor cable from the sensor
to the IntelliSync Temperature Water screw terminals.
13. Strip back the outer jacket of the cable by 1-inch, exposing the two conductors.
Strip back each conductor 1/4-inch.
14. Insert the conductors into the Temperature Water sensor screw terminals.
Secure the individual wires in screw terminals. See WATER temperature screw
terminal illustration on previous page.
IntelliSync Control and Monitoring System
Replacement Parts
• Water/Air Temperature Sensor Kit (P/N 520872)
• Temperature Sensor, 10k Ohms, 40 ft - P/N 521583
• Temperature Sensor, 10k Ohms, 20 ft - P/N 521584
• Hose Clamp (1-7/8” - 5” Clamp) - P/N 476168
• Hose Clamp 2-3/4 IN – P/N 9321004
• IntelliSync Unit P/N 523404
• Top Cover P/N 523413
• Power Supply P/N 523410
• Terminal Plug (2 Position) P/N 8023302
• Terminal Plug (4 Position) P/N 8023304
• Terminal Plug (6 Position) P/N 8023306
Tighten clamp nut
O-Ring (under clamp)
3/8" Drill
2" or 3" Pipe
Water Sensor
IntelliSync® Water Sensor Installation

1620 HAWKINS AVE., SANFORD, NC 27330 • [phone]
10951 WEST LOS ANGELES AVE., MOORPARK, CA 93021 • [phone]
WWW.PENTAIR.COM
All indicated Pentair trademarks and logos are property of Pentair Inc. or its global
aliates in the U.S.A. and/or other countries. Third party registered and unregistered
trademarks and logos are the property of their respective owners.
© 2020 Pentair. All rights reserved. This document is subject to change without notice.
* 523414*
P/N 523414.A 3/2020
