Pentair PC1354-P User manual

HIGH FLOW CARBON WATER FILTER SYSTEM
WITH PRE-FILTER
PC1354-P
pentair.com/homewater

TABLE OF CONTENTS
IMPORTANT INFORMATION ........................................................................................................................................................2
CUSTOMER SERVICE CONTACT INFORMATION ..........................................................................................................................2
PRODUCT OPERATION AND SPECIFICATIONS ............................................................................................................................3
COMPLETE PARTS LIST.............................................................................................................................................................3
INSTALLATION
INSTALLATION OVERVIEW .................................................................................................................................................4
CARBON TANK SOAK ..........................................................................................................................................................5
CARBON TANK WASH .........................................................................................................................................................6
SEDIMENT FILTER INSTALLATION .....................................................................................................................................7
TANK INSTALLATION..........................................................................................................................................................8
COMPLETE THE INSTALLATION .........................................................................................................................................9
MAINTENANCE .........................................................................................................................................................................10
TROUBLESHOOTING .................................................................................................................................................................11
PRODUCT WARRANTY & REGISTRATION FORM..........................................................................................................................12
PRODUCT CERTIFICATIONS ......................................................................................................................................................13
PERFORMANCE DATA SHEET ...................................................................................................................................................14
If this or any other system is installed in a metal (conductive) plumbing system, i.e. copper or galvanized metal, the plastic
components of the system will interrupt the continuity of the plumbing system. As a result any errant electricity from improperly
grounded appliances downstream or potential galvanic activity in the plumbing system can no longer ground through contiguous
metal plumbing. Some homes may have been built in accordance with building codes, which actually encouraged the grounding
of electrical appliances through the plumbing system. Consequently, the installation of a bypass consisting of the same material
as the existing plumbing, or a grounded "jumper wire" bridging the equipment and reestablishing the contiguous conductive
nature of the plumbing system, must be installed prior to your systems use.
WARNING
When adding a ltration/softening system to homes/buildings supplied by well water, the system should be installed following
the pressure tank. DO NOT USE this system for pneumatic or hydropneumatic applications. If you are using a booster pump,
then install this system following the booster pump. If you have questions, please call customer service.
CAUTION
IMPORTANT INFORMATION
• Read these instructions carefully and determine the location of all system components before beginning installation.
• Check all applicable plumbing, building, and electrical codes for installation compliance.
• Install the system on the main water supply.
• The use of plumbers tape and/or pipe thread seal paste will be needed on all threaded connections.
• To condition all water in the home, install the Carbon Water Filter System close to the water supply inlet, and upstream of
 allotherplumbingconnections,exceptoutsidewaterpipes.Outsidefaucetsshouldremainonunlteredwater.
• Systems that contain electronic components cannot be installed outside in uncovered areas.
Homeowners Phone: [phone] Professionals Phone: [phone]
Customer Service Contact Information Section
2 • HIGH FLOW CARBON WATER FILTER SYSTEM WITH PRE-FILTER

COMPLETE PARTS LIST
Part Qty.Description Part Qty.Description
2 2
1
1
1
2
1
PVC Adaptor:
1” to ¾” Threaded PVC
Adapt0r
Note: For Use with Tank Head
Prelter System:
Blue Filter Housing,
Mounting Bracket, Phillips
Head Screws (4), Bolt Head
Screws (4), and Washers (4)
Sediment Filter
Spanner Wrench
Sediment Filter:
5 Micron Polyspun
Sediment Filter
PVC Adaptor:
1-½” to 1” Threaded PVC
Adaptor
Note: For Use with Tank Head
¾” PVC Hose Bib
Tank
Note: The parts supplied are intended to accommodate a variety of water supply lines. Additional ttings may be needed to
t to your plumbing. Visit pentair.com to view our full line of installation kits.
Specication Description PC1354-P
Rated Service Flow 17 GPM
Rated Peak Flow 21 GPM
Working Pressure Range 25 - 80 PSI
Maximum Vacuum 5 inch/127 mm Hg
Operating Temperatures 36°F – 120°F
pH Range 6 - 11
PRODUCT OPERATION AND SPECIFICATIONS
Note: Drawings are not to scale.
Additional ttings will be needed to adapt to your plumbing.
HIGH FLOW CARBON WATER FILTER SYSTEM WITH PRE-FILTER • 3

Outgoing
Water to
House
Pre-Filter
Incoming
Water
Supply
Wall
Wall
Customer-Provided
Connection
Bypass
(Recommended) Water Filter
Top View
Unions
(Recommended)
IN
OUT
INLET OUTLET
IN
OUT
INSTALLATION OVERVIEW
Note: Sediment lter position is at the discretion of your professional installer. As a general guideline, the sediment prelter is
typically installed in the "pre" position (as shown above) for well water applications. For city water applications, the sediment
lter is typically installed in the "post" position after the Carbon Water Filter System.
Prelter
Water to Home
Bypass
Shutoff Valves
0 0
Front View
Water
Filter
Note: The plumber should follow the stickers on the head.
4 • HIGH FLOW CARBON WATER FILTER SYSTEM WITH PRE-FILTER

Water will ow out of the outlet side of the Bypass Valve during this process. Be sure you perform this series of steps in a
location suitable for water ow.
Notice
Note: Your system will not be ready for use for a minimum of 48 hours while the Carbon Soak process takes place.
Please plan your installation accordingly.
CARBON TANK SOAK
Water
Garden
Hose
Garden
Hose
IN
OUT
INLET OUTLET
Water Filter
Garden
Hose
1˝ to ¾˝ Threaded
PVC Adaptor
1½˝ to 1˝ Threaded
PVC Adapter
¾˝ PVC
Hose Bib
To lter
head
Top View
Carbon Tank Soak
Note: Steps 1-8 should be done prior to installation
1. Connect the 1-½” threaded PVC adapter to the inlet side of the tank head.
2. Connect the 1” threaded PVC adapter into the 1-½” adapter.
3. Connect the ¾” PVC hose bib into the 1” adapter.
4. Connect your garden hose to the Hose bib adapter.
5. Repeat steps 1-4 on the Outlet side of the tank head.
6.FillthePentairHighFlowCarbonWaterFilterTankfulluntilwaterowsoutofthesecondhose.
7. Turn the water off.
8. Allow the carbon tank to soak for at least 48 hours prior to tank installation.
HIGH FLOW CARBON WATER FILTER SYSTEM WITH PRE-FILTER • 5

Water will ow out of the outlet side of the Bypass Valve during this process. Be sure you perform this series of steps in a
location suitable for water ow.
Notice
Note: Do not perform the Carbon Tank Wash until the Carbon Tank Soak process is complete.
CARBON TANK WASH
IN
OUT
INLET OUTLET
Water Filter
Garden
Hose
Water
Garden
Hose
Top View
Carbon Tank Wash
1. Slowly turn on the water to the full position for this entire process.
2.RunwaterthroughtheINLETsideofthelterheadfor60minutes.
3. Turn off the water.
4. Remove the hoses and the hose bib adaptors.
6 • HIGH FLOW CARBON WATER FILTER SYSTEM WITH PRE-FILTER

The Pre-Filter Housing comes with a 1½” threaded female inlet/outlet and will require additional ttings to adapt to your
plumbing. It is recommended that a shut-off valve and a bypass be plumbed in around the system before installing the
Pre-Filter system.
Notice
Top View Filter
Blue Filter Housing
Inlet Water
Supply
Mounting
Bracket
SEDIMENT FILTER INSTALLATION
Sediment Filter Cover Sediment Filter
O-Ring x2
Stand Pipe
Blue Filter Housing
Part 1
1. Unscrewthecoverfromthebluelterhousing.
2.Removetheplasticcoveringfromthesedimentlter.
3.Placethesedimentlterontothestandpipeinthebluelterhousingandsetaside.
Part 2
1. Shut off the water.
2.Attachtheltercovertothemountingbracketusingthesuppliedboltheadscrewsandwashers.Makesuretoproperly 
 orientatetheINandOUTtomatchyourowpattern.
3. Attach the mounting bracket to the wall using the supplied phillips head screws.
4.Handtightenthebluelterhousingandthen,usingthesuppliedlterwrench,lightlysnugthehousingmakingsurenotto
over-tighten (counterclockwise).
5. Determine the size of your inlet water supply line.
Note: Sediment lter position is at the discretion of your professional installer. As a general guideline, the sediment pre lter is
typically installed in the "pre" position (as shown above) for well-water applications. For city water applications, the sediment
lter is typically installed in the "post" position after the Water Softener Alternative tank.
HIGH FLOW CARBON WATER FILTER SYSTEM WITH PRE-FILTER • 7

Outgoing
Water to
House
Pre-Filter
Incoming
Water
Supply
Wall
Wall
Customer-Provided
Connection
Bypass
(Recommended) Water Filter
Top View
Unions
(Recommended)
IN
OUT
INLET OUTLET
IN
OUT
If the tank is not level, lift the tank straight up six (6) inches and tap it on the ground until the tank stands vertically.
The bottom of the tank is round and the boot allows the tank to stand upright.
Notice
CARBON WATER FILTER SYSTEM TANK INSTALLATION
2. Determine the size and material of your incoming water supply line from the Carbon Water Filter and choose the appropriate
 ttingsrequiredtoconnectittotheBypassValve.
3.InstallthettingsintotheINLETandOUTLETsidesofthelter.
4.ConnecttheincomingwatersupplyfromthesedimentltertothettingontheINLETsideofthelter.
5.ConnecttheoutgoingwatersupplytotheOUTLETsideofthelter
Do not over-tighten any of the ttings during installation.
Note: Visit pentair.com/homewater to view our full line of installation kits.
Caution
1. Level the Carbon Water Filter System Tank.
Note: See "Troubleshooting" section on tips for leveling the tank.
8 • HIGH FLOW CARBON WATER FILTER SYSTEM WITH PRE-FILTER

COMPLETE THE INSTALLATION
1. Turn on the main water supply and check for leaks.
2. Peel off the protective plastic wrap from the stainless steel tank jacket(s).
3. Add the Pentair logo sticker(s) in the desired location on the tank.
Avoid high ow rates such as bathtub, utility sinks, hose bibs, multi-headed showers, body sprayers, or anything that is
considered high ow for the rst 72 hours to avoid ow restrictions caused by carbon blockage of the top basket inside
the carbon tank.
Caution
Carbon dust may be released into the water lines of the house/building during the rst few days of water use after carbon
tank installation. The carbon dust is harmless, but may give the water a gray appearance that should diminish within a week
or 10 days depending on water use.
Caution
HIGH FLOW CARBON WATER FILTER SYSTEM WITH PRE-FILTER • 9

MAINTENANCE
Media Replacement
YourPentairHighFlowCarbonWaterFilterSystemrequirescareandcleaningafteraperiodofve(5)years.Replacement
media and instructions can be ordered on-line at www.pentair.com/homewater or by calling 877-842-1635.
Replacing the Sediment Filter
1. Turnoffthemainwatersupplytothesedimentltersystemandbypassalltanks.
2. Run a faucet (cold water) inside the house to relieve the pressure. (leave the faucet open)
3.Unscrewthebluelterhousingclockwiseusingthesuppliedlterwrench.
4.Removetheexistingsedimentlteranddiscard.
5. Remove the o-ring and wipe the upper groove clean. Lubricate the o-ring with a coating of clean silicone grease.
 Replaceo-ring.Besuretopresstheo-ringdownintothegroovewithtwongers.
Note: This step is important to ensure the proper lter seal. Make sure the upper o-rings is seated level in the groove. If the
o-ring appears damaged, stretched, or crimped it should be replaced.
6.Placeanewsedimentlterontothestandpipeinthebluelterhousing.
7.Screwthebluelterhousingontotheltercoverhandtight.Lightlysnugthehousingwiththespannerwrenchmakingsure
not to over-tighten.
8.Turnonthemainwatersupplyslowlytoallowthesedimentltersystemtollwithwaterandexpelairfromlines.Puttanks
back in service (out of bypass).
9. Check for leaks.
Sediment Filter
Itisrecommendedthatthesedimentlterbereplacedevery6-9monthsdependingontheamountofsedimentpresentinthe
watersupply.Ifthesystemhasbeenworkingproperlyandthepressureisslowing,itmaybetimetochangethesedimentlter.
Checkthesedimentlterandreplaceifnecessary.
Sediment Filter Cover Sediment Filter
O-Ring
Stand Pipe
Blue Prelter Housing
10•HIGHFLOWCARBONWATERFILTERSYSTEMWITHPRE-FILTER

TROUBLESHOOTING
Problem Solution
Water appears grey or cloudy.
Unlevel
Tank
Boot
Unlevel
Tank
Boot
Level
Tank
Unlevel
Boot
Pressure is dropping off during the carbon wash. Turn the water off and let the tank sit about 30 minutes
to allow the carbon to settle down off of the basket
inside the tank.
If the pressure drops off again, let the system stand for
72 hours. There is air trapped in the carbon bed that
needs to be released from the tank. After 72 hours have
passed, continue the carbon wash by slowly turning the
water supply back on.
If the tank is not level, lift the tank straight up six (6)
inches and tap it on the ground until the tank stands
vertically. The bottom of the tank is round and the boot
allows the tank to stand upright.
It is recommended that the sediment lter be replaced
every 6-9 months depending on the amount of
sediment present in the water supply. If the system has
been working properly and the pressure is slowing, it
may be time to change the sediment lter. Check the
sediment lter and replace if necessary.
High ow rates such as bathtubs, utility sinks, hose
bibs, multi-headed showers, body sprayers, or anything
that is considered high ow for the rst 72 hours should
be avoided. If you suspect a carbon blockage of the top
basket due to a high-ow situation within the rst 72
hours of installation, turn off any running water for at
least 10 minutes. This will clear the blockage and you
can resume using water at low or normal ow rates.
You may need to turn the head to tighten it. The tank
head ispreinstalled hand-tight, donot overtighten the
head (simply turn it snug).
This is normal with all carbon lters and this will slowly
fade away. The carbon inside the tank can still have air
pockets inside that, when released, turn the water a little
gray with carbon dust. The carbon dust is harmless.
Water may appear grey or cloudy for the rst seven to
ten days after installation due to extra carbon dust.
The tank leans to one side or is not level.
Water pressure is slowing.
Water pressure is slowing immediately after installation.
Water leaking at the top of the tank around the head.
Water inside the tank is gray.
Notice: If you have experienced a Boil Alert or require your system to be sanitized, please go to pentair.com/assets/pwsboilalert
for product sanitization instructions.
HIGH FLOW CARBON WATER FILTER SYSTEM WITH PRE-FILTER • 11

PRODUCT WARRANTY AND REGISTRATION FORM
Warranty Registration Form
Send in this Warranty Registration Form to validate your warranty or visit pentair.com/register-warranty to complete the
warranty registration form online.
For details on your Pentair product warranty, please visit pentair.com/assets/residential-ltration-warranty.
Send to:
Pentair
2361MasonAvenue,Suite100
Daytona Beach, FL 32117
Phone: [phone]
Date Item(s) were Received: Order ID#: Model:
Dealer Purchased From:
Name:
Address:
City: State: Zip:
Model/Serial Number:
12 • HIGH FLOW CARBON WATER FILTER SYSTEM WITH PRE-FILTER

PRODUCT CERTIFICATION
PC1354 is IAPMO tested and certied to NSF/ANSI 42 for Chlorine Taste and Odor, and Structural
Integrity. IAPMO tested and certied to NSF/ANSI 61 for Material Safety.
Do not use where water is microbiologically unsafe or with water of unknown quality without proper disinfection before or
after the lter/softener system.
WARNING
HIGH FLOW CARBON WATER FILTER SYSTEM WITH PRE-FILTER • 13

PERFORMANCE DATA SHEET
Performance Data - Pentair Whole House Filters
Model Replacement Max Operating
Pressure
Rated Capacity Operating
Temp Range
Rated
Flow
Rated Pressure Drop
(At Rated Flow)
PC600-P PC600-R 25-80 PSI 662,400 gallons 36°F – 120°F 8 GPM 13 PSI
PC1000-P PC1000-R 25-80 PSI 1,324,800 gallons 36°F – 120°F 12 GPM 13 PSI
PC1354-P PC1354-R 25-80 PSI 1,987,200 gallons 36°F – 120°Fs 17 GPM 13 PSI
NSF/ANSI 42 Inuent Challenge
Chlorine
Minimum Required
Reduction
Average Reduction % Results
Chlorine Reduction,
Free Available
2 mg/L ±10% ≥50% 95.93% Pass
Performance Data - Pentair Whole House Filters
Model Accumulated
Volume (Gallons)
Chlorine, Free
Available (mg/L)
Flow Rate
(GPM)
Reduction %
Inuent Euent 1
PC600-P 650,885 2.05 0.07 8 GPM 96.6%
PC1000-P
PC1354-P
1,301,770
1,952,655
2.05
2.05
0.07
0.07
12 GPM
17 GPM
96.6%
96.6%
This system has been tested according to NSF/ANSI 42 for the reduction of the substances listed below. The concentration of
theindicatedsubstancesinthewaterenteringthesystemwasreducedtoaconcentrationlessthanorequaltothepermissible
limitforwaterleavingthesystem,asspeciedinNSF/ANSI42.
Statements: Testing was performed under standard laboratory
conditions, actual performance may vary. Filter usage must
comply with all state and local laws. Filter is only to be used
withcoldwater.Systemscertiedforcystreductionmay
beusedondisinfectedwatersthatmaycontainlterable
cysts.Allcontaminantsreducedbythislterarelisted.Notall
contaminants listed may be present in your water. Filter does not
remove all contaminants that may be present in tap water. See
owner’s manual for general installation conditions and needs as
well as manufacturer’s limited warranty.
CertiedByIAPMOR&TtoNSF/
ANSI Standard 42 for the reduc-
tionofChlorineTaste&Odor,
structuralintegrity&NSF/ANSI61
for material safety.

2361 Mason Ave | Suite 100 | Daytona Beach, FL 32117 | United States
P: 877.842.1635 | Technical Services: 877.842.1635 | pentair.com/homewater
© 2021 Pentair. All indicated Pentair trademarks and logos are property of Pentair. Third party registered
and unregistered trademarks and logos are the property of their respective owners. 4006017 Rev A JN21
