PENTEK®RO-2550 4STAGE REVERSE OSMOSIS
WATER FILTRATION SYSTEM
INSTALLATION AND OPERATION MANUAL
©2014 Pentair Residential Filtration, LLC www.pentairaqua.com

IMPORTANT: Before installing this reverse osmosis system,
make certain your water supply complies with the following
operating specifications. Failure to do so may reduce the
effectiveness of the system and will void the warranty.
SPECIFICATIONS
Thin Film Membrane: TFM-50
Feed Water Pressure: 40 to 100 psi (2.75–6.9 bar)
Temperature Range: 40–100°F (4.4–37.7°C)
TDS: 2000 ppm
Maximum Hardness†: 10 gpg (171 mg/L)
Sulfide, Iron and Manganese‡: 0 ppm <0.1 ppm
Chlorine in Water Supply: Less than 2 ppm
pH Limits: 3–11
Daily Product Water Rate: 15.04 gpd (56.93 Lpd)
TDS Rejection: 96.2%
Turbidity: 11 NTU Average
†If the hardness of your water is above 10 gpg (171 mg/L), lime
scale will build up rapidly on the membrane. Scale buildup will
plug the membrane and make the system ineffective. We do not
recommend these reverse osmosis systems to be used with
water in excess of 10 gpg (171 mg/L) hardness.
‡A maximum total level of approximately 0.01 ppm sulfide, iron
or manganese is permissible. See your local dealer to reduce
these substances in your water.
PRODUCTION CAPABILITIES
Tested by NSF International according to NSF/ANSI Standard 58
has given 15.04 gallons per day. Source water test parameters
are 50 psig, 77°F, pH of 7.5 ± 0.5 and 750 ppm total dissolved
solids.
PARTS INCLUDED: (SEE BACK OF MANUAL FOR DIAGRAM)
Pre-assembled filter system (mounting bracket, membrane
housing, membrane, pre- and post-filter housings and pre-
and post-filter cartridges).
• Reverseosmosismembrane •Storagetank
• Inletsupplyadapter  •Chromefaucet
• Drainclamp  •Feedtubing
• 1/4-inchTubing  •Sumpwrenches
• Tankvalve  •3/8-inchTubing
SYSTEM DIMENSIONS:
Overall Dimensions: 131⁄2-inch W x 51⁄2-inch D x 171⁄4-inch H
  (34.29cmWx12.7cmDx43.8cmH)
Weight: 17.3lbs.(7.84kg)
Tank Dimensions: 131⁄2-inch W x 9 inch D x 9 inch H
  (34.29cmWx22.86cmDx22.86cmH)
TankCapacityMax: 2.8gal.(10.6L)
TankAirPressureEmpty: 5to7psi(0.34to0.48bar)
TankWeight(Full): 28.5lbs.(12.9kg)
INSTALLATION
The RO-2550 is Tested and Certified by NSF International
againstNSF/ANSIStandard58forthereductionofTotal
Disolved Solids, Fluoride, Turbidity, Lead, Selenium,
Copper and Cysts.
Tools and Materials Required
• Hand or electric drill
(cordless preferred)
• (2) Adjustable wrenches
• Slotted and Phillips screwdrivers
• File
• Safety glasses
• Drillbits:1/8",3/16",1/4",3/8"
If sink does not have hole for separate faucet:
• Center punch
• Cone-shaped grinding wheel
• 1-1⁄4"holesawordrillbit
• Safety mask
NOTE: All tools may not be necessary for installation. Read
installation procedures before starting to determine
what tools are necessary.
2•Pentek®RO-2550 Installation and Operating Instructions

GENERAL
WARNING:
Do not use with water that is microbiologically
unsafe or of unknown quality without adequate
disinfection before or after the system.
Systems certified for cyst reduction* may be
used on disinfected waters that may contain
filterable cysts.
*NSF/ANSIStandard58certifiedtoreducecystssuchas
Cryptosporidium and Giardia by mechanical means.
CAUTION:
Filter must be protected against freezing, which can
cause cracking of the filter and water leakage.
CAUTION:
Because of the product’s limited service life and to
prevent costly repairs or possible water damage, we
strongly recommend that the bottom of all plastic
housings be replaced every five years for clear and
ten years for opaque. If the bottom of your housing
has been in use for longer than this period, it should
be replaced immediately. Date the bottom of any
new or replacement housing to indicate the next
recommended replacement date.
NOTE:
•Yourwatermustbewithinrequiredlimitsforsatisfactory
operation. If not, your membrane life may be shortened and
your warranty will be voided (see Specifications on page 1).
•Thisreverseosmosissystemwillnotprotectagainstdisease-
causing bacteria or remove naturally-occurring harmless
bacteria.
•Installoncoldwaterlineonly.
•Donotusewickingorsealertofitconnectionsintothecapof
the filter. Plumber tape is recommended.
•Makecertainthatinstallationcomplieswithallstateand
local laws and regulations.
•Thereplacementcartridgesandreverseosmosismembrane
included with this system have limited service lives. Changes
in taste, odor, and color of the water being filtered indicate
that the cartridge should be replaced (see Replacing the Pre-
andPost-Filtersonpage8,andReplacingtheMembrane,on
page 9).
•Afterprolongedperiodsofnon-use(suchasduringa
vacation) it is recommended that the system be flushed for 5
minutes before it is used.
•Adrinkingwatercartridgemaycontaincarbonfines(very
fine black powder). After installation, flush the system for 5
minutes to remove the carbon fines before using the water.
•Itisrecommendedthatyourunthetapatleast20seconds
prior to using water for drinking or cooking purposes.
•Thecontaminantsorothersubstancesremovedorreduced
by this water treatment device are not necessarily present in
your water.
RO MEMBRANE PRECAUTIONS
CAUTION:
Chlorine will destroy the TFM-50 membrane. If you
use the RO-2550 with a chlorinated or periodically-
chlorinatedwatersupply,itisABSOLUTELY
NECESSARYtouseacarbonpre-filter(included
with the system). This carbon pre-filter should
be changed at least every 3 months to avoid
chlorine bypass. See Warranty for disclaimers and
limitations that apply to the TFM-50 membrane.
HOW REVERSE OSMOSIS WORKS
The RO-2550 Reverse Osmosis (RO) System uses a semi-
permeable membrane to reduce dissolved salts and minerals,
improving the taste and odor of your water. The RO membrane
is made of layers of micron-thin film wound around a hollow
center core. Water molecules can pass through the membrane,
but dissolved salts and minerals are rejected.
The RO-2550 Reverse Osmosis System features 4-stage filter
action.Yourwatersupplyispre-filteredtoreducedirtand
chlorine that may foul the membrane. The RO membrane
separates this pre-filtered water into PRODUCT WATER and
DRAIN or REJECT WATER. Incoming water pressure forces
the product water through the membrane and into the storage
tank. Dissolved solids and other contaminants cannot pass
through the membrane and are sent to the drain as reject
water. When you open the drinking water faucet, product water
is drawn from the storage tank through an activated carbon
post-filter, providing you with cleaner, great-tasting water.
For each gallon of water produced, several gallons are
discharged as reject water. The storage tank can hold up to
2.8gallons(10.6L)ofwateratatime,fordrinkingandcooking
needs. When used under the Specifications on page 1 of the
manual, your Reverse Osmosis membranes should last 12-24
months.
BASIC INSTALLATION PROCEDURE GUIDELINES
•Forstandard,under-sinkinstallationon3/8-inch(10mm)
steel, brass, or copper cold water line.
•Pleasereadallinstructionsandprecautionsbeforeinstalling
and using your RO-2550.
•Numbereddiagramscorrespondwithnumberedsteps.
PRECAUTIONS
•Readallinstallationandoperatinginstructionsbefore
installing and using your RO system.
•Numbereddiagramscorrespondwithnumberedsteps.
1. Installing the Water Supply Adapter
The supply adapter fits 1/2-inch 14 NPS threads. If local codes
permit, it may be used to connect the RO-2550 to the cold
water supply line. If local codes do not permit the use of the
supply adapter, alternate connectors can be obtained from your
local plumbing wholesaler.
Directions:
(A) Turn off cold water inlet supply line. If cold water line does
not have a shut-off valve under the sink, you should install
one.
(B) Turn on the cold water faucet and allow all water to drain
from line.
(C) Disconnect cold water line from 1/2-inch 14 NPS threaded
stub on bottom of main faucet.
(D) Using the nut that previously connected the cold water line
to the faucet, screw the cold water line to the male supply
adapter threads.
INSTALLATION CONTINUED . . .
NOTE:
•Tomakesurenochlorineispresentinthewaterthatreaches
the membrane, you may want to use a chlorine test kit to
check the brine/reject water that flows from the membrane to
the drain. No chlorine should be detected.
•TheTFM-50membraneisresistanttonaturally-occurring
bacteria.
Pentek®RO-2550 Installation and Operating Instructions•3

2. Selecting the Faucet Location
The drinking water faucet should be positioned with function, convenience
and appearance in mind. An adequate flat area is required to allow faucet
base to rest securely. The faucet fits through a 11⁄4-inch hole. Most sinks have
pre-drilled 11⁄2-inch or 13⁄8-inch diameter holes designed for spray hoses. The
drinking water faucet may be installed using one of these holes, despite their
larger size. If these pre-drilled holes cannot be used or are in an inconvenient
location, it will be necessary to drill a 11⁄4-inch hole in the sink or through
countertop next to the sink for the faucet.
CAUTION:
This procedure may generate dusts which can cause severe
irritation if inhaled or come in contact with the eyes. The use of
safety glasses and safety mask for this procedure is recommended.
CAUTION:
Do not attempt to drill through an all-porcelain or porcelain-coated
sink. For applications on these types of sinks we recommend using
the sprayer hole or mounting the faucet through the countertop.
CAUTION:
When drilling through a countertop make sure the area below the
drilled area is free of wiring and piping. Make certain that you have
ample room to make the proper connections to the bottom of the
faucet.
CAUTION:
Do not drill through a countertop that is more than 1 inch thick.
CAUTION:
Do not attempt to drill through a tiled, marble, granite or similar
countertop. Consult a plumber or the countertop manufacturer for
advice or assistance.
The following instructions apply to stainless steel sinks ONLY.
(A) Line bottom of sink with newspaper to prevent shavings, parts or tools
from falling
down the drain.
(B) Place masking tape over the area to be drilled to help prevent scratches if
drill bit slips.
(C) Mark point with center punch. Use a 1/4-inch drill bit to drill a pilot hole
through sink.
(D) Use a 11⁄4-inch hole saw to enlarge hole. Smooth rough edges with a file.
3. Mounting the Faucet
(A) Loosen stem-nut on faucet, remove metal slotted disc (if attached).
(B) Attachlargediameter3/8-inchdraintubetobarbfittingatthefaucetbase.
This tube should be long enough to reach the drain clamp in Step 4.
(C) Attach small diameter 1/4-inch drain tube to other barb fitting at faucet
base. This tube should be long enough to reach right side of the RO
Assembly.
(D) Slide chrome plate and black rubber washer onto faucet by threading both
drain tubes through the holes on the plate and washer.
(E) Slide white extension onto long threaded section of faucet. Open end of
extension should come in contact with base of faucet.
(F) Apply 3-5 wraps of plumber tape to faucet stem. Screw quick connector
onto end of threads.
(G)Wetendof3/8"tube.Pushintobottomofconnector.Tuggentlytobesure
connection is complete.
NOTE: To remove the tube, push on the fittings' collar and pull the tube out.
(H) Holding the faucet, feed the three tubes through the hole in the sink.
Position the faucet handle at a desired location
(I) Center the faucet and slip slotted disc between the white extension and the
bottom of the counter or sink. Tighten the stem nut with a wrench until it is
tight.
(J) Firmly insert goose-neck spout into faucet base.
4. Installing the Drain Clamp
NOTE: If you have a single-basin sink with a disposal unit, call Technical
Support for options.
NOTE: Before installing the drain clamp, check the drainpipes under the sink
D
1
A
B
C
D
D
C
1⁄4”
11⁄4”
A
B
C
D
Pilot Hole
Mounting
Hole
11⁄4"
1/4"
2
3
Counter Top
B
C
D
E
G
F
I
A
4•Pentek®RO-2550 Installation and Operating Instructions

for corrosion. Corroded pipes should be replaced before continuing with
installation.
(A) Attach the drain clamp to a vertical section of the drainpipe, about 6 inches
above the trap. Make sure the opening on the drain clamp is facing towards the
drinking water faucet (see diagram on previous page).
(B) Using the fitting hole of the drain clamp as a guide, drill a 1/4-inch hole
through one side of the drainpipe.
(C)Removethedrainclampfromthedrainpipeandenlargetheholewitha3/8-
inch drill bit. Use a file to remove rough edges from the drilled hole.
(D) Make sure the black rubber gasket is adhered to the inside of the drain clamp
and place the drain clamp assembly over the drilled hole. Look through the
hole and position the clamp so that the center of the clamp hole is slightly
higher (about 1/16-inch) than the center of the drilled hole. Tighten the clamp
securely.
(E) Screw the plastic compression nut onto the drain clamp until hand-tight.
5. Connecting the Faucet to the Drain
CAUTION:
This is a gravity drain line. Any loops, kinks or sharp bends must be
eliminated before proceeding. Failure to create a straight line to the
drain may result in reject water leaking through the air gap in the faucet
onto the countertop and below the faucet.
(A)Alignthelargerreject(3/8-inch)tubingfromthefaucetwiththecompression
nut on the drain clamp. Create as straight and smooth a path as possible with
the tubing. Do not kink tube. Cut the tubing squarely below the nut and remove
the internal and external burrs.
(B) Loosen the compression nut two complete turns. Insert the tubing into the nut
until it stops. Tighten with fingers, then tighten 1 to 2 turns with a wrench.
6. Installation of Mounting Screws
(A) If system is being installed under the kitchen sink, locate it on back or right
wall. Make sure to allow ample space for installation. To change the filter
cartridges, a minimum of 1-1⁄2 inches of clearance is required underneath the
filter housings. A minimum of 2 inches of clearance from the left side of the
unit is also required or 5 inches from the left bracket mounting screw hole.
(B) Install mounting screws at least 15 inches from cabinet floor and 71⁄2-inches
apart. Leave a 5/16-inch space between the head of the screw and the wall to
slip bracket onto screws.
NOTE: Each connection fitting on the RO Assembly has a plug that must be
removed before inserting tubing. Push in on the collar and pull the plug
out.
7. Connecting the Faucet to the System
(A) Locate the reject tubing (reject water line) from the drinking water faucet. This
tubeisthesmallerofthetwo.Placeamarkonthetubing5/8-inchfromthe
end. Moisten the end of the tubing with water and insert tubing into the quick-
connect fitting on the flow restrictor found on the right side of system behind
the membrane.
If tubing is not firmly connected, leaking will occur. It is important for the tubing to
be inserted all the way until the mark is flush with the outer edge of the quick-
connect insert.
NOTE: Tubing may be quickly and easily removed from the fitting if necessary by
pressing the collar around the fitting then pulling the tubing with your other
hand.
(B) The faucet tube from the bottom of the threaded metal tube is inserted into the
post filter. The fitting is at the top left of the RO System. Push the free end of
the tubing into the quick connect fitting.
INSTALLATION CONTINUED . . .
8. Connecting the Storage Tank to the System
CAUTION:
Whentankisfull,itweighsapproximately28.5lbs.(12.9kg)Provide
ample support under the tank.
4
A
BC
6"
D
E
5
A
B
3/8"Tube
65"(min.) 71⁄2"
15"
(min.)
11⁄2"(min.)
2"(min.)
7
A
B
Port Reference
Pentek®RO-2550 Installation and Operating Instructions•5

(A) To prevent leaks, apply 3 or more wraps of plumber tape to threads on tank.
Thread the tank valve onto the top of the tank opening. Turn tank so handle is
in line with tubing.
CAUTION:
The tank/valve connection will leak if not properly sealed. plumber tape
will normally seal the threaded connection.
(B) Locatethe1/4-inchtubing.Placeamarkonthetubing5/8-inchfromeach
end. Moisten one end of the tubing with water and insert with a twisting
motionintotheportofthetankvalveuntilthe5/8-inchmarkisflushwiththe
quick connect fitting. Then locate the tank near the system's installation area.
(C) Cut the tubing to correct length. Install free end of tubing into white quick-
connect fitting on the post filter tee on the right side. Do not cut tubing.
(D) Place entire system over mounting screws on wall and slide down.
CAUTION:
Make certain system is firmly attached to wall to prevent it from falling
and possibly becoming damaged.
NOTE: Use caution not to bend or pinch the tubing behind the system while
attaching to mounting screws.
9. Connecting the Supply Adapter and Inlet Filter
(A) Locate remaining length of 1/4-inch plastic tubing.
(B) Push into quick connect fitting on the right side of system.
(C) Cut the tube to a length that will allow connection to the cold water supply
fitting. Ensure the tubing does not kink. Push the tube into the fitting.
10. Installing the Membrane
(A) Remove tube attached to membrane housing by pressing in the white collar
around the fitting while pulling the tubing with your other hand.
(B) Hold the membrane housing with one hand and turn the cap (wrench
provided) with other hand to remove. To make it easier to hold the membrane
housing, you may want to remove the post-filter.
(C) With clean hands (sanitary gloves preferred), remove the membrane from the
plastic bag. HANDLE WITH CARE.
CAUTION:
Do not unwrap the tape around the membrane, as it is part of the
membrane. Do not squeeze membrane.
(D) With the double O-ring side first, push membrane into housing until it stops.
About1/8-inchofthemembrane’splasticcorewillstickoutbeyondthe
housing.
(E) Use clean silicone grease (pack is included with the system) to lubricate both
O-rings and the brine seal. Hand-tighten membrane housing cap until you feel
resistance, then tighten an additional 1/2 turn. Do not over-tighten.
(F) Reinsert the tube by pushing it into the quick connect fitting.
INSTALLATION CONTINUED . . .
11. Faucet Operation
(A) For controlled water flow, push the handle down.
B
Port Reference
9A
C
1/4"Tube
5/8"
16 mm
5/8"
16 mm
10
A
A
D
E
Port Reference
Port Reference
C
8A
B
1/4"Tube
Apply
plumber
tape
5/8"
6•Pentek®RO-2550 Installation and Operating Instructions

(B) For constant water flow, lift the faucet handle to lock it in the open position.
12. System Start-up
NOTE: The reverse osmosis membrane is treated with a food grade sanitizing
agent that may cause an undesirable taste. Although it is not harmful, it
should be flushed from the system.
NOTE: The post-polishing filter may contain fine black carbon particles. These
fines are harmless, but may make the water appear gray in color. The
carbon fines are flushed from the system with the first tank full of water.
NOTE: The RO system does not produce a high volume of water on demand as an
ordinary filter does. Water is produced at a slow, drop-by-drop rate. The
system requires about 2 to 4 hours to fill the storage tank. As water is taken
from the tank, the system automatically starts the cycle of replacing the
water and then stops water production when the tank is full.
CAUTION:
Visually check the entire system for leaks. If a leak is present, see
Troubleshooting on page 10.
(A) Turn off valve at top of storage tank.
(B) Turn on the cold water supply.
(C) Lift the faucet handle to lock it in the open position and let it drip for 30 min.
(D) Completely open the cold water supply until it comes to a stop. Allow water
to drip from the faucet for 12 more hours. Then close the faucet and open the
valve on the storage tank. The tank valve is open when the handle lines up with
the tubing connection.
(E) Allow 3 hours for the tank to fill. Continue to periodically check the installation
for leaks. After the storage tank is filled, open the faucet to flush the post-filter
cartridge (on the right side of the filter housing). Allow 4 to 5 minutes for all of
the water to drain from the tank. Close faucet and allow tank to fill.
(F) Repeat step E four times.
NOTE: Initially, the water may appear cloudy. This is a result of air trapped in the
post-polishing filter. It is not harmful and will disappear in a matter of
minutes. It may take up to a week after installing a new post-polishing filter
for the trapped air to dissipate.
Thesystemisreadyforoperation.Youcannowenjoyqualitywaterfromyour
Reverse Osmosis System.
TESTING YOUR REVERSE OSMOSIS SYSTEM
Model RO-2550 Reverse Osmosis System
Total Dissolved Solids (TDS) Test
NOTE:UnderNSF/ANSIStandard58,itishighlyrecommendedthatyou(the
consumer) have your water tested at least every 6 months to verify that
your system is performing satisfactorily.
SAMPLING INSTRUCTIONS:
Sampling instructions are included with the Total Dissolved Solids (TDS) Test
Kit.IftheTDSTestKitismissingfromyourunit,pleasecall800.861.8758fora
replacement.
11
Push Down
Push Up
B
A
12 Closed
Tank Valve
B
A
Counter-
clockwise
Open
Tank Valve
Total Dissolved
Solids Test Kit
Pentek®RO-2550 Installation and Operating Instructions•7

OPTIONAL INSTALLATION
Connecting your Reverse Osmosis System to Refrigerator Icemaker / Water Dispenser
CAUTION:
If you are connecting this unit to your refrigerator/icemaker with initial RO installation, wait to turn on the icemaker until
the post-polishing filter has been flushed according to Step 12.
CAUTION:
Use plastic tubing and fittings. Do not use copper tubing or brass fittings.
NOTE: For optimum performance, it is recommended that the distance between the RO system and the refrigerator icemaker/water
dispenser be no greater than 10 feet (3 m). At distances greater than 10 feet, the water pressure from the system may not be
adequate to deliver water to the refrigerator.
MATERIALS REQUIRED (available from your local hardware store):
 •3/8-inchx3/8-inchx3/8-inch(0.952cmx0.952cmx0.952cm)compressionorquick-connecttee
 •10feet(3m)of3/8-inch(0.952cm)polyethylenetubing
 • Shut-offvalve
1. Turn off refrigerator water supply and icemaker (consult manufacturer’s guidelines).
2. Close tank valve (on top of storage tank).
3. Turn off water to RO system at the cold water supply.
4. Open drinking water faucet to relieve pressure.
5. Locate tubing (permeate) leading to your drinking water faucet. Cut and insert the
3/8-inch x 3/8-inch x 3/8-inch compression or quick-connect tee into the permeate tubing.
Consult manufacturer’s guidelines before installing the supply adapter.
NOTE: When cutting the permeate tubing, you may experience some water leakage.
6. Using a length of 3/8-inch polyethylene tubing, connect the
icemaker/dispenser line with the free port on the compression tee.
7. The shut-off valve should be installed as close to this port of the tee
as possible. Shut-off valve should be installed in the OFF position
Consult manufacturer’s guidelines before installing the shut-off valve.
8. Completely open cold water supply.
9. Open tank valve.
10.Turn off the drinking water faucet.
11.Turn on water to RO system at cold water supply.
12.Turn on icemaker and open shut-off valve.
Consult manufacturer’s instructions.
13.Check for leaks and tighten connections if necessary.
1
2
7
6
5
4
3
8•Pentek®RO-2550 Installation and Operating Instructions

1st Stage Pre-Filter and 2nd Stage Pre-Filter Cartridges:
The cartridge should be replaced every six months. If your
water contains a high amount of sediment, it may be necessary
to change the 1st stage cartridge more frequently. If your water
contains a high amount of chlorine, it may be necessary to
change the 2nd stage pre-filter more often.
1. Turn off incoming water supply and valve on the storage
tank. Place a tray under the system to catch any water that
spills during removal of the filter housings.
2. Open faucet to release pressure.
3. Unscrew bottom of filter housings from caps. Use the filter
wrench. Discard used cartridges.
4. Remove black rubber O-rings from grooves in housings.
Wipe grooves and O-rings clean; set O-rings aside.
5. Rinse out housings and fill each 1/3 with water. Add 2
tablespoons of bleach and scrub with non-abrasive brush or
sponge. Rinse thoroughly.
6. Lubricate each O-ring with a coating of clean silicone grease.
With two fingers, press each O-ring securely into groove
below the threads of the appropriate housing.
CAUTION:
The rubber O-ring provides the
water-tight seal between
the cap and the bottom
of the housing. It is
important that the
O-ring be properly
seated in the groove
below the threads
of the housing or
a water leak could
occur.
7. Insert cartridges in the bottom of
the housings. Make sure
cartridge slips over standpipe in the bottom of the housing.
NOTE: Be sure to install cartridges in proper housings (see diagram
below).
8. Screw bottoms of housings back onto caps securely; do not
over-tighten. Turn on cold water supply.
Check for leaks. Continue to check periodically to make sure
no leaks develop.
4th Stage Post-Filter Cartridge: post-filter should be replaced
every twelve months.
1. Turn off incoming water supply and valve on the storage
tank. Place a tray under the system to catch any water that
spills during removal of the filter housings.
2. Open faucet to release pressure.
3. Remove filter from bracket and discard.
4. Remove tubes from fittings by pressing in collar around the
fitting while pulling the tubing out with your other hand.
NOTE: If quick connect fittings need to be installed, tape
threads of fittings with 3 wraps of plumber tape and
attach to filter.
CAUTION:
Ensure the tape is not touching O-ring on the fitting
or a leak may occur.
NOTE: The filter has an arrow on it showing the direction of
flow. The tee fitting connects to the inlet side of the filter
and the elbow fitting attaches to the outlet side.
NOTE: Hand tighten fittings, then tighten with wrench 1/4 turn.
5. Attach 4th stage filter to bracket with the tee fitting on the
right hand side.
6. Attach tubes to fittings by pushing in until the tube stops.
Check to see if tube is in place by trying to gently pull tube out.
REPLACING THE PREFILTER AND POSTFILTER CARTRIDGES
1/4"Feed
Tube
1/4"Faucet
Drain Tube
3/8"DrainTube
GS-10RO
(4th Stage Post-Filter)
TFM-50 Membrane
(3rd Stage Pre-
Filter)
P5
(1st Stage
Pre-Filter)
EPM10
(2nd Stage
Post-Filter)
1/4"Storage
Tank
Permeate
Tube
3/8"Faucet
Permeate Tube
Pentek®RO-2550 Installation and Operating Instructions•9

About the Reverse Osmosis Membrane
When used under operating conditions specified on page 1 of
the manual, your reverse osmosis membrane should last at
leastoneyear.Youshouldreplacethemembraneafter18to24
months. Replace it sooner if you notice a return of unpleasant
tastes or odors or a noticeable decline in water production. The
precise life span of your system's membrane will depend on
the quality of the water entering the system and the frequency
with which you use it. Frequent system use prevents the
filtered salts and minerals from building up on the membrane
as scale. The more water the system is required to produce,
thelongerthemembranewilllast.Youmaywishtofinda
variety of uses for your system in order to prolong the life of the
membrane.
During extended periods of non-use (such as during a
vacation), remove the membrane from the membrane housing
and place it in a sealed plastic bag. Store membrane in
refrigerator for future use. DO NOT FREEZE.
NOTE: If system stands for more than 2 to 3 days without being
used, the storage tank should be emptied.
Replacing the Membrane and Sanitizing the
System and Filters
NOTE: It is recommended that you sanitize the system each
time you change the membrane. It is not necessary to
sanitize the system when changing only the pre-filters
or post-filter.
NOTE: When installing a new membrane, it is recommended
that you replace the pre-filter and post-filter cartridges
as well.
Removing the Membrane and Filters
1. Turn off the cold water supply. Allow five minutes for system
to depressurize.
Place a tray under the system to catch any water that spills
during removal of the filter housings.
2. Open drinking water faucet to drain tank. When tank is
drained, close faucet.
3. Hold the membrane housing with one hand and remove the
cap with the other hand.
CAUTION:
Do not disconnect tubing from membrane cap.
4. To remove the RO membrane, grasp membrane tube with
pliers and pull. Discard old membrane. Screw cap back onto
membrane housing. DO NOT install new membrane.
5. Unscrew filter housings from caps and discard used
cartridges.
6. Remove black rubber O-rings from grooves in housings.
Wipe grooves and O-rings clean; set O-rings aside.
Sanitizing the System
7. Rinse out bottom of housings and fill each 1/3 with water.
Add 2 tablespoons of household bleach to each housing and
scrub cap, bottom of housings, and membrane housing with
non-abrasive sponge or cloth. Rinse thoroughly.
8. Lubricate O-rings with a coating of clean silicone grease.
With two fingers, press each O-ring securely into groove
below the threads of the appropriate housing.
CAUTION:
The rubber O-ring provides the water-tight seal
between the cap and the bottom of the housing. It is
important that the O-ring be properly seated in the
groove below the threads of the housing or a water
leak could occur.
9. Screw bottom of housing onto caps WITHOUT inserting
prefilters and hand-tighten. Do not over-tighten.
10. Open the cold water supply and let the system run for 2 to 3
minutes to carry the bleach solution throughout the system.
11. Close the cold water supply and turn on the drinking water
faucet. Let the faucet run for about 30 seconds before
turning off.
12. Let the entire system stand for 30 minutes to sanitize.
13. After 30 minutes, turn on the drinking water faucet to allow
the bleach water to run out (about 3 to 5 minutes).
14. Unscrew bottom of housings. Discard bleach water and
rinse.
Replacing the Membrane and Filter Cartridges
To replace the filters, see Replacing the Pre-Filters and
Post-Filteronpage8.
To replace the membrane, see Step 10: Installing the
Membrane
NOTE: After installing new membrane and cartridges, allow
system to run for 3 hours to fill tank. Check for leaks
every hour. As pressure builds in tank, leaks may occur
that did not exist directly after installation.
When the membrane and cartridges have been changed, follow
the system start-up procedure in Step 12: System Start-up.
SUGGESTED LIST PRICE REPLACEMENT
CARTRIDGES
 P5SedimentFilter:$3.89
EPM10 Carbon Filter: $6.50
50 GPD Element: $36.40
GAC Post Filter: $21.61
REPLACING THE 3RD STAGE REVERSE OSMOSIS MEMBRANE
10•Pentek®RO-2550 Installation and Operating Instructions

Leaks between bottom of housing and cap
1. Ensure sump is tightly screwed to cap. If it still leaks close
the cold water supply and tank valves.
2. Clean black rubber O-ring and lubricate with clean silicone
grease. With two fingers, insert O-ring in groove below
threads of housing and press into place. Tighten housing
back onto cap.
3. Open the cold water supply and tank valve.
If leaks persist, call Technical Support.
Leaks on tank valve assembly
1. Open drinking water faucet to drain storage tank. Let
drinking water faucet run until it drips. Turn off cold water
supply.
2. Push in on white collar of tank valve fitting and pull out
tubing. Unscrew the tank valve from the storage tank.
Rewrap threads on top of the tank with plumber tape. Screw
tank valve back onto tank. Trim 1/2-inch from end of tubing
andreinsert5/8-inchintotankvalvefitting.
3. Open the cold water supply and shut off the reverse osmosis
faucet. Let the system pressurize for several hours and
check for leaks. Check again after tank is fully pressurized.
Leaks on quick-connect fittings
1. Close the cold water supply and tank valve.
2. Depress plastic collar and pull out tubing.
3.Cutoff1inchoftubingandplaceamark5/8-inchfromend
of tubing. Tubing should be cut squarely. The internal and
external burrs should be removed.
4.Pushtubing5/8-inchintofitting.
5. Open the cold water supply and tank valve. If leaks persist,
call Technical Support.
No flow or slow flow from the brine (drain) line
Less than 1½ cups per minute
NOTE: Before checking brine (or reject) flow, make sure the
system is producing water by turning off the valve on the
storage tank and opening the faucet. Water should drip
from faucet.
1. Examine the P5 and EPM10 pre-filters. If clogged, replace
(seeReplacingthePre-FilterandPost-Filteronpage8)and
recheck the brine (or reject) flow rate.
2. If the pre-filters are not at fault, the brine (or drain) flow
controller is probably clogged. Call Technical Support.
High TDS in Product Water
If high levels of TDS (Total Dissolved Solids) are detected in
your product water (approximately 30% or greater of what is
measured in your tap water, as determined with a conductivity
meter or by the supplied TDS Test Kit), the RO membrane may
need to be replaced, or the brine (or drain) flow control tubing
may be clogged. See your dealer or plumber to check product
water TDS.
Reduced production
Slow or no product water flow usually indicates either a
clogged pre-filter or an exhausted membrane. First, replace
the pre-filters. If the production rate is not improved, replace
membrane.
Gradual return of taste and odor
Gradual return of unpleasant taste and odor over a period
of time may indicate that your filter cartridges and/or RO
membrane need to be replaced. See Replacing the Pre-Filters
onpage8 and Replacing the Reverse Osmosis Membrane”on
page 9.
Sudden return of taste and odor
If shortly after complete servicing noticeable taste and odors
return contact Technical Support.
No water pressure from the drinking water faucet
or low volume in storage tank
1. Close the cold water supply to system.
2. Lift storage tank to see if it is empty. If not, open the drinking
water faucet to empty water from tank.
NOTE: It may be necessary to pump a small amount of air into
the tank with a bicycle pump to remove all the water
from the tank.
3. When tank is empty, use a pressure gauge to check
tank pressure. An empty tank should contain 5 to 7 psi
pressure. Increase or decrease the air pressure in the tank
accordingly.
4. Open cold water supply. Let system run for 3 hours to fill
tank, then check system performance. If performance has
not improved, call Technical Support.
TROUBLESHOOTING GUIDE
Pentek®RO-2550 Installation and Operating Instructions•11

Important Notice: Read this performance data and compare the
capabilities of this system with your actual water treatment needs.
It is recommended that before installing a water treatment system,
you have your water supply tested to determine your actual water
treatment needs.
ThissystemhasbeentestedaccordingtoNSF/ANSI58forthe
reduction of the substances listed below. The concentration for the
indicated substances in water entering the system was reduced
to a concentration less than or equal to the permissible limit for
waterleavingthesystem,asspecifiedinNSF/ANSI58.
NOTE: Substances reduced are not necessarily in your water.
Filter must be maintained according to manufacturer’s
instructions, including replacement of filter cartridges.
Thetestedefficiencyratingforthissystemis7.68%.Efficiency
rating means the percentage of the influent water to the
system that is available to the user as reverse osmosis treated
water under operating conditions that approximate typical daily
usage. The tested recovery rating is 20.1%. Recovery rating
means the percentage of the influent water to the membrane
portion of the system that is available to the user as reverse
osmosis treated water when the system is operated without a
storage tank or when the storage tank is bypassed
Model RO-2550
Substance
Average
Influent
Concentration
Maximum
Permissible
Product
Water
Concentration
Reduction
Requirements
Average
Reduction
Standard58
Barium 10.0 mg/L ±
10% 2.0 mg/L 98.3%
Cadmium 0.03 mg/L ±
10% 0.005 mg/L 98.7%
Chromium
(Hexavalent)
0.3 mg/L ±
10% 0.1 mg/L 91.2%
Chromium
(Trivalent)
0.3 mg/L ±
10% 0.1 mg/L 94.8%
Copper 3.0 mg/L ±
10% 1.3 mg/L 98.9%
Fluoride 8.0mg/L±
10% 1.5 mg/L 95.6%
Lead 0.15 mg/L ±
10% 0.010 mg/L 98.7%
Radium
226/228 25 pCi/L ± 10% 5 pCi/L 80.0%
Selenium 0.10 mg/L ±
10% 0.05 mg/L 96.0%
Turbidity 11 NTU ± 1
NTU 0.5 NTU 99.0%
Total
Dissolved
Solids
750 mg/L ± 40
mg/L 187mg/L 96.2%
Cysts* Minimum
50,000/mL 99.95% 99.99%
PERFORMANCE DATA
*NSF/ANSIStandard58certifiedtoreducecystssuchasCryptosporidiumand
Giardia by mechanical means.
EPA#082989-CHN-001
12•Pentek®RO-2550 Installation and Operating Instructions

1 244796 Drain Clamp
2 244797 Inlet Supply Adapter
3 244959 Faucet
4 153049 Housing
5 244794 1/4-inch Tubing
6 244795 3/8-inchTubing
7244783 TankValve(1/4"NPTx1/4"QC)
8 244833 Storage Tank
9 155014-43 1st Stage Sediment Pre-filter (P5)
10 155634-43 2nd Stage Pre-filter (EPM1O)
PARTS GUIDE
11 555583-43 3rd Stage RO Membrane TFM-50
12 555574-43 4th Stage Post-filter GS-10RO-B with
fittings
13 150539 SW-1 Wrench
14 150640 RO Housing Wrench
15 143495 Silicone
16 244835 FaucetAdaptor7/16-24UNSx3/8"QC
17 244787 Valve Auto Shut-off
18 161080 Membrane Housing
19 150538 TDS Test Kit
*244837 Flow Restrictor, TFM-50 (*Not Shown)
For replacement parts, contact your nearest Water Filter dealer or call 800.279.9404
14
3
2
7
8
5
6
11
10
912
14
13
15
16
17
18
19
Pentek®RO-2550 Installation and Operating Instructions•13

Buyer Seller Date
14•Pentek®RO-2550 Installation and Operating Instructions

Pentek®RO-2550 Installation and Operating Instructions•15

FILTRATION & PROCESS
5730 NORTH GLEN PARK ROAD, MILWAUKEE, WI 53209
P:262.238.4400|WWW.PENTAIRAQUA.COM|CUSTOMERCARE:800.279.9404|[e-mail]
All Pentair trademarks and logos are owned by Pentair, Inc. or its affiliates. All other registered and unregistered trademarks and logos are the property of their
respective owners. Because we are continuously improving our products and services, Pentair reserves the right to change specifications without prior notice.
Pentair is an equal opportunity employer.
SH247113 REV C AP14 ©2014 Pentair Residential Filtration, LLC All Rights Reserved.
For Pentair® Product Warranties visit:
Pentair® para las gasantías de los productos visite:
Pour Pentair® garanties produit visitez le site:
}
www.pentairaqua.com/pro
