Pepperl+Fuchs IQT-18GM-R4-V1-Y911215 User manual

FACTORY AUTOMATION
MANUAL
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204

With regards to the delivery of products, the current issue of the following
document is applicable:
The General Terms of Delivery for Products and Services of the Electrical
Industry, published by the Central Association of the Electrical Industry
(Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its
most recent version as well as the supplementary clause: "Expanded
reservation of proprietorship"

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
Contents
Declaration of conformity..................................................................... 1
Symbols Used...................................................................................... 2
Safety.................................................................................................. 3
Intended use.................................................................................... 3
General safety instructions............................................................... 3
Product description.............................................................................. 4
Product family.................................................................................. 4
Read/write heads..........................................................................4
Tags ..............................................................................................4
Handhelds ....................................................................................5
Accessories...................................................................................... 5
Connection cables for power and serial communication ............... 5
Converter .................................................................................... 6
Installation .......................................................................................... 7
Storage and transport....................................................................... 7
Unpacking ....................................................................................... 7
Device connection............................................................................ 7
Power supply/RS-485 serial connections ..................................... 7
Ground connection...................................................................... 8
Instructions for connecting communication interface ................... 8
Commissioning ................................................................................... 10
Connection ..................................................................................... 10
Device settings................................................................................ 10
Operation through the communications interface............................. 11
Protocol with checksum.............................................................. 12
Commands.......................................................................................... 14
General information about serial interface ....................................... 14
Command examples................................................................... 14
Command types .............................................................................. 16
Single mode................................................................................16
Enhanced mode ......................................................................... 16
Command overview ......................................................................... 16
System commands.......................................................................... 19
Fixed code (read only) ..................................................................... 22
Reading data................................................................................... 23
Writing data .................................................................................... 24
Special command codes.................................................................. 26
Legend............................................................................................ 27
Error/status messages ........................................................................ 28
Troubleshooting.................................................................................. 29
Technical data..................................................................................... 30
Dimensions..................................................................................... 30
General data ................................................................................... 31
Read/write range............................................................................. 33
Read/write range in air ................................................................33
Read/write range on steel............................................................33
ASCII table.......................................................................................... 34

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
1
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
Declaration of conformity
The IDENT Control System was developed and manufactured compliant with
applicable European and North American standards and guidelines.
A corresponding declaration of conformity may be requested from the
manufacturer.
The manufacturer of the product, Pepperl+Fuchs GmbH in D-68307 Mannheim,
has a certied quality assurance program in accordance with ISO 9001.
Note
ISO9001

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
2
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
Symbols Used
This symbol warns of a danger.
Failure to observe this warning may result in personal injury
or death, or property damage or destruction.
This symbol warns of a possible fault.
Failure to observe the instructions given in this warning may
result in the device and any facilities or systems connected to
it developing a fault or even failing completely.
This symbol draws your attention to important information.
Warning
Attention
Note

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
3
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
Safety
Intended use
The IQT-... serial read heads are designed to be stand-alone. Only one read head
can be connected to the RS-485 line at a time. The serial connection should be
shielded and grounded at both the read head and the cabinet. Proper wiring
must be used.
Protection of operating personnel and the system is not
ensured if the module is not used in accordance with its
intended purpose.
The IQT-... read heads may only be operated by trained
professionals in accordance with these operating instructions.
General safety instructions
Any use other than that described in these instructions endangers the safety
and functionality of the device and the connected systems.
Only a qualied electrical technician may connect and perform maintenance on
the live device.
If malfunctions cannot be eliminated, take the device out of service and secure
it from accidental use.
Only the manufacturer can make repairs to the device. Interventions in and
modications to the device are not permissible and render the warranty null and
void.
The responsibility for the adherence to local safety standards lies with the
operator.
Warning

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
4
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
Product description
Product family
Read/write heads
Read head housing styles range from an 18 mm cylindrical to an 80 mm x 80
mm at pack. Regardless of housing style, the programming steps are identical
for all IQT-... heads.
IQT-18GM-R4-V1-Y911215 IQT-FP-R4-V1-Y911204
Tags
13.56 MHz frequency range (inductive)
Tags in this frequency range oer a signicantly higher read rate than tags
in 125- and 250-kHz systems. Since this is a non-proprietary system, cost-
eective tags are available from many third-party manufacturers. The 13.56 MHz
technology also makes so-called smart labels possible (tags as stick-on foil with
a printed optical barcode).
Available tags have a 64 bit ROM and 896 bits (IQC21-...), 256 bits(IQC31-...),
2048 bits (IQC22-...), or 7936 bits (IQC24-...) of freely programmable memory.
Tags

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
5
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
Handhelds
For process control (read/write functionality, initialization of tags), a mobile
read/write device is available.
IQT1-HH20
Accessories
Connection cables for power and serial communication
These dual ended cables can be used without modication for both power and
communication. If desired, the male end can be cut o and the read head can be
hard-wired back in the main panel.
Connector cables
Standard accessories Description
Length 2 m (straight socket, right-angled connector) V1-G-2M-PUR ABG-V1-W
Length 3 m (straight socket, right-angled connector) V1-G-3M-PUR ABG-V1-W
Length 5 m (straight socket, right-angled connector) V1-G-5M-PUR ABG-V1-W
Length 10 m (straight socket, right-angled connector) V1-G-10M-PUR ABG-V1-W
Length 15 m (straight socket, right-angled connector) V1-G-15M-PUR ABG-V1-W
Length 20 m (straight socket, right-angled connector) V1-G-20M-PUR ABG-V1-W
Congurable socket, shielded V1-G-IVH

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
6
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
Special order cables Description
Length 12 m (straight socket, right-angled connector) V1-G-12M-PUR ABG-V1-W
Length 30 m (straight socket, right-angled connector) V1-G-30M-PUR ABG-V1-W
Length 40 m (straight socket, right-angled connector) V1-G-40M-PUR ABG-V1-W
Length 50 m (straight socket, right-angled connector) V1-G-50M-PUR ABG-V1-W
Length 70 m (straight socket, right-angled connector) V1-G-70M-PUR ABG-V1-W
Length 80 m (straight socket, right-angled connector) V1-G-80M-PUR ABG-V1-W
Converter
This optional converter, Pepperl+Fuchs part number ICZ-R4-R2, is used to
convert the RS-485 signal from the read head to an RS-232 signal for use back
to a PC or PLC.
ICZ-R4-R2

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
7
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
Installation
Storage and transport
When the device is stored and/or transported, the device must be packaged and
prevented from moving and protected from humidity.
The original packaging provides the optimum protection.
Unpacking
Take note that the contents are not damaged. In case of damage, inform the post
oce or delivery agent and notify the supplier.
Check the scope of delivery against your order and the delivery documents.
Keep the original packaging in case the device must be stored or shipped at a
later date.
If you have any questions, please contact Pepperl+Fuchs.
Device connection
Plug connectors make installation simple and easy.
Power supply/RS-485 serial connections
Connection is made using an M12 plug connector. On the housing there is a
plug with the following pin layout:
IQT wiring diagram
For the appropriate connection cable, see "Connection cables for power and
serial communication"" on page 5.
Shield
+
A
-
B
1
2
3
4
1
42
3

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
8
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
Ground connection
All read heads should be grounded using the grounding screw (only included
with the IQT-FP-...) or directly with a metal bracket. The cable should be
grounded at both ends.
Principle of the ground connection
We recommend using a conductor of at least 12 AWG in size for the ground wire.
Instructions for connecting communication interface
The baud rate is congured using a serial command. The following options are
available:
1200, 2400, 4800, 9600, 19200, 38400 bps
When delivered from the factory, 9600 baud is congured.
The device works with the following xed parameters:
• 8 data bits
• 1 start bit
• 1 stop bit
• no parity
Housing Lock washer Crimp connector
Fastening screw

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
9
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
The RS-485 interface is connected using a 4-pin M12 connector. The shielding of
the cable must be attached to the connector.
Pinout of the M12 connector for RS-485
Example of connection of RS-485 interface to PC
Transmission rates, line lengths, and line types
The maximum cable length between the control unit and the computer depends
on the data rate and the level of interference. The value given here is only a
suggestion.
Standard Max. cable length
RS-485 1200 mm
1
2
3
4
1
42
3
A
-
B
+24 V
1
42
3
IQT-...-R4-V1
Host-PC
A
B
A
B

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
10
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
Commissioning
Before commissioning, make sure that no risk can occur
to the installation in which the device is installed, e.g., due to
uncontrolled processes.
Connection
Before commissioning, verify that all connections are correct.
After the power supply is connected, the green LED must light up.
Device settings
Devices must be congured before connecting them to the
interface.
Before commissioning, some parameters may have to be congured.
All parameters are non-volatile. They will remain intact even after a power cycle.
Non-volatile parameters
Parameters Factory setting Range
Read/write head
Tag type 20 20 ... 31
RS-485 interface
Baud rate 9600 1200, 2400, 4800,
9600, 19200, 38400
Timeout 1 (100 ms) 0 ... 100
Congure the read/write station using the system commands described in the
"System commands" table on page 17.
Warning
Attention
Attention

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
11
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
Operation through the communications interface
The commissioning of the IQT-... read head is described below using the serial
RS-485 interface, a PC, and a model number IPC21 tag. All the steps below
assume that the IQT-... read head is in the factory delivered state.
The factory setting of the transmission rate is 9600 baud with a 100 ms timeout.
The data carrier type is preset as "20" (tag type independent).
Check whether you have connected an RS-485 interface.
The transmission rate (baud rate) is selected through the software (see
"Instructions for connecting communication interface" on page 8). The
following transmission rates are available:
1200, 2400, 4800, 9600, 19200, 38400 bps
When delivered from the factory, 9600 baud is congured. The device works
with the following xed parameters:
• 8 data bits
• 1 start bit
• 1 stop bit
• no parity
First operating step
On the PC, open the terminal program (e.g. Hyperterminal or the command entry
window of the "RFID control," software which can be downloaded from our web
page, www.pepperl-fuchs.com).
In the terminal program, set the interface conguration to 9600 baud, 8 data
bits, no parity, 1 stop bit, and no protocol/handshake.
If you now switch the power supply to the device o and on again, after the
power is restored the following message appears on the terminal:
End character
Checksum
Status
22<ETX>

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
12
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
This tells you that communications are working between the device and the
terminal program and that the device is ready to operate. As a check, send the
version command
VE#<CR>
from the terminal. This command should be typed into a text le and sent.
Typing on the screen directly will fail because of the 100 ms serial timeout.
Depending on the device connected, you will receive a response with its name,
part number, and a version message.
Example:
0 (C) P+F IDENT-I<CR><LF>
IQT-18GM-R4-V1-Y911215<CR><LF>
#911215<CR><LF>
1830635<CR><LF>
05.04.07 #<CR>
Note
If you receive a dierent response, communication between your PC
and the device is not working correctly (the software number and
software date, however, may vary).
Check your installation and repeat the steps for commissioning.
Note
The device ignores capitalization of the commands. That is, commands
are not case sensitive. However, please note that all parameters follow
the command without spaces.
Protocol with checksum
All commands are concluded with the characters
<CHCK> = "Checksum"
and
<ETX> = "End of Text" (<ETX> = 03h).
These are used for data security in the serial transmission.
For simple operation from a standard terminal, the control unit can also accept a
#<CR>
instead of
<CHCK><ETX>.
Note
By using the checksum, you increase the data security on the interface.

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
13
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
The checksum is calculated using simple addition of all previous characters with
no overow.
Example of the calculation of the checksum:
For the message without the checksum
VE#<CR>
or
ve#<CR>
the checksum should be calculated.
First, an ASCII table is used to look up the hexadecimal values for the characters
"V" = 56h and "E" = 45h
or
"v" = 76h and "e" = 65h.
If these are added, the result is:
"V" = 56h plus "E" = 45h gives the sum 9Bh
or
"v" = 76h plus "e" = 65h gives the sum DBh.
The message with checksum is then
VE<9Bh><ETX>
or
ve<DBh><ETX>.
If a longer message is to be transmitted, there will probably be an overow in
the checksum. That is, the value obtained from the addition will no longer t in
one byte. The overow is discarded.
To transmit the message
ER000702#<CR>
with a checksum, the following checksum results:
45h + 52h + 30h + 30h + 30h + 37h + 30h + 32h = 1C0h.
After the overow is discard, the following message results with the checksum:
ER000702<C0h><ETX>.
The device ignores capitalization of the commands. However, please note
that dierent checksums result for upper- and lowercase letters. Also, do not
send the ASCII characters "C0". It is the single ASCII character which has a
hexadecimal value of C0. Many characters cannot be entered directly at the
keyboard.

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
14
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
Commands
General information about serial interface
The RS-485 serial interface allows simple, fast connection of the IQT-... read
head to a PC or PLC. No device address is used. Conguration is limited to
setting the desired baud rate and serial timeout desired.
Command examples
1st example: Setting the tag type
When delivered, the tag type 20 is congured. This tag type is used when you
want the read head to automatically determine the tag type. The 64 bit code
is read rst and the tag type is set accordingly. Because the code is read rst,
the response time is increased by at least 20 ms. To make the system as fast as
possible, set the tag type exactly to the model number used (ex. IQC21 to 21).
To do this, you send the command "change tag."
As a response you receive:
This shows that the read/write head has correctly received the command (status
= '0'). You can nd an overview of all status codes on page 28.
The data carrier type is stored in non-volatile memory.
End character
End character
Tag type IQC21
"change tag" command
CT21#<CR>
End character
End character
Status
0#<CR>
Note

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
15
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
2nd example: Writing 2 double words starting at address 7
Now place an IQC21 tag in front of the read/write head. Send the command
"single write words" (for the syntax of this command, see "single write words"
on page 24).
If the tag is in the detection range, then you receive the message
0#<CR>.
Otherwise,
5#<CR>
is returned to show that writing was not possible because the tag was outside
the detection range (status = '5'). You can nd an overview of all status codes
on page 28.
The LED on the read/write head ashes green if the read command is activated
and turns yellow if the command has been executed successfully.
3rd Example: Reading 2 double words starting at address 7
Send the read command "enhanced buered read words" (for the syntax of this
command see "enhanced buered read words" on page 23).
End character
End character
Data
Number of double words (4-byte words)
Address (in hexadecimal format)
Command "single write words"
SW000702ABCDEFGH#<CR>
End character
End character
Number of double words
Address (in hexadecimal format)
Command "enhanced buffered read words"
ER000702#<CR>

Singapore: [phone]
[e-mail]
USA: [phone]
[e-mail]
Germany: [phone]
[e-mail]
Pepperl+Fuchs Group
www.pepperl-fuchs.com
Subject to modifications without notice Copyright Pepperl+Fuchs
16
IQT-18GM-R4-V1-Y911215
IQT-FP-R4-V1-Y911204
If you bring a tag into the detection range, then the previously written data will
be displayed, with the message
Command types
When using commands, the two modes "Single mode" and "Enhanced mode"
are dierentiated.
Single mode
Each command is executed once, and an immediate response is returned. To
use this command, the tag must stop over the read head before the command is
sent by the control system.
Enhanced mode
Each command remains active until it is cancelled by the user, a new command
is sent, or there is a power cycle. A response is sent when the tag shows up
in front of the read head and also when it leaves the detection zone. These
commands are typically used to read tags "on the y."
Command overview
The commands listed are described in detail on the pages shown in the tables
below.
End character
End character
Data
Status
0ABCDEFGH#<CR>
