Percussion Play Rainbow Sambas User manual

Spares available from
percussionplay.com or from your
local distributor
Surface Fixed
Rainbow Sambas
Page 1 of 2
1. Assemble fixing brackets
to base of sambas using
M8x25mm security screws
and nyloc nuts. (1.1)( See
Assembly Guide)
2.Arrange Sambas in desired
location and mark holes to fix
to desired surface.
3. Fix to Surface using
recommended ground
anchors (Ground Anchors are
not supplied)
4. Make sure all fixings are
covered and secure using
cover caps provided
Ground Surface
Installation Instructions
Sambas will arrive
on site in pre set
heights.
(1.1)
Played with hands
Ground Fix
Components:
Instrument
Components:
Rainbow
Sambas
are pre-
assembled
Weight of heaviest part 14.6kg (XL Samba)
BS EN 1176
47 Kg
Ground Fix
Components:
M8x25 Security Screw
x34
L Brackets
x17
2 Part M12
Cover Cap
x17
M8 Nyloc Nut
x34
1.5m
1.5m
Install Instrument
with 1.5m free space
(from widest point)
around it.
230mm 230mm 230mm 230mm
Metric Conversion:
80mm/ 3”
100mm/ 4”
230mm/ 9”
300mm/ 12”
400mm/ 16”
450mm/ 18”
1.5m/ 59”

Surface Fixed
Assembly Guide PPRASA
47 Kg
Played with hands
Instrument
Components:
Rainbow
Sambas
are pre-
assembled
Rainbow Sambas
Page 2 of 2
TX 40 Driver Bit
Tools:
x1
BS EN 1176
Ground Fix
Components:
Thread Lock Solution
Required (Not Supplied)
Thread Lock Solution
Required (Not Supplied)
Spares available from
percussionplay.com or from your
local distributor
M8x25 Security Screw
x34
L Brackets
x17
2 Part M12
Cover Cap
x17
M8 Nyloc Nut
x34
PPRASA PLAN
M8x25 Pin torx X34
COMPONENTS LIST:
Surface Fix L Bracket X17
M12 2 Part black cap X17
M8 Nyloc nut X34
