Performance Tool W1637 User manual

LIMITED WARRANTY
PERFORMANCE TOOL extends only the following warranties, and only to original retail purchasers. These warranties give spe-
cific legal rights. Except where prohibited by local law, the law of the State of Washington governs all warranties and all exclusions
and limitations of warranties and remedies. There may be other rights which vary from state to state.
PERFORMANCE TOOL warrants the product to be free from defects in materials and workmanship under normal use and service.
A defective product may be returned for a free replacement within 90 days from the date of purchase, provided that product is
returned to place of purchase immediately after discovery of defect. After 90 days and up to 1 year from date of purchase,
PERFORMANCE TOOL will replace at no charge any parts which our examination shall disclose to be defective and under war-
ranty. These warranties shall be valid only when a sales receipt showing the date of purchase accompanies the defective product
or defective part(s) being returned. For part(s) after 90 days, please remit your request, postage prepaid to: PERFORMANCE
TOOL, P.O. Box 88259 Tukwila, WA 98138
These warranties exclude blades, bits, punches, dies, bulbs, fuses, and other consumables which must be replaced under normal
use and service. These warranties shall not apply to any product or part which is used for a purpose for which it is not designed,
or which has been repaired or altered in any way so as to affect adversely its performance or reliability, nor shall these warranties
apply to any product or part which has been subject to misuse, neglect, accident or wear and tear incident to normal use and
service.
PERFORMANCE TOOL does not authorize any other person to make any warranty or to assume any liability in connection with
its products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL makes no express or
implied warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL makes no implied warranty of
merchantability and no implied warranty of fitness for any particular purpose, except that for goods purchased primarily for per-
sonal, family or household use and not for commercial or business use, PERFORMANCE TOOL makes an implied warranty of
merchantability (and, if otherwise applicable, an implied warranty of fitness for a particular purpose), but only for the particular
qualities or characteristics, and for the duration, expressly warranted above. The laws on limitation of implied warranties may differ
from state to state, so the above limitations may not apply in all cases.
PERFORMANCE TOOL shall not be liable for consequential, incidental or special damages resulting from or in any manner
related to any product, or to the design, use, or any inability to use the product. The sole and exclusive remedy for a defective
product or part shall be the repair, or replacement thereof as provided above. The laws on limitation of remedies or on consequen-
tial, incidental or special damages may vary from state to state, so the above limitations may not apply in all cases.
Copyright © 2008 PERFORMANCE TOOL – All rights reserved
OPERATION
Before using your jack:
Place pump handle over release valve and turn counter-clockwise to
open. Pump jack about 6 full strokes to ensure complete distribution
of hydraulic fluid. (See Figure 1)
To raise:
Refer to vehicle owner’s manual for
proper jacking procedures. Lift only on areas of vehicle as specified
by manufacturer. Make certain that load is centered on saddle. Place
pump handle over release valve and turn clockwise to close. Insert
handle into handle socket and
pump to raise load to desired
height. ALWAYS support load
with jack stands. (See figure
2)
To lower:
Raise load enough to remove jack stands. SLOWLY turn release
valve counter-clockwise just enough to allow controlled descent.
(Never turn more than 3 full turns)
Open
Close
Release
Valve
1. When jack is not in use, ram and pump piston should be in fully down
position to keep their machined surfaces free from corrosion.
2. Keep jack clean and well lubricated at points illustrated in figure 3.
3. For best results, use only hydraulic fluid with a rating of SAE 10 for
refills. Check fluid level with jack in fully down position. Fluid level
should be up to bottom of oil fill port. (See figure 5)
4. Regularly check for loose, worn or damaged parts. Any jack that
appears damaged in any way must
be removed from service.
5. Replace worn or damaged parts with
Performance Tool replacement parts.
Be sure that only qualified personnel
perform repairs.
CARE & MAINTENANCE
1
2
3
4
Figure 3
Figure 2
Jack Stands
Figure 1
50 Ton
Hydraulic Bottle Jack
OWNER'S MANUAL
Stock Number W1637
FOR YOUR SAFETY,
please read these instructions carefully and retain them for future use.

Read these safety warnings before operation.
WARNING!
Failure to heed these warnings may result in loss of load, dam-
age to jack, and/or jack failure resulting in personal injury or
property damage.
WARNING!
This is a lifting device only. Load must be supported immedi-
ately by Jack Stands.
Do not overload jack beyond rated capacity. Overloading can
cause damage to or failure of the jack.
REFER TO YOUR VEHICLE OWNERS MANUAL FOR PROPER
JACKING PROCEDURES. Lift only on areas of the vehicle as
specified by the vehicle manufacturer.
This jack is designed for use only on hard level surfaces capa-
ble of sustaining the load. Use of jack on other than hard level
surfaces can result in jack instability and possible loss of
load.
Be sure all personnel are clear of load before lowering load.
Ensure that no personnel pass underneath load until load is
securely supported by jack stands.
Specifications are subject to
change without notice
IMPORTANT SAFETY INFORMATION
Figure 5
TROUBLESHOOTING
Your Performance Tool hydraulic jack was constructed with quality
materials and workmanship and will give you many years of trouble free
use when cared for as described in the "Care & Maintenance" section
on page 3. However, as with any mechanical device, periodic adjust-
ments are necessary to maintain a peak level of performance. Should
your jack be displaying any of the following symptoms, the simple pro-
cedures shown below will correct the problem.
Will not lift load
Will not hold load
Will not lift to full height
Pump feels "spongy" under load
Handle raises under load
Handle lowers under load
Valves may not
be closing
completely.
To seat valves:
a.) Close
release valve.
b.) With jack in
fully lowered
position,
manually raise
ram/extension
screw assy. as
high as
possible.
c.) Open release
valve and
allow jack
to descend
to lowered
position.
Power unit may
be low on fluid.
With jack on level
surface and in
down position,
remove filler plug
and add clean
hydraulic jack
fluid to level of
filler hole.
Power unit may
be airbound.
Open the release
valve a minimum
of 2 full turns.
Pump the handle
a minimum of 20
full strokes to
purge air from
the system.
NOTE:
Problems listed above with more than one solution may have a combination of causes.
Please be sure that all solutions listed for each problem have been checked to eliminate
possibility of further trouble. Sometimes solutions may need to be repeated for best results.
WARNING - Remove jack from service before making adjustments
Oil Filler Port
Check & fill
oil here.
Oil must be
level with
bottom edge
of port.
REPLACEMENT PARTS
Part # Description Qty. Part # Description Qty.
*Included in Repair Kit, stock number W1637CK
Parts List
Figure 4
24
9
10
8
7
5
11
17
19
20
16
15
13
12
2
1
234
18
23
24
2
6
23
14
SPECIFICATIONS
Capacity: ................ 100,000 lbs.
Low Height:..................... 11-3/4"
Max. Height: ................... 18-1/8"
1 W1637-1 Hydraulic Unit Body 1
2 W1637-2 6 mm Steel Ball* 3
3 W1637-3 Release Valve O-Ring* 1
4 W1637-4 Release Valve* 1
5 W1637-5 Flat Washer* 1
6 W1637-6 Pump Cylinder 1
7 W1637-7 Pump Piston O-Ring* 1
8 W1637-8 Pump Piston Back-up Ring* 1
9 W1637-9 Pump Piston* 1
10 W1637-10 Handle Socket Assembly 1
11 W1637-11 Filter Screen* 1
12 W1637-12 Cylinder Seal* 1
13 W1637-13 Cylinder 1
14 W1637-14 O-Ring* 1
15 W1637-15 O-Ring Retainer* 1
16 W1637-16 Ram Assembly 1
17 W1637-17 Reservoir 1
18 W1637-18 Oil Filler Plug* 1
19 W1637-19 O-Ring* 1
20 W1637-20 Top Nut 1
21 W1637-21 Pump Handle Set 1 Set
