Petsafe In-Ground Fence System User manual

PetSafe®In-Ground Fence™
Receiver Collar
Operating Guide
Please read this entire guide before beginning.
BATTERY 6V
RFA-67

2 1-800-732-2677
Thank you for choosing PetSafe®, the best selling brand of electronic training solutions
in the world. Our mission is to be the most trusted brand in the pet ownership
experience.We want to ensure your pet’s safety by providing you with the tools and
techniques to successfully train your pet. If you have any questions, please contact the
Customer Care Center at 1-800-732-2677 or visit our website at www.petsafe.net.
To get the most protection out of your warranty, please register your product within
30 days at www.petsafe.net. By registering and keeping your receipt, you will enjoy the
product’s full warranty and should you ever need to call the Customer Care Center, we
will be able to help you faster. Most importantly, PetSafe®will never give or sell your
valuable information to anyone. Complete warranty information is available online at
www.petsafe.net.
How the System Works
A radio signal travels from the Fence Transmitter through a buried wire, marking the
boundaries you wish to set for your dog.Your dog wears a Receiver Collar that detects
the signal at the boundary. As your dog approaches the boundary, the receiver issues a
warning tone. If he proceeds further, he receives a safe but startling Static Correction.
While harmless, the correction will persuade him to stay in the containment area
you’ve established. Boundary flags are a temporary visual aid for your pet; remove
them after training. This PetSafe®In-Ground Fence™has been proven safe,
comfortable, and effective for pets over 8 pounds.
Fence Installation and training help: www.petsafe.net/fence

www.petsafe.net 3
Prepare the Receiver Collar
Your Receiver Collar comes with short Contact Points. Long
Contact Points for pets with long or thick hair are available
through our Customer Care Center at 1-800-732-2677.Tighten
the Contact Points using Test Light Tool (A) one-half turn
beyond finger tight. Check the tightness weekly.
To Insert and Remove the Battery
Note: Do not install the battery while the Receiver Collar is
on your pet.
This Receiver Collar utilizes a replaceable PetSafe®battery
(RFA-67). This unique battery is designed to make battery
replacement easier and increase water protection.
To insert the battery, align the symbols on the battery
(arrow) and Receiver Collar (triangle) (B). Use the edge of
the Test Light Tool to turn the battery clockwise until the
arrow lines up with the lock symbol on the housing.
To remove the battery, turn the battery counter-clockwise
using the edge of the Test Light Tool (C). DO NOT attempt
to cut into or pry open the battery. Be sure to discard the
used battery properly.
A
B
C

4 1-800-732-2677
Battery life will vary depending on how often your pet tests the system and receives a
Static Correction. Test your Receiver Collar at least once a month to verify that it is
functioning properly. Check that it activates at the Boundary Wire.
A replacement PetSafe®battery (RFA-67) can be found at many retailers. Contact the
Customer Care Center at 1-800-732-2677 or visit our web site at www.petsafe.net to
locate a retailer near you.
Over Correction Protection
In the unlikely event that your pet “freezes” in the Static Correction Zone, this feature
limits the static correction duration to a maximum of 30 seconds.While the system
locks out further static correction, the warning tone will continue until the pet leaves
the Static Correction Zone.
Fit the Receiver Collar
Important: The proper fit and placement of your
Receiver Collar is important for effective training.
The Contact Points must have direct contact with
your pet’s skin on the underside of his neck.
To assure a proper fit, please follow these steps:
Make sure that the battery is not installed in the1.
Receiver Collar.
Start with your pet standing comfortably (2. D).
D

www.petsafe.net 5
Place the Receiver Collar on your pet so that the3.
“PetSafe” logo is facing your pet’s chin. Center
the Contact Points underneath your pet’s neck,
touching the skin. Note: It is sometimes necessary to
trim the hair around the Contact Points to make sure
that contact is consistent.
Check the tightness of the Receiver Collar4.
by inserting one finger between the end of
a Contact Point and your pet’s neck. The fit
should be snug but not constricting (E).
Allow your pet to wear the collar for several5.
minutes then recheck the fit. Check the fit again
as your pet becomes more comfortable with the
Receiver Collar.
F
E
Once you are satisfied with the fit of the Receiver Collar then you may trim any6.
excess collar strap as follows (F):
Mark the desired length of the Receiver Collar with a pen. Allow for growth ifa.
your pet is young or grows a thick winter coat.
Remove the Receiver Collar from your pet and cut off the excess.b.
Before placing the Receiver Collar back onto your pet, seal the edge of the cutc.
collar by applying a flame along the frayed edge.

6 1-800-732-2677
Important: For comfort, safety and effectiveness of product, please ensure
the following:
During the first 2 weeks of training, do not use the training device on your•
pet without direct supervision.
Check the fit of the Receiver Collar to prevent excessive pressure.You should•
be able to insert one finger between the Contact Point and your pet’s skin.
Never leave the Receiver Collar on your pet for more than 12 consecutive hours.•
Your pet must be carefully examined daily for any signs of a rash or sore.•
If a rash or sore is observed, discontinue the use of the Receiver Collar for a•
few days.
If the condition persists beyond 48 hours, see your veterinarian.•
Your dog’s neck and the Contact Points must be washed weekly with a wash•
cloth and mild hand soap, then rinsed thoroughly.
A condition called Pressure Necrosis, which is a devitalization of the skin due
to excessive and prolonged contact against the Contact Points, may occur if
the steps above are not followed.

www.petsafe.net 7
To Re-Thread the Collar
Slide Buckle
Ridges
The slide buckle prevents the collar from
becoming loose around your pet’s neck.
The ridges must be facing up; the collar
will slip if it is not properly threaded.

8 1-800-732-2677
Taking Your Pet Out of the Pet Area
Important: Remove the Receiver Collar and leave it in the Pet Area.
Once your pet learns the Boundary Zone, he will be
reluctant to cross it for walks or car rides.
Option 1: Replace the Receiver Collar with a regular collar.
Put your pet in a car that is within the Pet Area and drive
him out of the Pet Area.
Option 2: Replace the Receiver Collar with a regular collar
and leash.Walk your pet out of the Pet Area while giving a
command such as “OK” at a specific place of the Boundary
Zone (the end of your driveway, sidewalk, etc.). Always
leave the Pet Area with a leash at this place and your pet
will associate leaving the Pet Area only on a leash, only at
this place, and only with a person.You may initially need to
convince your pet to leave the Pet Area with a food treat and
lots of praise.
Note:You may also carry your pet out of the Pet Area.

www.petsafe.net 9
Troubleshooting
Receiver Collar
is not beeping
or correcting.
Check battery to make sure it is installed properly.•
Check that both lights are lit on the Fence Transmitter. If not,•
perform the “Short Loop Test” (page 12).
The Receiver
Collar is
beeping, but
the pet is not
responding
to the Static
Correction.
Test the Receiver Collar with the Test Light walking toward the•
Boundary Wire.
If the Test Light flashes, check the fit of the Receiver Collar.•
Trim your pet’s fur where the Contact Points touch the neck•
and/ or purchase long Contact Points by contacting the Customer
Care Center at 1-800-732-2677.
Repeat training steps to reinforce training.•
Purchase a stronger Receiver Collar by contacting the•
Customer Care Center at 1-800-732-2677.
The Receiver
Collar has
to be held
on top of the
Boundary Wire
to activate.
Replace battery.•
Adjust Boundary Width Control knob clockwise to increase•
the distance from the Boundary Wire that the Receiver Collar
activates.You can also adjust the Boundary Control Switch to
another setting.
If using a Double Loop, make sure Boundary Wires are•
separated 3 to 5 feet.
If the Receiver Collar still has to be held on top of the Boundary•
Wire, contact the Customer Care Center at 1-800-732-2677.

10 1-800-732-2677
The Receiver
Collar activates
inside the
house.
Turn the Boundary Width Control knob counterclockwise to•
decrease the distance from the Boundary Wire that the Receiver
Collar activates.
Make sure the Boundary Wire is not running too close to the•
house.The signal can transmit through the walls of your house.
Make sure Boundary Wires are twisted from Boundary to the•
Fence Transmitter.
Additional Information
The system should only be used with healthy pets. Contact your veterinarian if you•
have concerns about the medical condition of your pet (medication, pregnant, heart
conditions, etc.).
This system is not for vicious or aggressive pets. If your pet may pose a threat to•
others, DO NOT USE THIS SYSTEM. If you are unsure if your dog is aggressive,
please consult your veterinarian or a certified trainer.
The• PetSafe®In-Ground Fence™ is for residential use only.
The Static Correction will get your pet’s attention, but will not cause harm. It is•
designed to startle, not to punish.
Test the Receiver Collar at least once a month to verify that it is functioning properly.•
Check that it activates at the Boundary Wire. Battery life depends upon how often
the Receiver Collar is activated.
Remove the Receiver collar from your pet when indoors for the comfort of your pet.•
Never leave the Receiver Collar on your pet for more than 12 consecutive hours.•

www.petsafe.net 11
Test Light Instructions
Make sure the Receiver Collar battery is properly installed.1.
Hold the Test Light contacts to the Contact Points (2. G).
Walk toward the Boundary Wire with Contact Points3.
pointing up and holding the Receiver Collar at your pet’s
neck level (H) until the Receiver Collar beeps and the
Test Light flashes (I).
Note:The Receiver Collar is waterproof, which can make the
beep hard to hear.
G
Save the Test Light for future testing.
If the Test Light does not flash, refer
to the Troubleshooting section, or
contact the Customer Care Center
at 1-800-732-2677.
H
Boundary
Wire
I

12 1-800-732-2677
Short Loop Test
The Short Loop Test is a simple test to determine if each component (Fence
Transmitter, Receiver Collar and Boundary Wire) is functioning properly.
Disconnect the Boundary Wire.1.
Cut approximately 10 feet of unused Boundary Wire and connect it to the2.
Boundary Wire Terminals.
Spread the Boundary Wire out into a circle. Set the Boundary Control Switch to B.3.
Set the Boundary Width Control knob to 10.4.
If the Loop Indicator Light is not lit, then your Fence Transmitter is not5.
functioning
properly. Contact the Customer Care Center at 1-800-732-2677.
If the Loop Indicator Light is lit, disconnect one end of the Boundary Wire from6.
the Boundary Wire Terminal.
If the loop alarm does not sound, the Fence Transmitter needs to be replaced.7.
Contact the Customer Care Center at 1-800-732-2677.
If the loop alarm does sound, plug the Boundary Wire back into the Boundary8.
Wire Terminal.
Hold the Test Light Contacts to the Receiver Contact Points. Hold the Receiver9.
Collar next to the 10-foot length of Boundary Wire. The Receiver Collar should
beep about one foot away from the Boundary Wire. The Test Light should then
flash as you hold the Receiver Collar closer to the Boundary Wire.

www.petsafe.net 13
If Receiver Collar does not beep and the Test Light does not flash, replace the10.
battery in the Receiver Collar. If it still does not beep and the Test Light does not
flash, contact the Customer Care Center at 1-800-732-2677.
If the Receiver Collar beeps, there may be a complete or partial break in the11.
Boundary Wire.
Terms of Use and Limitation of Liability
Terms of Use1.
This Product is offered to you conditioned upon your acceptance without
modification of the terms, conditions and notices contained herein. Usage of this
Product implies acceptance of all such terms, conditions, and notices.
Proper Use 2.
This Product is designed for use with pets where training is desired.The specific
temperament of your pet may not work with this Product. We recommend that you
not use this Product if your pet is less than 5 pounds or if your pet is aggressive.
If you are unsure whether this is appropriate for your pet, please consult your
veterinarian or certified trainer.
Proper use includes reviewing the entire Guide provided with your Product and
any specific Caution statements.

14 1-800-732-2677
No Unlawful or Prohibited Use3.
This Product is designed for use with pets only. This pet training device is not
intended to harm, injure or provoke. Using this Product in a way that is not
intended could result in violation of Federal, State or local laws.
Limitation of Liability4.
In no event shall Radio Systems®Corporation be liable for any direct, indirect,
punitive, incidental, special or consequential damages, or any damages whatsoever
arising out of or connected with the use or misuse of this Product. Buyer assumes
all risks and liability from the use of this Product.
Modification of Terms and Conditions5.
Radio Systems®Corporation reserves the right to change the terms, conditions and
notices under which this Product is offered.
Compliance
FCC/Canada
This Class B digital apparatus complies with Canadian ICES-003.This equipment has
been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a residential environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction guide, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in

www.petsafe.net 15
a practical installation. If this equipment causes harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Relocate the interfered receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different to that to which the•
receiver is connected.
Contact the Customer Care Center at 1-800-732-2677.•
This device complies with Industry Canada Rules.This device complies with part 15
of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Unauthorized changes or modifications to the equipment, not approved by Radio
Systems®Corporation, could result in not meeting compliance with FCC regulations
and could void the user’s authority to operate the equipment.
Australia
This device complies with the applicable EMC requirements specified by the ACMA
(Australian Communications and Media Authority).

16 1-800-732-2677
Customer Care International
United States / Canada: 1-800-732-2677
Australia: 1800 786 608
New Zealand: 0800 543 054
Caution
This System is NOT a solid barrier.The system is designed to act as a deterrent,
using Static Correction to condition pets to remain outside of the established barrier
area. It is important that you reinforce training with your pet on a regular basis.
Since the tolerance level to Static Correction varies from pet to pet, Radio Systems®
Corporation CANNOT guarantee that the system will in all cases keep a pet outside
of the established barrier area. Not all pets can be trained to avoid entering the barrier
area.Therefore, if you have reason to believe that your pet may harm himself or pose
a danger to others if he is not kept from entering the barrier area, you should NOT
rely solely upon this system to restrict your pet. Radio Systems®Corporation shall
NOT be liable for any personal injuries, property damage, injury to or death of your
pet, economic loss or any consequential damages sustained as a result of any animal
entering the barrier area.

www.petsafe.net 17
Perchlorate Battery
Perchlorate Material – special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate.

18 1-800-732-2677

www.petsafe.net 19

Radio Systems®Corporation
10427 Electric Avenue
Knoxville, TN 37932
1-800-732-2677
www.petsafe.net
Protected by US Patents 6,921,089 and D515,027.
Other patents pending.
400-1116/1
©2004 Radio Systems®Corporation
