Philco POB 15 X User manual

POB 15 X
BUILTIN ELECTRIC OVEN
USER’S MANUAL

Dear customer,
thank you for buying aPHILCO brand product. So that your appliance serves you well, please read
all the instructions in this user’smanual.

EN - 1
07/2016
Copyright © 2016, Fast ČR, a. s.
CONTENTS
PART 1: IMPORTANT SAFETY INSTRUCTIONS ............................................................................................. 2
PART 2: HOW TO USE ...................................................................................................................................... 6
PART 3: PRODUCT DESCRIPTION .................................................................................................................. 6
PART 4: ACCESSORIES .................................................................................................................................... 7
PART 5: SHELF PLACEMENT WARNING:........................................................................................................ 8
PART 6: BULB REPLACEMENT........................................................................................................................ 8
PART 7: SECURING THE OVEN TO THE CABINET.......................................................................................... 8
PART 8: VENTILATING OPENINGS ................................................................................................................. 9
PART 9: CONNECTION OF THE OVEN ............................................................................................................ 9
PART 10: INSTALLATION................................................................................................................................. 9
A ) INSTRUCTIONS FOR INSTALLATION................................................................................................. 9
B) TECHNICAL DRAWINGS..................................................................................................................... 10
PART 11: CLEANING AND MAINTENANCE.................................................................................................. 11
PART 12: INFORMATION SHEET................................................................................................................... 12

EN - 2
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 1: IMPORTANT SAFETY INSTRUCTIONS
ACKNOWLEDGMENT
Thank you for purchasing our product. We hope you enjoy using the many features and bene ts it provides.
Before using this product please study this entire Instruction Manual carefully. Keep this manual in a safe place
for future reference. Ensure that other people using the product are familiar with these instructions as well.
WARNING
•When the oven is rst switched on, it may give o
an unpleasant smell. This is due to the bonding
agent used for the insulating panels within the
oven.
Please run up the new empty product with
the conventional cooking function, 250 °C,
90 minutes to clean oil impurities inside the cavity.
•During the rst use, it is completely normal that
there will be a slight smoke and odors. If it does
occur, you merely have wait for the smell to clear
before putting food into the oven.
•Please use the product under the open
environment.
•The appliance and its accessible parts become
hot during use. Care should be taken to avoid
touching heating elements. Children less
than 8 years of age shall be kept away unless
continuously supervised.

EN - 3
07/2016
Copyright © 2016, Fast ČR, a. s.
•If the surface is cracked, switch o the appliance
to avoid the possibility of electric shock.
•This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall
not be made by children without supervision.
•During use, the appliance becomes very hot.
Care should be taken to avoid touching heating
elements inside the oven.
•Do not allow children to go near the oven when
it is operating, especially when the grill is on.
•Ensure that the appliance is switched o before
replacing the oven lamp to avoid the possibility
of electric shock.
•The means for disconnection must be
incorporated in the xed wiring in accordance
with the wiring specications.
•Children should be supervised to ensure that
they do not play with the appliance.

EN - 4
07/2016
Copyright © 2016, Fast ČR, a. s.
•This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by person responsible for
their safety.
•Accessible parts may become hot during use.
Young children should be kept away.
•An all-pole disconnection means must be
incorporated in the fixed wiring in accordance
with the wiring rules.
•If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
•Do not use harsh abrasive cleaners or sharp
metal scrapers to clean the oven door glass since
they can scratch the surface, which may result in
shattering of the glass.
•A steam cleaner is not to be used.
•The appliances are not intended to be operated
bymeansofanexternaltimerorseparateremote-
control system.
•This appliance is intended to be used only in
household.

EN - 5
07/2016
Copyright © 2016, Fast ČR, a. s.
•The instructions for ovens that have shelves shall
include details indicating the correct installations
of the shelves.
SAFETY HINTS
• Do not use the oven unless you are wearing something on your feet. Do not touch the oven with wet or
damp hands or feet.
• For oven: Oven door should not be opened often during the cooking period.
• The appliance must be installed by an authorized technician and put into use. The producer is not
responsible for any damage that might be caused by defective placement, and installation by unauthorized
personnel.
• When the door or drawer of oven is open do not leave anything on it, you may unbalance your appliance
or break the door.
• Some parts of appliance may keep its heat for a long time; it is required to wait for it to cool down before
touching onto the points that are exposed to the heat directly.
• If you will not use the appliance for a long time, it is advised to plug it o.
FITTING THE OVEN INTO THE KITCHEN UNIT
Fit the oven into the space provided in the kitchen unit; it may be tted underneath a work top or into an
upright cupboard. Fix the oven in position by screwing into place, using the two xing holes in the frame. To
locate the xing holes, open the oven door and look inside. To allow adequate ventilation, the measurements
and distances adhered to when xing the oven.
IMPORTANT
If the oven is to work properly, the kitchen housing must be suitable. The panels of the kitchen unit that
are next to the oven must be made of a heat resistant material. Ensure that the glues of units that are
made of veneered wood can with stand temperatures of at least 120 ºC. Plastics or glues that cannot
withstand such temperatures will melt and deform the unit, once the oven has been lodged inside the
units, electrical parts must be completely insulated. This is a legal safety requirement. All guards must
be rmly xed into place so that it is impossible to remove them without using special tools. Remove the
back of the kitchen unit to ensure an adequate current of air circulates around the oven. The hob must
have a rear gap of at least 45 mm.
DECLARATION OF COMPLIANCE
When you have unpacked the oven, make sure that it has not been damaged
in any way. If you have any doubts at all, do not use it: contact a professionally
qualied person. Keep packing materials such as plastic bags, polystyrene, or nails
out of the reach of children because these are dangerous to children.

EN - 6
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 2: HOW TO USE
• If no need to set the cooking time, when turn counterclockwise the timer knob to “ ”, the timer will not
return to“0”automatically and the oven will keep in power-on state.
• If need to set the cooking time, turn clockwise the timer knob to the time you need.
When the setting cooking time was reached, the timer will return to “0” automatically with the sound of
“Ding, Ding, Ding”and the oven will be power-o.
• To set functions by turning the function knob to desired level.
• To set the temperature by turning the temperature knob.
The oven will automatically start cooking after function, time and temperature are set.
• If the oven is not in use, always set all the knobs to“0”.
PART 3: PRODUCT DESCRIPTION
Function Knob Timer knob Temperature Knob
Symbol Function description
Oven Lamp: Which enables the user to observe the progress of cooking without opening the door.
Oven lamp will light for all cooking functions.
Defrost:The circulation of air at room temperature enables quicker thawing of frozen food, (without
the use of any heat). It‘s a gentle but quick way to speed up the defrosting time and thawing of
ready-made dishes and cream lled produce etc.
Bottom heater: Heat is applied only by the bottom side of the oven. Use this option for browning
the bottom side of the food. This function is suitable for slow cooking recipes or for warming up
meals.
Conventional cooking: Heaters from the upper and the lower side uniformly heat the exposed food.
Baking and roasting is possible only at single level.
Convention with fan: The top heating element and the bottom heating element are working with
fan. The appliance to be cooked is evenly and quickly cooked all around.
Grill-small: This cooking method is normal grilling, utilizing the inner part only of the top heating
element, which directs heat downwards onto the food.
Double grill: The inner heating element and the outer heating element in the top of the oven are
working. Suitable for grilling larger quantities
Double grill with fan (at the rear panel): The inner heati.ng element and the outer heating element
in the top of the oven are working with fan. It is suitable for grilling large amount of meat.
Warm air heated: Warm air heated by the rear heater is evenly distributed throughout the oven
very fast by means of the fan. This results in a faster and more economical cooking process.
The convection allows food to be cooked simultaneously on dierent shelves.

EN - 7
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 4: ACCESSORIES
Wire shelf:
For grill .dishes, cake pan with items for roasting and grilling.
Slider bracket:
These shelf support rails on the right and left sides of the oven can
be removed for cleaning oven walls.
(only for specic models)
Universal pan:
For cooking large quantities of food such as moist cakes, pastries,
frozen food etc, or for collecting fat/ spillage and meat juices.
Telescopic runner:
Some of models might with telescopic runners to facilitate the use
of oven.
These telescopic runners could be disassembled for cleaning by
unscrew the screws use to x it.
(only for specic models)

EN - 8
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 5: SHELF PLACEMENT WARNING:
To ensure the oven shelves operate safely, correct placement of the shelves between the side rail is imperative.
This will ensure that during careful removal of the shelf or tray, hot food items should not slide out.
PART 6: BULB REPLACEMENT
For replacement, process as follows:
1. Disconnect power from the mains outlet or switch o the circuit breaker of the unit’s mains outlet.
2. Unscrew the glass lamp cover by turning it counter-clockwise (note, it may be sti) and replace the bulb
with a new one of the same type.
3. Screw the glass lamp cover back in place.
NOTE:
Only use 25-40W/220V-240V, T300°C halogen lamps.
PART 7: SECURING THE OVEN TO THE CABINET
1. Fit oven into the cabinet recess.
2. Open the oven door.
3. Secure the oven to the kitchen cabint with two distance holders“A”
which t the holes in the oven frame and t the two screws“B”.

EN - 9
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 8: VENTILATING OPENINGS
When cooking is nished, if the temperature of ventilating openings is over 70 degree, the cooling fan will
continue working. The cooling fan will not stop working until the temperature becomes lower than 60 degree.
Ventilating openings
PART 9: CONNECTION OF THE OVEN
L
N
PART 10: INSTALLATION
A) INSTRUCTIONS FOR INSTALLATION
Installation
WARNING!
Only a qualied person mustinstall this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Obey the installation instruction supplied with the appliance.
• Always be careful when you move the appliance because it is heavy. Always wear safety gloves.
• Do not pull the appliance by the handle of the door.
• Keep the minimum distance from the other appliances and units.
• Make sure that the appliance is installed below and adjacent safe structures.
• The sides of the appliance must stay adjacent to appliances or to units with the same height.

EN - 10
07/2016
Copyright © 2016, Fast ČR, a. s.
Electrical connection
WARNING!
Risk of re and electrical shock.
• All electrical connections should be made by a qualied electrician.
• The appliance must be earthed.
• Make sure that the electrical information on the rating plate agrees with the power supply. If not, contact
an electrician.
• Always use a correctly installed shockproof socket.
• Do not use multi-plug adapters and extension cables.
• Make sure not to cause damage to the mains plug and to the mains cable. Contact the Service or an
electrician to change a damaged mains cable.
• Do not let mains cables to come in touch with the appliance door, specially when the door is hot.
• The shock protection of live and insulated parts must be fastened in such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is
access to the mains plug after the installation.
• If the mains socket is loose, do not connect the mains plug.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
• Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses removed from the
holder), earth leakage trips and contactors.
• The electrical installation must have an isolation device which lets you disconnect the appliance from the
mains at all poles. The isolation device must have a contact opening width of minimum 3 mm.
B) TECHNICAL DRAWINGS FOR INSTALLATION
C575
B595
A595
G560
F570
min. H560
D606
E600
80 250
100
Remark:
1. Only plus deviations are admissible for all dimension.
2. The cabinet is not include the power switch or socket.
NOTE:
The number of accessories included depends on the particular appliance purchased.

EN - 11
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 11: CLEANING AND MAINTENANCE
For the sake of good appearance and reliability, keep the unit clean. The modern design of the unit facilitates
maintenance to a minimum. The parts of the unit which come into contact with food have to be cleaned
regularly.
• Before any maintenance and cleaning, disconnect the power.
• Set all controls in the OFF position.
• Wait until the inside of the unit is not hot but only slightly warm- cleaning is easier than when warm.
• Clean the surface of the unit with a damp cloth, soft brush or ne sponge and then wipe dry.
In case of heavy soiling, use hot water with non- abrasive cleaning product.
• For cleaning the glass of the oven door, do not use abrasive cleaners or sharp metal scrapers, these can
scratch the surface or lead to the glass being damaged.
• Never leave acidic substances (lemon juice, vinegar) on stainless steel parts.
• Do not use a high pressure cleaner for cleaning the unit.The baking pans may be washed in mild detergent.
WARNING!
Risk of injury, re or damage to the appliance.
• Be careful when you remove the door from the appliance. The door is heavy!
• Clean regularly the appliance to prevent the deterioration of the surface material.
• Remaining fat or food in the appliance can cause re.
By ensuring this product is disposed correctly, you will help prevent potential negative consequences for
the environment and human health, which could otherwise be caused by inappropriate waste handling of
this product. The symbol on the product indicates that this product may not be treated as household waste.
Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic
equipment. Disposal must be carried out in accordance with local environmental regulations for waste dispoasl.
For more detailed information about treatment, recovery and recycling of this product, please contact your
local city oce, your household waste disposal service or the shop where you purchased the product.

EN - 12
07/2016
Copyright © 2016, Fast ČR, a. s.
PART 12: INFORMATION SHEET
INFORMAČNÍ LIST: Philco
Obchodní značka Philco:
Name Philco
Model identication number POB 15 X
Energy eciency index * 94
Energy eciency class A
Power consumption per cycle for baking area ** 0.84 kWh/cycle
Power consumption per cycle for baking area *** 0.81 kWh/cycle
Number of baking areas 1
Heat source electricity
Oven volume **** 70 l
Type of oven built-in
Gross / net weight (kg) 33.4/29.6
Complies with norm EN 60350/-1.
*(EEI of baking area)
** in natural convection mode (convection heat function)
*** in forced convection air mode
**** Volume of individual baking zones

EN - 13
07/2016
Copyright © 2016, Fast ČR, a. s.
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING MATERIALS
Dispose of packaging material at a public waste disposal site.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES
The meaning of the symbol on the product, its accessory or packaging indicates that this product
shall not be treated as household waste. Please, dispose of this product at your applicable
collection point for the recycling of electrical & electronic equipment waste. Alternatively in
some states of the European Union or other European states you may return your products to
your local retailer when buying an equivalent new product. The correct disposal of this product
will help save valuable natural resources and help in preventing the potential negative impact on
the environment and human health, which could be caused as a result of improper liquidation of
waste. Please ask your local authorities or the nearest waste collection centre for further details.
The improper disposal of this type of waste may fall subject to national regulations for fi nes.
For business entities in the European Union
If you wish to dispose of an electrical or electronic device, request the necessary information from
your seller or supplier.
Disposal in other countries outside the European Union
If you wish to dispose of this product, request the necessary information about the correct disposal
method from local government departments or from your seller.
This product meets all the basic EU regulation requirements that relate to it.
Changes to the text, design and technical specifi cations may occur without prior notice and we reserve the
right to make these changes.
Czech is the original version.
Manufacturer address: PHILCO, Praha 10, Černokostelecká 2111, CZ-10000; CZECH REPUBLIC

EN - 14
07/2016
Copyright © 2016, Fast ČR, a. s.
Table of contents
Other Philco Oven manuals

Philco
Philco POB 16 XP User manual

Philco
Philco POB90 User manual

Philco
Philco POB68 User manual

Philco
Philco POB70 User manual

Philco
Philco POB 7810 CBX User manual

Philco
Philco POP 688 BX User manual

Philco
Philco M32 Series User manual

Philco
Philco POB62 User manual

Philco
Philco POB 6010 X User manual

Philco
Philco POB93 User manual

Philco
Philco POC 19 STXP User manual

Philco
Philco PSO6072 User manual

Philco
Philco POB79 User manual

Philco
Philco POB68 User manual

Philco
Philco PSMO634X User manual

Philco
Philco POB 18 XP User manual

Philco
Philco POB 819 User manual

Philco
Philco POP 788 TBX User manual

Philco
Philco POB77 User manual

Philco
Philco POB 321 User manual
