Philco PSMO634X User manual

Built-in Combination Steam
Oven with Hot air and
Microwave
USER MANUAL
Model : PSMO634X
Read these instruction carefully before
using your oven, and keep it carefully.
If you follow the instructions, your oven
will provide you with many years of
good service.
SAVE THIS USER MANAL CAREFULLY

CONTENTS 2
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY 3
ADDENDUM 3
SPECIFICATIONS 3
IMPORTANT SAFETY INSTRUCTION 4-5
TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION
SETTINGUPYOUR OVEN
IMPORTANT INFORMATION ABOUT INSTALLING 9
PLACEMENT 10
INSTALLATIONDIMENSIONS 1
BUILDING IN
BEFORE FIRST USE 1
OPERATION INSTRUCTION 1
TROUBLESHOOTING
CONTENTS
8
10-11
2
3-31 30
2
0
6-8

(a) Do not attempt to operate this oven with the door open since this can
result in harmful exposure to microwave energy. It is important not to
break or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent person.
If the apparatus is not maintained in a good state of cleanliness, its surface could
be degraded and affect the lifespan of the apparatus and lead to a dangerous
situation.
Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
External Dimensions:
Net Weight:
Rated Output Power(Grill):
Rated Input Power(Convection):
230V~50Hz
900W
Approx.
454mm
Rated Input Power(Steam):
3 L
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
Specifications
ADDENDUM
1550W
1200W
1750W
1500W
550
4
33kg
595
Rated Input Power(Maximum):
00W33
3
PSMO634X

IMPORTANT SAFETY INSTRUCTIONS
WARNING To reduce the risk of fire, electric shock, injury to persons
or exposure to excessive microwave oven energy when
using your appliance, follow basic precautions, including
the following:
1. Warning: Liquids and other foods must
not be heated in sealed containers since
they are liable to explode.
2. Warning: It is hazardous for anyone other
than a competent person to carry out any
service or repair operation that involves
the removal of a cover which gives
protection against exposure to microwave
energy.
3. This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
4. Keep the appliance and its cord out of
5. Only use utensils suitable for use in
microwave ovens.
6. The oven should be cleaned regularly and
any food deposits should be removed.
7. Read and follow the specific:"PRECAU-
TIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY".
8. When heating food in plastic or paper
containers, keep an eye on the oven due
to the possibility of ignition.
9. If smoke is emitted, switch off or unplug
the appliance and keep the door closed
in order to stifle any flames.
10. Do not overcook food.
11. Do not use the oven cavity for storage
purposes. Do not store items, such as
bread, cookies, etc. inside the oven.
12. Remove wire twist-ties and metal handles
from paper or plastic containers/bags
before placing them in the oven.
13. Install or locate this oven only in
accordance with the installation
instructions provided.
14. Eggs in the shell and whole hard-boiled
eggs should not be heated in microwave
ovens since they may explode, even
after microwave heating has ended.
15.This appliance is intended to be used in
household and similar applications such
as:
-staff kitchen areas in shops, offices and
other working environments;
-by clients in hotels, motels and other
residential type environments;
-farm houses;
-bed and breakfast type environments.
16. If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.
17. Do not store or use this appliance
outdoors.
18. Do not use this oven near water, in a
wet basement or near a swimming
pool.
19. The temperature of accessible surfaces
may be high when the appliance is
operating. The surfaces are liable to get
hot during use. Keep cord away from
heated surface, and do not cover any
vents on the oven.
20. Do not let cord hang over edge of table
or counter.
21. Failure to maintain the oven in a clean
condition could lead to deterioration
of the surface that could adversely
affect the life of the appliance and
possibly result in a hazardous situation.
22. The contents of feeding bottles and
baby food jars shall be stirred or shaken
and the temperature checked before
consumption, in order to avoid burns.
knowledge if they have been given
supervision or instruction concerning use
of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall
not be made by children unless they are
older than 8 and supervised.
reach of children less than 8 years.
IMPORTANT SAFETY INSTRUCTIONS
4

5
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE
23. Microwave heating of beverages can result in delayed eruptive boiling, therefore
care must be taken when handling the container.
24.Children should be supervised to ensure that they do not play with the appliance.
25.The appliances are not intended to be operated by means of an external timer or
separate remote-control system.
26. Accessible parts may become hot during use. Young children should be kept away.
27.Steam cleaner is not to be used.
28 During use the appliance becomes hot. Care should be taken to avoid touching heating
elements inside the oven.
facility to use a temperature-sensing probe.)
30. WARNING: The appliance and its accessible parts become hot during use.Care should
be taken to avoid touching heating elements. Children less than 8 years of age shall be
kept away unless continuously supervised.
31. The microwave oven must be operated with the decorative door open.(for ovens with a
decorative door.)
3. Surface of a storage cabinet can get hot.
29. Only use the temperature probe recommended for this oven.(for ovens provided with a
2
33. The microwave oven is intended for heating food and beverages.Drying of food
warming pads,slippers,sponges,damp cloth and similar
may lead to risk of injury,ignition or fire.
or clothing and heating of
34. WARNING: When move the stove, do not carry handle. ( Stove is overweight,
handles are easily broken.)
35. The water in the receiving tank, inside the oven and in the water tank should be
cleaned up after each use.
36. Do not use the paper cups and plastic containers with temperature below 120
3 . Steam is the main heating function for this product.
degrees. The glass, ceramic, stainless steel utensils can be used.
7

CLEANING
Be sure to disconnect the appliance from the
power supply.
1. Clean the cavity of the oven after using
with a slightly damp cloth.
2. Clean the accessories in the usual way
in soapy water.
3. The door frame and seal and
neighbouring parts must be cleaned
carefully with a damp cloth when they
are dirty.
2)The extension cord must be a grounding-
type 3-wire cord.
3)The long cord should be arranged so that
it will not drape over the counter top or
tabletop where it can be pulled on by
children or tripped over unintentionally.
4. Do not use harsh abrasive cleaners
or sharp metal scrapers to clean the
oven door glass since they can
scratch the surface, which may
result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the
cavity walls that the food cooked can
touch:
Place half a lemon in a bowl, add 300ml
(1/2 pint) water and heat on 100%
microwave power for 10 minutes.
Wipe the oven clean using a soft, dry cloth.
To Reduce the Risk of Injury to Persons
Grounding Installation
6
DANGER
Electric Shock Hazard
Touching some of the internal components
can cause serious personal injury or death.
Do not disassemble this appliance.
WARNING
Electric Shock Hazard
Improper use of the grounding can result in
electric shock. Do not plug into an outlet until
appliance is properly installed and grounded.
1. A short power-supply cord is provided
to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. If a long cord set or extension cord is
used:
1)The marked electrical rating of the cord
set or extension cord should be at least as
great as the electrical rating of the appliance.
This appliance must be grounded. In the
event of an electrical short circuit,
grounding reduces the risk of electric
shock by providing an escape wire for
the electric current. This appliance is
equipped with a cord having a grounding
wire.
Consult a qualified electrician or
serviceman if the grounding instructions
are not completely understood or if doubt
exists as to whether the appliance is
properly grounded.

CAUTION
Personal Injury Hazard
It is hazardous for anyone
other than a competent person
to carry out any service or repair
operation that involves the removal
of a cover which gives protection
against exposure to microwave
energy.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
Materials you can use in microwave oven
Utensils Remarks
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of
meat or poultry to prevent overcooking. Arcing can occur if foil is too
close to oven walls. The foil should be at least 1 inch (2.5cm) away from
oven walls.
Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
UTENSILS See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven."
There may be certain non-metallic utensils that are not
safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
7

Remove the oven and all materials from the carton and oven cavity
Your oven comes with the following accessories:
Instruction Manual 1
1. Control panel
2. Grill element
3. Light
4. Level
5 Glass door
6. Hinge
7. Grill Rack
8. Glass Dish
7
8
1
2
3
4
5
6
Names of Oven Parts and Accessories
SETTING UP YOUR OVEN
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
8

The accessible surface
may be hot during
operation.
•
•
•
•
Please observe the installation instructions provided and note that this appliance
should only be installed by a qualified technician.
Adapters, multiway strips and extension cords must not be used. Overloading can
This appliance is NOT intended for use in a commercial environment.
The appliance installed earthed socket.
result in fire.
If the appliance is not fitted with a supply cord and a plug, the connection equipment
must have a contact separation in all poles that provide full disconnection, and the
appliance must be incorporated in the fixed wiring in accordance with the wiring rules.
•
must be connected to a properly
IMPORTANT INFORMATION ABOUT INSTALLING
9

• Do not hold or carry the appliance by the door handle. The door handle cannot hold
the weight of the appliance and may break off.
1. Carefully push the appliance into the cabinet, making sure that it is in the centre.
2. Open the door and fasten the appliance with the screws that were supplied.
Note: There should be gap above the oven.
•
•
•
•
•
•
Placement
Installation dimensions
Building in
"./9 '662/'4)+ /9 542? /4:+4*+* :5 (+ ,;22? ,/::+* /4 ' 1/:).+4
"./9 '662/'4)+ /9 45:
• *+9/-4+* :5 (+ ;9+* '9 ' :'(2+:56 '662/'4)+ 58 /49/*+ ' );6(5'8*
".+ ,/::+* )'(/4+: 3;9: 45: .'<+ ' (')1 ='22 (+./4* :.+ '662/'4)+
 -'6 5, ': 2+'9:  (+:=++4 :.+ ='22 '4* :.+ ('9+ 58 (')1
6'4+2 5, :.+ ;4/: '(5<+
".+ ,/::+* )'(/4+: 3;9: .'<+ ' <+4:/2':/54 56+4/4- 5,  )3
54 :.+ ,854: "5
')./+<+ :./9 );: (')1 :.+ ('9+ 6'4+2 58 ,/: ' <+4:/2':/54 -8/22+
$+4:/2':/54 925:9 '4* /4:'1+9 3;9: 45: (+ )5<+8+*
".+ 9',+ 56+8':/54 5, :./9 '662/'4)+ )'4 542? (+ -;'8'4:++* /, /: .'9 (++4 /49:'22+* /4
'))58*'4)+ =/:. :.+9+ /49:'22':/54 /49:8;):/549
• ".+ ,/::+8 /9 2/'(2+ ,58 '4? *'3'-+ 8+9;2:/4- ,853 /4)588+): /49:'22':/54
".+ ;4/:9 /4:5 =./). :.+ '662/'4)+ /9 ,/::+* 3;9: (+ .+':X8+9/9:'4:
;6 :5 A 
•
min 100
Cupboard feet
Ventilation grid
min 100
50
460
250
100
33 3;9: (+ 3'/4:'/4+*
250
10




Fully insert the appliance and centre it.
Do not kink the connecting cable.
Screw the appliance into place.
The gap between the worktop and the appliance must not be closed by
addtional battens.
10
0
11

Initial cleaning and heating
Removing all of the protection foil on the front of the appliance.
For more information see the "CLEANING". Before the first use of the appliance,
●Before using your appliance for the first time:
●Touch “ ” keys. Appliance turn on, the main menu appears in the display.
●Touch "
Recommended temperature will be highlighted, along with microwave
started directly.
●Raise the temperature to maximum temperature. This can be achieved by
using beside proximity keys or the numeric keypad to achieve.
●Touch " " symbol next to the sensor keys. Heat the empty oven for at least an
hour.
When you do this, make sure that the room is well ventilated. Close the door to the other
room to avoid odor pervaded the House.
●Let the appliance cool down to room temperature .Then solution of neutral detergent
mixed with hot water to clean inside the microwave oven, then wipe dry with a clean
soft cloth.
Keep the door open until completely dry in the oven.
" to choose the convection function.
BEFORE FIRST USE
12
1.Take out and clean all the tray, wire rack and glass dish.
2.Clean the appliance interior cavity with a damp cloth and warm water. Never use
abrasive detergent to clean the cavity.
3.Heat the empty oven to banish odor.

Control Panel
This oven uses modern electronic control to adjust cooking parameters
to meet your needs better .
When 0:00" will blink, buzzer will ring once.
2) After you have set the right time, press " ". The clock has been set.
Note: 1) If you want to change the time, you have to press and hold the " "
to confirm the setting.
Clock Setting
button for 3 seconds. The actual time disappears and then the time will
blink in the display.
button
1) to set the right time(between 00:00 and 23:59.)
Press" " or " " to set the new time and press the " "
Press " " or " "
2) When you set the clock, long press " " or " " when adjusting 10MIN,
short press time (each time you adjust 1MIN).
OPERATION INSTRUCTION
.
13
connecting to the power, "0
Symbol Function
Clock
Start
Temperature/Weight
Rapid preheating/Auto menu/Defrost
Press and hold:Childproof Lock
Press briefly:Stop
Press twice:Cancel
Steam
Water tank
Heat Mode (Microwave, Grill ,Convection,Grill+Fan, MW+Grill,
NOTE: Grill+Fan,MW+Convection, MW+ Grill function, Microwave+Grill +Fan.
Press " ",you could choose Microwave, Grill, Convection,
Using the programmer
MW+Convection,Microwave+Grill+Fan,Grill+Fan function)

Microwave Power Chart
Microwave Power 80% 50% 30%
100%
Display 900W 700W 450W 300W 100W
You can see from the table below from which
which foods the power levels are suitable.
Power level Food
900 W - Boiling water, reheating
- Cooking chicken,
700 W - Reheating
- Cooking mushrooms, shell
- Cooking dishes containing eggs and cheese
450 W - Cooking rice, soup
300 W - Defrosting
- Melting chocolate and butter
100 W - Defrosting sensitive/delicate foods
- Defrosting irregularly-shaped foods
- Softening ice cream
- Allowing dough to rise
power levels you can choose and for
fish, vegetables
fish
20%
14
1) Press the " " button to activate the program selection. "01:00" will light in
the display and the microwave icon appears.
Press " ", then press " " or " " to set the microwave power
(900W ). The default power is 900W
Press " " or " " or " " mode.to select microwave cooking2)
The max. cooking time depends on the power that has been set. When the power
is 900W, the MAX. time is 30 minutes and other powers are 90 minutes.
3)
4) Press " " ,then press " " or " " to set the cooking time.
5) Press " " button to start cooking.
,700W,450W,300W,100W
1. Microwave Cooking

) Press " " button to start cooking.
Press " " to select the time setting mode. The default time is 10 minutes.
. Convection Cooking
Press " " or " " or " " to select convection mode.
" to enter to the temerpature mode.
The default temperature is 180 degrees.
. The temperature is from 50 to
230 degrees.(50,100,105,110,115,120,125,130,135,140,145,150,155,160,
Press " " or " " to select the cooking time. The MAX.time is 5 hours.
1) Press the " " button to activate the program selection. "01:00" displays
and the microwave icon appears.
to enter to the temperature selection.
Press " "or " "or " " to select grill fan mode. The default temperature
is 180 degrees.
1) Press the " " button to activate the program selection. "01:00" displays
and the microwave icon appears.
2)
3) Press " "
2)
3) Press "
4) Press" " or " " to select temerpature
5)
6
15
165 ),170,175,180,185,190,195,200,205,210,215,220,225,230
3
4. Grill Fan Cooking
" to choose the grill level.
Press " " to select the time setting mode. The default time is 10 minutes.
Press " " or " " or " " mode. The default grill power is the
Press" "or " " to select the cooking time of grill. The MAX.time is 90 minutes.
third level.
level 3(the MAX.), level 2 or level 1(the MIN.).
to select grill
1) Press the " " button to activate the program selection. "01:00" displays
and the microwave icon appears.
2)
3) Press "
4) Press" "or " " to select the
5)
6) Press " " button to start cooking.
2. Grill Cooking

2) Press" " or " "or " " to select the " MW+GRILL" combination mode.
to enter to the microwave power level selection.
The default power is 300W.
7) Press" " to select the time setting mode. The default time is 10 minutes.
Microwave + Grill Cooking
Press" "or " " to select the cooking time . The MAX.time is 90 minutes.
1) Press the " " button to activate the program selection. "01:00" displays
and the microwave icon appears.
" to enter to the grill level selection.
level 3(the MAX.), level 2 or level 1(the MIN.).
3) Press "
4) Press" "or " " to select the
microwave power(700W, 450W, 300W, 100W).
5) Press " "
8)
9) Press " " button to start cooking.
6) Press " " or " " to select the
2) Press" " or " "or " " to select the "MW+ CONV."combination mode.
to enter to the microwave power level selection.
The default power is 300W.
Microwave +
1) Press the " " button to activate the program selection. "01:00" displays
and the microwave icon appears.
microwave power(700W, 450W, 300W, 100W).
to enter to the temperature selection.
The default temperature is 180 degrees.
temperature between to degrees.50 230
Convectional Cooking
16
(50,100,105,110,115,120,125,130,135,140,145,150,155,160,
165 ),170,175,180,185,190,195,200,205,210,215,220,225,230
7) Press" " to select the time setting mode. The default time is 10 minutes.
3) Press " "
4) Press " " or " " to select the
5) Press " "
6) Press " " or " " to select the
5.
6.
temperature .
Press" " to select the time setting mode. The default time is 10 minutes.
Press " " or " " to select the cooking time. The MAX.time is 5 hours.
4) Press " " or " " to select the
5)
6) Press " " button to start cooking.
The temperature is
from to 0 degrees.(35,100,105,110,115,120,125,130,135,140,145,150)35 18
155 ),160,165,170,175,180

Microwave + Grill + Fan Cooking
2) Press" " or " "or " " to select the "MW+GRILL+FAN"combination mode.
1) Press the " " button to activate the program selection. "01:00" displays
and the microwave icon appears.
to enter to the temperature selection.
temperature .
The default temperature is 180 degrees.
to enter to the microwave power level selection.
The default power is 300W.
7) Press" " to select the time setting mode. The default time is 10 minutes.
Press" "or " " to select the cooking time . The MAX.time is 90 minutes.
microwave power(700W, 450W, 300W, 100W).
The temperature is
Press" "or " " to select the cooking time . The MAX.time is 90 minutes.
press the key more than once, you can switch between the different cooking types such as
d01, P01, S01, at this point you can press the " " or " " to choose Defrost, Non Steam
When the display " " lights, enter menu mode automatically, the default symbol weight,
cooking time and cooking light; the display shows P01 or S01.
1) In standby mode, press " " button once, the display " " lights, go into defrost menu mode;
17
from to 0 degrees.(100,105,110,115,120,125,130,135,140,145,150)
18
155 )
,160,165,170,175,180
100
press " "or " ", select the Menu type (P01-P40 or S01-S40).
2) Press the " " and flashing display shows P01 or S01, at this point, you can
8)
9) Press " " button to start cooking.
3) Press " "
4) Press " " or " " to select the
5) Press " "
6) Press " " or " " to select the
8)
9) Press " " button to start cooking.
7.
8. Auto Cook
Menu ,Steam Menu switches between three types of cooking.

Note:
1) For non-steam menu (P01-P40), press " " to confirm menu selection and
enter the weight of menu selection state automatically, at this point, you can
press " " or " ", choose the automatic menu weight cooking time display.
2) For the steam menu, at this time, if you need to adjust the default cooking time,
you can press , and makes the default cooking time of flashing, at this point,
press " " or " " adjust the Cook time menu.
1) In standby mode, press" "button once, select defrost mode, the display " "
lights, into Auto Defrost Mode; display shows d01, initial weight, cooking time
and cooking signs light up;
2) Press " ", to confirm the selected defrost mode and enter the defrost
weight selection state, press " "or " "to select automatic defrost
weight cooking time display;
3) Press " " button to start cooking.
3) Press " " button to start cooking.
1) Press " " button. When the preheat icon appears in the display.
2) Press " " button to start preheating. When the right tem ature is reached,
you will hear three beeps. You can stop the preheating by opening the oven door
or by pressing the " " button.
The preheating function can be activated after you have set the functions has been set:
Convection, Grill fan, ,MW-convection,MW-Grill fan.
Note: The preheating function only works if you have already chosen one of the modes
above. During preheating, the microwave function is switched off.
10. Preheating Function
NOTE:
1) After steam auto menu, the water pump will withdraw the water back to water tank,
2) After steam auto menu, you need to clean the water on cavity and door panel.
there will be some noise.
per
18
to
3) If the menu need preheating, don't put the food in the oven during preheating.
Only when the temperature is reached, then you can put in the food to start cooking.
During preheating, don't put the food in the oven. You may put in the food for cooking,
9. Defrost
when the temperature is reached.

11. Steam Function
1) In standby mode, press " " button, enter the steam mode, time lights up by default
10:00. Press the key several times, you can switch to other steam modes (or you can
press " " or " " to select other desire steam modes.)
2) When you select Steam mode, the icon is displayed, signs light up. The icon is displayed,
and "10:00", "Min" and " " lights up. Tank icon on the right show current water level
(lack of water or not), and the default temperature 100 lights up.
3) Press the " " key to switch to the temperature selection, the temperature flashes,
at this point, press " " or " " to select a temperature (50
.
4) Press" " to select the time setting mode. The default time is 10 minutes.
Press" "or " " to select the cooking time . The MAX.time is 90 minutes.
5)
6) Press " " button to start cooking.
1 . Microwave+Steam Function
1) In standby mode, press " " button, enter the steam mode, time lights up by default
2) When you select MW+Steam mode, the icon is displayed, then displays 300W.
to enter to the microwave power level selection.
microwave power(900W, 700W, 450W, 300W,
3) Press " "
4) Press " " or " " to select the
100W). The default power is 300W.
5) Press " " button, adjust the steam, and the steam icon flashes, then press
" " or " " to set steam (default 30 percent), if the steam is not in Flash, you can
6) Press" " to select the time setting mode. The default time is 10 minutes.
Press" "or " " to select the cooking time . The MAX.time depends on the
7)
8) Press " " button to start cooking.
power that has been set. When the power is 900W, the MAX.time is 30 minutes
and other powers are 90 minutes.
19
press the " " key to make it Flash and then press " " and " " to set the steam.
℃
℃
2
10:00. Press the key several times, you can switch to other steam modes (or you can
press " " or " " to select other desire steam modes.)
C
o
,60 ,70 ,80 ,90 ,100 .)
C
oC oC oC oC o

13. Convection+Steam Function
2) When you select Conv.+Steam mode, the icon is displayed, the default temperature is
5) Press " " button, adjust the steam, and steam the display flashes, then press
" " or " " to set steam (default 30 percent), if the steam is not in Flash, you can
6) Press" " to select the time setting mode. The default time is 10 minutes.
Press" "or " " to select the cooking time . The MAX.time is 90 minutes.
7)
8) Press " " button to start cooking.
180 degrees.
to enter to the temperature selection.
Press " " or " " to select temperature
.
3) Press " "
4) (180 ,190 ,200 ,210 ,220 )
Lock: In standby mode, press "
denoting entering into the children-lock state and " " indicator will light.
Unlock : In locked mode, press "
"beep" denoting that the lock is released, and " " indicator will disapear.
" for 3 seconds, there will be a long "beep"
" for 3 seconds, there will be a long
1) In standby mode, press " " button, enter the steam mode, time light up by default
(1) When setting, if no other operation,it will confirm automatically after 10 seconds.
Except clock setting for the first time.
(2) During setting program, after adjusted for 3 seconds, it will confirm after 3 seconds.
(3) When the oven is in setting state or pause state, including auto menu and defrost program,
if no operation in 5 minutes, it will enter into the off state.
(4) The oven lamp will light all the time if the door is open.
(5) The oven lamp will light all the time if the oven is paused.
(6) " " button must be pressed to continue cooking if the oven door is open
during cooking process.
(7) The " " button can be press in any state to open the water .
tank
20
press the " " key to make it Flash and then press " " and " " to set the steam.
s
10:00. Press the key several times, you can switch to other steam modes (or you can
press " " or " " to select other desire steam modes.)
*Child Safety Lock Function
Display Specification
*
C
oC oC oC oC o
