Philips HR2200/80 User manual

SOUP MAKER
HR2200/80
HR2200/81
Published by Philips Consumer Lifestyle Printed in China Copy Right Reserved Subject to modification
1
Technical information
-Voltage : 220V-240V
- Frequency rated : 50Hz
-Motor Power rated : 120W
-Heating Power rated : 900-990W
-Product dimensions( LxDxH) mm
205x153x310mm
-Capacity :1000~1200ml
(for2~4 people)
-Net Weight : 2.0kg
Material
- Jug : Stainless steel
- Blade :stainless steel
- Motor housing : PP (food contact)
HR2200/80
HR2200/81
For UK
Difference in Power Cord:

Product introduction
Control panel
2
A: Smooth soup program with light. Smooth soup program to make a smooth soup in 23 minutes.
B: Chunky soup program with light.Chunky soup program to make a chunky soup in 20 minutes.
C: Compote program with light. Compote program to make a compote in 13 minutes.
D: Smoothie program with light.Smoothie program to make a smoothie in 3 minutes.
E: Manual blending program with light
F: Program selection button
G: Start/stop button
F G
A B C D E

Main feathers
3
1
2 DC motor，light weight and small noise
3 Unique blade design, perfect blading performance.
Cageless design, easier clean
4 Streamlined raised surface, ensure perfect blading
performance

4
Technical information
- Electrical diagram:
Jug
Motor
thermostat
Thermal
fuse
Power
socket
Heating
element
Upper
coupler
Control
board
Motor Unit
Main
PCBA
Low coupler
DC
motor
Overflow
sensor

5
Exploded drawing

6
Position
12NC
Part name
PCM
Remark
1
996510054806
LID HANDLE COVER
Q776K200Y80R
2
996510057705
LID HANDLE
Q776K360850R
3
996510057699
SCREW COVER
Q776G955H14R
4
996510057702
CONTROL PANEL
Q7760095H14R
5
996510057703
LID COVER
Q7763650850
6
996510057692
LID
B776298S203R
7
996510057696
KEY PCB
D9776033002R
8
996510057691
MAIN PCBA
A7761000002R
9
996510054782
MOTOR COVER
Q7769420B55R
10
996510057694
MOTOR ASSY
A7760210002R
11
996510049007
MOTOR BRACKET SEAL
X6001350001R
12
996510054807
LID SEAL
X7762820001R
13
996510054804
ANTI-SPILL SENSOR ASSY
B776328S201R
14
996510057695
MOTOR HOUSING
Q776D490839R
15
996510048973
BLADE WASHER
J0200000118R
16
996510054793
BLADE
J2420000095R
17
996510048971
DIAMETER 5 SPRING WASHER
J0150000437R
18
996510048969
M5 LOCK NUT
J0020000186R
19
996510057698
LOWER COUPLER ASSY
A7767060002R
20
996510054785
SEAL FOR LOWER COUPLER
X6920930001R
21a
996510057693
INNER PAN ASSY (220V)
A7766110002R
21b
996510057706
INNER PAN ASSY (230V)
A7766110003R
for UK
22
996510048981
COUPLER HOLDER
Q616371AB01
23
996510054797
CUP HANDLE
Q776F540Y80R
24
996510057697
CUP HANDLE COVER
Q776A92A850
25
996510057701
SOCKET ASSY
A7764970002R
26
996510054799
CUP BASE ASSY
B776084S201R
27a
996510057704
POWER CORD (2 PINS)
D1AF104D001R
27b
996510057707
POWER CORD (3 PINS)
D1AH204D001R
for UK
Spare parts

DISASSEMBLY ADVISE
7
!
Screw cover
Before you start dismantling!
For your safety be sure the plug is
disconnected from the mains!
Step 1：Remove the upper handle.
Step 2：Remove control panel and screw
cover（adhesive label), you can touch eight
screws.
Step 3：Remove 9 fixing screws. You can
get main PCBA, Key PCB.
Main PCBA EMC PCB Key PCB
Main PCBA Assy

8
Wide red
cable
Narrow
blue cable
How to replace DC motor.
Step 1: Remove main PCBA and EMC PCB.
Easy-to- click design, easy to remove
main PCBA.
Step 2: Remove blade with spanner.
Step 3: Remove dust-protect cover.
Step 4: Remove 4 fixing screws, then you
can get out the motor.
DC motor

Trouble shooting
9
Overflow
Proper
program
selected?
No Select proper program
according to recipe Change ingredients and restart
Yes
Water level ?
Ingredients
?
No
Too much ingredients
Too much or too less water Fill in water between MIN with
MAX
No
Yes
Yes
According to recipe to control
the quantity
No
Overflow is dirty
No
Yes
Is Overflow
normal? Clean the overflow
Repair itOverflow cable is broken
connect
Overflow cable isn’t connected
with grounding wire
Is main
PCBA
normal?
Replace main PCBA
Yes
Air leaked from motor
house Replace motor house Issue close
No

Trouble shooting
10
After 20 minutes, ingredients are not bladed.
LED lights
flash
Yes
Select program Press Start
No
Check or replace DC motor if
necessary
Ensure water level between MIN
and MAX
Does water
level touch
overflow
sensor?
Clean overflow sensor
Yes
No
Overflow sensor short
cut
Was water
be heated?
Yes
No
No power, replace main PCBA
Alarming when power cord plugs in
Replace main PCBA

Trouble shooting
11
Problem
Cause
Solution
The appliance doesn’t
work
There is connection problem
Check if the small plug is inserted in the
appliance properly and if mains plug is
inserted in the wall socket properly. Remove
the plugs and reinsert them.
The motor unit does not fit
onto the jug properly
because there are too many
ingredients in the jug.
Remove some of the ingredients and make
sure not to fill the jug beyond the MAX
indication.
Motor unit problem
Please contact with local service center or
call center
The light of selected
mode doesn’t go on
There is connection problem
Check if the small plug is inserted in the
appliance properly and if mains plug is
inserted in the wall socket properly. Remove
the plugs and reinsert them.
During making process,
power had been cut off.
Please follow the proper steps to make
soup.
The motor unit does not fit
onto the jug properly
Make sure motor unit connector and the jug
connector are aligned before you lower the
motor unit into the jug.
You have exceeded the
MAX indication in the jug.
Remove some of the ingredients and make
sure the ingredients are spread evenly over
the bottom of the jug.
The light of selected
program is on, but the
appliance doesn’t work
You have not pressed start
button.
Press the start button.
You have exceeded the
MAX indication in the jug.
Remove some of the ingredients and make
sure the ingredients are spread evenly over
the bottom of the jug.
The ingredients have
not blended well
You have exceeded the MAX
indication in the jug
Remove some of the ingredients and make
sure the ingredients are spread evenly over
the bottom of the jug.
The appliance
overflows
You have selected wrong
program
Select correct program according to recipe
You have exceeded the MAX
indication in the jug
Remove some of the ingredients and make
sure the ingredients are spread evenly over
the bottom of the jug.
The overflow sensor is dirty
The overflow sensor prevents the appliance
from overflowing. Clean the overflow sensor.
The food is burnt
You have selected wrong
program
Select correct program according to recipe
You did not add enough
water or other liquid
Make sure the liquid level is above the MIN
and below the MAX indication.
You have heated up milk
The soup maker is not suitable for heating
up milk.
This chapter summarises the most common problems you could encounter with the appliance. If
you are unable to solve the problem with the information below, visit www.philips.com/support
for a list of frequently asked questions or contact the Consumer Care Centre in your country.
