4
1 Important
Read and understand all instructions•
before you use the apparatus. If damage
is caused by failure to follow instructions,
the warranty does not apply.
Use of controls or adjustments or•
performance of procedures other than
herein may result in hazardous radiation
exposure or other unsafe operation.
This unit is designed for negative ground•
(earth) 12 V DC operation only.
To reduce the risk of traffic accident, do•
no watch video during driving.
To ensure safe driving, adjust the volume•
to a safe and comfortable level.
Improper fuses can cause damage or•
fire. When you need to change the fuse,
consult a professional.
Use only the supplied mounting hardware•
for a safe and secure installation.
To avoid short circuit, do not expose the•
apparatus, remote control or remote
control batteries to rain or water.
Never insert objects into the ventilation•
slots or other openings on the apparatus.
Never place any objects other than discs•
into the disc tray/slot.
Visible and invisible laser radiation when•
open. Avoid exposure to beam.
Risk of damage to the screen! Never•
touch, push, rub or strike the screen with
any object.
Never use solvents such as benzene,•
thinner, cleaners available commercially,
or anti-static sprays intended for discs.
Clean the apparatus with soft, damp•
cloth. Never use substances such as
alcohol, chemicals or household cleaners
on the apparatus.
EN
ce229um55.indd4 24/05/201121:45:49
ce229um55.indd4ce229um55.indd4 25/05/201117:59:5425/05/201117:59:54

5
2 Your car audio
system
Congratulations on your purchase, and
welcome to Philips!
To fully benefit from the support that Philips
offers, register your product at www.Philips.
com/welcome.
Read this user manual carefully before you
install and use the unit. Save it for future
reference.
Introduction
With the in-car audio system, you can enjoy
your drive while you listen to:
FM or AM (MW) radio•
Audio from a USB drive, a SD/SDHC•
card, external devices.
Music CDs•
DVD and VCD video•
EN
English
ce229um55.indd5 24/05/201121:45:49
ce229um55.indd4 24/05/201121:45:49
ce229um55.indd5ce229um55.indd5 25/05/201117:59:5525/05/201117:59:55

ce229um55.indd7 24/05/201121:45:51
6
2Insert the disc into the disc slot with label
side facing up.
Play resumes from the point where it»
was last stopped.
3To remove the disc, press the button.
When the disc is ejected, the»
unit switches to TUNER mode
automatically.
4Close the front panel.
After a few seconds, the screen»
illuminates.
For video discs, press• or to select
an item, then press to start playing.
For discs that contain MP3s, WMAs, or•
JPEGs, press or to select a folder,
track or picture. Press to start playing.
Tip
If the disc is blocked in the disc compartment, press•
and hold the button until the disc comes out.
3 Play
Make sure that the disc or device contains
playable music or video.
Note
For CDs recorded in multiple sessions, only the first•
session is played.
Does not support MP3 Pro audio format.
•
It may not support and display special characters•
track name (ID3) or album name properly.
It cannot play some WMA is protected by Digital
•
Rights Management (DRM).
The system does not display or play the folders or
•
files that exceed the supporting limit.
Warning
To reduce the risk of traffic accident, do not watch•
video during driving.
Load and eject discs
1Press to open the front panel.
EN
ce229um55.indd6 24/05/201121:45:50
ce229um55.indd6ce229um55.indd6 25/05/201117:59:5525/05/201117:59:55

7
2Insert SD or SDHC card into the card
slot.
The unit starts playing from the SD/»
SDHC card automatically.
3To remove the SD or SDHC card, press
to turn off the unit.
4Press the card until you hear a click
sound.
The card is now disengaged.»
Skip/search
During video and audio disc play
To skip to a specified chapter or track,•
press the numeric buttons.
Insert and remove USB
device
1Slide down the USB socket cover.
2Insert the USB device into the USB
socket.
The unit starts playing from the USB»
device automatically.
3To remove the USB device, press to
turn off the unit.
4Remove the USB device.
Insert and remove SD/MMC
card
1Press to open the front panel.
EN
English
ce229um55.indd7 24/05/201121:45:51
ce229um55.indd6 24/05/201121:45:50
ce229um55.indd7ce229um55.indd7 25/05/201117:59:5625/05/201117:59:56

ce229um55.indd9 24/05/201121:45:53
8
Intro play
This feature plays the first 10 seconds of each
audio track.
Press the button to enable and
disable this function.
Repeat play
There are 3 standard modes of repeat play for
video, audio, and MP3/WMA.
Press the button repeated to select.
• [REP ONE]: play the current chapter or
track repeatedly.
• [REP DIR]: play the current folder
repeatedly.
• [REP ALL]: play all chapters in the title or
all tracks repeatedly.
• [REP CANCEL]: cancel repeat play.
To skip to the previous or next chapter•
or track, press or .
To search backward or forward quickly,•
press or for 3 seconds.
Press• to resume normal play.
During MP3/WMA play
To select a specific song folder, press•
twice to display the folder list. Press
or to select, and then press to
confirm.
To select a specific track, press or
within the folder. Press to confirm.
To skip to a specified chapter or track,•
press the numeric buttons.
EN
ce229um55.indd8 24/05/201121:45:51
ce229um55.indd8ce229um55.indd8 25/05/201117:59:5625/05/201117:59:56

9
Audio
You can select the audio language if the video
discs contain two or more audio channels.
During play, press on the remote control
repeatedly until the language is selected.
Dynamic Bass Boost
1Press / on the car audio
system for 3 seconds or press on
the remote control.
»[DBB ON]: The Dynamic Bass Boost
(DBB) function is on.
»[DBB OFF]: The DBB function is off.
2Press again to change the DBB
setting.
Random play
There are 3 standard modes of random play
for audio and MP3/WMA.
Press the button repeatedly to select.
• [SHUFFLE ALL]: start random play for all
tracks.
• [SHUFFLE DIR]: start random play in
current folder.
• [SHUFFLE OFF]: cancel random play.
Select Language
Subtitle
You can select the subtitle language if the
DVD or DivX discs contain two or more
subtitle languages.
During play, press on the remote
control repeatedly until the language is
selected.
EN
English
ce229um55.indd9 24/05/201121:45:53
ce229um55.indd8 24/05/201121:45:51
ce229um55.indd9ce229um55.indd9 25/05/201117:59:5825/05/201117:59:58

ce229um55.indd11 24/05/201121:45:58
10
MAX sound
1Press / to produce an
instant boost in bass and maximize volume.
2Press / again to turn off.
Zoom
To zoom in and out of video images and
pictures:
1Press on the remote control
repeatedly.
»[ZOOM] is displayed.
2Press the navigation buttons to pan
across the display.
EN
ce229um55.indd10 24/05/201121:45:56
ce229um55.indd10ce229um55.indd10 25/05/201117:59:5925/05/201117:59:59

11
Manual tune to a radio
station
1Press until you select radio.
2Press and hold or to select band.
»[FM-1], [FM-2], [FM-3], [FM], [MW-
1], or [MW-2] is display.
3Press or to tune to a radio station
manually.
4 Radio
Select tuner sensitivity
Before you start to search for radio station,
you can select tuner sensitivity.
1Press .
The main menu is displayed.»
2Press the navigation buttons to select
[SETTINGS], then press on remote
control or on the car audio to confirm.
3Press or button to select .
4Press to select [LOC_DX],
5Press again to reach the [LOC_DX]
option list.
• [LOC]: only broadcast local stations
with strong signals.
• [DX]: broadcast any stations with
strong and weak signals.
6Press or button to select [LOC]
or[DX] , then press on remote
control or on the car audio to
confirm.
EN
English
ce229um55.indd11 24/05/201121:45:58
ce229um55.indd10 24/05/201121:45:56
ce229um55.indd11ce229um55.indd11 25/05/201118:00:0125/05/201118:00:01

ce229um55.indd13 24/05/201121:46:01
12
Select stereo or mono
broadcasting
1Press .
The main menu is displayed.»
2Press the navigation buttons to select
[SETTINGS].
3Press on the remote control or
on the unit to confirm.
4Press or buttons to select the radio
setting .
5Press to select [STEREO_MONO].
6Press again to reach the [STEREO_
MONO] option list.
7Press or to select [STEREO] or
[MONO].
8Press on the remote control or
on the unit to confirm.
Auto tune to a radio station
In [RADIO] mode, press and hold or
for 3 seconds.
Store stations manually
You can store up to 6 stations in each band.
1Tune to the station which you want to
store.
2Press and hold the numeric buttons (1 to
6) for 3 seconds.
Store stations automatically
You can store up to 6 stations in each band.
1Press on the remote control or
on the unit.
The six strongest stations of the»
selected band are saved in preset
channels 1-6 automatically.
Select the preset station
1Press and hold or to select band.
»[FM-1], [FM-2], [FM-3], [FM], [MW-
1], or [MW-2] is display.
2Press the numeric button (1 to 6) to
select the preset station.
EN
ce229um55.indd12 24/05/201121:46:00
ce229um55.indd12ce229um55.indd12 25/05/201118:00:0225/05/201118:00:02

13
The settings menu is displayed»
3Press or buttons to select the
general setting .
4Press , and then or to select the
sub-menus.
Select DVD video settings
You can adjust the settings for the video
output and the screen display.
1Press .
2Press the navigation buttons to select
[SETTINGS], the press to confirm.
The general settings menu is displayed»
3Press or buttons to select the DVD
setting .
4Press , and then or button to
select the sub-menus.
5 System settings
Within system settings, there are:
General settings,•
DVD settings,•
Language settings, and•
Radio settings.•
Adjust general settings
1Press .
2Press the navigation buttons to select
[SETTINGS], the press to confirm.
EN
English
ce229um55.indd13 24/05/201121:46:01
ce229um55.indd12 24/05/201121:46:00
ce229um55.indd13ce229um55.indd13 25/05/201118:00:0325/05/201118:00:03

ce229um55.indd15 24/05/201121:46:04
14
Adjust radio settings
1Press .
2Press the navigation buttons to select
[SETTINGS], the press to confirm.
The settings menu is displayed»
3Press or buttons to select the radio
setting .
4Press , and then or button
to select [LOC_DX] or [STEREO_
MONO].
5Press , and then or button to
select your preferred settings.
Select language settings
1Press .
2Press the navigation buttons to select
[SETTINGS], the press to confirm.
The settings menu is displayed»
3Press or buttons to select the
language setting .
4Press , and then or button to
adjust.
EN
ce229um55.indd14 24/05/201121:46:03
ce229um55.indd14ce229um55.indd14 25/05/201118:00:0425/05/201118:00:04

15
4Then, press or to select of [BASS]
and [TREBLE].
5Press or to adjust the values.
6Press to exit.
Control zone settings
1Press .
The current zone setting is displayed.»
2Then, you can select one of the following
methods to preset zone settings.
Press• or ;
Turn the control knob; or•
Press• continuously.
Here are the options of zone setting:
• [ALL] - all speakers are in same
volume level.
• [LEFT] - front left speaker is louder
than the rest of the speakers.
• [RIGHT] - front right speaker is
louder than the rest of the speakers.
• [FRONT] - the front speakers are
louder than the rear speakers.
6 Other settings
Select equalizer settings
You can select preset equalizer settings, and
they are:
• [USER]
• [TECHNO]
• [ROCK]
• [CLASSIC]
• [JAZZ]
• [OPTIMAL]
• [FLAT]
• [POP]
Note
Only when you select• [USER], then you can adjust
the sound value of [BASS] and [TREBLE] .
1Press .
The current equalizer setting is»
displayed.
2Press or to select one of the
preset equalizer settings.
3You can also select [USER], and then
press to confirm.
EN
English
ce229um55.indd15 24/05/201121:46:04
ce229um55.indd14 24/05/201121:46:03
ce229um55.indd15ce229um55.indd15 25/05/201118:00:0525/05/201118:00:05

ce229um55.indd17 24/05/201121:46:06
16
Select Video Output format
The default video output format is based on the
format that is broadcast in your country. If the
picture is distorted, change the video output.
Simply press the button repeatedly to
select the correct video output format.
Turn on or off the screen
backlight
To turn on or off the screen backlight of the
system, press and hold .
Reset
To reset the car audio system to its default
setting:
1Detach the front panel.
2Press by using a ball-point pen or
similar tool.
All settings are erased except clock.»
Other sound settings
You can adjust the front and rear speaker
balance, and the left and right speaker balance.
1Press and hold for 3 seconds.
The following options are displayed.»
2Press or to select the audio settings
to be adjusted.
• [BALANCE]: 7L to 7R (L= left
speaker ; R= right speaker)
• [FADE]: 7R to 7F (R= rear speaker ;
F= front speaker)
3Press or to change the value, and
then press to confirm.
You can also turn the control knob•
to select a value.
4Press to exit.
EN
ce229um55.indd16 24/05/201121:46:05
ce229um55.indd16ce229um55.indd16 25/05/201118:00:0625/05/201118:00:06

17
Replace fuse
If the system does not power on, the fuse may
be damaged and need replacement.
1Detach the front panel and take out the
system.
2Check the electric connection.
3Buy a new fuse that matches the voltage
of the damaged fuse (15A).
4Replace the fuse.
EN
English
ce229um55.indd17 24/05/201121:46:06
ce229um55.indd16 24/05/201121:46:05
ce229um55.indd17ce229um55.indd17 25/05/201118:00:0725/05/201118:00:07

ce229um55.indd19 24/05/201121:46:07
18
Tuner
Frequency range
- FM
87.5 - 108.0 MHz
(100kHz per step in auto
search and 50kHz per step
in manual search)
Frequency range
- AM (MW)
530 - 1710 kHz (10kHz)
Usable sensitivity
- FM
8 uV
Usable sensitivity
- AM (MW)
30 uV
LCD
Screen size 3 inches (16:9)
Display resolution 960 x 240 dots
Contrast ratio 300
Brightness 250 cd/m²
Compatible USB devices
USB flash memory (USB 2.0 or USB1.1)•
USB flash player (USB2.0 or USB1.1)•
Memory cards (SD / MMC / SDHC)•
Supported formats
USB or memory file format: FAT16.•
FAT32
MP3 bit rate (data rate): 32 - 320 Kbps•
and variable bit rate
WMA v9 or earlier•
Directory nesting up to a maximum of 8•
levels
Number of albums / folders: maximum 99•
Number of tracks / titles: maximum 999•
ID3 tag v2.0 or later•
File name in Unicode UTF8 (maximum•
length: 128 bytes)
7 Product
information
Note
Product information is subject to change without•
prior notice.
General
Power supply 12V DC (11V
- 16V), negative
ground
Fuse 15A
Suitable speaker
impedance
4-8 Ω
Continuous power
output
18W x 4 channels
Line output voltage 2.0V
Aux-in level 500mV
Dimensions (W x H
x D)
188 x 58 x 194 mm
Weight 1.7kg
Disc player
System DVD / CD audio /
MP3 system
Frequency response 20Hz - 20k Hz
Signal / noise ratio > 75dB
Total harmonic
distortion
Less than 1%
Channel separation > 55dB
Video signal format NTSC / PAL / AUTO
Video output 1.0V
EN
ce229um55.indd18 24/05/201121:46:07
ce229um55.indd18ce229um55.indd18 25/05/201118:00:0825/05/201118:00:08

19
Unsupported formats
Empty albums: an empty album is an•
album that does not contain MP3 / WMA
files, and is not be shown in the display.
Unsupported file formats are skipped.•
For example, Word documents (.doc) or
MP3 files with extension .dlf are ignored
and not played.
AAC, WAV, and PCM audio files.•
DRM protected WMA files (.wav, .m4a,•
.m4p, .mp4, .aac)
WMA files in Lossless format•
ISO9660, Joliet•
Maximum title number: 512 (depending•
on file name length)
Maximum album number: 255•
Supported sampling frequencies: 32 kHz,•
44.1 kHz, and 48 kHz
Supported bit-rates: 32 ~ 256 (Kbps),•
variable bit rates
EN
English
ce229um55.indd19 24/05/201121:46:07
ce229um55.indd18 24/05/201121:46:07
ce229um55.indd19ce229um55.indd19 25/05/201118:00:0825/05/201118:00:08

ce229um55.indd21 24/05/201121:46:08
20
Disc is blocked in the disc compartment
Press and hold•until the disc comes out.
No image
Parking brake wire connection is•
incorrect. Check the parking wiring.
Image flashes or distorted
Video DVD settings do not match with•
the DVD. Adjust video DVD settings.
Video connection is improper. Check the•
connections.
Noise in broadcasts.
Signals are too weak. Select other•
stations with stronger signals.
Check the connection of the car antenna.•
Change broadcast from stereo to mono.•
Preset stations lost.
Battery cable is not connected correctly.•
Connect the battery cable to the terminal
that is always live.
Fuse is broken
The Fuse type is incorrect. Replace it with•
a 15A fuse.
Speaker wire or power wire is grounded.•
Check the connections.
Display show ERR-12
USB/SD/MMC data error. Check the USB•
device or SD/MMC card.
8 Troubleshooting
Caution
Never remove the casing of this apparatus.•
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
system, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips web site (www.
philips.com/support). When you contact Philips,
make sure that your system is nearby and the
model number and serial number are available.
No power
Car engine has not been started. Start•
the car engine.
Connections is incorrect.•
Fuse has been damaged. Replace fuse.•
No sound
Volume is too low. Adjust volume.•
Speaker connections is incorrect.•
No response to the remote control
Ensure that the path between the•
remote control and the unit iis clear from
obstacles.
From a close distance, point the remote•
control directly at the unit.
Replace the remote control battery.•
The function does not work. Refer to the•
instructions.
Disc does not play
Disc is upside down. Ensure the printed•
side is upwards.
Disc is dirty. Clean the disc with a•
clean, soft, lint-free cloth. Wipe the disc
outwards from the center.
Disc is defective. Try another disc.•
Imcompatible disc is used. Try another disc.•
Disc rating exceeds the restrict setting.•
Change the rating settings to lower one.
Disc region code is not compatible with•
the unit. Use disc with proper region code.
EN
ce229um55.indd20 24/05/201121:46:08
ce229um55.indd20ce229um55.indd20 25/05/201118:00:0825/05/201118:00:08

21
Koninklijke Philips Electronics N.V. or their
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
9 Notice
The making of unauthorized copies of
copy-protected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
Manufactured under license from Dolby
Laboratories.
“Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.
Other trademarks and trade names are those
of their respective owners.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
2010 © Koninklijke Philips Electronics N.V. All
rights reserved.
Specifications are subject to change without
notice. Trademarks are the property of
EN
English
ce229um55.indd21 24/05/201121:46:08
ce229um55.indd20 24/05/201121:46:08
ce229um55.indd21ce229um55.indd21 25/05/201118:00:0925/05/201118:00:09
