Philips CID2680/93 User manual

Register your product and get support at
www.philips.com/welcome
EN User manual
=+&1 Ⴌ߀൱Ҭ

3
6 Play with Bluetooth device 23
Pair the Bluetooth-enabled devices 23
Make a call 23
Receive call 24
Listen to music from Bluetooth device 24
Adjust Bluetooth settings 24
7 Adjust sound 26
Adjust volume 26
Mute 26
Select preset equalizer 26
Adjut fader/balance 26
Set Dynamic Bass Boost (DBB) 27
8 Adjust settings 28
Display system setup menu 28
Adjust general settings 28
Adjust sound settings 29
Adjust video settings 29
Adjust Bluetooth settings 30
Adjust language settings 31
Adjust volume settings 31
Adjust DVD rating 31
9 Others 33
Listen to other devices 33
Reset 33
Remove the unit 33
Replace fuse 34
10 Product information 35
11 Troubleshooting 37
About Bluetooth device 37
12 Glossary 39
Contents
1 Important 4
Safety 4
Notice 4
Introduction 5
What’s in the box 5
Overview of the main unit 6
Overview of the remote control 7
2 Get started 9
Install the car audio 9
Install remote control battery 13
Turn on 13
Set date and time 13
3 Use map 15
Upgrade the map 15
4 Listen to radio 16
Tune to a radio station 16
Store radio stations in memory 16
Tune to a preset station 17
5 Play 18
Load discs 18
Connect USB device 18
Insert USB or SD/MMC card 19
Play/Pause 19
Search for a folder 19
Search within a title/folder 20
Repeat 20
Repeat a section 21
Random play 21
Select audio language 21
Select audio mode 21
Select subtitle language 21
Change view angle 22
Rotate pictures 22
Zoom 22
Select slide show duration 22
English
EN

4
Notice
The making of unauthorized copies of
copy-protected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
“DivX, DivX” Certified, and associated logos
are trademarks of DivX, Inc. and are used
under license.
Offical DivX® Certified product. Plays all
versions of DivX® video (including DivX® 6)
with standard playback of DivX® media files.
The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Philips
is under license.
Manufactured under license from Dolby
Laboratories.
“Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.
Other trademarks and trade names are those
of their respective owners.
This apparatus includes this label:
1 Important
Safety
Read and understand all instructions•
before you use the apparatus. If damage
is caused by failure to follow instructions,
the warranty does not apply.
Use of controls or adjustments or•
performance of procedures other than
herein may result in hazardous radiation
exposure or other unsafe operation.
This unit is designed for negative ground•
(earth) 12 V DC operation only.
To reduce the risk of traffic accident, do•
no watch video during driving.
To ensure safe driving, adjust the volume•
to a safe and comfortable level.
Improper fuses can cause damage or•
fire. When you need to change the fuse,
consult a professional.
Use only the supplied mounting hardware•
for a safe and secure installation.
To avoid short circuit, do not expose the•
apparatus, remote control or remote
control batteries to rain or water.
Never insert objects into the ventilation•
slots or other openings on the apparatus.
Never place any objects other than discs•
into the disc tray/slot.
Visible and invisible laser radiation when•
open. Avoid exposure to beam.
Risk of damage to the screen! Never•
touch, push, rub or strike the screen with
any object.
Never use solvents such as benzene,•
thinner, cleaners available commercially,
or anti-static sprays intended for discs.
Clean the apparatus with soft, damp•
cloth. Never use substances such as
alcohol, chemicals or household cleaners
on the apparatus.
EN

5
What’s in the box
Check and identify the contents of your
package:
aMain unit
bTrim plate
cRemote control
dAV out cable
eControl/Camera wire
fUSB cable
gAV in cable
hMZ-TFT/Video out 2 cable
iGPS antenna
jISO connectors (x2)
kScrews
- M5x6mm x 8 pcs
- M5x7mm x 8 pcs
- M5x15 x 1pc
Screw nut (4x25.4) x 1 pc
lRemote control battery
mScreen cleaning cloth
nPrinting material (include User manual,
Quick start guide)
abc
def
gihj
klm n
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
2008 © Koninklijke Philips Electronics N.V. All
rights reserved.
Specifications are subject to change without
notice. Trademarks are the property of
Koninklijke Philips Electronics N.V. or their
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
Congratulations on your purchase, and
welcome to Philips!To fully benefit from the
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With the car entertainment system, you can
Quickly found routine through the•
navigation system
And you can also enjoy:
Audio/video/JPEG pictures from•
DVD, VCD or CD•
USB devices•
SD/SDHC/MMC cards•
External devices•
FM or AM (MW) radio•
Audio from Bluetooth-enabled devices•
Besides, you can make/receive phone calls with
Bluetooth-enabled devices.
English
EN

6
fAV IN
External equipment audio/video in•
socket.
g
USB socket•
hRESET
Reset the unit when it hangs up.•
iSD/SDHC/MMC card slot
jDisc slot
kMAP
Open the cover and insert/remove•
the GPS map card.
Overview of the main unit
a
Eject disc.•
bRemote control sensor
Detects signals from the remote•
control. When using the remote
control, point it directly at the IR
sensor.
cNAVI
Enter the GPS navigation system or•
exit.
d/MUTE/VOL -/+
Turn the unit on or off.•
Turn mute on or off.•
Adjust volume.•
eSOURCE
Select source.•
a
b
c
k
j
d
e
fi
g
h
EN

7
gAUDIO
Select audio language or audio•
channel.
hBAND
Select AM or FM band.•
iMUSIC
Switch to music playing mode.•
jGOTO
Select track/chapter.•
k(green)
Answer phone.•
Dial number.•
lDVD MENU
Return to DVD main menu.•
mNumeric keypad
nSHUFF
Turn random play on or off.•
oREPEAT
Select repeat play mode.•
pSUBTITLE
Select DVD or DivX subtitle•
language.
q
Delete entered numbers/characters.•
r#/ *
Symbols for making phone call.•
s(red)
Terminate call.•
tENTER
Confirm the character/number•
inputs.
u/
Skip to previous/next track/chapter.•
Tune for radio station.•
v
Start play or pause.•
Confirm selection.•
Overview of the remote
control
aHOME
Toggles the home menu on or off.•
bPWR
Turn the unit on or off.•
c
Adjust screen brightness/contrast.•
dVOLUME +/-
Adjust volume.•
eEQ
Access audio setting menu.•
f
Mute or unmute audio.•
a|
{
z
y
x
w
u
s
r
v
t
b
d
f
g
m
h
i
j
k
l
n
o
p
q
c
e
English
EN

8
wVIDEOANGLE
Select a difference angle/version of•
the current DVD scene.
xPHOTOZOOM
Zoom in or out a picture/video•
image.
yF/R
Switch to front/rear control mode.•
zNavigation buttons
• /
Skip to the previous/next preset
station.
Skip to the previous/next folder.
Search backward/forward for DVD
video.
Move cursor up/down.
• /
Skip to the previous/next track.
Move cursor to left/right.
Press the navigation button down•
Start play or pause.
Confirm selection.
{
Return to previous menu or exit.•
|SOURCE
Select source.•
EN

9
Notes on speaker connection
Never connect speaker wires to the•
metal body or chassis of the car.
Never connect speaker wires with stripes•
to one another.
Connect wires
Caution
Ensure that all loose leads are insulated with•
electrical tape.
1Check the car’s wiring carefully, then
connect them to the two supplied ISO
wires.
Connector Connect to
1 Brown wire Telephone mute
2RedwireThe +12V power
terminal which is
live in the accessory
(ACC) position of the
ignition switch
If there is no
accessory position,
connect to the +12V
car battery terminal
that is always live.
Be sure to connect
the black ground
(earth) lead to a metal
surface of the car first.
a
g
h
i
j
b
c
d
e
f
2 Get started
Caution
Use of controls or adjustments or•
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
Always follow the instructions in this chapter in
sequence.
Install the car audio
These instructions are for a typical installation.
However, if your car has different requirements,
make the corresponding adjustment. If you have
any questions regarding installation kits, consult
your Philips car audio dealer.
Caution
This unit is designed for negative ground•
(earth) 12 V DC operation only.
Always install this unit in the car dashboard.
•
Other locations can be dangerous as the rear
of the unit heats up during use.
To avoid short-circuit: before you connect,
•
ensure that the ignition is off.
Ensure that you connect the yellow and red
•
power supply leads after all other leads are
connected.
Ensure that all loose leads are insulated with
•
electrical tape.
Ensure that the leads do not get caught under
•
screws orin parts that will move (e.g. seat rail).
Ensure that all ground (earth) leads are run to
•
a common ground (earth) point.
Use only the supplied mounting hardware for a
•
safe and secure installation.
Improper fuses can cause damage or fire.
•
When you need to change the fuse, consult a
professional.
Note on the power supply lead (yellow)
When you connect other devices to this•
system, ensure that the rating of the car
circuit is higher than the total fuse value
of all the connected devices.
English
EN

10
2Connect the other end of the two ISO
connectors to the car audio system.
3If necessary, do the other connections:
3 Orange wire Illumination switch
4BlackwireA metal surface of
the car
First connect the
black ground (earth)
lead, then connect the
yellow and red power
supply leads.
5YellowwireThe +12V car battery
which is live at all
times.
6BluewireThe electric antenna
control lead or
power supply lead of
the antenna booster
If there is no electric
antenna or antenna
booster, or it is
manually operated
telescopic antenna,
it is not necessary to
connect this lead.
7 Green and
green/black
wires
Left speaker (Rear)
8 White and
white/black
wires
Left speaker (Front)
9 Gray and
gray/black
wires
Right speaker (Front)
10 Purple and
purple/black
wires
Right speaker (Rear)
EN

11
Connect GPS antenna
To receive signal from satellites, connect the
supplied GPS antenna to your car and the
system.
1Connect the supplier GPS antenna to the
system first.
Red
White
Yellow
Red
Red White Yellow
Black
Yellow
Yellow Green Blue
Yellow
White
Black
Touch controller
Rear screen
Amplifier
Yellow
White
Brown
Red Red
English
EN

12
If the car battery is not disconnected,•
to avoid short-circuit, ensure that
bare wires do not touch each other.
2Ensure that car dashboard opening is
within these measurements:
Since the unit cannot be used if the•
dashboard opening’s slant angle
is above 20 degrees: Ensure that
the horizontal slant of the car
dashboard opening is between 0
and 20 degrees.
3Slide the unit into the dashboard until a
click sound is heard.
4Attach the trim plate.
3.5mm
116 mm
187 mm
2Stick the other end of the GPS antenna to
a metal surface of the car.
Connect radio antenna
If your car has built-in radio antenna, connect
it to the radio antenna of the system for
better radio signal.
1Connect the radio antenna to the car
antenna.
Mount in the dashboard
Note
Check wire connection before you mount the•
unit into a car.
If preset radio stations are lost when the
•
ignition key is turned OFF and then back ON,
reconnect the red leads crosswise to the
yellow ones.
1If the car does not have an on-board
drive or navigation computer, disconnect
the negative terminal of the car battery.
If you disconnect the car battery in•
a car that has an on-board drive or
navigation computer, the computer
may lost its memory.
EN

13
Turn on
Caution
Risk of road accidents! Never watch video or•
adjust settings while you drive.
1Press to turn on the unit.
The available OSD (On-Screen»
Display) languages are displayed.
2Touch a language to select.
The OSD language is changed to the»
selected language immediately.
To adjust screen brightness/contrast,•
press /on the remote control, then
press , , or .
To turn off the unit, press• for 3
seconds.
Set date and time
1Touch the upper left corner to display
main menu.
2Touch in the middle right side of the
screen.
The second main menu is displayed.»
5Reconnect the negative terminal of the
car battery.
Install remote control battery
Caution
Risk of explosion! Keep batteries away from•
heat, sunshine or fire. Never discard batteries
in fire.
Note
Remove batteries if they are exhausted or if•
the remote control is not to be used for a long
time.
Batteries contain chemical substances, they
•
should be disposed of properly.
Perchlorate Material - special handling may
•
apply. See www.dtsc.ca.gov/hazardouswaste/
perchlorate.
1Open the battery compartment.
2Insert one CR2025 battery with correct
polarity (+/-) as indicated.
3Close the battery compartment.
English
EN

14
Set time
1.Touch [Time].
2.Touch on the displayed time.
A submenu is displayed.»
3.Touch or to set hour and minute.
Tip
When date/time is set, touch• first and then
touch to return to main menu.
3Touch [Settings].
4Touch [Time].
The date/time setup menu is displayed.»
Set date
1Touch [Date].
2Touch on the displayed date information.
A submenu is displayed.»
3Touch or to set year, month and day.
Set clock mode
1Touch [Clock mode] .
2Touch on [12Hr] or [24Hr] to select
clock mode.
EN

15
4Insert the upgraded map card back into
the map card slot.
5Turn on the car audio.
The map upgrades in a few minutes.»
3 Use map
Note
You may need to upgrade the map before•
using it (see “Upgrade the map” section)
1Touch the upper left corner to display
home menu.
2Touch [Navigation].
The navigation menu is displayed in a»
few seconds.
3Refer to the map manual (in Chinese) to
operate the navigation tool.
Tip
You can press• NAVI to enter/exit the
navigation system.
Upgrade the map
1Turn off the car audio system.
2Press the map card until you hear a click
sound.
3Take out the card and bring it to the
authorized service center for upgrade.
English
EN

16
Touch• to clear the last entered
number.
Touch• to clear all the entered
numbers.
5Touch to confirm.
The radio station is broadcast.»
Select radio range
Before you start to search for radio stations,
you can select radio range.
1Touch .
2Touch [Radio range] to toggle tuner
sensitivity from normal to high sensitivity.
• [Distance]: Only stations with strong
signals can be broadcast.
• [Local]: Stations with strong and
weak signals can be broadcast.
Store radio stations in
memory
You can store up to 6 stations in each band.
Store stations manually
1Tune to the station.
2Touch .
3Touch [Save].
4 Listen to radio
Tune to a radio station
1Touch the upper left corner to display
home menu.
2Touch [Radio].
Band and frequency information is»
displayed.
3Touch on FM or AM to select band:
FM band options:• FM1, FM2, FM3
AM band options:• AM1, AM2
4Briefly touch or to tune to a radio
station by step.
Touch• or for over 1 seconds to
tune to a radio station automatically.
Tune by frequency
1Touch .
2Touch [Goto].
3Touch FM or AM to select band.
4Touch the numbers to enter frequency.
EN

17
4Touch one of the channels 01 to 06 to
save the select band.
Store stations automatically
You can search for a station with intro search,
which broadcasts a 10-second preview of each
detected radio station.
1Select band.
2Touch .
3Touch [Search].
Auto search starts.The six strongest»
stations of the selected band are saved
in preset channels 1-6 automatically.
Tune to a preset station
1Touch [Radio].
2Select band.
3Touch one of the preset channels
(01 to 06) to select a preset station.
English
EN

18
Connect USB device
Note
Ensure that the device contains playable•
content.
1Open the USB door.
2Insert the small end of the supplied USB
cable to the USB socket, then connect
the other end of the USB cable to your
USB device.
Play starts automatically.»
Remove the USB device
1Press SOURCE to switch to another
source.
2Remove the USB device.
5 Play
Load discs
You can play video, audio or images stored on
the following discs:
DVD video, DVD-R, DVD-RW•
VCD•
Audio CD, CD-R, CD-RW•
Note
Ensure that the disc contains playable content.•
1Insert the disc into the disc slot with label
side facing up.
Play starts automatically.»
To remove the disc, press the»button.
When the disc is ejected, the unit»
switches to the previous source,
if connected. Otherwise, the
unit switches to [Radio] mode
automatically.
P
r
i
n
t
i
n
g
i
n
C
h
i
n
a
P
r
i
n
t
i
n
g
i
n
C
h
i
n
a
EN

19
For DVD movie, if a menu appears, press
to start play.
2To pause, touch .
To resume play, touch• again.
Search for a folder
For video files
1Touch to return to playlist menu.
2Touch to display all available video file
folders.
3Touch a folder, then touch or to
select a file.
4Touch to start play.
For audio files
1Touch to return to playlist menu.
2Touch to display all available audio
folders.
Insert USB or SD/MMC card
Note
Ensure that the device contains playable•
content.
The unit supports SDHC card.
•
1Open the USB/SD/MMC card cover.
2Insert the SD/MMC card into the
SD/MMC card slot.
Play starts automatically.»
Remove the SD/MMC card
1Press SOURCE to switch to another
source.
2Press the card until you hear a click
sound.
The card is now disengaged.»
3Remove the SD or MMC card.
Play/Pause
1Once a disc, USB or SD/MMC card is
inserted, play starts automatically.
English
EN

20
Repeat
During play, you can select different repeat play
modes.
For DVD/VCD movie disc:
1Touch anywhere except for the upper left
corner to display menu on the screen, if
necessary.
2Touch to display the 2nd menu.
3Touch to select:
• [Repeat chapter]: play the current
chapter repeatedly.
• [Repeat title]: play all chapters in the
title repeatedly.
• [Repeat off]: cancel repeat play.
ForVCD karaoke or audio CD:
1Touch anywhere except for the upper left
corner to display menu on the screen, if
necessary.
2Touch to select:
• [Repeat]: play the current track
repeatedly.
• [Repeat off]: cancel repeat play.
For MP3/WMA files:
1Touch anywhere except for the upper left
corner to display menu on the screen, if
necessary.
2Touch to select:
• [Repeat]: play the current track
repeatedly.
3Touch a folder, then touch or to
select a file.
4Touch to start play.
For picture files
1Touch to return to playlist menu.
2Touch to display all available picture
folders.
3Touch a folder, then touch or to
select a picture.
4Touch to view the picture.
Search within a title/folder
Search by step
1Touch anywhere except for the upper left
corner to display menu on the screen, if
necessary.
2Touch or to skip to the previous or
next chapter/track.
Direct search
1Touch anywhere except for the upper left
corner to display menu on the screen, if
necessary.
2Touch .
The search screen is displayed.»
For video files, touch»first, then
touch .
3Touch the numbers to enter chapter/file
number, then touch .
To clear the previous input, touch• .
To clear all input, touch• .
EN

21
Select audio language
For video discs that contain two or more audio
channels.
1During play, touch anywhere except for
the upper left corner to display menu on
the screen, if necessary.
2Touch to display the 2nd menu.
3Touch repeatedly.
The audio channel information is»
displayed on the upper line of the
screen.
Select audio mode
When you play VCDs, you can select an audio
mode (R/L/Stereo).
1During play, touch anywhere except for
the upper left corner to display menu on
the screen.
2Touch repeatedly until the audio
mode is selected.
Select subtitle language
For DVD or DivX discs that contain two or
more subtitle languages.
1During play, touch anywhere except for
the upper left corner to display menu on
the screen, if necessary.
2Touch to display the 2nd menu
3Touch repeatedly to select a language.
The selected language is displayed.»
Tip
You may also press• SUBTITLE on the remote
control repeatedly to select subtitle language.
• [Repeat folder]: play all the tracks in
the current folder repeatedly.
• [Repeat off]: cancel repeat play.
Tip
You can also press• REPEAT on the remote
control to select repeated play mode.
Repeat a section
You can repeat a specific section of video file
(repeat A-B).
1During play, touch anywhere except for
the upper left corner to display menu on
the screen, if necessary.
2Touch to display the 2nd menu, if
necessary.
3Touch repeatedly to mark:
• [Repeat A-]: the start of the section
to repeat.
• [Repeat A-B]: the end of the section
to repeat.
The selected section plays•
repeatedly.
4To exit A-B repeat mode, touch
repeatedly until [Repeat A-B off] is
displayed.
Random play
You can play audio tracks/files in random order.
1During play, touch repeatedly to turn
random play on or off.
• is highlighted : start random play.
• turns gray: cancel random play.
Tip
You can also press• SHUFF on the remote
control to select random play mode.
English
EN
