Philips DC200/79 User manual

DC200Docking Entertainment System
Register your product and get support at
www.philips.com/welcome
User Manual
DC200_79_CCR 2008.2.21 17:01 Page 1

1
2
6
%
#
@
$
!
0
8
7
95
4
3
1
DC200_79_CCR 2008.2.21 17:01 Page 2

P-01
AL1
AL1
840
840
T001
2
3
4
DC200_79_CCR 2008.2.21 17:01 Page 3

English
Congratulations on your purchase and welcome to Philips! To fully
benefit from the support that Philips offers, register your product at
www.philips.com/welcome.
SUPPLIED ACCESSORIES
–1Xcertified AC/DC 9V adaptor
(Brand name: PHILIPS, Model No.: AS140-090-Dw,
Input: 100-240V ~ 50/60Hz 0.7A, Output: 9.0V 1.56A)
– 4Xdock adaptors (for different iPod types)
– 1XAUX-IN cable
CONTROLS (See 1)
1SOURCE
–selects TUNER/iPod/USB/NATURE/AUX mode
2POWER
–switches the system on or to standby mode
–stops active alarm for 24 hours
–deactivates the sleep function
3SLEEP
–activates/ deactivates the sleep function
4iPod MENU
– enters the iPod menu
5PROG / SET TIME
–activates/confirms clock time setting
6
3/ 4/1/ 2
for iPod . . . . . . . . . . . . . navigates in iPod menu
ALBUM/PRESET -/+ 1/ 2
– selects a preset radio station
– selects albums in USB mode
– selects time zone in clock mode
VOLUME
3/ 4
– adjusts the sound level
DC200_79_CCR 2008.2.21 17:01 Page 4

OK
for iPod
. . . . . . . . . . . . . . confirms menu selection.
7Dock connector
– connects iPod player
8USB jack
– connects an external USB mass storage device
9
REPEAT ALARM / BRIGHTNESS CONTROL
–switches off the alarm for a 9 minute period
–changes the brightness of the display illumination
0TUNING
¡1 / 2™
–adjusts clock/alarm time
–tunes to radio stations
–selects previous/next tracks in the iPod/USB mode
–fast searches forward/backward in the iPod/USB mode
MODE
– selects different play modes: e.g. REPEAT or SHUFFLE (random order).
2;
–starts/pauses playback in the iPod/USB mode
9
–stops playback in the iPod/USB mode
!1
ALM / 2 ALM
– activates/confirm alarm 1/alarm 2 time setting
–displays alarm 1/ alarm 2 time
–switches off alarm 1/ alarm 2 time
@DISPLAY
– shows clock/alarm times and status of the set
#AUX IN jack (3.5 mm)
– connects to external audio source
$POWER jack
– socket for AC/DC 9V adaptor
%
Pigtail
–improves FM reception
DC200_79_CCR 2008.2.21 17:01 Page 5

POWER SUPPLY
Mains adaptor
1
Connect the mains adaptor to the set's DC 9V socket and to the power socket.
Helpful hints: To avoid damage to the set, use only the adaptor supplied!
The power rating is located on the bottom of the set.
SELF-POWERED BACK-UP
The self-powered back-up conveniently allows your alarm and clock time settings to be
stored for up to 10 minutes when there is a power interruption e.g. AC power failure.
The complete clock radio and backlight illumination will be switched off.
If power supply returns after 10 minutes and the display shows:
•clock time blinking - indicates you need to re-adjust the clock time.
BASIC OPERATION.
Switching on the system
•Press POWER.
™
The system will switch to the last selected source.
Switching the system to standby mode
•In any source mode, press POWER.
Illumination brightness
Press REPEAT
ALARM / BRIGHTNESS CONTROL once or more.
• The brightness of the display can be adjusted:
Bright ➟Low ➟Off ➟Bright
.
SETTING THE CLOCK
1In standby mode, press and hold PROG/SET TIME until clock digits flashes.
2
Hold down or press ¡1 /2™ repeatedly to set and adjust the hours.
3Press PROG/SET TIME to confirm.
™ The clock digits for the minutes flash.
4 Hold down or press ¡1 /2™ repeatedly to set and adjust the minutes.
DC200_79_CCR 2008.2.21 17:01 Page 6

5Press PROG/SET TIME to confirm.
6 In clock mode, press ALBUM/PRESET -/+ 1/2to set your time zone.
7 To zoom in/out the clock display, press MODE in clock mode.
TUNER
1
Press SOURCE repeatedly to switch on the radio (FM only).
™ Display shows the radio frequency of the last selected waveband. Your pre-
set station is also shown if you are listening to a preset.
( See 2 )
2
Adjust the sound using VOLUME 3/4 .
3To select preset stations, press ALBUM/PRESET -/+
1/2 once or repeatedly.
TUNING TO RADIO STATIONS
1Press and hold ¡1 /2™ until the frequency in the display starts changing.
™After the system tunes to a station of sufficient reception, display shows its
frequency.
•To tune to a weak station, press
¡1 /2™ briefly and repeatedly until an
optimal reception is found.
To improve reception (FM):
Extend and position the pigtail fully to obtain optimum reception.
STORING AND USING PRESET STATIONS
You can store up to 20 FM radio stations in the memory.
1Tune to your desired station (see TUNING TO RADIO STATIONS).
2
Press PROG to activate the programming, and then press ALBUM/PRESET -/+ 1
/ 2
to select a desired preset number .
3 Press PROG again to confirm.
4
Press ALBUM/PRESET -/+ 1/ 2 to listen to a preset station.
AUTOSTORE: Automatic programming
1 Press and hold PROG for more than two seconds.
™Available radio stations will be automatically stored.
DC200_79_CCR 2008.2.21 17:01 Page 7

USING THE ALARM
GENERAL
Two different alarm times can be set. This can be useful when you need to be
woken up at a different time e.g. during the week and at the weekend, and you
can set different wake-up modes:
•Tuner mode.
•iPod/USB mode.
•Nature sound mode.
•Buzzer mode. The gentle wake buzzer alarm increases its beep tone frequency
within seconds.
SETTING THE ALARM TIME AND MODE (See 3)
1In any mode, press and hold 1 ALM or 2 ALM for two seconds.
™
AL1 / AL2 icon and the hour digits flash.
2 Hold down or press ¡1 /2™ repeatedly to set and adjust the hours.
3Press 1 ALM or 2 ALM to confirm.
™ AL1 / AL2 icon and the minutes digits flash.
4 Hold down or press ¡1 /2™ repeatedly to set and adjust the mintues.
5Press 1 ALM or 2 ALM to confirm.
™ The icon for the current alarm mode flashes.
6Press ¡1 2™ / SOURCE repeatedly to select your desired alarm mode.
•For Nature sound mode, press ALBUM/PRESET -/+ 1/ 2 to select your desired
nature sound track.
™
At the set alarm time, the selected sound source or buzzer will switch on
automatically.
Helpful hints:
– If you have selected TUNER alarm mode,make sure you have properly tuned to a
station before turning off the set.
– If you have selected iPod/USB alarm mode,make sure you have connected the com-
patible iPod player or USB device, or the buzzer mode will be selected automatically.
– To check the alarm time setting for AL1 or AL2, press 1 ALM or 2 ALM.
DC200_79_CCR 2008.2.21 17:01 Page 8

SWITCHING OFF THE ALARM
There are three ways of switching off the alarm. Unless you cancel the alarm
completely, the 24-hour ALARM RESET will be automatically selected after 59
minutes from the time your alarm first goes off.
24 HOUR ALARM RESET
If you want the alarm mode to be stopped immediately but also wish to retain
the same alarm setting for the following day:
•
Press
POWER or 1
ALM / 2 ALM
.
REPEAT ALARM
This repeats your alarm call at 9 minute intervals.
• During the alarm call, press REPEAT ALARM / BRIGHTNESS CONTROL.
™ Display shows AL1 or AL2 flashing during a repeat alarm.
• Repeat if desired (up to a maximum of 6 times).
CANCELING THE ALARM COMPLETELY
•
Press 1 ALM
or 2
ALM
button once or more until AL1 or AL2 disappears.
DOCK (See 4)
By connecting the iPod to your DC200, you can listen to the music stored in iPod
player through the powerful speakers of the set.
COMPATIBLE PORTABLE PLAYERS
•
Most Apple iPod models with 30-pin dock connector as follows:
iPod Touch 4GB/8GB, 20GB, 40GB, iPod Photo 20GB/30GB/40GB/60GB, iPod
Video 30GB/60GB/80GB, iPod Classic 80GB/160GB, Mini and Nano.
DOCK ADAPTORS
Before plugging your player in the dock, snap the suitable dock adaptor into the
dock to provide a snug fit for the player to be docked.
Selecting the correct dock adaptor
•For the iPod dock, 4 dock adaptors of different type, as indicated at the back
of the adaptor, are included to fit the following iPod:
iPod Touch 4GB/8GB, 20GB, 40GB, iPod Photo 20GB/30GB/40GB/60GB, iPod
Video 30GB/60GB/80GB, iPod Classic 80GB/160GB, Mini and Nano.
DC200_79_CCR 2008.2.21 17:01 Page 9

PLAYING iPod USING DC200
1
Remove the top cover of dock.
2 Snap the compatible iPod into the dock connector.
3 Press SOURCE repeatedly to switch on the iPod mode.
• Make sure that you have powered on Apple iPod before selecting iPod source.
™ On the DC200’s display, “iPod” is displayed when iPod is connected.
4T he connected iPod player will play automatically.
Notes:
–
By using the buttons ( 2;, ¡1, 2™ and VOLUME ) on the DC200, the following
playback features are available: Play/Pause, selecting next/previous track, fast for-
warding/rewinding and changing volume.
– The buttons ( 2;, ¡1, 2™ and VOLUME ) on the DC200 can work only with
playback of the audio contents stored on the docked player.
– To navigate the iPod menu, you may use iPod MENU, 34 and OK buttons on
the set.
– When you press iPod MENU in iPod mode, 1234 and OK buttons first per-
form the navigation function, and then restore the original functions.
– For iPod operations and features, refer to the user manual of your iPod player.
– This set does not support iPod video output.
Using USB connectivity
•DC200 is fitted with a USB port on the top panel, offering a plug and play feature
which allows you to play, from your DC200, digital music and audio contents stored
on a USB mass storage device.
•Using a USB mass storage device, you can also enjoy all the features offered by
DC200.
Compatible USB mass storage devices:
With the DC200, you can use
– USB flash memory (USB 2.0 or USB 1.1)
– USB flash player (USB 2.0 or USB 1.1)
•USB device which requires driver installation under Windows XP is not
supported.
