Philips sonicare ProtectiveClean 4700 User manual

ProtectiveClean
4700

1
2
11
4
3
5
6
7
8
910

empty page before TOC

English 6
Русский 26
Қазақша 49

English
Important safety information
Read this important information carefully before
you use the appliance and save it for future
reference.
Note: The accessories and features of different
models vary. For example, some models come with
a sanitizer.
DANGER
- Keep the charger and/or sanitizer away
from water. Do not place or store the
appliance where it can fall or be pulled into
a tub or sink.
- Do not immerse the charger and/or sanitizer
in water or any other liquid.
- After cleaning, make sure the charger
and/or sanitizer is completely dry before
you connect it to the wall socket.
6English

WARNINGS
- This appliance can be used by children and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Cleaning and user
maintenance shall not be made by children
without supervision.
- Children shall not play with the appliance.
- Keep the sanitizer out of the reach of
children at all times.
- Stop using the sanitizer if the UV light bulb
remains on when the door is open. UV light
can be harmful to the human eye and skin.
- Do not operate the sanitizer without the
protective screen in place to avoid contact
with a hot UV light bulb.
- The UV light bulb of the sanitizer is hot
during and immediately after the sanitizing
cycle. Do not touch the UV light bulb when it
is hot.
7
English

- If you have used the sanitizer for 3 UV clean
cycles in a row, switch it off for at least 30
minutes before you start another UV clean
cycle.
- If the appliance is damaged in any way
(brush head, toothbrush handle, charger
and/or sanitizer), stop using it.
- The mains cord cannot be replaced. If the
mains cord is damaged, discard the charger
and/or sanitizer.
- Always replace the charger and/or sanitizer
with one of the original type in order to
avoid a hazard.
- This appliance contains no user-serviceable
parts. If the appliance is damaged, contact
the Consumer Care Center in your country
(see 'Warranty and support').
- Keep the cord away from heated surfaces.
- Do not use the charger and/or sanitizer
outdoors or near heated surfaces.
- When using Philips Sonicare Patient Trial
handle, refer to separate disinfection
procedure.
8English

CAUTION
- Do not clean the brush head, handle,
charger, charger cover or sanitizer in the
dishwasher.
- If you have had oral or gum surgery in the
previous 2 months, consult your dentist
before you use this appliance.
- Consult your dentist if excessive bleeding
occurs after using this appliance or if
bleeding continues to occur after 1 week of
use. Also consult your dentist if you
experience discomfort or pain when you use
this appliance.
- This Philips appliance complies with the
safety standards for electromagnetic
devices. If you have a pacemaker or other
implanted device, contact your doctor or the
appliance manufacturer of the implanted
appliance prior to use.
- If you have medical concerns, consult your
doctor before you use this appliance.
9
English

- This appliance has only been designed for
cleaning teeth, gums and tongue. Do not
use it for any other purpose. Stop using the
appliance and contact your doctor if you
experience any discomfort or pain.
- Do not use other brush heads than the ones
recommended by Philips Sonicare.
- Stop using a brush head with crushed or
bent bristles. Replace the brush head every
3 months or sooner if signs of wear appear.
- Avoid direct contact with products that
contain essential oils or coconut oil. Contact
may result in bristle tufts dislodging.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Intended use
ProtectiveClean series power toothbrushes are
intended to remove adherent plaque and food
debris from the teeth to reduce tooth decay and
improve and maintain oral health. ProtectiveClean
10 English

series power toothbrushes are intended for
consumer home use. Use by children should be
with adult supervision.
Your Philips Sonicare (Fig. 1)
1 Hygienic travel cap
2 Smart brush head(s)*
3 Handle
4 Power on/off button
5 Mode/intensity button
6 Mode light
7 Brush head replacement reminder light
8 Battery indication
9 Charging base
10 UV sanitizer with integrated charger and cord
wrap (specific types only)*
-Not shown: UV light bulb
-Not shown: Sanitizer drip tray
-Not shown: Protective screen for UV light
bulb
11 Travel case (specific types only)*
*Note: The content of the box may vary based
on the model purchased.
Brush heads
Your Philips Sonicare comes with one or more
brush heads which are designed to deliver
superior results for your oral care needs.
Philips Sonicare BrushSync Technology
Your smart brush heads use a microchip to sync
with your handle, enabling brush head
replacement reminder. For more information
regarding the brush head replacement reminder,
see 'Features'.
11
English

This symbol indicates the brush head is equipped
with BrushSync technology.
Brushing modes
To toggle between modes press the mode button
located below the on/off button.
Your power toothbrush is equipped with 2
brushing modes.The following modes are
available:
Clean mode
Clean is a 2-minute mode. It gives you a thorough
and complete clean and is recommended to be
used with the C2 Optimal Plaque Control brush
head.
Gum Care mode
Gum Care is a 3-minute mode, recommended to
be used with the G2 Optimal Gum Care brush
head.
Intensity settings
Your power toothbrush gives you the option to
choose between 3 different intensity levels: low,
medium and high. Based on the brush head you
attach, the intensity will be selected. The intensity
can be changed by pressing the mode/intensity
button while brushing. For optimal results it is
recommended to use the automatically selected
intensity. The intensity cannot be changed as long
as the handle is powered off or paused.
12 English

Using your Philips Sonicare
Brushing instructions
1Press the brush head onto the handle in such a
way that the bristles will face the front of the
handle.
2Firmly press the brush head down onto the
metal shaft until it stops.
Note: It is normal to see a slight gap between
the brush head and the handle.
3Wet the bristles.
4Apply a small amount of toothpaste on the
bristles.
5Place the toothbrush bristles against the teeth
at a slight angle (45 degrees), pressing firmly to
make the bristles reach the gumline or slightly
beneath the gumline. A change in vibration (and
a slight change in sound) alerts you when you
apply too much pressure while brushing.
Note: Keep the center of the brush in contact
with the teeth at all times.
13
English

6Press the power on/off button to turn on the
Philips Sonicare.
7Gently keep the bristles placed on the teeth
and in the gumline. Brush your teeth with small
back and forth motion so the bristles reach
between the teeth.
Note: The bristles should slightly flare. Do not
scrub.
8To clean the inside surfaces of the front teeth,
tilt the brush handle semi-upright and make
several vertical overlapping brushing strokes on
each tooth.
2
4
3
1
9To make sure you brush evenly throughout the
mouth, divide the mouth into 4 sections using
the Quadpacer feature. The quadpacer feature
beeps after 30 seconds.
30
sec.
30
sec.
1 2
10 Brush for the full 2 minutes following the
Quadpacer. After 2 minutes, the toothbrush will
automatically shut off.
- In white mode, after 2 minutes the handle will
continue to brush for 30 seconds so that you
can brighten and polish your front teeth.
- In gum care mode, after 2 minutes the handle
will continue to brush for an additional minute
so you can gently stimulate and massage your
gums.
14 English

3 4
30
sec. 30 sec.
- After you have completed the brushing cycle,
you can spend additional time brushing the
chewing surfaces of your teeth and areas where
staining occurs. You may also brush your
tongue, with the toothbrush turned on or off, as
you prefer.
Your Philips Sonicare toothbrush is safe to use
on:
- Braces (brush heads wear out sooner when
used on braces)
- Dental restorations (fillings, crowns, veneers)
Note: When the Philips Sonicare toothbrush is
used in clinical studies, it must be used in the
Clean mode (for plaque and gum health claims) or
in White mode (for whitening claims) at high
intensity with EasyStart turned off.
Features
- EasyStart
- Brush head replacement reminder
- Pressure sensor
- Quadpacer
EasyStart
This Philips Sonicare model comes with the
EasyStart feature activated. The EasyStart feature
gently increases the power over the first 14
brushings to help you get used to brushing with
the Philips Sonicare. The EasyStart feature works in
all modes.
To deactivate EasyStart see 'Activating or
deactivating features'.
15
English

Brush head replacement reminder
Your Philips Sonicare is equipped with BrushSync
technology that tracks the wear of your brush
head.
1When attaching a new smart brush head for the
first time the brush head replacement reminder
light blinks green three times. This confirms you
have a Philips brush head with BrushSync
technology.
2Over time, based on the pressure you apply and
the amount of time used, the handle will track
brush head wear in order to determine the
optimal time to change your brush head. This
feature gives you the guarantee for the best
cleaning and care of your teeth.
3When the brush head replacement reminder
light lights up amber, you should replace your
brush head.
To deactivate the brush head replacement
reminder see 'Activating or deactivating features'.
Pressure sensor
Your Philips Sonicare is equipped with an
advanced sensor that measures the pressure you
apply while brushing. If you apply too much
pressure, the toothbrush will provide immediate
feedback to indicate that you need to reduce the
pressure. This feedback is given by a change in
vibration and therefore brushing sensation.
To deactivate the pressure sensor see 'Activating
or deactivating features'.
Quadpacer
The Quadpacer is an interval timer that has a short
beep and pause to remind you to brush the
different sections of your mouth. Depending on
16 English

the brushing mode you have selected (see
'Brushing modes'), the Quadpacer beeps at
different intervals during the brushing cycle.
Activating or deactivating features
You can activate or deactivate the following
features of your toothbrush:
- EasyStart
- Brush head replacement reminder
- Pressure sensor
To activate or deactivate these features, follow the
instructions below:
EasyStart
1Put the handle on the plugged-in charger.
2Press and hold the power on/off button while
the handle remains on the charger.
3Keep the power on/off button pressed until you
hear a single short beep (after 2 seconds).
4Release the power on/off button.
-Triple tone of low-med-high means the
EasyStart feature has been activated. The
brush head replacement light and battery
light will also blink green 2 times in unison to
confirm activation.
-Triple tone of high-med-low means the
EasyStart feature has been deactivated. The
brush head replacement light and battery
light will also blink amber 1 time in unison to
confirm deactivation.
Note: To achieve clinical efficacy, EasyStart needs
to be deactivated.
Brush head replacement reminder
Note: Make sure a brush head is attached on the
handle before you start this procedure.
17
English

1Put the handle on the plugged-in charger.
2Press and hold the power on/off button while
the handle remains on the charger.
3Keep the power on/off button pressed until you
hear a series of two short beeps (after 4-5
seconds).
4Release the power on/off button.
-Triple tone of low-med-high means the
Brush head replacement reminder feature
has been activated. The brush head
replacement light and battery light will also
blink green 2 times in unison to confirm
activation.
-Triple tone of high-med-low means the
Brush head replacement reminder feature
has been deactivated. The brush head
replacement light and battery light will also
blink amber 1 time in unison to confirm
deactivation.
Pressure sensor
1Put the handle on the plugged-in charger.
2Press and hold the power on/off button while
the handle remains on the charger.
3Keep the power on/off button pressed until you
hear a series of three short beeps (after 6-7
seconds).
4Release the power on/off button.
-Triple tone of low-med-high means the
pressure sensor feature has been activated.
The brush head replacement light and
battery light will also blink green 2 times in
unison to confirm activation.
18 English

-Triple tone of high-med-low means the
pressure sensor feature has been
deactivated. The brush head replacement
light and battery light will also blink amber 1
time in unison to confirm deactivation.
If you continue holding the power on/off button
after the three short beeps, the
activate/deactivate sequence repeats.
Battery status and charging
1Put the plug of the charger in an electrical
outlet.
2Place the handle on the charger.
-The charger will emit 2 short beeps to
confirm that the handle is placed properly.
-The flashing light of the battery level
indicator shows that the toothbrush is
charging.
-When handle is fully charged on the charger,
the battery light shows solid green for 30
seconds and switches off.
Note: Your toothbrush comes pre-charged for first
use. After first use, charge for at least 24 hours.
Battery status (when handle is not on charger)
When removing the Philips Sonicare from the
charger, the battery light at the bottom of the
toothbrush will indicate the status of the battery
life.
- Solid green LED: full battery
- Flashing green LED: medium battery
- Flashing amber LED and three beeps: low
battery
19
English

- Flashing amber LED and two sets of five beeps:
No brushing sessions left (charge toothbrush)
Sanitizing
- With the UV sanitizer you can clean your brush
head after every use.
Unplug the sanitizer, discontinue use and call
Consumer Care if:
- The UV light bulb remains on when the door is
open.
- The window is broken or missing from the
sanitizer.
- The sanitizer gives off smoke or a burning smell
while it is operating.
Note: UV light can be harmful to the human eye
and skin. This device should be kept out of reach
of children at all times.
1After brushing, rinse the brush head and shake
off excess water.
Warning: Do not place the travel cap on
the brush head during sanitization.
2Place your finger in the door recess on top of
the sanitizer and pull open the door.
3Place the brush head on one of the 2 pegs in
the sanitizer with the bristles facing the light
bulb.
Note: Only clean Philips Sonicare snap-on
brush heads in the sanitizer.
Note: The Philips Sonicare for Kids brush head
wears and degrades in the UV sanitizer. You
have to check and replace your child's brush
20 English
