Philips Essence HR7768 User manual

ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Essence Foodprocessor
HR7768
07/02
PRODUCT INFORMATION
- The Foodprocessor is equipped with mechanical and
thermal safety switches.
Materials used:
- Food processor bowl and lid, : SAN
blender jar & safety lid
- Pushers, blender lid, inlay : PP
bowl handle, juice extractor
housing, storage system
- Housing, Screw cap : Stainless steel, PP
- Safety lever blender jar : PC
- Feeding tray, sausage horn : ABS
- Kneading accessory : PP / 30% chalk,
stainless steel
- Toolholder bowl, : POM
sausage seperator
- Balloon beater : POM, Alu, stainless steel
- Grip blender jar : ABS
- Food processor knifes : Stainless steel / PP
- Food processor discs : Stainless steel / POM
- Cutter, grinding discs : Metal
- Meat mincer processing tube, : Alu - alloy
worm shaft
- Fruit filter : PP, stainless steel (mesh)
- Juicer sieve : PA, 30% glass fibre,
stainless steel
- Foil on panel buttons : Silicone rubber
Colours:
- White with vapor dusk grey accents, orange LED
lightrings, clear transparent bowl & jar, brushed stainless
steel screwcap and control panel.
TECHNICAL INFORMATION
- Motor : universal, radio / TV interference
suppressed
- Power consumption : 800 Watt max.
- Voltage & frequency : 230 V, 50 Hz
- Cordset : 100 cm, double insulated with
moulded on plug
- Speed setting : Smart Process Control
- Bowl capacity : 2.5 L dry ingredients, 1.7 L liquids
- Blender capacity : total jar capacity 2.0 L,
1.5 L effective
- Speeds unloaded : blender drive shaft 19500 rpm (max)
accessories drive shaft from 660 rpm
to 2150 rpm, depends on application
- Weight in fancy box : 9.2 kg
- Dimensions : 546 x 380 x 390 (mm)
fancy box (l x w x h)
Safety:
- Automatically resettable : protects motor against
thermal cut out overheating
- Built – in safety lock : detects wheter lid & bowl are
assembled
- Motor brake system : stops the appliance within
1.5 seconds
- This product meets the requirements regarding interference
suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as officially
laid down at this moment.

HR7768
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- The blender coupling on the motor shaft has been provided
with a customary left-handed thread.
The drive coupling (item 10) can be detached by means of
a hammer and a screwdriver. Strike the screwdriver with a
short sharp blow and remove the drive coupling, or block
the acc. drive wheel (item 17) and thereby the rotor shaft,
by sticking a pin through the hole (5 mm dia. – marked
with an arrow) in the bottom plate.
- The assembly of the accessories depends on the national
version.
REPAIR INSTRUCTIONS
- For specific versions, the component configuration may
differ from the one shown on the exploded view. However,
the actual components can be distinguished by their code
numbers.
- Make sure that all functions, including the safety devices,
are working correctly after you have completed the repair.
Automatic resettable cut-out (part of item 11)
To prevent damage due to overheating, the appliance has been
equipped with an automatic cut-out system.
This system will automatically cut off the power supply when
the appliance overheats.
If the appliance suddenly stops running:
- Unplug the appliance
- Switch off the appliance
- Let the appliance cool down for 15 minutes
- Plug the appliance in again
- Switch the appliance on again
Safety lock (item 7)
Place the lid on the bowl in the right position. The appliance
will only function if the line on the applinace is directly
opposite the mark on the lid of the food processor bowl and
the same holds for the other accessoires. The built-in safety lock
will now be deblocked and you can turn the appliance on.
Note that if both the blender jar and the bowl have been
correctly mounted, only the blender will function.
Important:
If the appliance is used without the blender jar, the appliance
will not function, when the blender coupling (item 10) has not
been protected by the blender cover (item 1).
Note:
The blender cover can only be removed, when the bowl
including the bowl lid is not mounted on the foodprocessor.
How to set the belt tension:
Step 1: Give 30 N pretension force on the adjusting plate to
minimise the distances between the belt and the belt
wheels
Step 2: Reduce the tension force from 30 N down to 10 N
which is the required belt drive force for the appliance.
Step 3: Fix the adjusting screw on the adjusting plate when the
tension force reaches the value of 10 N (after coming
down from 30 N!)
OPTIONAL (accessories)
- No specific issues
MAINS C1
Change-over switch
in braking position
Motor
winding
Motor
winding
Main PCB
brown
red
yellow
white
red
S1
S2
black
yellow
Rotor
Y-
capacitor
X2
capacitor
TCO
Thermal
Cut Off
Y-
capacitor
Choke
Choke
2-8

HR7768
PARTS LIST
Attention:
In case you have an appliance with
HR7768
Ain the typeplate and one of the parts 10, 11 or 97 is defective, you have to order
the complete assy Pos 9 due to incompatibility of old and new parts.
In case you have an appliance with
HR7768
Bin the typeplate and one of the parts 10, 11 or 97 is defective, they can be
ordered seperately.
3-8
Pos Service code Description
1
2
3
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19
19
32
33
34
35
40
41
42
43
44
46
47
49
50
51
60
61
62
4203 065 65810
4203 065 63620
4203 065 65820
4203 065 65830
4203 065 63490
4203 065 63580
4203 065 63510
4203 065 66200
4203 065 65840
4203 065 63930
4203 065 63590
4203 065 63600
4203 065 63540
4203 065 60310
4203 065 60440
4203 065 63560
4203 065 63610
4203 065 63980
4203 065 63990
4203 065 64010
4203 065 63800
4203 065 63760
4203 065 63770
4203 065 63780
4203 065 61840
4203 065 61960
4203 065 61970
4203 065 61830
4203 065 63670
4203 065 63970
4203 065 63690
4203 065 63680
4203 065 64740
4203 065 64750
4203 065 65560
4203 065 65550
4203 065 65850
Blender cap
Screw cap
Top housing Assy
Main - PCB
Housing parts
Safety switch lever
PCB brake
Motor / Coupling / Sieve - Assy
Blender coupling
Motor assy - 230 V
Motor coupling assy
Mounting plate
Adjusting piece
Motor screw
Tooth belt
Belt wheel
Single speed gear
Cordset EURO
Cordset UK
Cordset SWISS
Pusher closed bowl
Bowl lid
Lid bearing
Closed bowl
Potato grating disc (Reibekuchen)
Grating disc (fine/very fine)
Grating disc (coarse/medium) opt.
French fries
Adjustable slicing disc
Plastic kneader
Metal knife (incl. protecting cover)
Toolholder
Balloonbeater Gearbox
Balloon Beater
Blender Safety Lid
Blender Lid
Blender Jar
Pos Service code Description
70
71
72
73
74
75
76
77
78
80
81
82
83
84
85
86
87
88
89
90
95
96
97
98
99
100
101
102
103
104
4203 065 64160
4203 065 64170
4203 065 64180
4203 065 64220
4203 065 64240
4203 065 64230
4203 065 64190
4203 065 64210
4203 065 64200
4203 065 64050
4203 065 64060
4203 065 64070
4203 065 64080
4203 065 64090
4203 065 64100
4203 065 64110
4203 065 64140
4203 065 64150
4203 065 64120
4203 065 64130
4203 065 65860
4203 065 65870
4203 065 65880
4203 065 65890
4203 065 65900
4203 065 65910
4203 065 65920
4203 065 65930
4203 060 65940
4203 065 65970
Housing upper part
Housing lower part
Mounting plate
Gear assy
O-ring
Release button
Coupling part
Drive gear
Sealing
Feeding tube
Worm shaft assy
Coupling
Cutting blade
Cutting Disc (Dia. 4 mm)
Cutting Disc (Dia. 8 mm)
Screw ring
Sausage horn bearing
Sausage horn
Feeding tray
Pusher Meat Mincer
Pusher Juice Extractor
Lid
Sieve
Housing
Clip
Axle with spring
Hinge
Axle
Spout
Storage system
= changed

HR7768
EXPLODED VIEW
8
7
3
5
1
2
6
4-8

HR7768
EXPLODED VIEW
10
9
15
13
11
12
18
19
14
16
17
97
5-8

HR7768
EXPLODED VIEW
32
35
33
34
46
42
44
43
49
50
51
47
62
61
60
41
40
6-8

HR7768
EXPLODED VIEW
90
89
86
85
84
88
87
78
76
82
83
74
70
71
80
81
77
73
75
72
7-8

HR7768
EXPLODED VIEW
95
96
97
98
102
103
101
100
99
8-8
