Philips QC5370 User manual

QC5375
QC5370
User manual

1

QC5375, QC5370
ENGLISH 6
 10
 14
 17
 21
 25
 29
 33
 37
 41
 45
 49
 53
 57
 61
 65

6
Introduction
Congratulations on your purchase and welcome to Philips!
To fully benet from the support that Philips offers, register
your product at www.philips.com/welcome.
General description (Fig. 1)
1 Cutting element
2 On/off button
3 Zoom wheel
4 Charging light
5 Socket for appliance plug
6 Appliance plug
7 Adapter
8 Comb
9 Cleaning brush
10 Pouch (QC5375 only)
Preparing for use
Charging
Charge the appliance for at least 1 hour before you use it for the rst time
and after a long period of disuse.
When the appliance is fully charged, it has an operating time of up to
60 minutes.
When the charging light lights up orange, the battery is running low
(approx. 10 minutes of operating time left) and you need to recharge
the appliance.
1 Switch off the appliance before you charge it.
2 Insert the appliance plug into the socket on the appliance and put
the adapter in the wall socket.
,The charging light starts to ash green to indicate that the appliance
is charging.
,When the batteries are fully charged, the charging light lights up
green continuously.After 30 minutes the charging light goes out to
save energy.
ENGLISH


Note:You can also use the appliance directly from the mains when the battery
is empty.
Clipping with comb
The appliance comes with 1 comb for different hair lengths.
The hair length settings are indicated in millimetres on the comb.
The settings correspond to the remaining hair length after clipping.
1 Slide the comb straight into the guiding grooves on both sides
of the handle (‘click’).
2 Turn the zoom wheel to set the comb to the desired setting.
,The settings in the window show the selected hair length in
millimetres after cutting.
Tip:Write down the hair length settings you selected to create a certain
hairstyle as a reminder for future clipping sessions.
3 Press the on/off button to switch on the appliance.
4 Move the appliance through the hair slowly.

- To clip most effectively, move the appliance against the hair growth
direction.
- Since all hair does not grow in the same direction, you need to move
the appliance in different directions (upwards, downwards and across).
- Make sure that the at part of the comb is always fully in contact with
the scalp to obtain an even result.
- Make overlapping passes over the head to ensure that you cut all the
hair that needs to be cut.
5 Regularly remove cut hair from the comb.
If a lot of hair has accumulated in the comb, remove the comb from the
appliance and blow and/or shake the hair out of it.
ENGLISH 7

Contouring without comb
You can use the appliance without comb to clip hair very close to the
skin (0.5mm) or to contour the neckline and the area around the ears.
Be careful when you clip without comb because the cutting
element removes every hair it touches.
1 Pull the comb off the appliance.
2 Before you start to contour the hairline around the ears, comb the
hair ends over the ears.
3 Press the on/off button to switch on the appliance.
4 Tilt the appliance in such a way that only one edge of the cutting
element touches the hair ends when you shape the contours around
the ears.
Only cut the hair ends.The hairline should be close to the ear.
5 To contour the neckline and sideburns, turn the appliance and make
downward strokes.
Move the appliance slowly and smoothly. Follow the natural hairline.
ENGLISH8

Cleaning
Clean the appliance every time you have used it with the cleaning brush
and with warm water (max. 40°C).
Never use compressed air, scouring pads, abrasive cleaning agents
or aggressive liquids such as petrol, acetone or ethereal oils to clean
the appliance.
Note:The appliance does not need any lubrication.
1 Switch off the appliance and disconnected it from the mains.
2 Remove the comb from the appliance and rinse it under the tap.
3 Brush the outside of the shaving unit with the brush supplied.
4 Push the centre top end of the cutting element upwards with your
thumb until it opens.
5 Use the cleaning brush to remove the cut hair.
6 Clean the appliance under a warm running tap to ush out the cut
hair.
ENGLISH 9

10

Поздравления за вашата покупка и добре дошли във Philips! За
да се възползвате изцяло от предлаганата от Philips поддръжка,
регистрирайте продукта си на адрес www.philips.com/welcome.

1 Подстригващ елемент
2 Бутон за вкл./изкл.
3 Регулиращо колелце
4 Светлинен индикатор за зареждане
5 Гнездо за жака за уреда
6 Жак на уреда
7 Адаптер
8 Гребен
9 Четка за почистване
10 Калъф (само за QC5375)


Оставете уреда да се зарежда в продължение на поне 1 час, преди да
го използвате за първи път или ако не сте го използвали дълго време.
Когато уредът е напълно зареден, той може да осигури до
60 минути работа.
Когато индикаторът за зареждане светне в оранжево,
батерията е изтощена (остават около 10 минути работа)
и трябва да заредите уреда.
1 Изключвайте уреда, преди да го заредите.
2 Включете щекера в гнездото на уреда и включете адаптера
в контакта.
,Индикаторът за зареждане започва да мига в зелено, което
показва, че уредът се зарежда.
,Когато батериите са напълно заредени, индикаторът за
зареждане свети постоянно в зелено. След 30 минути
индикаторът за зареждане угасва, за икономия на енергия.

