Philips TD6820/AH051P User manual

Safety information
This product may be used legally only in a country where the appropriate
authority has given its specific authorisation. This authorisation appears
on a label at the back of the charger.
The marking on the product certifies its conformity with the technical
regulations for user safety and electromagnetic disturbance which were
applicable on the date of approval in accordance with European Union
Directive No. N°91/263/EEC.
Power requirements
This product requires an electrical supply of 230 volts, alternating
monophased current, excluding IT installations defined in standard
EN 60-950.
Warning:
The electrical network is classified as excessive according to criteria in the
standard EN41-003.
The only way to power down this product is by unplugging the power cable
from the electrical outlet. Make sure the electrical outlet is located close to
the apparatus and is always easily accessible.
It is recommended that this telephone be used as a complement to
another telephone which does not require mains power.
Telephone connection
The voltage on this network is classified as TNV (Telecommunication
Network Voltages, as defined in the standard EN 41-003).
Safety precautions
•Do not allow the handset to come into contact with water.
•Do not open the handset or the charger. This could expose you
to high voltages. Contact our after-sales service for all repairs.
•Do not allow the charging contacts or the battery to come into
contact with conductive materials such as keys, paper clips,
rings, bracelets, etc.

Contents 1
Contents
Introduction 2
Installing your extra handset 3
Deciding where to put the charger 3
Installing the charger on a horizontal surface 3
Mounting the charger on a wall 5
Charging your handset 6
Subscribing your handset to your Xalio base station 7
Using your Xalio 9
Making an outside call 9
Answering an outside call 9
Making an internal call 10
Answering an internal call 10
Using the handset loudspeaker 10
Setting up Baby Sit (Xalio 6820 & 6850 only) 11
Transferring calls 12
Switching on the battery saver 13
Switching off the battery saver 13
Maintenance 14
Changing the battery 14
Caring for your handset 15

Introduction2
Introduction
The Xalio 6800 is an extra handset for the Xalio digital cordless
telephone.
The Xalio 6820 is an extra handset for the Xalio Plus digital
cordless telephone.
The Xalio 6850 is an extra handset for the Xalio Vox digital
cordless telephone with answering machine.
Your Xalio 6800/6820/6850 comprises:
•a charger
•a handset
•a power cable
This guide shows you how to install and use your extra Xalio
handset.
Please refer to the corresponding Xalio user manual for
information on:
•using the phonebook
•using the emergency number
•using the answering machine (Xalio Vox only)
•troubleshooting

Installing your extra handset 3
Installing your extra handset
Deciding where to put the charger
•Place the charger near a mains outlet supplying 230V at 50Hz.
•To reduce to a minimum any interference with other electronic
devices such as telephones, televisions, screens, etc. we
advise you to place your charger at least 50cm from any other
electronic device.
•Place the charger on a flat surface as with the base station or
mount it on a wall.
•Significant obstacles such as concrete walls or metallic
supports (windows and door frames, partitions, etc.) will lessen
the communication range between the base station and the
handset.
Installing the charger on a horizontal surface
Plug the power cable into the charger.
1

Installing your extra handset4
Plug the power cable into the wall socket.
Place the handset in the charger.
2
3

Installing your extra handset 5
Mounting the charger on a wall
Fix the screws (not supplied) according to the diagram
below.
Plug the power cable into the charger as shown on
page 3.
Mount the charger on the screws.
Plug the power cable into the wall socket as shown on
page 4.
Place the handset in the charger.
1
2 - 2.5 mm
8 mm
46 mm
1.5 - 2 mm
3 mm
2
3
4
5

Installing your extra handset6
Charging your handset
Your handset is powered by a rechargeable battery.
Before you use your handset for the first time, charge
it for at least 12 hours. This precaution helps to lengthen the
life of the battery.
To charge the handset, place it on the charger or on the base
station. The bsymbol will appear on the display to indicate that
the battery is charging.
When the bsymbol disappears, your handset is fully charged.
The charger must be connected to a power supply using the power
cable supplied.
Tip
To ensure an optimum handset charge, replace the handset on
the charger regularly.

Installing your extra handset 7
Subscribing your handset to your Xalio
base station
Before you can use your handset, you must subscribe it to your
base station.
Press the button on the base station for 10
seconds.
The base station beeps to indicate that it is now in
subscription mode.
Move the handset to be subscribed close to the base
station and press Rto enter menu mode.
Press -until SUBSCRIBE is displayed.
Press o.
The handset will search for a base station that is in
subscription mode.
After a few seconds, the name or ID number of the base
station will be displayed. In this case go to the next step.
If it cannot find one, NO BASE will be displayed and you will
need to try again.
Press oagain.
CODE? will be displayed.
Enter the subscription code (1590) on the handset
keypad.
Press o.
If the base station has a name, this will be displayed. When
you first use your telephone, the base station name is
PHILIPS. You can delete the existing name using the -
key. If the base station has no name, BASE NAME? will be
displayed.
1
2
3
4
5
6
7

Installing your extra handset8
Enter a name (maximum 8 characters) on the handset
keypad.
If you do not enter a name, the base station keeps its
existing name.
You can enter characters by pressing the key with the
required character on it one or more times. These
characters are printed on the handset keypad. If you wish to
enter two successive characters which are on the same key,
you need to distinguish them by pressing the +key
between the two characters. You delete a character with the
-key.
For example: to enter PHILIPS 1 you would press the
following keys.
Press o.
The new handset beeps to confirm that it has been
subscribed successfully.
Press Rto leave menu mode.
8
Space
9
10
11

Using your Xalio 9
Using your Xalio
Making an outside call
Direct dialling
Press the tkey on the handset.
Dial the number using the number keys.
To hang up, press tor replace the handset on the base
station or charger.
Dialling with number preparation
Dial the number before pressing the tkey. You can
use the -key to make corrections by cancelling the
last digit entered.
Press the tkey on the handset.
To hang up, press tor replace the handset on the base
station or charger.
Answering an outside call
Press the tkey on the handset or simply lift it off the
base station or charger.
To hang up, press tor replace the handset on the base
station or charger.
1
2
3
1
2
3
1
2

Using your Xalio10
Making an internal call
When you have more than one handset you can make internal
calls free of charge between handsets subscribed to the same
base station.
Press e.
Dial the number of the handset you want to call.
This is the single-digit number shown on its display.
To hang up, press t(or e) or replace the handset on
the base station or charger.
Answering an internal call
When another handset calls you, your handset will ring with the
internal call melody, the esymbol will blink on the display and
the number of the handset calling you will be displayed.
Press t(or e) or simply lift the handset off the base
station or charger.
To hang up, press t(or e) or replace the handset on
the base station or charger.
Using the handset loudspeaker
(Xalio 6820 & 6850 only)
Your handset is fitted with a loudspeaker to allow other people with
you to listen to the conversation.
During a call, press H.
The sound is amplified through the loudspeaker at the back
of the handset.
You can adjust the sound volume of the loudspeaker
when it is on by pressing +or -.
To turn off the loudspeaker, press Hagain.
1
2
3
1
2
1
2
3

Using your Xalio 11
Setting up Baby Sit (Xalio 6820 & 6850 only)
The Baby Sit function allows you to monitor sounds in another
room (e.g. the baby’s room). Because Baby Sit is a special type of
internal call, it requires two handsets (of type Xalio 6820 or
Xalio 6850): one left in the baby’s room and one you keep with you
(the parent handset).
Setting a handset in Baby Sit mode
In order to use Baby Sit, you must first set the handset to be left in
the room to be monitored (e.g. the baby’s room) in Baby Sit mode.
Press Rto enter menu mode.
Press -until HS SETUP is displayed.
Press ountil INTERCOM is displayed.
Press +or -to select BABY SIT.
Press o.
Your handset beeps to indicate that the setting has been
changed.
Press Rto exit menu mode.
Note:
The handset in Baby Sit mode will not ring but can be used to make
and receive calls.
1
2
3
4
5

Using your Xalio12
Using Baby Sit
Place the handset in Baby Sit mode in the room you
want to monitor (e.g. the baby’s room).
Using the other (parent) handset, press eand the
number of the handset in Baby Sit mode.
Turn on the loudspeaker of the parent handset by
pressing H.
Note:
If you receive an outside call while you are using the Baby Sit
function neither the handset in Baby Sit mode nor the handset you
are using to monitor sounds will ring. However, the base station
will ring and you will hear a call waiting tone on the parent handset.
To take the call, use the parent handset and press ethen tor
press ttwice.
To use Baby Sit again, press t to end your outside call and then
efollowed by the number of the handset in Baby Sit mode.
Transferring calls
You can transfer an outside call from one handset to another
handset subscribed to the same base station.
During the call, press e.
Dial the number of the handset to which you wish to
transfer the call.
Once the other handset answers, you can either:
- Transfer the call by pressing t.
- Switch back and forth between the other
handset and your outside call by using e.
1
2
3
1
2
3

Using your Xalio 13
Switching on the battery saver
Use the battery saver if you want to use the handset away from the
base station or charger for a long period of time (up to a week).
Press the okey for 5 seconds.
Your handset will beep and switch to battery saver mode.
On the 6820, press the akey for more than 1 second.
Note:
In battery saver mode the handset will not ring. However, if
someone calls, the base station will ring.
Switching off the battery saver
•The battery saver will switch off as soon as you press a key.
•If you want to answer a call with a handset in battery saver
mode, simply press the tkey for one second and wait a few
seconds to be connected.
•The battery saver mode will also switch off if you place your
handset on the base station or charger. The handset will start
to recharge if necessary.

Maintenance14
Maintenance
Changing the battery
From time to time, you may need to replace the battery installed on
your handset.
You can obtain a new battery from your Philips dealer.
Warning!
Slide the battery cover down as shown in the
diagram below.
Disconnect the battery.
Put the new battery in place and connect it.
Slide the battery cover back in place until it
clicks into position.
Your handset battery contains cadmium.
Check your local regulations for special disposal
instructions.
1
2
3
4

Maintenance 15
Caring for your handset
To clean your handset or charger, first unplug the mains cable.
Wipe with a cloth or chamois moistened with slightly soapy water,
then with a dry cloth.
Note:
Never spray your handset or charger with cleaning products or
solvents.
Clean the charging contacts on the handset and the charger using
a dry lint-free cloth.
