Philips Leko Lite 11430C Troubleshooting guide

Beam Shutter Operation
CAUTION: When adjusting the luminaire’s beam shutter, it is important to wear protective gloves. The luminaire produces
extreme heat and all surfaces could cause serious burns if touched.
Each LEKO LITE Luminaire is equipped with four
independent shutters (as shown in Figure 6) to block
or shape light as desired. After the luminaire is
installed and positioned, move the shutters in or out
as required.
Gobos
Each LEKO LITE Luminaire is capable of holding two
gobo holders, each containing one "B" sized glass or
steel gobo.
To install or change a gobo:
1. As shown in Figure 7, loosen, but do not
remove, two retaining knobs that secure gobo
access panel. Slide open gobo access panel.
2. Install gobo into gobo holder in desired
orientation.
3. Slide gobo holder into luminaire gobo slot.
4. Close gobo access door. Make sure gobo
holder handle fits inside one of two slots in
gobo access panel.
5. Hand tighten gobo access panel retaining
knobs.
Maintenance & Cleaning
Lenses, reflector, gobos, lamps, etc. should only be
cleaned with isopropyl alcohol and never with any
ammonia-based product. Also, cleaning should only
be done with power completely removed from the
luminaire and the luminaire cool to the touch.
Note: For extremely dirty lenses, a mild soap/detergent and distilled water solution should be used prior to cleaning with
Isopropyl Alcohol. Always use a soft, lint free cloth after blowing away loose particulates with clean, oil-free air.
Strand Lighting Offices:
Strand Lighting - Dallas
10911 Petal Street
Dallas, TX 75238
Tel: [phone]
Fax: [phone]
Strand Lighting Asia Limited
Room 6-10,
20/F Delta House 3 On Yiu Street
Shatin, N.T. Hong Kong
Tel: + 852 2757 3033
Fax: + 852 2757 1767
Strand Selecon - Auckland
19-21 Kawana Street
Northcote, Auckland 0627
New Zealand
Tel: [phone]
Fax: [phone]
Strand Lighting - New York
267 5th Ave, 4th Floor
New York, NY 10016
Tel: [phone]
Fax: [phone]
Strand Lighting - Europe
Marssteden 152
Enschede 7547 TD
The Netherlands
Tel: [phone]
Fax: [phone]
For service and support, please contact your
Authorized Strand Lighting Dealer or the nearest
Strand Lighting office. For the office or dealer
near you, please visit www.strandlighting.com.
Figure 6: Beam Shutters
Beam Shutters
(4 Each)
Front View
See Detail A
Figure 7: Gobo Holder & Access Panel
Retaining Knobs
(2 Each)
Gobo Access Panel
Detail A
Gobo
Area
Gobo Holder
User’s & Installation Guide
IMPORTANT! Retain these instructions for future reference. DO NOT DISCARD!
For use with the following models:
11430C, 15oto 32oVariable Beam Angle LEKO LITE Luminaire
11440C, 23oto 50oVariable Beam Angle LEKO LITE Luminaire
11500C, 5oFixed Beam Angle LEKO LITE Luminaire
11510C, 10oFixed Beam Angle LEKO LITE Luminaire
11520C, 19oFixed Beam Angle LEKO LITE Luminaire
11530C, 26oFixed Beam Angle LEKO LITE Luminaire
11540C, 36oFixed Beam Angle LEKO LITE Luminaire
11550C, 50oFixed Beam Angle LEKO LITE Luminaire
Manual Number: 02.8101.0001 A
LEKO LITE Luminaire User’s & Installation Guide

Important Safeguards
When using electrical equipment, basic safety precautions should always be followed including:
• READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
• Do not use outdoors.
• Do not mount near gas or electric heaters or near flammable materials.
• Do not use this equipment for other than intended use.
• Always follow, local and national safety codes and requirements when using or mounting equipment.
• Refer service to qualified personnel.
Introduction
LEKO LITE Luminaires are designed to conform to the latest safety standards and requirements. The following describes
the safety and operational information on the luminaire’s label.
Figure 1: Luminaire Warning Label
Compliance
All LEKO LITE Luminaires are ETL-listed and conform to all applicable CE requirements. You
should adhere to all local and national safety requirements and codes when mounting and using
the LEKO LITE Luminaire.
© 2010, Philips Group. All rights reserved. The material in this manual is for information purposes only and is subject to change
without notice. Strand Lighting assumes no responsibility for any errors or omissions, which may appear in this manual. Informa-
tion contained in this document may not be duplicated in full or in part by any person without prior written approval of Strand
Lighting. Its sole purpose is to provide the user with detailed installation information for the equipment supplied. The use of this
document for all other purposes is specifically prohibited. Additional information for this and all Strand Lighting products can be
found at www.strandlighting.com.
Luminaire model number and
manufacture date code. For any
warranty service, you must provide the
model number and proof of purchase.
Specifies the minimum distance from the luminaire to a
flammable surface. The top figure is to a surface in the
light beam and the bottom figure to a surface near the
luminaire body.
Tmax specifies the maximum surface
temperature for the luminaire body.
Ta specifies the maximum ambient
operating temperature for the luminaire.
Luminaire operational voltage range.
Do not mount luminaire on, or allow contact
with, flammable materials.
C
Pan and Tilt Adjustment
CAUTION: When adjusting the luminaire’s position, it is important to wear protective gloves. The luminaire produces
extreme heat and all surfaces could cause serious burns if touched.
