Philips BVP525 HGB User manual

BVP525 HGB BVP525 BV BVP515 HGB BVP515 BV
OptiVision LED gen2
Floodlight
BVP525/BVP515
1,25 RG2
1/16
443000017273_B
© 2 / 2016, Philips Lighting Holding B.V. All rights reserved
Printed in Spain
Data subject to change without notice
Keep for future reference: www.philips.com/lighting
HGB 15º 40º BV 15º 40º
BVP525 100000h 757 194000 1471 15° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 757 186000 1392 20° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 757 179000 1314 25° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 757 171000 1236 30° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 757 163000 1160 35° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 757 155000 1082 40° C -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 757 142000 964 45° C -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 757 142000 964 - 35° C -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 757 129000 845 - 45° C -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 740 185000 1471 15° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 740 178000 1392 20° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 740 171000 1314 25° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 740 164000 1236 30° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 740 156000 1160 35° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 740 148000 1082 40° C -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 740 136000 964 45° C -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 740 136000 964 - 35° C -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 100000h 740 124000 845 - 45° C -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 50000h 757 194000 1471 15° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 50000h 757 194000 1471 20° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 50000h 757 194000 1471 25° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 50000h 757 186000 1392 30° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 50000h 757 179000 1314 35° C - -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 50000h 757 171000 1236 40° C -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 50000h 757 163000 1160 45° C -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 50000h 757 163000 1160 - 35° C -40° C 31,5 0,39 0,48 25 0,23 0,32
BVP525 50000h 757 142000 964 - 45° C -40° C 31,5 0,39 0,48 25 0,23 0,32

Any modication on the luminaire will cancel the warranty
Tolerances on weight: +/-10%
Tolerances on light ux: +/- 7%
Tolerances on system power: +/-10%
Tolerances on CCT: +/-400°K
2/16
HGB 15º 40º BV 15º 40º
BVP525 50000h 740 185000 1471 15° C - -40° C 35 0,39 0,48 28 0,23 0,32
BVP525 50000h 740 185000 1471 20° C - -40° C 35 0,39 0,48 28 0,23 0,32
BVP525 50000h 740 185000 1471 25° C - -40° C 35 0,39 0,48 28 0,23 0,32
BVP525 50000h 740 178000 1392 30° C - -40° C 35 0,39 0,48 28 0,23 0,32
BVP525 50000h 740 171000 1314 35° C - -40° C 35 0,39 0,48 28 0,23 0,32
BVP525 50000h 740 164000 1236 40° C -40° C 35 0,39 0,48 28 0,23 0,32
BVP525 50000h 740 156000 1160 45° C -40° C 35 0,39 0,48 28 0,23 0,32
BVP525 50000h 740 156000 1160 - 35° C -40° C 35 0,39 0,48 28 0,23 0,32
BVP525 50000h 740 136000 964 - 45° C -40° C 35 0,39 0,48 28 0,23 0,32
BVP515 100000h 757 129000 981 15° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 757 124000 928 20° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 757 119000 876 25° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 757 114000 824 30° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 757 109000 773 35° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 757 103000 722 40° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 757 95000 643 45° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 757 95000 643 - 35° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 757 86000 564 - 45° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 740 123000 981 15° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 740 119000 928 20° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 740 114000 876 25° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 740 109000 824 30° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 740 104000 773 35° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 740 99000 722 40° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 740 91000 643 45° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 740 91000 643 - 35° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 100000h 740 82000 564 - 45° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 757 129000 981 15° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 757 129000 981 20° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 757 129000 981 25° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 757 124000 928 30° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 757 119000 876 35° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 757 114000 824 40° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 757 109000 773 45° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 757 109000 773 - 35° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 757 95000 643 - 45° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 740 123000 981 15° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 740 123000 981 20° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 740 123000 981 25° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 740 119000 928 30° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 740 114000 876 35° C - -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 740 109000 824 40° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 740 104000 773 45° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 740 104000 773 - 35° C -40° C 29 0,34 0,4 22 0,18 0,24
BVP515 50000h 740 91000 643 - 45° C -40° C 29 0,34 0,4 22 0,18 0,24

BVP525 HGB BVP525 BV
BVP515 HGB BVP515 BV
710
750
616
750
710
616
710
750
616
750
710
616
600
600
130
130
130
130
450
450
BV VERSION
HGB VERSION
BRACKET FIXATION DETAIL
3/16

M20
50
1
2
17
x2
RECOMMENDED WASHER
ACCORDING TO DIN9021
100
In case of using only one xation point
and if the luminaire is higher >3m, the use
of a 2nd xing security system is needed
The fasteners have to resist environment corrosion.
Stainless steel screws not recommended and protective
coating might be applied.
4/16

MAINTENANCE
x2
17 x2
10
3
x2
17
1 2
43
5 6
1
Mark the position with a
pen (to remember the posi-
tion) before untighting the
grub screw and rotate the
luminaire.
Rotate back to the marked
position before tightening
Disconnect from connection
box
Connect the cable of the
module to the connection
box
x4
2
34
H5
2.5
10
5/16

PC
CLEANING TECHNIQUES
OPTICAL COVER
1. Always test the sample with the cleaner and
according to the chosen technique before
2. Do not leave cleaners on plastic parts for a
long period
3. Do not apply cleaners in direct sunlight or at
elevated temperatures
1. Remove physical elements that can block
and modify the aircooling (heatsink ns)
2. Cleaning Frequency (depending on installa-
tion place and environment)
CLEANING PARTS
FORBIDDEN
Abrasive Cleaners
Highly Alkaline Cleaners
Aromatic Solvents
Halogenated Solvents
Brushes
Steel Wood
Squeegess, razorblades
RECOMMENDED
Mild Soap
Lukewarm Water
Soft/Grid free Cloth
Sponge
Water Cleaning
Cleaning Interval
(months)
Pollution Category
High Medium Low
6 0,91 0,92 0,96
12 0,86 0,88 0,94
18 0,83 0,85 0,92
24 0,81 0,83 0,91
36 0,79 0,82 0,9
CLEANING
The list is not exhaustive
OPTIC TYPE
S2 TO S8
LIGHT MODULE LABEL
12 NC: 9123XXXXXXXX
I : 0,8-2,0 A
Tc: 90ºC
OPTIC TYPE
NB/MB/WB/VBW
6/16

ACCESORIES
2,5
(8x) 4x10mm screws
12NC: 912300022867 (ZVP520 L-A90): External zero candela louvre
LOUVRE
PRECISION AIMING DEVICE
12NC: 910503910040
ZVP520 PAD A30 (for A-Optics)
2,5
(8x) 4x10mm screws
12NC: 912300022990 (ZVP520 L-A90): External zero candela louvre
TOP
BOTTOM
12NC: 910503910039
ZVP420 PAD A0 (for S-Optics)
ZVP520 PAD A30 (for A-Optics)
ZVP420 PAD A0 (for S-Optics)
7/16

EVP500
OptiVision LED gen2
Driver box
EVP500
6
145
500
477
129
120
Iin (Mains 230V) 2.5A-6.4A
Iin (Mains 400V) 1.6A-3.7A
Inrush (230V) 18 A during 160 µs
Inrush (400V) 30 A during 160 µs
Power Factor > 0.95 at full power
Surge Protection 10kV Standard
Maximum Heat Disipation* 75W
Driver box Features
* According to the maximum heat disipation, a thermal study should be done for a cabinet installation
8/16

ELECTRICAL CONNECTION (HGB AND BV VERSION)
a
1,6
CONNECTION
BOX DALI
MAINS MAINS CONNECTION
BOX
Cable from Driver box
to Connection Box
MAINS
DALI
Recommended cable diameter DALI: Ø10mm-Ø14mm
Recommended cable diameter MAINS: Ø13mm-Ø18mm
Dmin Dmax TORQUE
(Nm)
M20 (DALI Cable) 10 14 3
M25 (MAINS Cable) 13 18 8
b
9/16

WIRING CONNECTION BOX
Dmin Dmax TORQUE
(Nm)
M20 (Cables to Modules) 10 14 3
M25 (Cable to Driver box) 13 18 8
1,6
BVP515 BVP525
Maximum distance from driver box to luminaire 200m
The cross section rules with regard to voltage drops over
long distances applies and the choice of cable cross-sec-
tion and also cabling way remains under responsibility of
the installer.
This cable has to be suitable for 1000V rated.
Recommended wire section:
• Lenght < 25 m for 7G1,5 mm2 cable
• Lenght < 50m for 7G2,5 mm2 cable
• Lenght < 200m for 8G2,5 mm2 cable
Recommended diameter: Ø13-Ø18
10/16
TOP
Module
BOTTOM
Module
MIDDLE
Module
TOP
Module
BOTTOM
Module
1 2 3456
1 2 3+NTCNTCGND
1 2 3+NTCNTCGND NTCNTC +NTCNTC +
GND

How to connect a cable with length between 50m and 200m
50m<L<200m
3 pole connector (1 pole in 2 pole out, not supplied by Philips ), to be installed inside the driver box
11/16

TEMPERATURES
ORIENTATION DISTANCES
A temperature sensor must be installed inside the cabinet between two driver boxes.
The temperature measured by the sensor has to be lower than 45°C.
We recommend a cabinet protected against solar action.
MAXIMUM Relative Humidity:
95% -> Storage & Transport
90% -> Operating (no condensation allowed)
The distances between driver box-
es or wall have to be higher than:
Each driver box in the
cabinet has to be in
vertical position
Item Distance
1, 3 Min 50mm
2 Min 80mm
4 Min 150mm
5 Min 200mm
Cabinet
5
4
2
3
1
Installation of drivers boxes on cabinet
An active cooling can be added in the cabinet to guarantee a maximum temperature of
45°C all along the year
Cables
12/16

Installation of driver boxes in the mast
minimum width of the door: 125mm
minimum height of the door: 600mm
30
Depending of the driver xation in the mast, please select the
most suitable hook.
5
13/16

Installation of driver boxes on the bracket or in horizontal position
TOP
BOTTOM
Breathers cannot be exposed directly to water
14/16

BVP525 Mains voltage Max Nr luminaires
connected
MCB 16A A type 230V 1
MCB 16A B type 230V 1
MCB 32A A type 230V 3
MCB 32A B type 230V 3
MCB 16A A type 400V 3
MCB 16A B type 400V 3
BVP515 Mains voltage Max Nr luminaires
connected
MCB 16A A type 230V 2
MCB 16A B type 230V 2
MCB 32A A type 230V 5
MCB 32A B type 230V 5
MCB 16A A type 400V 5
MCB 16A B type 400V 5
Maximum number of luminaires to be connected to standard circuit breakers (fuse)
15/16

© 2016 Philips Lighng Holding B.V.
All rights reserved Reproducon in whole or in part is prohibited without consent of the copyright owner
The informaon presented in ths document does not form part of any quotaon or contract is believed to be accurate and
reliable and may be changed without noce. No liability will be accepted by the publisher for any consequence of its use
Publicaon thereof does not convey nor imply any license under patent or other industrial or intellectual property rights
Philips Lighng Holding B.V.
The Netherlands
16/16
