Foxfury Lighting Solutions TAKER B30 User manual

PRODUCT MANUAL
480-331
TAKERTAKER B30

INTRODUCTION
Taker B30 Reference Guide 3
Physical Characteristics & Warnings 4
BATTERY
Battery Installation and Replacement 5
Battery Life 6
OPERATION
Operational Modes 6
FEATURES
Kill Switch 7
Pressure Switch 7
Dual Settings 8
Heavy Duty Braided Cable 8
Replaceable Lens 8
Retrofit 8
INSTALLATION
Shield Installation 9
WARRANTY 10–11
CONTACT FOXFURY 11
TABLE OF CONTENTS

3
TAKER B30 REFERENCE GUIDE
SHIELD LIGHT
REPLACEABLE
LENS
BATTERY PACK
(FRONT SIDE - PLACED AGAINST SHIELD)
CONNECTING THE BATTERY PACK
LED (3)
3M RECLOSABLE
FASTENER
POWER/KILL
SWITCH
CABLE
ENTRY
LOCATION
BATTERY
COVER TABS (2)
PRESSURE SWITCH
CONNECTOR
PRESSURE
SWITCH
LIGHT HEAD
CONNECTOR

4
PHYSICAL CHARACTERISTICS
Please read below before using the Taker B30 as it relays beneficial operating
and safety information.
SHIELD LIGHT (P/N 480-331)
DIMENSIONS
(LxWxH)
Light Head: 3.9 x 0.9 x 2.0 in (100 x 23 x 50 mm)
Battery Pack: 5.3 x 1.2 x 2.2 in (135 x 31 x 56 mm)
WEIGHT 9.2 oz (261 g)
WARNINGS
Do not stare into LEDs for long periods of time or from a close range, less
than 2 ft / 0.6 m.
FoxFury’s Turbo-Strobe™is purposely designed to induce disorientation.
Prolonged viewing may produce vertigo or even vomiting.
INCLUDED
(6) 3M Reclosable Fastener, 2” width, P/N 51-030
(8) Shield Light Cable Clips, P/N 61-041
Black Cable Sleeve (installed), P/N 51-035
Pressure Switch (installed), P/N 35-002

5
BATTERY INSTALLATION AND REPLACEMENT
Unlock both two (2) of the Battery Cover Tabs.
Insert two (2) 18650, four (4) CR123, or four (4) RCR123 batteries.
Reference the plus (+) and minus (-) symbols located on the ridge of the
Battery Pack for proper installation. (Image shown above is with two
18650 batteries.)
Once batteries are installed, test the light’s performance by activating the
Power/Mode Switch. If the light does not turn on, push the POWER/KILL
SWITCH once and try again. If the light still does not turn on, please make
sure that the batteries are inserted correctly
Secure the Battery Cover by snapping both (2) Battery Cover Tabs. A
‘click’ should be heard as the snaps are shut.
NOTE: Make sure the Battery Cover is properly closed to maintain a
water tight seal.
BATTERIES
The Taker B30 uses two (2) 18650, four (4) CR123, or four (4) RCR123.
Do not mix used and new batteries, different battery brands, or different
types of batteries as this could damage your product or cause battery
leakage or explosion.
1
2
3
4
1 2
–+
+
–

6
BATTERY LIFE*
MODE CR123 18650 LUMENS
MOMENTARY 2.5 hours 4 hours
600CONTINUOUS ON 2.5 hours 4 hours
TURBO-STROBE™ 4 hours 6.5 hours
*Battery life may vary according to mode selected, battery quality and prevailing ambient conditions.
For MOMENTARY mode: Press and hold the Power/Mode Switch. While
the Switch is depressed, the light will operate continuously. When the user
removes pressure from the Switch, the light will turn OFF.
For CONTINUOUS ON mode: Press the Power/Mode Switch two (2)
times in rapid succession. The light will remain ON.
For TURBO-STROBE™: Press the Power/Mode Switch three (3) times in
rapid succession.
For OFF: Press the Power/Mode Switch once. Then, continue following
the directions above to progress to desired mode.
NOTE: The light does not retain the mode in memory. Once you turn the light
ON, you will have to re-select the mode you desire. To change Mode Settings,
see under “DUAL SETTINGS” in the FEATURES, page 8.
OPERATIONAL MODES

7
FEATURES
POWER/KILL SWITCH
The Taker B30 has a Power/Kill Switch located on the BOTTOM of the
Battery Pack. This mechanism is used to shut down or disable the shield light.
PRESSURE SWITCH (INCLUDED)
The Taker B30 includes a Pressure Switch that allows the user to place
it anywhere on the shield. This makes it easier to access the Power/Mode
Switch. The Pressure Switch can easily be attached to the shield via Velcro®or
glue.
To connect the Pressure Switch Connector to the Pressure Switch,
simply confirm alignment, insert the connector, and tighten the Screw
Cap.
To connect the Light Head Connector to the Light Head, simply confirm
alignment, insert the connector, and tighten the Screw Cap.
POWER/KILL
SWITCH
PRESSURE SWITCH
CONNECTOR
LIGHT HEAD
CO
NNE
C
TOR
PRESSURE
SWITCH
PRESSURE SWITCH
CONNECTOR
LIGHT HEAD
CONNECTOR

8
FEATURES (CONT’D)FEATURES (CONT’D)
DUAL SETTINGS
The Taker B30 includes two mode settings: the ON/OFF SETTING and the
TACTICAL SETTING. The ON/OFF SETTING simply allows the Light Head
to turn ON and OFF. The TACTICAL SETTING allows you to choose from
three (3) different Operational Modes: Momentary, Continuous On, and Turbo-
Strobe™. The Taker B30 comes in the TACTICAL SETTING.
To change from the TACTICAL SETTING to the ON/OFF SETTING:
With the light turned OFF, press the Power/Mode Switch twice in rapid
succession and hold for 10 seconds. The light should begin to flash. Once
it begins flashing, it is now in the ON/OFF SETTING.
To change from the ON/OFF SETTING to the TACTICAL SETTING:
With the light turned OFF, press and hold the Power/Mode Switch for 10
seconds. The light should begin to go through a slow Turbo-Strobe™ cycle
and then turn OFF. It is now in the TACTICAL SETTING.
REPLACEABLE LENS
The LEDs of the B30 are protected by a lens that can easily be replaced if it
were to be damaged.
HEAVY DUTY BRAIDED CABLE
The cable of the B30 is made of steel that protects the internal wiring. The
installed Black Cable Sleeve (P/N 51-035) helps to protect the steel cable while
providing a black covering.
RETROFIT
The B30 can retrofit to most ballistic shields without drilling or permanent
modification.

9
1. Clean the surface of the shield where the Battery Pack and Light Head
will be placed.
2. Remove the protective plastic from the back of the provided 3M
Reclosable Fastener (P/N 51-030). Place it on the front of the Battery
Pack (see p. 3). Then, place the Battery Pack onto the back of the
shield (at desired location) and firmly press down. Ensure the strips are
perpendicular to each other to prevent detachment.
3. Remove the protective plastic from the other piece of the Reclosable
Fastener and place it on the back of the Light Head. Then, place the Light
Head onto the front of the shield (at desired location) and firmly press
down.
It is recommended that the Light Head is placed on the “upper-center”
portion of the front of the shield, but it can be placed anywhere.
The Battery Pack should be placed on the back of the shield. It can
be placed anywhere as long as it is on the back of the shield.
Using the Shield Light Cable Clips (P/N 61-041) can help to secure the
Braided Cable of the Light Head.
NOTE: The Pressure Switch also has a provided Reclosable Fastener that
allows the user to place it in desired location.
SHIELD INSTALLATION
1
2
3
LIGHT HEAD
BALLISTIC
SHIELD
Place the shield in
between the battery
pack and Light
Head. (The shield
pictured is cut in
half for this visual)
CABLE
BATTERY PACK
PRESSURE SWITCH

10
WARRANTY AND OTHER
INFORMATION
being used by a minor.
Any FoxFury product should be
operated at speeds safe enough
to maneuver around surrounding
obstacles.
Do not use under the influence
of drugs or alcohol.
LIMITED LIFETIME
WARRANTY
FoxFury, LLC (“FoxFury”) warrants
this product to be free from defects
in material for a lifetime of use except
for batteries, LEDs, abuse, and
normal wear. We will repair or replace
this product should we determine it
to be defective. This limited lifetime
warranty excludes rechargeable
batteries, chargers, switches, and
electronics, which have a 2-year
warranty with proof of purchase.
This limited lifetime warranty is
given only to the original end user of
the accompanying product. If you
purchased a product from someone
other than an authorized FoxFury
reseller/distributor or if the product
was used, (including but not limited
to demo models, show models or
refurbished product by someone
other than FoxFury) prior to your
purchase, you are not the Original
Purchaser and the product that you
purchased is not covered by this
warranty. This limited warranty is
VOID if this Product has been altered
or modified in any way (including but
not limited to attempted warranty
repair without authorization from
FoxFury and/or alteration/removal
of the serial number). To expedite
warranty concerns, we encourage
PRODUCT DURABILITY
CARE/CLEANING
Your FoxFury product is a professional
tool. Regular maintenance and care of
your light will maximize performance for
you. As needed, wash your FoxFury
product using a soft washcloth, clean
water and a mild soap. Be sure that all
parts are reassembled securely before
washing. When done, pat dry with a
damp cloth.
AVAILABLE ACCESSORIES
Black Cable Sleeve (2),
P/N 51-035
Square Pressure Switch,
P/N 35-009-1
Pressure Switch, P/N 35-002
Shield Light Cable Organizer Box,
P/N 85-030
WARNINGS
FoxFury, LLC is not responsible for the
incorrect use of any FoxFury Lighting
product.
When used for extended periods of
time the light will become HOT to
the touch. Please use care when
operating.
Lights are strong enough to cause
damage to the human eye.
Do not stare into LEDs for long
periods of time or from a close
range (less than 2 ft / 0.6 m).
FoxFury, LLC is not responsible
for any injury or damage caused
during the use of this product.
Usage of this product must be
supervised by an adult when it is

11
the end user to register their FoxFury
Product at www.foxfury.com/pages/
warranty-registration.
THIS IS THE ONLY WARRANTY,
EXPRESSED OR IMPLIED,
INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
INCIDENTAL, CONSEQUENTIAL
OR SPECIAL DAMAGES ARE
EXPRESSLY DISCLAIMED EXCEPT
WHERE SUCH LIMITATION IS
PROHIBITED BY LAW.
You may have other specific legal
rights which vary by jurisdiction. Go
to www.foxfury.com/pages/warranty
for a complete copy of the warranty.
Retain your receipt for proof of
purchase.
CONTACT FOXFURY
FoxFury, LLC
Oceanside, CA 92056 USA
Toll-Free: 844-FOXFURY
Te l : 760.945.4231
Fax: [phone]
Email: [e-mail]
Web: FoxFury.com
All FoxFury products are designed in
Oceanside, CA. All FoxFury products
are manufactured with the highest
quality USA and foreign parts.
Products are assembled in either
FoxFury’s controlled plant in Asia or
the USA, under strict quality control.
CALIFORNIA PROPOSITION
65
This product can expose you to
chemicals including Lead and DEHP,
which are known to the State of
California to cause cancer and birth
defects or other reproductive harm.
For more information go to www.
P65Warnings.ca.gov.

FOXFURY.COM 12/2021
