Philips HMP7100 User manual

www.philips.com/welcome
User manual
Always there to help you
Register your product and get support at
Question?
Contact
Philips
Question?
Contact
Philips
HMP7100

1EN

2EN
SOURCE
TV
HDMI IN
AV
HDMI 1
HDMI 2
HDMI 3
Side HDMI
Side AV
HDMI
AC IN
Press to switch on.The
power indicator lights up
white.
Press again to switch off.
The power indicator lights
up red.
On the remote control of
the TV, use the source button
to select the HDMI input
connector of HMP7100.
Switch on

3EN
WWW
HDMI
The network wizard helps
you to connect the device
to the internet.
Please select the type of
network setup
Cancel
Wired (Ethernet)
Wireless (Wi-Fi)
Select the type of
Wi-Fi connection.
Cancel
Wi-Fi Protected Setup (WPS)
Scan
3,13%&6WDQGDUG
www.
.com
.net
.org +
ௗၿ
$%& DEF #
SPACE
.!@
DONE
Setup: Connect to your home network
On the screen of initial setup, select
[Wireless (Wi-Fi)]. Select [Scan] to
search for networks in range. Select a
network. Follow onscreen instructions
to complete Wi-Fi connection.
• Ifyouselect[Standard], enter the
password to your network.
On the remote control, press
to select an input mode.To enter
text, press to select
a key on the onscreen keyboard.
To complete text entry, select
DONE on the onscreen keyboard.
Connect through Wi-Fi

4EN
The network wizard helps
you to connect the device
to the internet.
Please select the type of
network setup
Cancel
Wired (Ethernet)
Wireless (Wi-Fi)
WWW
Setup: Connect to your home network
On the screen of initial setup, select Wired
(Ethernet).
Connect through an Ethernet cable

5EN
HDMI
6PDUW79+RPHQHWZRUN86%
6HWXS
HDMI
6PDUW79+RPHQHWZRUN86%
6HWXS
SmartTV: Play from online services
Next time you switch
on HMP7100, HMP7100
connects to the previously
connected network. On
the Home screen,
changes to . Select .
Play from a USB storage device
From the Home screen, select .

6EN
6PDUW79+RPHQHWZRUN86%
6HWXS
Play from a PC
1 Connect your PC to the same network as HMP7100.
2 On HMP7100, select .
PC that runs the software of
DLNA media server

7EN
SimplyShare
SimplyShare
HDMI
MyRemote
SimplyShare: Play from an iOS or Philips Android
device
Make sure that you
have connected
your iOS or Philips
Android device to
the same network as
HMP7100.
From App Store
or Google Play,
download the Philips
MyRemote app to
your device.

8EN
SimplyShare: Play from an iOS or Philips Android
device
In MyRemote,
select SimplyShare.
Select the source
of media, and then,
selectamediale
to start play.
To use your iOS or
Android device as
remote control, select
Control.

9EN
Contents
1 Trademark notice 11
2 Safety and notice 12
Safety 12
Compliance 14
Copyright 15
Care of the environment 15
Warranty 16
3 Basics 17
Connect 17
Switch on or off 17
Use the remote control 19
Enter text 20
4 First-time setup 21
Connect to your home network 21
5 Play 25
Play from online services 25
Play from your home network 27
Play from a USB storage device 31

10 EN
6 Setup 33
Video 34
Audio 34
Network 35
Preference 35
Advanced 35
7 EasyLink 36
8 UpdatethermwareofHMP7100 37
Updatethermwareonline 37
UpdatethermwarethroughaUSBstoragedevice 38
9 Troubleshooting 39
10Specication 40
11 Written Offer 41

11EN
1 Trademark notice
ThetermsHDMIandHDMIHigh-DenitionMultimediaInterface,andtheHDMI
Logo are trademarks or registered trademarks of HDMI Licensing LLC in the
United States and other countries.
DivX®,DivXCertied®,DivXPlus®HDandassociatedlogosaretrademarksof
Rovi Corporation or its subsidiaries and are used under license.
ABOUT DIVX PLUS® HD: DivX® is a digital video format created by DivX, Inc.
ThisisanofcialDivXCertied®devicethatplaysDivXvideo,includingDivX®
Plus HD video (H.264/.MKV) up to 1080p and premium content.Visit www.divx.
comformoreinformationandsoftwaretoolstoconvertyourlesintoDivX
video.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a
subsidiaryofRoviCorporation.ThisisanofcialDivXCertied®devicethatplays
DivX video.Visit divx.com for more information and software tools to convert
yourlesintoDivXvideos.
ABOUTDIVXVIDEO-ON-DEMAND:ThisDivXCertied®devicemustbe
registered in order to play purchased DivXVideo-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX VOD section in your device
setup menu. Go to vod.divx.com for more information on how to complete your
registration.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
®

12 EN
Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535
& other U.S. and worldwide patents issued & pending. DTS, the Symbol, & DTS
and the Symbol together are registered trademarks & DTS 2.0+Digital Out is a
trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.
2 Safety and notice
Read and understand all instructions before you use this product. If damage is
caused by failure to follow the instructions, the warranty does not apply.
Safety
Important notes for users in the U.K.
Mains fuse
This information applies only to products with a UK mains plug.
Thisproductisttedwithanapprovednon-moldedplug.Ifyoureplacethefuse,
use one with:
• the ratings shown on the plug,
• a BS 1362 approval, and
• the ASTA approval mark.
Contact your dealer if you are not sure about what type of fuse to use.
Caution:To conform with the EMC directive (2004/108/EC), do not detach the
plug from the power cord.
How to connect a plug

13EN
The wires in the power cord are colored as follows: blue = neutral (N), brown =
live (L).
If the colors do not correspond with the colors on your plug, identify the terminals
in your plug as follows:
1 Connect the blue wire to the terminal marked N or colored black.
2 Connect the brown wire to the terminal marked L or colored red.
3 Do not connect either wire to the earth terminal in the plug, marked E (or
e) or colored green (or green and yellow).
Before you replace the plug cover, make sure that the cord grip is clamped over
the sheath of the cable and not just over the two wires in the cable.
This 'bolt of lightning' indicates uninsulated material within the device may cause
an electrical shock. For the safety of everyone in your household, please do not
remove the covering.
The 'exclamation mark' calls attention to features for which you should read the
enclosed literature closely to prevent operating and maintenance problems.
WARNING:Toreducetheriskofreorelectricshock,thedeviceshouldnotbe
exposedtorainormoistureandobjectslledwithliquids,suchasvases,should
not be placed on the device.
CAUTION:To prevent electric shock, fully insert the plug. (For regions with
polarized plugs:To prevent electric shock, match wide blade to wide slot.)
• Onlyuseattachments/accessoriesspeciedbythemanufacturer.
• Use only power supplies listed in the user manual.
• The product shall not be exposed to dripping or splashing.
• Donotplaceanysourcesofdangerontheproduct(e.g.liquidlledobjects,
lighted candles).
• Batteries (battery pack or batteries installed) shall not be exposed to
excessiveheatsuchassunshine,reorthelike.
• Danger of explosion if battery is incorrectly replaced. Replace only with the
sameorequivalenttype.

14 EN
ModicationoftheproductcouldresultinhazardousradiationofEMCor
other unsafe operation.
Warning
•Never remove the casing of this product.
•Never lubricate any part of this product.
•Neverplacethisproductonotherelectricalequipment.
•Keepthisproductawayfromdirectsunlight,nakedamesorheat.
•Ensure that you always have easy access to the power cord, plug or adaptor to disconnect the
product from the power.
•Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect
device shall remain readily operable.
Compliance
ThisproductcomplieswiththeradiointerferencerequirementsoftheEuropean
Community.
Thisproductcomplieswiththerequirementofthe1999/5/ECdirective.
Class II equipment symbol:
CLASS II apparatus with double insulation, and no protective earth provided.
Anychangesormodicationsmadetothisproductthatarenotexpressly
approved by Philips Consumer Lifestyle may void the user’s authority to operate
the equipment.
0700

15EN
Note
•The type plate is located on the bottom of the product.
Copyright
This item incorporates copy protection technology that is protected by U.S.
patents and other intellectual property rights of Rovi Corporation. Reverse
engineering and disassembly are prohibited.
Copyright in the U.K.
• Recordingandplaybackofmaterialmayrequireconsent.SeeCopyrightAct
1956 and The Performer’s Protection Acts 1958 to 1972.
Specicationsaresubjecttochangewithoutnotice.Trademarksaretheproperty
of Koninklijke Philips Electronics N.V or their respective owners. Philips reserves
the right to change products at any time without being obliged to adjust earlier
supplies accordingly.
Care of the environment
Environmental information
All unnecessary packaging has been omitted.We have tried to make the packaging
easy to separate into three materials: cardboard (box), polystyrene foam (buffer)
and polyethylene (bags, protective foam sheet.)
Your system consists of materials which can be recycled and reused if
disassembled by a specialized company. Please observe the local regulations
regardingthedisposalofpackagingmaterials,andoldequipment.

16 EN
Yourproductisdesignedandmanufacturedwithhighqualitymaterialsand
components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a product it means that
the product is covered by the European Directive 2002/96/EC.
Please inform yourself about the local separate collection system for electrical and
electronic products.
Please act according to your local rules and do not dispose of your old products
with your normal household waste. Correct disposal of your old product helps to
preventpotentialnegativeconsequencesfortheenvironmentandhumanhealth.
Your product contains batteries covered by the European Directive 2006/66/EC,
which cannot be disposed with normal household waste.Please inform yourself
about the local rules on separate collection of batteries because correct disposal
helpstopreventnegativeconsequencesfortheenvironmentalandhumanhealth.
Warranty
• Never attempt to repair the product, this could lead to the risk of injury,
damage to the product and will void your warranty.
• Use the product and accessories only as intended by the manufacturer.The
caution sign printed on the back of the product indicates risk of electric
shock.
• Never remove the cover of the product. Always contact Philips Customer
Support for service or repairs.
• Any operation expressly prohibited in this manual, or any adjustments and
assembly procedures not recommended or authorized in this manual shall
void the warranty.

17EN
3 Basics
Connect
a HDMI connector for audio/ video output
• Connectstoahigh-denitionTV(HDTV)throughanHDMIcable
b Power connector
• Connects to power supply through the AC power cord
For high quality audio
• Through OPTICAL,useaberopticalcabletoconnectHMP7100 to the
OPTICAL or SPDIF input connector on an audio/video system.
Switch on or off
1 On HMP7100, press on the remote control to switch on.
» The power indicator lights up white.
a
b
HDMI IN
HDMI
AC IN

18 EN
2 On the TV, switch to the input source of HMP7100:
• On the remote control of your TV, use the source button to select the
input connector of HMP7100.
3 To switch HMP7100 to standby mode, press again on the remote control.
» The power indicator lights up red.
Auto standby
From the Home screen, switch on [Auto standby ]in [Setup] > [Preference ].
If there is no button press or media play on HMP7100 for 30 minutes, HMP7100
switches to standby mode automatically.
Screen saver
From the Home screen, go to [Setup] > [Preference ] to switch on [Screen
saver].
If there is no button press or media play on HMP7100 for 10 minutes, the screen
saver is activated.To exit the screen saver, press any button on the remote control.
SOURCE
TV
AV
HDMI 1
HDMI 2
HDMI 3
Side HDMI
Side AV
