Philips SBM155 User manual

www.philips.com/welcome
User manual
Always there to help you
Register your product and get support at
SBM155
Question?
Contact
Philips
Question?
Contact
Philips

1EN
Contents
1 Important 2
2 Your Portable Speaker 3
Introduction 3
What's in the box 3
Overview of the speaker 4
3 Get started 5
Power supply 5
Turn on/off 5
Select a source 5
4 Play 6
Play from Micro SD card 6
Play from USB device 6
Control play 6
Play from an external device 7
5 Other features 8
Amplify your sound 8
Record 8
Adjust volume 8
6 Product information 9
Specications 9
USB playability information 9
7 Troubleshooting 10
8 Notice 11
Disposal of your old product and
batteries 11

2EN
1 Important
• Read these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or
otherapparatus(includingampliers)that
produce heat.
• Onlyuseattachments/accessoriesspecied
by the manufacturer.
• Referallservicingtoqualiedservice
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
• The battery shall not be exposed to
excessiveheatsuchassunshine,reorthe
like.
• Apparatus shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on the
apparatus(e.g.liquidlledobjects,lighted
candles).
Caution
•Removal of the built-in battery invalidates the warranty
and may destroy the product.
Always bring your product to a professional to
remove the built-in battery.

3EN
2 Your Portable
Speaker
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this speaker, you can:
• enjoy audio from Micro SD card, USB
devices, and other external devices;
• amplify your voice by speaking or singing
with the microphone; and
• record your voice or audio from USB
devices/external audio device to SD card.
What's in the box
Check and identify the contents of your
package:
• Main unit X 1
• USB cable X 1
• Aux-in cable X 1
• Microphone X 1
• Shoulder strap X 1
• Short user manual X 1

4EN
Overview of the speaker
a VOL/ON/ OFF
• Turn the speaker on or off.
• Adjust volume.
b Source selector
• Select SD, USB or AUX source.
c Display panel
d
• Microphone input jack.
e AUX
• Audio input connector for an external
audio device.
f
• USB socket for a USB storage device.
g MICRO SD
• Micro SD card slot.
h Battery indicator
i DC 5V
• Power socket for charging.
a
b
c
d
e
m
l
k
j
i
h
g
f
j MIC
• Adjust the sound effect of the
microphone.
k
• Start or pause play.
• Enable folder selection.
l /
• Select a track or folder.
• Search within play.
m REC
• Start or stop recording.
• Listen to the recorded sound.

5EN
3 Get started
Always follow the instructions in this chapter in
sequence.
Power supply
Caution
•Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
•Risk of damage to the speaker. Charge through the USB
socket of a computer only.
The speaker is powered by the built-in
rechargeable battery.
Note
•The battery indicator blinks when the battery power
is low.
To recharge the built-in battery:
Connect the supplied USB cable to:
• the DC 5V socket on the speaker.
• the USB socket on a computer.
» The speaker is powered off
automatically and the battery indicator
lights up.
» When the battery is fully charged, the
battery indicator light turns off.
Turn on/off
1 Rotate the VOL knob clockwise to turn on
the speaker.
» The speaker switches to the last
selected source.
2 Rotate the VOL knob anticlockwise to turn
off the speaker.
Select a source
Adjust the source slider to select a source: SD,
USB or AUX.

6EN
4 Play
Play from Micro SD card
Note
•Make sure that the Micro SD card contains playable
audio content.
1 Insert a Micro SD card into the card slot.
2 Adjust the source slider to select the SD
source.
» [SD] displays on the panel.
» Play starts automatically.
Note
•Due to different materials and product techniques, it
cannot be guaranteed that all Micro SD cards work
with this speaker.
Play from USB device
Note
•Make sure that the USB storage device contains
playable audio content.
•Do not charge any other external device through this
speaker.
1 Insert the USB device into the socket.
2 Adjust the source slider to select the USB
source.
» [USB] displays on the panel.
» Play starts automatically.
Control play
In USB or Micro SD mode, you can control play
through the following operations.
/ Selectanaudiole;
Press and hold to fast-forward
or fast-reverse the track during
playback, then release to resume
play.
Start or pause play.
If the USB device or Micro SD card contains
several folders, you can select a folder to play
music.
1 Press and hold for 2 seconds.
» The current folder [F X] (X stands for
thefoldernumber)isdisplayed.
2 Press / repeatedly to select a folder.
» Thersttrackinthefolderisplayed
automatically.
Note
•All the root directories and sub-folders can be selected
to play music.

7EN
Play from an external device
With this speaker, you can also enjoy audio
from an external device such as an MP3 player.
1 Adjust the source slider to select the AUX
source.
2 Connect the supplied Aux-in cable to:
• the AUX socket on the speaker.
• the headphone socket on an external
device.
3 Play audio on the device (see the user
manualofthedevice).

8EN
5 Other features
Amplify your sound
1 Connect the supplied microphone to the
socket.
2 Speak or sing through the microphone.
• To adjust the volume of the sound,
rotate the VOL knob.
• To adjust the volume of the
microphone, rotate the MIC knob.
Note
•Make sure that the microphone core aims towards
your mouth.
Record
Note
•In SD card mode, the speaker can only record sound
from mic.
•In USB/AUX mode, the speaker can record sound from
mic and USB/AUX.
Record audio from microphone
1 Insert a Micro SD card into the card slot.
2 Connect the supplied microphone to the
jack.
3 Press REC to start recording.
» [REC] displays on the panel.
4 Speak or sing to the microphone.
5 Press REC again to stop recording.
» The recorded sound is saved as wav.
formatleintheconnectedMicroSD
card.
6 Press and hold REC for 2 seconds to play
the recorded sound.
• Press REC again to stop playing.
Record audio from a USB device/an
external audio device
1 Insert a Micro SD card and connect a USB
device/an external audio device.
2 Select USB/AUX source and play the
audio to record from.
3 Press REC to start recording.
» [REC] displays on the panel.
4 Press REC again to stop recording.
» The recorded sound is saved as wav.
formatleintheconnectedMicroSD
card.
5 Press and hold REC for 2 seconds to play
the recorded sound.
• Press REC again to stop playing.
Note
•Donotchangethesavedlename/foldername,
otherwise,theaudiolecannotbeplayed.
•Amaximumof999audiolescanbesavedintheSD
card.
Adjust volume
During play, rotate VOL to adjust volume.

9EN
6 Product
information
Note
•Product information is subject to change without prior
notice.
Specications
Amplier
Max Output Power 1.5 W
Signal to Noise Ratio 50 dBA
Aux Input 800mV RMS, 22
kohm
General information
Power Supply 5V 0.6A
Built-in Battery Ni-MH battery
Micro SD card Compatibility: SDHC
2.0(upto32GB)
Dimensions - Main Unit
(WxHxD)
90 x 131 x 52 mm
Weight - Main Unit 0.34 kg
USB playability information
Compatible USB devices:
• USBashmemory(USB1.1)
• USBashplayers(USB1.1)
• memory cards (requires an additional
card reader to work with this unit;
Some multi-card USB reader may not
besupported.)
Supported formats:
• USBormemoryleformat:FAT12,
FAT16,FAT32(sectorsize:512bytes)
• MP3bitrate(datarate):32-320Kbps
and variable bit rate
• Directory nesting up to a maximum of
8 levels
• Number of albums/ folders: maximum
99
• Number of tracks/titles: maximum 999
• File name in Unicode UTF8 (maximum
length:16bytes)
Unsupported formats:
• Empty albums: an empty album is an
album that does not contain MP3/
WMAles,andisnotbeshowninthe
display.
• Unsupportedleformatsareskipped.
Forexample,Worddocuments(.doc)
orMP3leswithextension.dlfare
ignored and not played.
• AAC,WAV,PCMaudioles
• DRMprotectedWMAles(.wav,.m4a,
.m4p,.mp4,.aac)
• WMAlesinLosslessformat

10 EN
7 Troubleshooting
Warning
•Never remove the casing of this product.
To keep the warranty valid, never try to repair
the product yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Web page (www.philips.
com/support).Whenyoucontactthe
Consumer Care, make sure that the product
is nearby and the model number and serial
number are available.
No power
• Recharge the battery.
No sound
•Adjust volume.
•Check if you have selected the correct
audio source.
No response from the speaker
•Turn on the speaker.
•Recharge the battery.
Cannot record your voice
•DeletelesintheVOICEfolderoftheSD
card.
•Replace with a new SD card.
The speaker turns off automatically when
plugging in the microphone
•Recharge the battery.
USB device not supported
•The USB device is incompatible with the
unit.Try another one.

11EN
8 Notice
Anychangesormodicationsmadetothis
device that are not expressly approved by
WOOX Innovations may void the user’s
authority to operate the equipment.
Disposal of your old product
and batteries
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products and batteries.
The correct disposal of these products helps
prevent potentially negative consequences on
the environment and human health.
Your product contains batteries, which cannot
be disposed of with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries.The correct
disposal of batteries helps prevent potentially
negative consequences on the environment and
human health.
Please visit www.recycle.philips.com for
additional information on a recycling center in
your area.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separateintothreematerials:cardboard(box),
polystyrenefoam(buffer)andpolyethylene
(bags,protectivefoamsheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
Note
•The type plate is located on the back of the apparatus.

2013 © WOOX Innovations Limited.All rights reserved.
Philips and the Philips’ Shield Emblem are registered trademarks of
Koninklijke Philips N.V. and are used by WOOX Innovations Limited
under license from Koninklijke Philips N.V. SBM155_UM_93_V1.0 wk1337.5
