Philips CDR776C User manual

Dual deck CD-Recorder CDR 776C
• Two separate CD decks (Recording and playback)
• Double speed & Listen mode recording (disc)
• 2-disc simultaneously playback / 2-disc random playback
• Separate outputs for CDR and CD (digital/analogue)
• 3x CD text features (recording,input & editing for max.60 characters)
• CD deck plays unfinalised RW discs
• AD - DA convertor UDA1341TS (CODEC)
• Sample Rate Conversion (12-56 kHz)
• Direct Line Recording (DLR)
• Records HD-CD format (Via DLR only)
• Analogue + digital (separate channel) record level control (64 steps)
• Continuous calibration (Running OPC)
• Max.99-track program on both CDR and CD deck
• CD Synchronised auto start recording from
all analogue and digital sources (disc)
• Text scrolling
• Standby (via RC) + hard on/off
• Music calendar
• Easy jog (Menu controlled user interface)
• High quality starbust FTD (display)
• Auto (un) finalise
• Erasing per track,selection of last tracks & whole disc
(takes max.2 min.)
• Introscan
• Tray blocking (dealer function)
• Gold plated headphone connection
• Remote control
Audio CD-Recorder
CDR776C
Opm leaflets 26/4/99 2:14 pm Page 11

Audio CD-Recorder
CDR776C
Theproductsandservicesdescribedherearenotnecessarilytobecomeavailableinthemarket.Thisdocumentcontainspreliminaryinformation. Due to continuous improvements this specification is subject to changes without notice. Printed in the Netherlands.2/99
700+ series CD player
Technical Specifications CDR 775C
General
• System Compact disc digitalAudio
(Dual deck CD-recorder + CD-player)
• Number of channels 2 (stereo)
• Applicable supply Multi voltage 100V - 240V 50-60 Hz (/00 only) 117V (/17)
• Power consumption 19W (<=6W in standby)
• Operating temperature 5-35°C
• Weight 4 kg
• Dimensions 435 x 305 x 88 mm (w x d x h)
Audio
• Digital frequency range 2 Hz - 22,05 kHz
• Playback S/N (CDR &CD) 100 dB (A-weighted)
• Playback dynamic range (CDR &CD) 95 dB 90 dB
• Play back total harmonic distortion
+ Noise (CDR &CD) 88 dB (0,0039%) & 85 dB (0,0056%)
• Recording S/N (Analogue) 98 dB (A-weighted)
• Recording S/N (Digital) Recording quality equal to Source
• Recording dynamic range 92 dB
• Recording total harmonic distortion 85 dB (0,0079%)
• Headphones 3Vrms / 8-2000Ω
Output
• 1xAnalogue line output CDR (+ CD) 2Vrms +/- 2 dB / 0.2 kΩ
• 1xAnalogue line output CD 2Vrms +/- 2 dB / 0.2 kΩ
• 1x Digital coaxial output CDR (+CD) 0.5V(pp) / 75Ω
• 1x Digital coaxial output CD 0.5V(pp) / 75Ω
Input (level adjustment)
• Direct line recording (bypass SRC) for 44.1 kHz +/- 100 ppm
• 1x Digital coaxial input (SRC) 12 - 56 kHz / 0.5Vrms / 75Ω
• 1x Digital optical input (SRC) 12 - 56 kHz
• 1xAnalogue input 500 mVrms / 50 kΩ= 0 dB
Recording functions
• Recording on CD-R & CD-RW disc
• Records from all home stereo analogue and digital sources
• Recording from internal & external source
• Single & double speed recording (disc,track)
• Auto start recording
• Multi track erase (CD-RW disc)
• Soft mute insert function
• Erase disc (CD-RW disc)
• Auto finalise / unfinalise disc (CD-RW disc)
• Manual /Auto track increment
• Remaining recording time display
• Double speed finalising (make disc compatible to CD-player)
• SCMS (Serial Copy management system)
• Auto switch over to analogue recording in case
of copy protected track or disc.
• RID code (Recorder Unique identifier)
Playback functions
• Plays allAudio CD’s
(120 mm + 80 mm discs)
• Simultaneously playback
(recorder + player)
• Introscan - Pause - Stop
• Random playback from 2 discs
• Direct track selection
• Track selection with easy jog
• Search forward / reverse
• Repeat (all / per track)
• Program play (99 tracks)
• Time display switching
• Permanent text option
Accessories
• Remote control (+batteries)
• Audio cable (x2)
• Digital coaxial cable (x1)
• AC mains cord
DISPLAY SCROLL DJ MODE
REPEATSHUFFLE
PROG
Recordable
IR SENSOR
OPEN / CLOSE
REC
TYPE REC START
OPEN / CLOSE PLAY/ PAUSE STOP
ENTER
PLAY/ PAUSE STOP FINALIZE ERASE SOURCE
CDR CD
PHONES
AUDIO CD RECORDABLE/REWRITABLE
CDR 775AUDIO CD RECORDER
AUDIO CD PLAYBACK
CANCEL/
DELETE
STORE/
MENU
EASY JOG
ON/OFF
TRACK
REC
DIGITAL PROG
SHUFFLE
REPEAT
II
CD
RW
CHANGER
SYNC MANUAL RECORD
TRACK
FADE
CD
R
123456789 10 11 12 13 14 15 16 17 18 19 20 +
DOUBLE SPEED
SCAN
ABC
13
2
46
5
79
8
GHI
DEF
JKL OPQ
MN
RST XYZ
UVW
0
SPACE
ENTER CANCEL
TRACK INCR.
MENU/
STORE
PROG.
CDR CD
SCROLL
SHUFFLE REPEAT
