Philips Lightolier Controls CLMIR User manual

ROGRAMMING AND
OERATION INSTRUCTIONS
HANDHELD INFRARED TRANSMITTER - CLMIR
IM ORTANT: RETAIN THESE INSTRUCTIONS FOR THE END USER. DO NOT DISCARD.
CLMIR
HANDHELD INFRARED TRANSMITTER
Made in U.S.A. Technical/Sales assistance: 1-800-526-2731 /N 85-6348A0
Lightolier Controls is a Philips Controls brand

CLMIR - HANDHELD INFRARED TRANSMITTER Programming and Operation
Instructions
The CLMIR Handheld Infrared Transmitter is capable of
operating over an unobstructed range of approximately 75 feet.
Within this range, scenes can be selected, raised and lowered,
and lighting may be turned On and Off using the handheld,
wireless remote transmitter. In addition, the CLMIR is capable
of controlling up to four different Brilliance II, MultiSet ro,
Compose LC or Lytemode control station groups.
Description
Programming:
The wall keypad must be enabled to receive the IR signal before the sensor will work. To enable
the keypad, perform the following sequence of keystrokes on the keypad. The Handheld Infrared
Transmitter is already configured to control up to four different keypad addresses (rooms).
1. On the wall keypad, press and hold the A and D buttons
for three seconds. The A, B, C, D and OFF keys will
illuminate with one of them blinking. (The keypad may
be custom engraved to change the labels.) Button A
refers to the keypad being configured as Room 1, B to
Room 2, C to Room 3, and D to Room 4. If OFF is
blinking, the infrared receiver is disabled. Refer to the
drawing at right. The factory default is Room 1 (A).
2. ress the desired Room Number or OFF. This will con-
figure the keypad as that room or disable infrared
input. The selection will blink.
3. ress ON to save and exit.
Operation:
Use the CLMIR unit to remotely operate the corresponding con-
trol station.
NOTE: This system is based on line-of-sight operations, therefore, the receiver must be able to
“See” the transmitter. Any obstruction between the transmitter and receiver may adversely affect
the performance of the unit.
Programming and Operation
A
ON
C
B
D
OFF
Ellipse Series
Wall Keypad
The CLMIR Handheld Infrared Transmitter is powered by two
AAA batteries (included).
1. Remove CLMIR unit and two AAA batteries from clam shell
package.
2. Install batteries in CLMIR unit and close compartment.
3. roceed to rogramming and Operation section.
Unpack Procedure
Lightolier Controls is a Philips Controls brand
Lightolier Controls
2828 Trade Center Drive, Suite 130B
Carrollton, Texas 75007
Technical/Sales assistance: 1-800-526-2731
Made in U.S.A. ©2008 hilips Controls.
www.lolcontrols.com /N 85-6348A0
