Today, outdoor lighting is expected to do much more than simply enable us to
see at night. Lighting has also become an essential tool that is widely used to
create a more welcoming environment. Outdoor lighting, therefore now has
both functional and decorative roles to play. In addition, the wide choice of
lamps available means that there are many outdoor lighting solutions for each
application area.
The best choice will depend on your needs, which can be cost of ownership,
ambience or environment. Our lamps aim to meet some or all of these values. It
provides a reference guide to the light properties of the full range of Philips
lamps for outdoor lighting, and also indicates the application areas for which
their benets are most applicable.
Road and tunnel lighting
Improves traffic safety for everyone on the road, and at the same time provides guidance
and orientation.. Here, the requirement is for lighting that is both functional and economical,
combining optimum safety with the lowest costs of ownership. Lamps must have good lighting
performance and energy efficiency, and every lamp must have a long lifetime. Reliability is
essential, as traffic congestion during spot replacement of premature failures can be very
expensive.
The recommended HID families that anticipate upon these lamp specifications are
MASTER SON PIA, MASTER SOX and Ceramic Metal Halide.
Urban lighting
Covers streets, parks and squares, shopping and leisure areas in city centers and can serve
a decorative as well as an amenity role. In addition to safety and orientation, it is capable of
providing comfort, ambience, identity and even spectacle, helping to create a new and beautiful
nightscape for residents and visitors alike.The primary requirement is good light quality,
expressed by the color rendering index and color temperature of the lamp.The choice of
lighting for residential areas, once made solely on functional criteria, is increasingly influenced by
a perceived need for improved amenity, and improved vision for safety.As a result, high-quality
white light is now making an appearance. Because traffic speeds are relatively low, security
and comfort for pedestrians and cyclists are as important a requirement as road lighting for
motorised traffic.
The ultimate HID choice is MASTER Cosmo White & MASTER City White, next
to MASTER SON PIA in case functional requirements prevail.

3.4 OEM Catalogue 2009/2010

HID Lamps
HID Lamps
3.5OEM Catalogue 2009/2010
Urban architectural lighting of buildings, bridges, statues and gardens can also help to create a
nightscape even more striking than the same area as seen by day.
Today’s architectural lighting does not necessarily involve high light levels but models
architectural features with color and shade. High light quality and even colored right sources
are appropriate in this application.
Compact HID lamps (Master Colour CDM & CDM Elite) next to Master SON &
Master HPI are most suitable for this application area.
Sports lighting
Increases revenue by extending the activities of a sports club into the hours of darkness.
Special care is needed with lighting design to avoid light entering players’ eyes directly, wherever
they may be in the playing area, and also to avoid light pollution in residential areas. In local
recreational facilities and small clubs, the requirements are for functional lighting at low
initial and running costs. Each lighting point should therefore provide high light output with a
reasonable colour quality, and the lamps should have a long lifetime.As well as careful design to
avoid glare and light spill, professional sports lighting must cater for the needs of colour TV
coverage and photography.This requires extremely high light levels – three times those used in
commercial offices – and superb colour rendering. Because of the limited burning period, lamp
lifetime is a less important consideration than reliability.
Dedicated lamps for these applications are the MASTER MHN-FC for recreational
and MASTER MHN LA & SA for professional sports.
Area lighting
Covers a range of applications, industrial areas, transport and parking facilities, services and
care institutes, etc. It has gained in importance with the appearance of large industrial estates
outside or at the edges of urban areas. Its role is to provide orientation and safe working
conditions in the hours of darkness as well as by day. Area lighting must be, functional,
economical and reliable, and provide glare-free illumination without causing light pollution to
the surrounding environment. Parking areas and loading and unloading zones often require
better colour rendering than the other areas. High light levels with a good efficacy and
reasonable colour rendering, together with a long service lifetime are usually the key criteria in
area lighting.
Recommended high power lamps are Quartz Metal Halide (MASTER HPI &
MASTER MHN) as well as MASTER SON PIA

OEM Catalogue 2009/20103.6
MASTER MHN-SA
MHN-SA X830R
Product Description
● Compact quartz metal halide lamps with double-pinch
Product Features
● Very compact source (Short Arc) with high luminous efficacy and
superior colour rendering
● Double-pinch concept results in long lifetime
● Natural white colour appearance, high colour rendering and good
colour stability
● Daylight colour temperature eases transition from daylight to
artificial lighting
Product Benefits
● Allows compact and very efficient luminaire systems with high
precision optics for good beam control and minimal spill light
● Very good colour rendering creates a pleasant ambience with high
visual comfort for players and spectators
● Continuous spectral distribution offers a superior solution for
(semi-) professional stadiums with regular TV coverage
Application
● Professional sports lighting and floodlighting
Luminaires
● MHN-SA lamps require UV-absorbing and protective front glass and
correct thermal behaviour for optimal lamp performance
Environment
● This product is RoHS compliant
● This product is covered by WEEE
Recommended gear page 3.170
www.philips.com/OEM
C
O
D
MHN-SA (P)SFC
Type CMax DMax ONom
MASTER MHN-SA 1800W/956 (P)SFC 230V UNP 364 41 25

OEM Catalogue 2009/2010 3.7
HID Lamps
MASTER MHN-SA
X
D
O
A
C
MHN-SA XW
Type ANom CMax DMax ONom XNom
MASTER MHN-SA XW UNP 318 369 41 25 25
MHN-SA (P)SFC
Technical data
Type Lamp
Current
EM
(A)
Lamp
Wattage
EM
(W)
Lamp
Voltage
(V)
Voltage
(V)
Rated
Lamp
Wattage
Dimmable Ignition
Supply
Voltage
(V)
Life to
50%
failures
(hrs)
MASTER MHN-SA 1800W/856/956 230V XW/(P)SFC UNP 17.3 1800.0 120 230 1800 No 198 5000
MASTER MHN-SA 1800W/956 (P)SFC 400V UNP 10.5 1850.0 205 400 1800 No 342 5000
MASTER MHN-SA 2000W/956 400V XW UNP 11.3 2040.0 205 400 2000 No 360 5000
Light data
Type Luminous
Flux Lamp
EM
(lm)
Luminous
Efficacy
Lamp EM
(lm/W)
Colour
Designation
Colour
Temperature
(K)
Colour
Rendering
Index
(Ra)
Chromaticity
Coordinate X
Chromaticity
Coordinate Y
Operating
Position
MASTER MHN-SA 1800W/856 230V XW UNP 170000 95 Daylight 5600 85 330 360 p15
MASTER MHN-SA 1800W/956 230V XW/(P)SFC UNP 155000 86 Daylight 5600 90 330 339 p15
MASTER MHN-SA 1800W/956 (P)SFC 400V UNP 160000 86 Daylight 5600 90 330 339 p15
MASTER MHN-SA 2000W/956 400V XW UNP 200000 98 Daylight 5600 90 330 362 p15
Ordering and packing data
Type ILCOS EAN code
1 piece
Weight Qty bulk
packing
Dimensions bulk packing EAN code
bulk packing
EOC
8711500
MASTER MHN-SA 1800W/856 230V XW UNP MN-1800-H-X830R-/H 8711500202680 0.107 kg 1 43 cm x 9.5 cm x 8.5 cm 8711500202680 202680 00
MASTER MHN-SA 1800W/956 230V XW UNP MN-1800-H-X830R-/H 8711500201065 0.107 kg 1 43 cm x 9.5 cm x 8.5 cm 8711500201065 201065 00
MASTER MHN-SA 1800W/956 (P)SFC 230V UNP MN-1800-H-PSFc20=6-/H 8711500200754 0.219 kg 1 43 cm x 9.5 cm x 8.5 cm 8711500200754 200754 00
MASTER MHN-SA 1800W/956 (P)SFC 400V UNP MN-1800-E-PSFc20=6-/H 8711500200761 0.22 kg 1 43 cm x 9.5 cm x 8.5 cm 8711500200761 200761 00
MASTER MHN-SA 2000W/956 400V XW UNP MN-2000-E-X830R-/H 8711500200792 0.107 kg 1 43 cm x 9.5 cm x 8.5 cm 8711500200792 200792 00

OEM Catalogue 2009/20103.8
MASTER MHN-SA
Spectral power distribution
W/nm
2
4
6
8
10
400 500 600 700
[nm]
MHN-SA 1800W 230V
2
4
6
8
10
400 500 600 700
[nm]
W/nm
MHN-SA 1800W /956 400V
4
8
12
16
20
400 500 600 700
[nm]
W/nm
MHN-SA 2000W /956 400V
Performance diagram
%
t
0
40
80
120
160
200
51 2 3 4
Ila
Wla

Vla
MHN-SA
Lamp performance during run up
Lumen maintenance diagram
50
60
70
80
90
100
4000
Lumen in %
Burning hours
1000 3000
02000
5000
MHN-SA 1800W /856/956 230V/400V
50
60
70
80
90
100
4000
Lumen in %
Burning hours
1000 3000
02000
5000
MHN-SA 2000W /956 400V

OEM Catalogue 2009/2010 3.9
HID Lamps
Life expectancy diagram
50
60
70
80
90
100
4000
Survivals in %
Burning hours
1000 3000
02000
5000
MHN-SA 1800W /856/956 230V/400V
MASTER MHN-SA
50
60
70
80
90
100
4000
Survivals in %
Burning hours
1000 3000
02000
5000
MHN-SA 2000W /956 400V
Cap Base
18
(P)SFC
Operating position
p15

OEM Catalogue 2009/20103.10
MASTER MHN-LA
MHN-LA 2000W
Product Description
● Compact quartz metal halide lamps with double-pinch
Product Features
● Compact source (Long Arc) with high luminous efficacy
● Double-pinch concept results in long lifetime
● Natural white colour appearance, high colour rendering and good
colour stability
● Daylight colour temperature eases transition from daylight to
artificial lighting
Product Benefits
● Allows compact and efficient luminaire systems with precision optics
for good beam control and minimal spill light
● Good colour rendering creates a pleasant ambience with high visual
comfort for players and spectators
● Continuous spectral distribution offers options for semi-professional
stadiums and for professional stadiums with regular TV coverage
Application
● Professional and semi-professional sports lighting and floodlighting
Luminaires
● MHN-LA lamps require UV-absorbing and protective front glass and
correct thermal behaviour for optimal lamp performance
Environment
● This product is RoHS compliant.
● This product is covered by WEEE
Recommended gear page 3.170
www.philips.com/OEM
D
X
A
O
MHN-LA
Type ANom DMax ONom XNom
MASTER MHN-LA 1000W/842/956 230V XWH UNP 294 40 40.5 35
MASTER MHN-LA 2000W/842/956 400V XWH UNP 364 40 108 58

OEM Catalogue 2009/2010 3.11
HID Lamps
MASTER MHN-LA
MHN-LA 1000W
Technical data
Type Lamp
Current
EM
(A)
Lamp
Wattage
EM
(W)
Lamp
Voltage
(V)
Voltage
(V)
Rated
Lamp
Wattage
Dimmable Ignition
Supply
Voltage
(V)
Life to
50%
failures
(hrs)
MASTER MHN-LA 1000W/842 230V XWH UNP 9.3 1040.0 125 230 1000 No 198 10000
MASTER MHN-LA 2000W/842 400V XWH UNP 9.6 2040.0 235 400 2000 No 342 12000
MASTER MHN-LA 2000W/956 400V XWH UNP 10.3 2040.0 225 400 2000 No 342 12000
Light data
Type Luminous
Flux Lamp
EM
(lm)
Luminous
Efficacy
Lamp EM
(lm/W)
Colour
Designation
Colour
Temperature
(K)
Colour
Rendering
Index
(Ra)
Chromaticity
Coordinate X
Chromaticity
Coordinate Y
Operating
Position
MASTER MHN-LA 1000W/842 230V XWH UNP 100000 96.2 Cool White 4200 80 370 370 p5
MASTER MHN-LA 1000W/956 230V XWH UNP 90000 86.5 Daylight 5600 90 330 339 p5
MASTER MHN-LA 2000W/842 400V XWH UNP 220000 108 Cool White 4200 80 370 370 p5
MASTER MHN-LA 2000W/956 400V XWH UNP 190000 93 Daylight 5600 90 330 339 p5
Ordering and packing data
Type ILCOS EAN code
1 piece
Weight Qty bulk
packing
Dimensions bulk packing EAN code
bulk packing
EOC
8711500
MASTER MHN-LA 1000W/842 230V XWH UNP MN-1000-E-K-/H 8711500200785 0.141 kg 1 43 cm x 9.5 cm x 8.5 cm 8711500200785 200785 00
MASTER MHN-LA 1000W/956 230V XWH UNP MN-1000-E-K-/H 8711500200778 0.137 kg 1 43 cm x 9.5 cm x 8.5 cm 8711500200778 200778 00
MASTER MHN-LA 2000W/842 400V XWH UNP MN-2000-E-K-/H 8711500200747 0.172 kg 1 43 cm x 9.5 cm x 8.5 cm 8711500200747 200747 00
MASTER MHN-LA 2000W/956 400V XWH UNP MN-2000-E-K-/H 8711500200730 0.168 kg 1 43 cm x 9.5 cm x 8.5 cm 8711500200730 200730 00
Spectral power distribution
2
4
6
8
10
400 500 600 700
[nm]
W/nm
MHN-LA 1000W /842 230V
2
4
6
8
10
400 500 600 700
[nm]
W/nm
MHN-LA 1000W /956 230V

OEM Catalogue 2009/20103.12
MASTER MHN-LA
5
10
15
20
25
400 500 600 700
[nm]
W/nm
MHN-LA 2000W /842 400V
4
8
12
16
20
400 500 600 700
[nm]
W/nm
MHN-LA 2000W /956 400V
Performance diagram
%
t
0
40
80
120
160
200
102 4 6 8
Ila
Wla
Vla 
MHN-LA
Lamp performance during run up
Lumen maintenance diagram
50
60
70
80
90
100
8000
Lumen in %
Burning hours
2000 6000
04000
10000
MHN-LA 1000W /842/956 230V
50
60
70
80
90
100
Lumen in %
Burning hours
3000 9000
06000
12000
MHN-LA 2000W /842/956 400V
Life expectancy diagram
50
60
70
80
90
100
8000
Survivals in %
Burning hours
2000 6000
04000
10000
MHN-LA 1000W /842/956 230V
50
60
70
80
90
100
Survivals in %
Burning hours
3000 9000
06000
12000
MHN-LA 2000W /842/956 400V
Operating position
p5

OEM Catalogue 2009/2010 3.13
HID Lamps
MASTER MHN-LA

OEM Catalogue 2009/20103.14
MHN-SB
MHN-SB
Product Description
● Compact quartz metal halide lamp with single pinch
Product Features
● Compact source (Short Base lamp dimensions) with short electrode
distance and high luminous efficacy
● Single pinch concept with long lifetime
● Natural white colour appearance, good colour rendering and
stability
● Daylight colour temperature eases transition from daylight to
artificial lighting
Product Benefits
● Allows compact and efficient luminaire systems with precision optics
for good beam control and minimal light spill
● Long lifetime and high reliability in Short Base outer dimensions to
minimise service needs and maintenance costs
● Good colour rendering for a pleasant ambience with high visual
comfort
Application
● Semi-professional sports, area and floodlighting
Luminaires
● Requires UV-absorbing and protective front glass
● Correct thermal conditions are required for optimal lamp
performance
Recommended gear page 3.170
www.philips.com/OEM
D
O
A
C
X
MHN-SB
Type ANom CMin DMax ONom XNom
MHN-SB 2000W/956 400V K12s-7 WH UNP 157 187 41 25 50

OEM Catalogue 2009/2010 3.15
HID Lamps
MHN-SB
Technical data
Type Lamp
Current
EM
(A)
Lamp
Wattage
EM
(W)
Lamp
Voltage
(V)
Voltage
(V)
Rated
Lamp
Wattage
Dimmable Ignition
Supply
Voltage
(V)
Life to
50%
failures
(hrs)
MHN-SB 2000W/956 400V K12s-7 WH UNP 11.5 2040 205 400 2000 No 360 -
Light data
Type Luminous
Flux Lamp
EM
(lm)
Luminous
Efficacy
Lamp EM
(lm/W)
Colour
Designation
Colour
Temperature
(K)
Colour
Rendering
Index
(Ra)
Chromaticity
Coordinate X
Chromaticity
Coordinate Y
Operating
Position
MHN-SB 2000W/956 400V K12s-7 WH UNP 200000 100 Daylight 5600 90 325 355 p15
Ordering and packing data
Type ILCOS EAN code
1 piece
Weight Qty bulk
packing
Dimensions bulk packing EAN code
bulk packing
EOC
8711500
MHN-SB 2000W/956 400V K12s-7 WH UNP MN-2000-E-Cable-/H 8711500206732 0.08 kg 8711500206732 43 cm x 9.5 cm x 8.5 cm 8711500206732 206732 00
Spectral power distribution
4
8
12
16
20
400 500 600 700
[nm]
W/nm
MHN-SB 2000W /956
Performance diagram
%
t
0
40
80
120
160
200
51 2 3 4
Ila
Wla

Vla
MHN-SB
Lamp performance during run up
Lumen maintenance diagram
50
60
70
80
90
100
4000
Lumen in %
Burning hours
1000 3000
02000
5000
MHN-SB 2000W /956
Life expectancy diagram
50
60
70
80
90
100
4000
Survivals in %
Burning hours
1000 3000
02000
5000
MHN-SB 2000W /956
Operating position
p15

OEM Catalogue 2009/20103.16
HPI-T
HPI-T 2000W
Product Description
● Quartz metal halide lamps with clear outer bulb
Product Features
● Clear tubular outer bulb
● Unique 3-band technology resulting in high luminous efficacy, both
initially and over long lifetime
● Renders a natural white colour appearance and good colour stability
Product Benefits
● High safety and comfort level, maintained over life
● Minimal maintenance cost
Application
● Sports lighting, floodlighting of buildings and monuments, area
lighting e.g. harbours and building sites
Luminaires
● HPI-T lamps require a protective front glass
Recommended gear page 3.170
www.philips.com/OEM
D
L
C
O
HPI-T 1000W
Type CMax DMax LNom ONom
HPI-T 1000W/643 E40 220V CRP 382 66 240 80

OEM Catalogue 2009/2010 3.17
HID Lamps
HPI-T
D
L
C
O
HPI-T 2000W
Type CMax DMax LNom ONom
HPI-T 2000W/642 E40 380V CRP 430 101.5 267 120
HPI-T 2000W/646 E40 220V CRP 430 101.5 290 89
HPI-T 1000W
Technical data
Type Lamp
Current
EM
(A)
Lamp
Wattage
EM
(W)
Lamp
Voltage
(V)
Voltage
(V)
Rated
Lamp
Wattage
Dimmable Ignition
Peak
Voltage
(V)
Ignition
Supply
Voltage
(V)
Life to
50%
failures
(hrs)
HPI-T 1000W/643 E40 220V CRP 8.25 985.0 130 220 1000 No 5000 198 12000
HPI-T 2000W/642 E40 380V CRP 9.1 1955 232 380 2000 No 5000 342 12000
HPI-T 2000W/646 E40 220V CRP 16.5 1960.0 130 220 2000 No 5000 198 12000
Light data
Type Luminous
Flux Lamp
EM
(lm)
Luminous
Efficacy
Lamp EM
(lm/W)
Colour
Designation
Colour
Temperature
(K)
Colour
Rendering
Index
(Ra)
Chromaticity
Coordinate X
Chromaticity
Coordinate Y
Operating
Position
HPI-T 1000W/643 E40 220V CRP 85000 86 Cool White 4300 65 370 380 p20
HPI-T 2000W/642 E40 380V CRP 210000 107 Cool White 3800 65 397 403 p20
HPI-T 2000W/646 E40 220V CRP 189000 96 Cool White 4200 65 375 385 p75
Ordering and packing data
Type ILCOS EAN code
1 piece
Weight Qty bulk
packing
Dimensions bulk packing EAN code
bulk packing
EOC
8711500
HPI-T 1000W/643 E40 220V CRP MT-1000/43/2B-H-E40-/H 8711500183736 0.433 kg 4 18.6 cm x 18.6 cm x 42.6 cm 8711500183743 183736 45
HPI-T 2000W/642 E40 380V CRP MT-2000/42/2B-H-E40-/H 8711500202352 0.616 kg 4 27.3 cm x 25.3 cm x 47.6 cm 8711500202369 202352 45
HPI-T 2000W/646 E40 220V CRP MT-2000/46/2B-H-E40-/H 8711500183767 0.603 kg 4 27.3 cm x 25.3 cm x 47.3 cm 8711500183774 183767 45

OEM Catalogue 2009/20103.18
HPI-T
CRV diagram
HPI-T 1000W
a*
b*
HPI-T 1000W/2000W
Performance diagram
%
t
0
40
80
120
160
200
51 2 3 4
Ila
Wla
Vla

HPI-T
Lamp performance during run up
Lumen maintenance diagram
50
60
70
80
90
100
8000
Lumen in %
Burning hours
2000 6000
04000
10000
HPI-T 1000W/2000W /643/646
50
60
70
80
90
100
8000
Lumen in %
Burning hours
2000 6000
04000
10000
HPI-T 2000W /642
Life expectancy diagram
50
60
70
80
90
100
8000
Survivals in %
Burning hours
2000 6000
04000
10000
HPI-T 1000W/2000W /643/646
50
60
70
80
90
100
8000
Survivals in %
Burning hours
2000 6000
04000
10000
HPI-T 2000W /642
Cap Base
40
E40
Operating position
p20 p75

OEM Catalogue 2009/2010 3.19
HID Lamps
HPI-T

OEM Catalogue 2009/20103.20
MASTER HPI-T Plus
HPI-T
Product Description
● Quartz metal halide lamps with clear outer bulb
Product Features
● Clear tubular outer bulb
● Unique 3-band technology resulting in high luminous efficacy, both
initially and over long lifetime
● Renders a natural white colour appearance and good colour stability
Product Benefits
● High safety and comfort level, maintained over life
● Minimal maintenance cost
● Initial investment saving options with “Plus”-concept
Application
● Sports lighting. floodlighting of buildings and monuments, area
lighting e.g. harbours and building sites, canopy lighting e.g. petrol
stations, horticultural lighting
Luminaires
● HPI-T Plus lamps require a protective front glass
System
● Can be run on HPI-gear as well as on SON-gear (“Plus”-concept).
The results in both light output and colour temperature are
different
Environment
● Good environmental choice because of long service life
● This product is RoHS compliant
● This product is covered by WEEE
Recommended gear page 3.170
www.philips.com/OEM
D
L
C
O
HPI-T
Type CMax DMax LNom ONom
MASTER HPI-T Plus 250W/645 E40 SLV 255 46.5 158 29
MASTER HPI-T Plus 400W/645 E40 SLV 286 46.5 180 40
