XitaniumTM LED Drivers
Optimal operation of LuxeonTM high power
LEDs for indoor and outdoor applications
• Enjoy more design freedom
• Increase safety and reliability
Industrial bank, Moscow.
Staircase lighting by Art.
Décor International, Belgium.
a Philips original

Original thinking
In the past 10 years dramatic progress has been made in
LED technology – especially the colour range, luminous efficacy, and light
output.This has created new opportunities for lighting designers in all
kinds of applications ranging from retail to orientation and emergency
lighting to signage. At the forefront of this progress is Philips Lighting.
In 1999 our joint venture with Agilent Technologies, Lumileds, launched
the world’s first commercially available high output LED: the Luxeon
range.This has been continually improved and is now at the heart of
Philips LED Module and Component Systems. In parallel, Philips has
developed the Xitanium range of LED Drivers - optimized for use with
the Luxeon LEDs.Take a look at how you can benefit:
With an output of 60W of red
Luxeons the chimneys of
Technopolis, Athens, Greece,
are visible from 1 kilometer.
Lighting by Philips Luminaires.
Wetherspoon pub Durham, UK.
Sign by Pearce Signs.
What is a Xitanium™ LED Driver?
Indoor OutdoorIndoor Outdoor
Xitanium LED Drivers from Philips are designed specifically to power Luxeon high power LEDs. Philips has used its extensive expertise in
electronics to ensure that Driver and LED are perfectly ‘fine-tuned’ to each other, and that the exceptionally steady DC output enhances the long
life and optimum operation the high power LEDs.
Outdoor

New design opportunities
The Xitanium’s small, compact size enables you
to innovate with new, low-profile fixture designs.
Hazard-free
All the major safety requirements (as defined in
CE, ENEC, KEMA, and UL) are met, so you can
install them in practically any location.
Excellent reliability
Xitanium LED Drivers last up to 50,000 hours, to
take advantage of the long life of LEDs.They come
with the Philips electronic ballast guarantee.
Wide choice
Extensive product portfolio gives you a wide
choice. Portfolio consist of in- and outdoor types
with power ratings from 12 to 80W, including a
25W for dimming possibilities.
Improved safety
Xitanium LED Drivers generate a limited output
voltage and current and also provide isolation for
safe operation.
Low-temperature performance (-40°C)
So you can be confident in any outdoor
application.
Universality
Although optimized for high power Luxeon LEDs,
the Xitanium range of Drivers is also suitable for
other LED based systems.
Typical applications include:
• Channel letter/contour lighting
• Architectural lighting
• Retail/theme lighting
• Orientation lighting (path lighting)
• Entertainment lighting
• Emergency and security
Sohar, Dubai.
Lighting by Philips Luminaires.
The bridge over the river Clyde in Glasgow, Scotland.
Lighting by Philips Luminaires.
• The LED Module System: lighting
blocks which can be joined in flexible
‘domino-like’ arrays to produce
creative luminaires and displays.
• LED String: a wire connected string of
LEDs for safer, more energy efficient
signs and architectural effects.
Xitanium Drivers perfectly operate the Philips LED-based systems including: Also Xitanium Drivers are optimized for use with all Luxeon LEDs
• Luxeon LEDs from the Lumileds Lighting company are state-of-
the-art solid-state lighting devices – the brightest LEDs on the
market in a very compact package. Ideal for high-lumen,
general lighting.

System overview
Note: for more detailed information on LED Drivers, LED Modules and LED String ask for specific product data sheets.
Xitanium™ is a registered trademark of Philips Electronics NV.
Luxeon™ is a registered trademark of Lumileds.
For more information:
Philips Lighting BV
Mathildelaan 1
5611 BD Eindhoven
Tel.: [phone]
Fax.: [phone]
Data subject to change. Printed in the Netherlands. 3222 635 49891 * NOV 2004
Input Output
Specifications
Ordering Information
12W indoor 207 - 264 15.0 0.14 12.0 350 +/- 5% 2.6 - 33.0 85
17W indoor 207 - 264 21.5 0.20 17.1 700 +/- 5% 2.6 - 24.6 85
25W indoor 207 - 264 31.9 0.30 25.5 1050 +/- 5% 2.6 - 24.6 85
25W DIM indoor 207 - 264 31.9 0.30 25.5 1050 +/- 5% 14 - 24.0 85
40W indoor 207 - 264 51.0 0.47 40.8 1750 +/- 5% 2.6 - 24.0 85
12W outdoor 207 - 264 15.0 0.14 12.0 350 +/- 5% 2.6 - 33.0 90
17W outdoor 207 - 264 21.5 0.20 17.1 700 +/- 5% 2.6 - 24.6 90
40W outdoor 207 - 264 51.0 0.47 40.8 1750 +/- 5% 2.6 - 24.0 50
67W outdoor 207 - 264 80.0 0.40 67.2 2800 +/- 5% 2.6 - 25.0 90
80W outdoor 207 - 264 95.0 0.50 80.0 3300 +/- 5% 2.6 - 25.0 90
Description
LED Driver Voltage
V
Max. power
W
Max. current
A
Max. power
W
Current
A
Voltage
V
Tc max.
12W indoor 10 749963 30
17W indoor 10 749987 30
25W indoor 12 927361 30
25W DIM indoor 12 927408 30
40W indoor 12 927385 30
Description LED Driver Box
packaging
EOC
12W outdoor 10 930453 30
17W outdoor 10 930958 30
40W outdoor 3 931221 30
67W outdoor 20 931207 30
80W oudoor 20 931245 30
Description LED Driver Box
packaging
EOC
Quick selection table
Description Configuration options
12W 350mA - 1-8 one-watt Luxeons
- max. 3.2m Philips LED String Red & Amber
- max. 3.5m Philips LED String Blue & Green
17W 700mA - 6, 8, 10 or 12 one-watt Luxeons
- 6-up and 12-up Luxeon lines, rings or arrays
- 1-5 three-watt Luxeons
- 1-3 five-watt Luxeons
- max. 5.0m Philips LED String Red & Amber
- max. 4.2m Philips LED String Blue & Green
- 1-10 Philips LED Modules
Description Configuration options
25W 1050mA - 3, 6, 9, 12, 15 or 18 one-watt Luxeons
(indoor only) - 18-up Luxeon array
- 1-5 three-watt at 1.0A Luxeons
25W 1050mA - 15 or 18 one-watt Luxeons
Dimming
(indoor only)
40W 1750mA - 5, 10, 15, 20, 25 or 30 one-watt Luxeons
- Philips LED String White max. 4.0m
- 1-24 Philips LED Modules
67W 2800mA - 8, 16, 24, 32, 40 or 48 one-watt Luxeons
(outdoor only) - 4, 8, 12, 16 or 20 three-watt Luxeons
80W 3150mA - 9, 18, 27, 36, 45 or 54 one-watt Luxeons
(outdoor only) - 5, 10, 15 or 25 three-watt Luxeons
