Phoenix Contact PSR-TRISAFE-S User manual

INTERFACE
UM EN PSR-TRISAFE-S
Order No. —
User Manual
Device description, configuration, and startup of
the PSR-TRISAFE-S safety module

Designation:
Revision:
Order No.:
This user manual is valid for:
INTERFACE
103503_en_03 PHOENIX CONTACT
2011-06-22
Device description, configuration, and startup of the
PSR-TRISAFE-S safety module
UM EN PSR-TRISAFE-S
03
—
Designation Order No.
PSR-TRISAFE-S
PSR-SCP-24DC/TS/S
PSR-SPP-24DC/TS/S
2986229
2986232
User Manual

PSR-TRISAFE-S
PHOENIX CONTACT 103503_en_03
Please observe the following notes
In order to ensure the safe use of the product described, you have to read and understand
this manual. The following notes provide information on how to use this manual.
User group of this manual
The use of products described in this manual is oriented exclusively to
– qualified electricians or persons instructed by them, who are familiar with applicable
standards and other regulations regarding electrical engineering and, in particular, the
relevant safety concepts.
– qualified application programmers and software engineers, who are familiar with the
safety concepts of automation technology and applicable standards.
Phoenix Contact accepts no liability for erroneous handling or damage to products from
Phoenix Contact or third-party products resulting from disregard of information contained in
this manual.
Explanation of symbols used and signal words
The following types of messages provide information about possible property damage and
general information concerning proper operation and ease-of-use.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible
injury or death.
DANGER
This indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING
This indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION
This indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
NOTE
This symbol and the accompanying text alerts the reader to a situation which may cause
damage or malfunction to the device, either hardware or software, or surrounding
property.
This symbol and the accompanying text provides additional information to the reader. It is
also used as a reference to other sources of information (manuals, data sheets, literature)
on the subject matter, product, etc.

PSR-TRISAFE-S
103503_en_03 PHOENIX CONTACT
General terms and conditions of use for technical documentation
Phoenix Contact reserves the right to alter, correct, and/or improve the technical
documentation and the products described in the technical documentation at its own
discretion and without giving prior notice, insofar as this is reasonable for the user. The
same applies to any technical changes that serve the purpose of technical progress.
The receipt of technical documentation (in particular data sheets, installation instructions,
manuals, etc.) does not constitute any further duty on the part of Phoenix Contact to furnish
information on alterations to products and/or technical documentation. Any other
agreement shall only apply if expressly confirmed in writing by Phoenix Contact. Please
note that the supplied documentation is product-specific documentation only and that you
are responsible for checking the suitability and intended use of the products in your specific
application, in particular with regard to observing the applicable standards and regulations.
Although Phoenix Contact makes every effort to ensure that the information content is
accurate, up-to-date, and state-of-the-art, technical inaccuracies and/or printing errors in
the information cannot be ruled out. Phoenix Contact does not offer any guarantees as to
the reliability, accuracy or completeness of the information. All information made available
in the technical data is supplied without any accompanying guarantee, whether expressly
mentioned, implied or tacitly assumed. This information does not include any guarantees
regarding quality, does not describe any fair marketable quality, and does not make any
claims as to quality guarantees or guarantees regarding the suitability for a special purpose.
Phoenix Contact accepts no liability or responsibility for errors or omissions in the content
of the technical documentation (in particular data sheets, installation instructions, manuals,
etc.).
The aforementioned limitations of liability and exemptions from liability do not apply, in so
far as liability must be assumed, e.g., according to product liability law, in cases of
premeditation, gross negligence, on account of loss of life, physical injury or damage to
health or on account of the violation of important contractual obligations. Claims for
damages for the violation of important contractual obligations are, however, limited to
contract-typical, predictable damages, provided there is no premeditation or gross
negligence, or that liability is assumed on account of loss of life, physical injury or damage
to health. This ruling does not imply a change in the burden of proof to the detriment of the
user.

PSR-TRISAFE-S
PHOENIX CONTACT 103503_en_03
Statement of legal authority
This manual, including all illustrations contained herein, is copyright protected. Use of this
manual by any third party is forbidden. Reproduction, translation, and public disclosure, as
well as electronic and photographic archiving or alteration requires the express written
consent of Phoenix Contact. Violators are liable for damages.
Phoenix Contact reserves all rights in the case of patent award or listing of a registered
design, in as far as this concerns software of Phoenix Contact that meets the criteria of
technicity or has technical relevance. Third-party products are always named without
reference to patent rights. The existence of such rights shall not be excluded.
Windows 3.x, Windows 95, Windows 98, Windows NT, Windows 2000, Windows XP, and
Windows Vista are trademarks of the Microsoft Corporation.
All other product names used are trademarks of the respective organizations.
How to contact us
Internet Up-to-date information on Phoenix Contact products and our Terms and Conditions can be
found on the Internet at:
www.phoenixcontact.com.
Make sure you always use the latest documentation.
It can be downloaded at:
www.phoenixcontact.net/catalog.
Subsidiaries If there are any problems that cannot be solved using the documentation, please contact
your Phoenix Contact subsidiary.
Subsidiary contact information is available at www.phoenixcontact.com.
Published by .
Should you have any suggestions or recommendations for improvement of the contents and
layout of our manuals, please send your comments to
[email protected].
PHOENIX CONTACT GmbH & Co. KG
Flachsmarktstraße 8
32825 Blomberg
Germany
Phone +49 - (0) 52 35 - 3-00
Fax +49 - (0) 52 35 - 3-4 12 00
PHOENIX CONTACT
P.O. Box 4100
Harrisburg, PA 17111-0100
USA
Phone [phone]

103503_en_03 PHOENIX CONTACT i
Table of contents
1 For your safety ........................................................................................................................1-1
1.1 Purpose of this manual .......................................................................................1-1
1.2 General safety notes...........................................................................................1-1
1.3 Electrical safety ..................................................................................................1-3
1.4 Safety of the machine or system.........................................................................1-4
1.5 Directives and standards....................................................................................1-5
1.6 Intended use.......................................................................................................1-7
1.7 Documentation ...................................................................................................1-8
2 System description .................................................................................................................2-1
2.1 Method of operation and structure of the PSR-TRISAFE-S safety system .........2-1
2.2 Using the system ................................................................................................2-4
2.3 System startup and restart behavior ...................................................................2-5
2.4 Error detection in I/O devices .............................................................................2-8
2.5 Diagnostic tools ..................................................................................................2-9
2.6 Password protection.........................................................................................2-13
2.7 Ordering data ...................................................................................................2-14
2.8 System requirements for the SAFECONF configuration software ....................2-15
3 Hardware: PSR-TRISAFE-S safety module ............................................................................3-1
3.1 Device description..............................................................................................3-1
3.2 Operating modes (status) of PSR-TRISAFE-S ...................................................3-3
3.3 Operating and indication elements .....................................................................3-4
3.3.1 Diagnostic and status indicators .........................................................3-4
3.3.2 "Confirm" button ..................................................................................3-6
3.4 Signal connections .............................................................................................3-7
3.4.1 Signal inputs .......................................................................................3-7
3.4.2 Safe outputs ........................................................................................3-8
3.4.3 Alarm outputs M0 to M3 ......................................................................3-9
3.4.4 Test pulse outputs T0 and T1 ..............................................................3-9
3.4.5 24 V/0 V supply connection .................................................................3-9
3.4.6 Supply connections A1 and A2 ...........................................................3-9
3.4.7 Ground switching outputs O0- and O1- .............................................3-10
3.5 USB interface ...................................................................................................3-11
3.6 IFS-CONFSTICK..............................................................................................3-12
3.7 Installing the safety module ..............................................................................3-13
3.7.1 Mounting the safety module ..............................................................3-13
3.7.2 Connecting the supply voltage ..........................................................3-16
3.7.3 Connecting the signal lines ...............................................................3-17

PSR-TRISAFE-S
ii PHOENIX CONTACT 103503_en_03
4 SAFECONF configuration software ........................................................................................4-1
4.1 Installing SAFECONF.........................................................................................4-1
4.2 Overview of functions and features.....................................................................4-1
4.3 Description of the user interface .........................................................................4-3
4.4 Safe functional blocks and functions ..................................................................4-5
4.5 Operating the SAFECONF configuration software ...........................................4-10
4.5.1 Creating the configuration project .....................................................4-10
4.5.2 Adding and connecting functions, functional blocks,
and signals in the safety logic ...........................................................4-11
4.5.3 Device parameterization in the safe parameter editor .......................4-15
4.5.4 Checking, downloading, and starting up the project ..........................4-18
4.5.5 Documenting the signal assignment and the project .........................4-19
4.6 Simulation mode in SAFECONF.......................................................................4-21
5 Configuration and startup ........................................................................................................5-1
5.1 Configuration overview from A to Z.....................................................................5-1
5.2 Downloading the configuration from SAFECONF...............................................5-4
5.3 Downloading the configuration using the IFS-CONFSTICK................................5-7
5.4 Uploading the configuration from the PSR-TRISAFE-S safety module...............5-9
5.5 Function test.....................................................................................................5-10
5.6 Startup mode....................................................................................................5-11
6 Application examples ..............................................................................................................6-1
7 Problems and solutions ...........................................................................................................7-1
7.1 General...............................................................................................................7-1
7.2 Graphical connection editor................................................................................7-2
7.3 Device parameterization editor...........................................................................7-2
7.4 Online communication between SAFECONF and the PSR-TRISAFE-S
safety module .....................................................................................................7-3
7.5 Safety module messages ...................................................................................7-5
A Appendix ................................................................................................................................ A-1
A.1 List of figures ..................................................................................................... A-1
A.2 Index.................................................................................................................. A-3

For your safety
103503_en_03 PHOENIX CONTACT 1-1
1Foryoursafety
1.1 Purpose of this manual
This manual should enable the user to set up, configure, and start up the PSR-TRISAFE-S
configurable safety module according to the relevant safety requirements and the risk
analysis performed.
The user manual is therefore designed as a complete system description, which provides
an introductory system overview, then describes the PSR-TRISAFE-S configurable safety
module and the associated SAFECONF configuration software in detail, and finally explains
the necessary steps for configuration and startup.
For additional information and detailed step-by-step instructions for SAFECONF, please
refer to the online help for the configuration software.
This user manual is oriented exclusively to qualified electrical engineers and safety
specialists, application programmers, and software engineers, who are familiar with the
relevant safety concepts of automation technology as well as applicable standards and
other regulations. Please also read the "Qualified personnel" section in "General safety
notes" on page 1-1.
1.2 General safety notes
Requirements Knowledge of the following is required:
– The PSR-TRISAFE-S safety module used and the I/O devices (extension units,
sensors, actuators)
– The SAFECONF configuration software
– The safety directives for the field of application
Qualified personnel
This user manual is therefore aimed at:
– Qualified personnel who plan and design safety equipment for machines and systems
and are familiar with regulations governing safety in the workplace and accident
prevention.
The PSR-TRISAFE-S configurable safety module is referred to in this documentation as
"safety module" for short.
WARNING: Personal injury and damage to equipment if these safety notes are not
followed. When working with the PSR-TRISAFE-S safety module, please observe
all the safety notes included in this section.
WARNING: In the context of the use of the PSR-TRISAFE-S safety module with
SAFECONF configuration software and safe functional blocks, the following
operations may only be carried out by qualified personnel:
– Planning, parameterization, configuration (development of safety logic)
– Installation, startup, servicing
– Maintenance, decommissioning

PSR-TRISAFE-S
1-2 PHOENIX CONTACT 103503_en_03
– Qualified personnel who install and operate safety equipment in machines and
systems.
Within the context of the safety notes in this documentation, qualified personnel are persons
who, because of their education, experience and instruction, and their knowledge of
relevant standards, regulations, accident prevention regulations, and service conditions,
have been authorized to carry out any required operations, and who are able to recognize
and avoid any possible dangers.
Documentation
Safety of personnel and
equipment
The safety of personnel and equipment can only be assured if the safe functional blocks are
used correctly (see "Intended use" on page 1-7).
Error detection Depending on the wiring and parameterization of the inputs and outputs, the
PSR-TRISAFE-S safety module can detect various errors within the safety equipment
(e.g., cross circuits).
Observe startup behavior Some of the safe functional blocks in the SAFECONF configuration software have
parameters for specifying a startup inhibit and/or a restart inhibit. An active startup
inhibit/restart inhibit can be removed by pressing a reset button that is connected and
appropriately wired to the safety module.
Use these parameters in the SAFECONF configuration software to monitor the
startup/restart of the PSR-TRISAFE-S safety module.
Do not carry out any
repairs, do not open the
housing In the event that an error caused by reconfiguring or modifying the wiring, etc. cannot be
removed, please contact Phoenix Contact immediately.
You must observe all information in this documentation as well as in the documentation
listed in "Documentation" on page 1-8.
NOTE: Please note that responsibility for fault avoidance lies with the user.
WARNING: Repair work may not be carried out on the PSR-TRISAFE-S safety
module. It is strictly prohibited to open the safety module housing.

For your safety
103503_en_03 PHOENIX CONTACT 1-3
1.3 Electrical safety
Direct/indirect contact Protection against direct and indirect contact according to DIN VDE 0100-410 must be
ensured for all components connected to the PSR-TRISAFE-S safety module. In the event
of an error, parasitic voltages must not occur (single-fault tolerance).
Safe isolation Only use devices with safe isolation if hazardous contact voltages can occur at their
connections.
Power supply unit Only use power supply units with safe isolation and PELV according to
DIN EN 50178/VDE 0160 (PELV). This prevents short circuits between primary and
secondary sides.
ESD
DANGER: Hazardous body currents or the loss of functional safety.
In order to ensure electrical safety, please observe the following points and the
information in the user manuals for the devices used (e.g., sensors, actuators or
extension units).
NOTE: Electrostatic discharge
The device contains components that can be damaged or destroyed by electrostatic
discharge. When handling the device, observe the necessary safety precautions against
electrostatic discharge (ESD) according to EN 61340-5-1 and EN 61340-5-2.

PSR-TRISAFE-S
1-4 PHOENIX CONTACT 103503_en_03
1.4 Safety of the machine or system
Draw up and implement a
safety concept
In order to use the system described in this document with the associated safe functional
blocks, you must have drawn up an appropriate safety concept for your machine or system.
This includes a hazard and risk analysis, as well as a test report for validating the safety
functions.
The target safety integrity level (SIL according to DIN EN 61508 and category according to
DIN EN ISO 13849-1) is ascertained on the basis of the risk analysis.
The safety integrity level or category ascertained determines:
– How safe sensors, control devices, and actuators should be wired within the overall
safety function.
– How safe functional blocks should be used in the safety logic. (The safety logic is
created using the SAFECONF configuration software.)
Within the safe control system used, the safe functional blocks support the following safety
integrity requirements:
– Up to SIL 3 according to standard DIN EN 61508
– Up to SILCL 3 according to standard DIN EN 62061
– Up to category 4 according to standard DIN EN ISO 13849-1
Check hardware and
device parameterization
Please note that you must carry out a validation every time you make a safety-related
modification to your overall system. Use the relevant checklists when carrying out the
validation and also enter the details requested in the "Project Information" dialog box in the
SAFECONF safe configuration software.
Use your test report to ensure that:
– The safe sensors and actuators are connected correctly in the PSR-TRISAFE-S safety
application. To do this, use the "Wiring check" function in SAFECONF (see page 2-11).
– The parameterization of the inputs and outputs of the PSR-TRISAFE-S safety module
is correct.
– The signals have been connected to the safe sensors and actuators correctly (single-
channel or two-channel).
– Cross-circuit detection is implemented in your application, if required (see page 2-8).
– All safe functional blocks and functions in the SAFECONF configuration software are
connected correctly.
WARNING: Ensure the safety of the machine or system.
The operator bears sole responsibility for the safety of the machine or system. The
Machinery Directive must thus be observed.
Please note that you are responsible for implementing all additional requirements
resulting from applicable directives and legislation in order to meet the above safety
integrity requirements (see also "Directives and standards" on page 1-5).

For your safety
103503_en_03 PHOENIX CONTACT 1-5
1.5 Directives and standards
The manufacturers and operators of machines and systems, in which the PSR-TRISAFE-S
safety module is used, are responsible for adhering to all applicable directives and
legislation.
Directives and standards considered in the development and implementation of the
PSR-TRISAFE-S safety module:
Directives – Machinery Directive 2006/42/EC
– Machinery Directive 98/38/EC
– EMC Directive 2004/108/EC
– Low Voltage Directive 2006/95/EC
– Guideline for test and certification GS-ET-26: Bus systems for the transmission of
safety-related messages
Standards
Standard Contents
DIN EN 61508-1:11.2002
DIN EN 61508-2:12.2002
DIN EN 61508-3:12.2002
DIN EN 61508-4:11.2002
DIN EN 61508-5:11.2002
DIN EN 61508-6:06.2003
DIN EN 61508-7:06.2003
Functional safety of
electrical/electronic/programmable electronic safety-
related systems
DIN EN ISO 13849-1 Safety of machinery - Safety-related parts of control
systems; best suited for less complex systems.
Part 1: General principles for design
This standard was created on the basis of
EN 954-1:1996, quality management and reliability
aspects have been added.
DIN EN ISO 13849-2: 12.2003 Safety of machinery - Safety-related parts of control
systems - Part 2: Validation
EN ISO 12100-2 Safety of machinery - Basic concepts, general
principles for design
Part 2: Technical principles
DIN EN 62061
IEC 62061
Safety of machinery - Functional safety of electrical,
electronic and programmable control systems for
machinery.
Sector standard for machinery, created on the basis of
IEC 61508.
Safety for complex programmable systems.
Proof of safety of devices as well as evaluation of risk
reduction of the entire safety function through
calculation.
DIN EN 60204-1:11.1998 Safety of machinery - Electrical equipment of machines
- Part 1: General requirements

PSR-TRISAFE-S
1-6 PHOENIX CONTACT 103503_en_03
EN ISO 13850 Safety of machinery - Emergency stop, principles for
design
DIN EN 61131-2:02.04 Programmable controllers -
Part 2: Equipment requirements and tests
DIN EN 61131-3:02.04 Programmable controllers -
Part 3: Programming languages
DIN EN 61496-1:06.98 Safety of machinery - Electrosensitive protective
equipment - Part 1: General requirements and tests
DIN EN 1088 Safety of machinery - Interlocking devices associated
with guards - Principles for design and selection
DIN EN 953 Safety of machinery - Guards - General requirements
for the design and construction of fixed and movable
guards
DIN EN 574 Safety of machinery - Two-hand control devices -
Functional aspects - Principles for design
DIN EN 50254:07.1999 High efficiency communication subsystem for small
data packages
EN 50178:04.1998 Electronic equipment for use in power installations
EC/ISO 7498 Information Technology;
Open Systems Interconnection
Standard Contents

For your safety
103503_en_03 PHOENIX CONTACT 1-7
1.6 Intended use
PSR-TRISAFE-S The PSR-TRISAFE-S safety module should only be used in industrial applications
according to standards DIN EN 61508, DIN EN ISO 13849, and DIN EN 62061.
The PSR-TRISAFE-S safety module is designed for evaluating safety-related sensors on a
machine or system, which are connected to the inputs of the safety module, and for
controlling its outputs according to the configured safety logic.
The safety module can only perform its safety-related tasks if it has been integrated into the
execution process correctly and in such a way as to avoid errors.
You must observe all information in this manual as well as in the user manuals and online
help listed in "Documentation" on page 1-8. In particular, only use the PSR-TRISAFE-S
safety module according to the technical data specified in "System requirements for the
SAFECONF configuration software" on page 2-15.
SAFECONF The SAFECONF safe configuration software is designed for the configuration of the
PSR-TRISAFE-S safety module.
Safe functional blocks and
functions in SAFECONF
The safe functional blocks and functions available in the SAFECONF configuration software
for creating the safety logic are designed solely for use within the PSR-TRISAFE-S safety
module and support specific safety functions.
The safe functional blocks/functions can only perform their safety-related tasks within the
safe control system if they have been integrated into the execution process correctly and in
such a way as to avoid errors.
The area of responsibility of the block manufacturer in terms of the function of a safe
functional block or a safe function ends at the user interface, which is generated by the
inputs and outputs of the functional blocks/functions.
In order to fully execute a safety function, it is your responsibility to connect the inputs and
outputs of the safe functional blocks/functions in the SAFECONF configuration software:
– To your safety network
– To the single-channel or two-channel sensors and actuators connected to the inputs
and outputs of the safety module
In defining the safety integrity level or category for the overall safety function, you must take
into consideration all components involved in the execution of this safety function (sensors,
actuators, wiring, etc.).
WARNING: Only use the PSR-TRISAFE-S safety module according to the
information listed in this section.
You must observe all information in the online help for each functional block. Theoretical
examples of the use of the safe functional blocks are described in "Application examples".
WARNING: In order to use a safe functional block or a safe function according to
the required safety integrity as defined by DIN EN 61508, DIN EN ISO 13849 or
DIN EN 62061, you must take into consideration the entire path of the safety
function (safety module, device parameterization, wiring, sensors, actuators,
single-channel or two-channel operation, etc.) starting from the "functional block
I/O" interface.
Validate the entire path on completion.

PSR-TRISAFE-S
1-8 PHOENIX CONTACT 103503_en_03
1.7 Documentation
Latest documentation Make sure you always use the latest documentation. Find out from the manufacturer or their
homepage on the Internet whether any changes or additions have been made to the
documentation used.
When working on and with the PSR-TRISAFE-S safety module, you must always keep this
documentation and other items of product documentation to hand and observe the
information therein.
You must observe all information:
– In the technical description of the PSR-TRISAFE-S safety module
– In the user documentation for I/O devices (e.g., sensors/actuators, etc.) connected to
the PSR-TRISAFE-S safety module and connected to safe functional blocks in the
safety logic (SAFECONF configuration software)
– In the online help for the SAFECONF configuration software (see also Figure 1-1) and
for each of the safe functional blocks
– In the documentation for the supplementary standard technology, if applicable
Calling online help The diagram below illustrates the various options for opening the online help and searching
for information via context-sensitive help or via the contents or index.
Figure 1-1 Calling the online help in the SAFECONF configuration software
Start page for the
help system
Help page for the object
or
or or
Help page for the
dialog box or area
In this way for all object types

System description
103503_en_03 PHOENIX CONTACT 2-1
2Systemdescription
2.1 Method of operation and structure of the
PSR-TRISAFE-S safety system
The overall system:
Hardware and software
The PSR-TRISAFE-S safety system consists of the following components:
– PSR-TRISAFE-S safety module
– SAFECONF configuration software
– Suitable safe control devices, sensors, and actuators (depending on the application)
The PSR-TRISAFE-S safety module is designed for monitoring and evaluating safety-
related control devices in machines and systems (see "Intended use" on page 1-7). The
safety module monitors safe control devices and safety sensors connected at its inputs,
evaluates the incoming signals according to its configuration, and controls the outputs
accordingly.
The SAFECONF configuration software is used to configure the PSR-TRISAFE-S safety
module and therefore provides the relevant editors as well as suitable startup and
diagnostic tools.
The diagram below illustrates the overall system in an application example.
Figure 2-1 Typical structure of a safety system with PSR-TRISAFE-S
103503a004.e
p
s
Upload online values
during the function test
Download
configuration and
control parameters
Reset button for
removing active
startup/restart inhibits
Control signals for the
contactors at the safety
module outputs
Readback signal from the
monitoring contacts of the
contactor
Single-channel or
two-channel
connection to
safety module
Safe control devices or
sensors
SAFECONF
on configuration computer
Indicator lamp
Check valve
Motor
USB
PSR-TRISAFE-S
Contactor or
relay

PSR-TRISAFE-S
2-2 PHOENIX CONTACT 103503_en_03
Hardware:
PSR-TRISAFE-S
The PSR-TRISAFE-S safety module offers 20 digital safe inputs for connecting a maximum
of 20 single-channel or 10 two-channel safety-related sensors and control devices.
The PSR-TRISAFE-S has 4 digital safe outputs, which are semiconductor outputs
(24 V DC/2 A (total current)). The outputs are designed to meet up to category 4 according
to EN 954-1.
Depending on the configuration, stop category 0 according to DIN EN 60204-1 can be
achieved for each output (see "Stop category 0" on page 2-4).
In addition, four signaling current paths, two test pulses at two outputs each, and two ground
switching outputs are available.
For more detailed information about the safety module, please refer to the device
description in Section 3.
Software:
SAFECONF
The PSR-TRISAFE-S safety module can only be configured and parameterized using the
SAFECONF safe configuration software, which is executed on a separate Windows®PC.
The software offers a graphical connection editor for this purpose. The safety logic can be
created here by graphically connecting prepared safe functions and functional blocks to the
inputs and outputs of the safety module. The connections are made intuitively using the
mouse, and the editor prevents impermissible connections (e.g., between certain outputs).
In addition, the software provides a safe parameter editor, which can be used to configure
each input and output of the PSR-TRISAFE-S safety module.
A special online mode supports a detailed function test of the safety logic executed in the
PSR-TRISAFE-S safety module. Current signal values can be read from the
PSR-TRISAFE-S safety module, transmitted to the configuration software, and displayed
there "live" in the connection editor.
For more detailed information about the configuration software, please refer to the software
description in Section 4.
Secure communication Communication between the PSR-TRISAFE-S safety module and the configuration
software is via a USB interface.
A special security protocol enables secure data transmission via the USB interface.
There is communication between the two components in both directions:
–PC→safety module: The configuration data and device parameters are downloaded
from the configuration PC to the safety module. Configuration data refers to the
application logic, which was created using SAFECONF.
The configuration can also be downloaded using the plug-in IFS-CONFSTICK. Please
refer to "Downloading the configuration from SAFECONF" on page 5-4 and
"Downloading the configuration using the IFS-CONFSTICK" on page 5-7.
–Safetymodule→PC: For diagnostic purposes, online values can be read from the
PSR-TRISAFE-S safety module via the USB interface and displayed "live" in the
software. For more detailed information, please refer to "Function test" on page 5-10.

System description
103503_en_03 PHOENIX CONTACT 2-3
Communication via the
PSR TBUS DIN rail
connector
The PSR-TRISAFE-S safety module is equipped with an interface for the PSR TBUS DIN
rail connector. The PSR DIN rail connector from Phoenix Contact can be used to connect
slave extension modules. Communication with these modules is then established
automatically via the connector on the PSR DIN rail connector. Safety-related cross-wiring
is not required (see also "Mounting the safety module" on page 3-13).
Figure 2-2 PSR TBUS DIN rail connector from Phoenix Contact
The maximum continuous current for extension modules supplied via the TBUS is 4 A.
INTERFACE-PSR
use only
PSR-TBUS
PSR-TRISAFE-S on yellow PSR
DIN rail connector
Standard
extension module
on green
PSR DIN rail connector
(TBUS connection)
DIN rail
connector

PSR-TRISAFE-S
2-4 PHOENIX CONTACT 103503_en_03
2.2 Using the system
The PSR-TRISAFE-S safety module configured with SAFECONF is designed for
monitoring and evaluating safety control devices and safety sensors in machines.
Machinery Directives and various standards and safety regulations require machine or
system manufacturers to meet a high standard of safety.
Safety circuits Safety control devices and safety sensors differ as follows:
Emergency stop control devices can only be detected in the event of dangerous operation
and thus operate in the background. Safety door switches or light grids, for example, are
often required for operational reasons and therefore regularly control the
connection/disconnection of the safety-related part of the machine.
The PSR-TRISAFE-S safety module can be configured flexibly. For the creation of the
safety logic, it has safe functional blocks, which are part of the system. The
PSR-TRISAFE-S can be used to implement various safety functions in different safety
circuits. Some of the most important options are:
– Emergency stop monitoring
– Safety door monitoring (with and without guard locking)
– Two-hand control devices (Types II and III)
– External device monitoring (feedback monitoring)
– Monitoring and checking electrosensitive protective equipment
– Mode selector switch (evaluation of a mode selector switch and an enable switch)
– Muting applications (light grid monitoring with parallel muting)
Stop category 0 Depending on the safety logic configured for the actual application, PSR-TRISAFE-S safety
module outputs can be used to stop machines/drives with stop category 0 according to
DIN EN 60204-1.
DIN EN 60204-1 defines stop category 0 as uncontrolled stopping by immediate removal of
power to a machine.
Whether a safe output meets stop category 0 depends on the safe functional blocks
connected in the safety logic: only if the module output is connected directly to the enable
output of a safe functional block, which executes stop category 0 at its output, can the
module output also meet this category.
Example The EmergencyStop functional block executes stop category 0 at its enable output. If this
block output is connected directly to a module output, the safety module also executes stop
category 0 at this output.
Figure 2-3 on page 2-7 shows an example of this type of connection.
Equipment on the
machine
The configuration and startup of the relevant safety circuit must be planned and verified
precisely. Different machines are subject to different requirements for the implementation of
a safety function.
The term "machine" is used here to represent any technical systems according to
Machinery Directive 2006/42/EC.
